Panasonic SA-AKX92LM-K User manual

© Panasonic Corporation 2011. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
MEX1106008CE
CD Stereo System
Model No. SA-AKX92LM-K
Product Color: (K)...Black Type
TABLE OF CONTENTS
1 Safety Precautions
1.1. General Guidelines
1.2. Before Use
1.3. Caution For Fuse Replacement
1.4. Before Repair and Adjustment
1.5. Protection Circuitry
1.6. Safety Parts Information
2 Warning
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatic Sensitive (ES) Devices
2.2. Precaution of Laser Diode
2.3. Service caution based on Legal restrictions
2.4. Handling Precautions for Traverse Unit
3 Service Navigation
3.1. Service Information
4 Specifications
5 Location of Controls and Components
5.1. Main Unit Key Button Operation
5.2. Remote Control Key Button Operation
5.3. Media Information
6 Self-Diagnostic and Special Mode Setting
6.1. Cold-Start
6.2. Doctor Mode Table
6.3. Reliability Test Mode (CD Mechanism Unit
(BRS1C))
6.4. Self-Diagnostic Mode
6.5. Self-Diagnostic Error Code Table
6.6. Sales Demonstration Lock Function
Please refer to the original service manual for:
CD Mechanism Unit (BRS1C), Order No. PSG1102001CE
Speaker system SB-AKX92PU-K, Order No. MEX1106009CE
Nota: El idioma original de este Manual de Servicio es en idioma inglés, sin embargo algunas notas aquí mencionadas
serán escritas en español para mejor descripción para Centros de Servicio de México.

7 Troubleshooting Guide
7.1. Troubleshooting Guide for F61 and/ or F76
7.2. Part Location
7.3. D-Amp IC Operation & Control
8 Service Fixture & Tools
8.1. Service Tools and Equipment
9 Disassembly and Assembly Instructions
9.1. Disassembly Flow Chart
9.2. Main Components and P.C.B. Locations
9.3. Disassembly of Top Cabinet
9.4. Disassembly of Tuner P.C.B.
9.5. Disassembly of Front Panel Unit
9.6. Disassembly of Jupiter P.C.B.
9.7. Disassembly of Panel P.C.B.
9.8. Disassembly of Remote Sensor P.C.B.
9.9. Disassembly of USB P.C.B.
9.10. Disassembly of Music Port P.C.B.
9.11. Disassembly of CD Lid
9.12. Disassembly of Main P.C.B.
9.13. Replacement of Voltage Regulator IC
(IC2010)
9.14. Disassembly of D-Amp P.C.B.
9.15. Replacement of Audio Digital Amp IC
(IC5000)
9.16. Replacement of Audio Digital Amp IC
(IC5400)
9.17. Replacement of Audio Digital Amp IC
(IC5200)
9.18. Replacement of Audio Digital Amp IC
(IC5300)
9.19. Disassembly of SMPS P.C.B.
9.20. Replacement of Regulator IC (IC5701)
9.21. Replacement of Rectifier Diode (D5702)
9.22. Replacement of Rectifier Diode (D5801)
9.23. Replacement of Rectifier Diode (D5802)
9.24. Replacement of Rectifier Diode (D5803)
9.25. Disassembly of CD Mechanism Unit (BRS1C)
9.26. Disassembly of Rear Panel
9.27. Disassembly of Surround D-Amp P.C.B.
9.28. Replacement of Audio Digital Amp IC
(IC5900)
10 Replacement of Traverse Unit
10.1. Disassembly of Traverse Unit
10.2. Assembly of Traverse Unit
10.3. Disassembly of CD Servo P.C.B.
11 Service Position
11.1. Checking and Repairing of Main P.C.B.
11.2. Checking and Repairing of D-Amp P.C.B.
11.3. Checking and Repairing of Surround D-Amp
P.C.B.
11.4. Checking and Repairing of Panel P.C.B.
11.5. Checking and Repairing of Jupiter P.C.B.
11.6. Checking and Repairing of SMPS P.C.B.
11.7. Checking and Repairing of CD Servo P.C.B.
12 Voltage & Waveform Chart
12.1. CD Servo P.C.B.
12.2. Main P.C.B. (1/3)
12.3. Main P.C.B. (2/2)
12.4. Main P.C.B. (3/3)
12.5. Panel P.C.B.
12.6. Music Port P.C.B.
12.7. Tuner P.C.B.
12.8. Jupiter P.C.B. (1/3)
12.9. Jupiter P.C.B. (2/3)
12.10. Jupiter P.C.B. (3/3)
12.11. D-AMP P.C.B.
12.12. Surround D-AMP P.C.B.
12.13. SMPS P.C.B.
12.14. Waveform Table
13 Illustration of ICs, Transistor and Diode
14 Simplified Block Diagram
14.1. Overall Simplified Block Diagram
14.2. D-Amp Block Diagram
15 Block Diagram
15.1. Servo & System Control
15.2. IC Terminal Chart
15.3. Audio
15.4. Power Supply
16 Wiring Connection Diagram
17 Schematic Diagram
17.1. Schematic Diagram Notes
17.2. CD Servo Circuit
17.3. Main Circuit
17.4. Panel Circuit
17.5. Music Port Circuit
17.6. Remote Sensor, USB, Tuner & Voltage Circuit
17.7. Jupiter Circuit
17.8. D-Amp Circuit
17.9. Surround D-Amp Circuit
17.10. SMPS Circuit
18 Printed Circuit Board
18.1. CD Servo P.C.B.
18.2. Main P.C.B.
18.3. Panel P.C.B.
18.4. Music Port, Remote Sensor, USB & Tuner
P.C.B.
18.5. Jupiter P.C.B.
18.6. D-Amp P.C.B.
18.7. SMPS & Surround D-Amp
19 Terminal Function of ICs
19.1. IC2003 (MN101EF16KXW): IC MICRO-
PROCESSOR
19.2. IC6001(C0HBB0000057): IC FL Driver
20 Exploded View and Replacement Parts List
20.1. Exploded View and Mechanical Replacement
Parts List
20.2. Electrical Replacement Parts List

