Panasonic PT-LB90NT User manual

Network Operation Manual
(Wireless Manager mobile edition 5.5)
TQBH0205-4 (E/U/EA)
Windows
ENGLISH
※The projectors illustrated as examples are PT-FW300NTE.

2
Contents
Connecting with Wired LAN ……………………… 28
Software Licensing Agreement …………………… 3
Notes on Using Wireless Connection …………… 4
Request Regarding Security ……………………… 6
What you can do with Wireless Manager mobile edition 5.5 … 7
Check your computer ……………………………… 10
Necessary environment for computers to be connected …… 10
Various projection methods ……………………… 32
Description of the launcher……………………………………… 32
Live Mode…………………………………………………………… 34
Multi Live Mode …………………………………………………… 35
Switching from one style to another …………………………… 35
4-screen multi style ……………………………………………… 36
4-screen index style……………………………………………… 37
16-screen index style …………………………………………… 39
Multiple Source Live Mode ……………………………………… 40
Multiple Source Multi Live Mode ……………………………… 42
Useful Functions …………………………………… 44
Selective Area Transmission …………………………………… 44
Secondary display transmission ……………………………… 45
Secondary Viewer ……………………………………………… 45
AV Mute function ………………………………………………… 46
Pointer function …………………………………………………… 46
List of connectable projectors/available functions in each
projection method ………………………………………………… 47
Setting options ……………………………………… 48
Setting options …………………………………………………… 48
Transmission……………………………………………………… 48
Key setting………………………………………………………… 49
Other1 …………………………………………………………… 49
Other2 …………………………………………………………… 50
Version information ……………………………………………… 50
Software requirements ……………………………… 12
System requirements …………………………………………… 12
Installing and using software ……………………… 13
[1. Wireless Manager ME 5.5] ………………………………… 13
Installation free set up ……………………………… 14 [Installation free set up] ………………………………………… 14
Connecting with wireless LAN …………………… 15
Preparations ……………………………………………………… 15
Easy Wireless Set Up …………………………………………… 15
Parts name in search screen …………………………………… 15
“S-MAP” Connection …………………………………………… 18
“1-4/U” Connection ……………………………………………… 19
“PC Search” Connection………………………………………… 20
Connection error messages …………………………………… 22
Connecting through the access point ………………………… 24
When logging on without administrator authority ………… 25
Other operations for connection ………………… 29
Operations when password entry is required
for connection …………………………………………………… 29
Other search ……………………………………………………… 29
Automatic connection by “One-click connection” …………… 30
Exit Wireless Manager ………………………………………… 31
Network/Security setting of the projector ……… 51
Displaying the Network Menu…………………………………… 51
Wired LAN settings ……………………………………………… 52
Default wired LAN settings ……………………………………… 52
Setting network number (for wireless LAN) ………………… 53
[USER] settings …………………………………………………… 53
Setting IP ………………………………………………………… 53
Wireless settings ………………………………………………… 54
Default settings of [USER1] - [USER3]………………………… 55
Changing the projector name…………………………………… 56
Password setting ………………………………………………… 56
Network standby ………………………………………………… 57
Network control …………………………………………………… 57
Live mode cut-in…………………………………………………… 58
Computer search ………………………………………………… 58
Multi-live …………………………………………………………… 58
Verifying settings ………………………………………………… 59
Returning to the initial settings ………………………………… 59
Using WebBrowser ………………………………… 60
Before using the WebBrowser control ………………………… 60
Accessing from the WebBrowser ……………………………… 61
Monitor information window …………………………………… 62
Projector control window………………………………………… 63
Detailed settings window ……………………………………… 64
Switching Languages …………………………………………… 67
Using PJLink™ protocol …………………………… 68 Applicable commands …………………………………………… 68
Software Uninstall …………………………………… 69 Wireless Manager ME 5.5………………………………………… 69
Glossary ……………………………………………… 70 Frequently Asked Questions ……………………… 72

3
Please note the following.
• Panasonic cannot be held liable for any direct or indirect damages resulting from the use or malfunction of this projector.
• Panasonic cannot be held liable for damages arising from data corruption or loss as a result of using this projector.
Use of this Software is governed by the terms defined in this Software Licensing Agreement.
Article 1 License
The users obtain the license of the software (i.e. the information recorded or contained in CD-ROM, operation manual or
others), but the copyright or intellectual property right of the software does not transfer to the users.
Article 2 Use by a Third Party
Licensee may not transfer or allow any third party, to use or copy the Software, whether free of charge or not.
Article 3 Restrictions on Copying the Software
Licensee may make a single copy of the Software in whole or in part solely for backup purposes.
Article 4 Computer
Licensee may install and use the Software on more than one computer owned or managed by Licensee.
Article 5 Reverse Engineering, Decompiling or Disassembly
Licensee may not reverse engineer, decompile or disassemble the Software. Panasonic shall not be bound by warranty for
any defects in the Software caused by Licensee’s reverse engineering, decompiling or disassembly of the Software.
Furthermore, Panasonic or its distributors or dealers will not be responsible for any damage to the Licensee caused by
Licensee’s reverse engineering, decompiling or disassembly of the Software.
Article 6 After-sales Service
If you have a problem with the software, please contact the customer support center by telephone. Panasonic shall undertake
to notify Licensee of whether the problem is a known error in the program (“bug”), or whether the way in which the Software is
to be used should be modified.
Furthermore, the Software is subject to revision without prior notice.
Article 7 Indemnification
Panasonic’s liability with respect to this Software is limited to the conditions defined in Article 6 herein.
Panasonic or any of its distributors or dealers shall not be liable for any damage suffered by Licensee, either directly or
through claims from a third party, arising from or in connection with Licensee’s use of the Software.
Furthermore, Panasonic Corporation does not guarantee the successful operation of the software unless it is used with any of
Panasonic projectors.
Article 8 Export Control
Licensee agrees not to export or re-export the Software to any county other than the country of purchase of the projector in
any form without the appropriate export licenses under the regulations of the country where Licensee resides or of any other
country as may be required by such export or re-export.
Wireless Manager mobile edition 5.5 (hereinafter called “Wireless Manager ME 5.5”) uses the following software programs:
Portion of this software are based in part on the work of the Independent JPEG Group
Software Licensing Agreement

4
Wireless connection function of the projector uses radio waves in the 2.4 GHz band.
A radio station license is not required, but be sure to read and fully understand the following items before use.
Do not use near other wireless equipment.
The following equipment may use radio waves in the same band as the projector.
When the projector is used near these devices, radio wave interference may make communication impossible, or the
communication speed may become slower.
• Microwave ovens, etc.
• Industrial, chemical and medical equipment, etc.
• In-plant radio stations for identifying moving objects such as those used in factory manufacturing lines, etc.
• Designated low-power radio stations
If at all possible, avoid the use of cellular phones, TV sets or radios near the projector.
Cellular phones, TV sets, radios and similar devices use different radio bands from the projector, so there is no effect on
wireless communication or the transmission and reception of these devices. However, radio waves from the projector may produce
audio or video noise.
Wireless communication radio waves cannot penetrate steel reinforcements, metal, concrete,
etc.
Communication is possible through walls and floors made from materials such as wood and glass (except glass containing
wire mesh), but not through walls and floors made from steel reinforcements, metal, concrete, etc.
Avoid using the projector in locations prone to static electricity.
If the projector is used in a location prone to static electricity, such as on a carpet, the wireless LAN or wired LAN connection
may be lost.
If this happens, eliminate the source of static electricity or electromagnetic noise and reconnect to the wireless LAN or wired
LAN.
In rare cases static electricity or electromagnetic noise may make it impossible to establish a connection to the LAN.
If this happens, press the power button on the remote control or on the projector to power off the projector temporarily.
After the cooling fan stops operating (after the power monitor on the projector changes from orange to red), power on the
projector and reconnect to the LAN.
Using the projector outside the country
It is forbidden to take the projector outside the country or region where you purchased it, so use it only in the said country or
region. Also, note that depending on countries or regions there are restrictions on the channels and frequencies at which you
can use the wireless LAN.
Notes on Using Wireless Connection

5
Notes on Using Wireless Connection (cont.)
Channels that can be used
The channels (frequency range) that can be used differ according to the country or region. Refer to the table below.
Country or region Standard Channels used Frequency band
(Center frequency)
Japan ARIB STD-T66
1 - 13 2,412 MHz -
2,472 MHz
China SRRC
England, Germany, France, Spain,
Italy, Belgium, Austria, Sweden, Norway,
Denmark, Switzerland, Holland, Finland,
Portugal, Greece, Thailand, South Korea
ETSI 300.328
Singapore IDA
Australia,
New Zealand C-Tick
Malaysia SIRIM
United States FCC part 15
1 - 11 2,412 MHz -
2,462 MHz
Taiwan DGT
Wired LAN
Use straight or crossover LAN cable that is compatible with category 5 or above.
※1: Use category 5e or above when using 1000BASE-T.
※2: Whether straight cable, crossover cable or both can be used varies depending on the system configuration. For details,
consult your system administrator.