1 Safety Precautions
1.1. General Guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, carry out the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.1.1. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the two prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on
the equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the
chassis, the reading should be between 1MΩ and 5.2MΩ.
When the exposed metal does not have a return path to the chassis, the reading must be
1.1.2. Leakage Current Hot Check
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a 1.5kΩ, 10 watts resistor, in parallel with a 0.15µF capacitors, between each exposed metallic part on the set and a
good earth ground such as a water pipe, as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.
6. The potential at any point should not exceed 0.75 volts RMS. A leakage current tester (Simpson Model 229 or equivalent)
may be used to make the hot checks, leakage current must not exceed 1/2 milliamp. In case a measurement is outside of the
limits specified, there is a possibility of a shock hazard, and the equipment should be repaired and rechecked before it is
returned to the customer.
Figure 1
1.2. Before Use
Be sure to disconnect the mains cord before adjusting.
Use If the power supply in your area is ~ 127V
Note that this unit will be seriously damaged if the setting is not made correctly.
The correct voltage is already in the set.
1.3. Caution For Fuse Replacement

1.4. Before Repair and Adjustment
Disconnect AC power to discharge unit AC Capacitors as such (C5700, C5701, C5703, C5704, C5705, C5708) through a 10 Ω, 10
W resistor to ground.
Caution:
DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices.
After repairs are completed, restore power gradually using a variac, to avoid overcurrent.
Current consumption at AC ~127 V 60 Hz in Power ON, FM Tuner, No Signal, Volume minimal mode should be
~ 900 mA.
1.5. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
• No sound is heard when the power is turned on.
• Sound stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are
“shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
3. Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.

1.6. Safety Parts Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these
critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the
original design without permission of manufacturer.
Modelo: SC-AKX92LM-
K
Safety
VARISTORS ERZV10V511CS
CAPACITOR DE AC F1BAF471A013
INSTRUCTIVO RQTM0184
RKMX1011Z-KL
RD-DDL082-PX
CAPACITOR DE AC F1BAF1020020
K2AA2B000017
G4DYZ0000049
CAPACITOR DE AC
CAPACITOR DE AC
F0CAF224A105
PCB SMPS
F0CAF104A105
B3PBA0000503
RJBX0727D-1
GAB. MET. SIN DOBLAR
G0B932H00002
REAR PANEL
Numero de Parte
TRANSFORMADOR DE PODER
TRANSFORMADOR DE
RESPALDO
OPTOACOPLADOR
LECTOR OPTICO
(CD UNIT)
BOBINA
FUSIBLE PRIMARIO
Nombre del componente
SJA168-1A
ETS19AB2E6AG
K5D802BNA005
CABLE TOMACORRIENTE.
CONECTOR TOMACORRIENTE
RXTM0002-D

2Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive
(ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec-
trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alumi-
num foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as “anti-static (ESD protected)” can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution:
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) suf-
ficient to damage an ES device).

2.2. Precaution of Laser Diode
Caution:
This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens.
Wavelength: 790 nm (CD)
Maximum output radiation power from pickup: 100 µW/VDE
Laser radiation from the pickup unit is safety level, but be sure the followings:
1. Do not disassemble the pickup unit, since radiation from exposed laser diode is dangerous.
2. Do not adjust the variable resistor on the pickup unit. It was already adjusted.
3. Do not look at the focus lens using optical instruments.
4. Recommend not to look at pickup lens for a long time.

2.3. Service caution based on Legal restrictions
2.3.1. General description about Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30 degrees C (86°F) more than that
of the normal solder.
Definition of PCB Lead Free Solder being used
Service caution for repair work using Lead Free Solder (PbF)
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the PCB using the lead free solder.)
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt the
lead free solder.
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30 degrees
C (662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01K-----------(0.3mm 100g Reel)
RFKZ06D01K-----------(0.6mm 100g Reel)
RFKZ10D01K-----------(1.0mm 100g Reel)
Note
* Ingredient: tin (Sn), 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
The letter of “PbF” is printed either foil side or components side on the PCB using the lead free solder.
(See right figure)

2.4. Handling Precautions for Traverse Unit
The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be
taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit.
2.4.1. Cautions to Be Taken in Handling the Optical Pickup Unit
The laser diode in the optical pickup unit may be damaged due to electrostatic discharge generating from clothes or human body.
Special care must be taken avoid caution to electrostatic discharge damage when servicing the laser diode.
1. Do not give a considerable shock to the optical pickup unit as it has an extremely high-precise structure.
2. To prevent the laser diode from the electrostatic discharge damage, the flexible cable of the optical pickup unit removed
should be short-circuited with a short pin or a clip.
3. The flexible cable may be cut off if an excessive force is applied to it. Use caution when handling the flexible cable.
4. The antistatic FPC is connected to the new optical pickup unit. After replacing the optical pickup unit and connecting the flexi-
ble cable, cut off the antistatic FPC.

2.4.2. Grounding for electrostatic breakdown prevention
Some devices such as the DVD player use the optical pickup (laser diode) and the optical pickup will be damaged by static electric-
ity in the working environment. Proceed servicing works under the working environment where grounding works is completed.
2.4.2.1. Worktable grounding
1. Put a conductive material (sheet) or iron sheet on the area where the optical pickup is placed, and ground the sheet.
2.4.2.2. Human body grounding
1. Use the anti-static wrist strap to discharge the static electricity form your body.

3 Service Navigation
3.1. Service Information
This service manual contains technical information which will allow service personnel’s to understand and service this model.
Please place orders using the parts list and not the drawing reference numbers.
If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service
manual.
•CD Mechanism Unit (BRS1C):
1) This model uses CD Mechanism Unit (BRS1C).
•Micro-processor:
1) The following components are supplied as an assembled part.
- Micro-processor IC, IC2003 (MN101EF16KXW)
•Speaker System:
1) This model uses Speaker System, SB-AKX92LM-K.