6
Request Regarding Security
When using this product, security breaches of the type described below are conceivable.
• Leakage of your private information via this product
• Illegal operation of this product by a malicious third-party
• Harm to or cessation of operation of this product by a malicious third-party
Be sure to implement sufficient security measures.
• Set passwords, and limit the users that are permitted login access.
• Make sure the password is as hard to guess as possible.
• Change the password periodically.
• Panasonic Corporation and its affiliated companies never directly ask customers for their password.
Do not give out your password even if directly asked by a third-party representing themselves as Panasonic Corporation.
• Always use on a network that has safety protection such as a firewall implemented.
About Wireless LANs
The advantage of a wireless LAN is that information can be exchanged between a PC or other such equipment and an
access point using radio waves as long as you are within range for radio transmissions.
On the other hand, because the radio waves can travel through obstacles (such as walls) and are available everywhere
within a given range, problems of the type listed below may occur if security-related settings are not made.
• A malicious third-part may intentionally intercept and monitor transmitted data including the content of e-mail and personal
information such as your ID, password, and/or credit card numbers.
• A malicious third-party may access your personal or corporate network without authorization and engage in the following
types of behavior.
Retrieve personal and/or secret information (information leak)
Spread false information by impersonating a particular person (spoofing)
Overwrite intercepted communications and issue false data (tampering)
Spread harmful software such as a computer virus and crash your data and/or system (system crash)
Since most wireless LAN adapters or access points are equipped with security features to take care of these problems, you
can reduce the possibility of these problems occurring when using this product by making the appropriate security settings for
the wireless LAN device.
Some wireless LAN devices may not be set for security immediately after purchase. To decrease the possibility of occurrence
of security problems, before using any wireless LAN devices, be absolutely sure to make all security-related settings
according to the instructions given in the operation manuals supplied with them.
Depending on the specifications of the wireless LAN, a malicious third-party may be able to break security settings by special
means.
Please contact Panasonic if you need help taking care of security settings or other such.
If you cannot perform security settings for your wireless LAN by yourself, please contact the Panasonic Support Center.
Panasonic asks customers to thoroughly understand the risk of using this product without making security settings, and
recommends that the customer make security settings at their own discretion and responsibility.

7
What you can do with Wireless Manager mobile edition 5.5
Network Transmission
You can connect the projector to a computer via the wireless LAN or the wired LAN, and send moving and still images.
For information on the connection, refer to the description on page 15 for wireless LAN, and page 28 for wired LAN.
Project with various methods
<Live mode> (See page 34)
<Multi live mode> (See page 35)
• 4-screen multi style (See page 36)
Used for normal presentations.
Used for presentations involving multiple computers.
• 4-screen index style (See page 37)
This style is convenient in cases where you wish to focus attention on one of four presentations
displayed simultaneously.
This style is convenient in cases where you wish to display a large number of presentations as a
list.
• 16-screen index style (See page 39)

8
What you can do with Wireless Manager mobile edition 5.5 (cont.)
Project with multiple projectors
<Multiple source live mode> (See page 40)
Useful functions
<Selective area transmission> (See page 44)
<Secondary display transmission> (See page 45)
<Multiple source multi live mode> (See page 42)
This arrangement can be used when you wish to simultaneously display multiple
presentations using multiple projectors.
Moving the cursor outside the computer screen with the mouse
By using the selective area window, you can specify the necessary
information alone from the computer screen, and display it on the projection
screen.
This arrangement can be used when a number of projectors are
installed in a large conference room, or when holding simultaneous
presentations in several conference rooms, for example.
You can set the computer screen and the projector screen to the
multi-monitor mode, and use the computer screen as the primary
monitor and the projector screen as the secondary monitor. This
is convenient for when holding a presentation using the projector
screen while displaying reference material on the computer screen.
For details on the secondary display transmission function, see the
application section for the secondary display transmission function
in the instruction manual.
For connectable projectors and functions available for Wireless Manager ME 5.5, see “List of connectable projectors/available
functions in each projection method” on page 47.

9
What you can do with Wireless Manager mobile edition 5.5 (cont.)
<WebBrowser control> (See page 60)
The following operations are possible when using WebBrowser.
• Setting and adjusting the projector
• Displaying the projector status
• Setting for message transmission
<PJLink™> (See page 68)
Compatible with PJLink™ Class 1. The following operations can be performed from a computer when PJLink™ protocol is used.
• Setting the projector
• Querying the projector status
<Command control> (Refer to “Serial terminals” in the operation manual for the projector.)
You can control the projector from a PC, using the control commands of the serial terminals.
<Virtual remote control function> (See page 33)
You can perform the following operation from a PC, using the virtual remote control in stead of the remote control.
• Changing the channels
• Turning the power on and off
<One-click Connection> (See page 30)
You can connect to the projector by double-clicking or using drag-and-drop.
<Live mode cut-in function> (See page 58)
During live mode or multi live mode, a different computer can interrupt and project images in live mode.
If you use “Web control,” “PJLink™” or “Command control,” turn on [NETWORK CONTROL] in the network menu for the
projector. (See page 57)

10
Check your computer
• First, check your computer to see whether or not it has a wired LAN※or a built-in wireless LAN function.
※LAN : “Glossary” (See page 70)
• Before connecting the projector to the computer, be sure to check the following settings.
• Operation is not guaranteed for all wireless LAN adapters and built-in wireless LAN adapters.
Wireless LAN
Check 1 Wireless LAN settings
<Computer with a built-in wireless LAN function>
• Is your wireless LAN switched on?
<Computer without a built-in wireless LAN function>
• Is your wireless LAN adapter properly recognized?
• Is the wireless LAN adapter switched on?
• Install the wireless LAN adapter driver beforehand.
For details on how to install the driver, refer to the instructions accompanying the wireless card.
Check 2 Logon user’s settings
• Have you logged in as the Administrator?
Check 3 Computer’s settings
•
When security (firewall) software and utilities for network cards are installed, these may prevent connection of the projector.
<Windows XP/Windows Vista>
• Is Network Bridge enabled? (See page 73)
• Has your firewall been disabled? (See page 74)
Necessary environment for computers to be connected