4 Specifications
Sección del amplificador
Modo estéreo de potencia de salida RMS
Frontal alto (ambos controlados por los canales)
110 W por canal (5 ), 1 kHz, 10% THD
Frontal bajo (ambos controlados por los canales)
140 W por canal (4 ), 1 kHz, 10% THD
Canal envolvente 140 W por canal (4 ), 1 kHz, 10% THD
Canal de subwoofer 300 W por canal (8 ), 100 Hz, 10% THD
Potencia total del modo estéreo RMS 1380 W
Potencia total del modo estéreo PMPO 15100 W
Sección del sintonizador de FM/AM, terminales
Emisoras preconfiguradas 30 emisoras de FM
15 emisoras de AM
Modulación de frecuencia (FM)
Toma de audífonos
Terminal Estéreo, toma de 3,5 mm
Nivel de salida (CD, 1 kHz, –20 dB)
0,7 mW + 0,7 mW, 32 (máx.)
Toma de micrófono
Sensibilidad 0,7 mV, 1,1 k
Terminal Mono, toma de 3,5 mm (1 sistema)
Puerto de música (frontal)
Sensibilidad 100 mV, 4,7 k
Terminal Estéreo, toma de 3,5 mm
Entrada AUX Clavija jack RCA
Sección de discos compactos
Discos reproducidos (8 cm o 12 cm)
(1) CD-Audio (CD-DA)
(2) CD-R/RW (CD-DA, disco formateado con MP3
)
(3) MP3
MPEG-1 Layer 3
Lector
Longitud de onda 790 nm (CD)
Salida de audio (Disco)
Número de canales 4,2 canales (FL, FR, SL, SR, SW x 2)
FL = Canal frontal izquierdo
FR = Canal frontal derecho
SL = Canal sonido envolvente izquierdo
SR = Canal sonido envolvente derecho
SW = Canal de subwoofer
Sección de USB
Puerto USB
Estándar USB USB 2,0 velocidad total
Compatibilidad con formato de archivos de medios MP3( .mp3)
Sistema de archivo de dispositivo USB FAT 12, FAT 16, FAT 32
Energía puerto USB 500 mA (máx.)
Velocidad de bits 16 kbps a 320 kbps (reproducción)
Cómo grabar en el USB
Velocidad de bits 128 kbps, 192 kbps, 320 kbps
Velocidad de grabación USB 1x, 4x (CD solamente)
Formato de archivo de grabación MP3 (.mp3)
Sección de memoria
Memoria
Tamaño de la memoria 4 GB
Compatibilidad con formato de archivos de medios MP3 ( .mp3)
Cómo grabar en la memoria
Velocidad de bits 128 kbps, 192 kbps, 320 kbps
Velocidad de grabación en la memoria 1x, 4x (CD solamente)
Formato de archivo de grabación MP3 ( .mp3)
Capacidad de total de canciones grabadas 1000 canciones
(Usa 128 kbps, aproximadamente 1 canción = 4 minutos)
Sección de bafles
Bafles frontales (SB-PF92)
Tipo Sistema de 3 bocinas de 3 vías (reflejo de sonidos graves)
Bocina(s)
Super woofer Tipo cónico de 20 cm
Bocina para graves Tipo cónico de 10 cm
Bocina para agudos Tipo cónico de 6 cm
Impedancia 5 (alto), 4 (bajo)
Presión acústica de salida 86 dB/W (1 m)
Gama de frecuencias 48 Hz a 26 kHz (–16 dB)
66 Hz a 20 kHz (–10 dB)
Dimensiones (An x Al x Prf) 250 mm x 414 mm x 332 mm
Peso 6,0 kg
Bafles con sonido envolvente (SB-PS92)
Tipo Sistema de 2 bocinas de 2 vías (reflejo de sonidos graves)
Bocina(s)
Bocina para graves Tipo cónico de 20 cm
Bocina para agudos Tipo cónico de 6 cm
Impedancia 4
Presión acústica de salida 86 dB/W (1 m)
Gama de frecuencias 58 Hz a 21 kHz (–16 dB)
75 Hz a 20 kHz (–10 dB)
Dimensiones (An x Al x Prf) 250 mm x 414 mm x 298 mm
Peso 5,1 kg
Subwoofer (SB-WAKX92)
Tipo Sistema de 1 bocinas de 1 vías (reflejo de sonidos graves)
Bocina(s)
Super woofer Tipo cónico de 25 cm
Impedancia 8
Presión acústica de salida 82 dB/W (1 m)
Gama de frecuencias 43 Hz a 250 Hz (–16 dB)
47 Hz a 200 Hz (–10 dB)
Dimensiones (An x Al x Prf) 320 mm x 414 mm x 361 mm
Peso 8,0 kg
Subwoofer (SB-WAKX93)
Tipo Sistema de 1 bocina de 1 vía (reflejo de sonidos graves)
Bocina(s)
Super woofer Tipo cónico de 25 cm
Impedancia 8
Presión acústica de salida 82 dB/W (1 m)
Gama de frecuencias 43 Hz a 250 Hz (–16 dB)
47 Hz a 200 Hz (–10 dB)
Dimensiones (An x Al x Prf) 320 mm x 414 mm x 348 mm
Peso 7,9 kg
Generalidades
Fuente de alimentación ˜127 V, 60 Hz
Consumo de energía
165 W
Dimensiones (An x Al x Prf) 220 mm x 334 mm x 245 mm
Peso 3,6 kg
Gama de temperaturas de funcionamiento 0°C a +40°C
Gama de humedades de funcionamiento
35% a 80% humedad relativa (sin condensación)
Consumo en el modo de espera 0,2 W (aproximado)
Nota:
1. Las especificaciones están sujetas a cambios sin previo aviso.
El peso y las dimensiones son aproximados.
2. La distorsión armónica total se mide con el analizador de espectro
digital.
Gama de frecuencias
87,9 MHz a 107,9 MHz (en pasos de 200 kHz)
87,5 MHz a 108,0 MHz (en pasos de 100 kHz)
Terminales de la antena 75 (desbalanceado)
Modulación de amplitud (AM)
Gama de frecuencias 520 kHz a 1710 kHz (en pasos de 10 kHz)

5 Location of Controls and Components
5.1. Main Unit Key Button Operation

5.2. Remote Control Key Button Operation

5.3. Media Information

6 Self-Diagnostic and Special Mode Setting
6.1. Cold-Start
Here is the procedure to carry out cold-start or initialize to shipping mode.
1. Unplug AC power cord
2. Press & hold [POWER] button
3. Plug AC power cord while [POWER] button being pressed
FL Display will show “_ _ _ _ _ _ _ _”
4. Release [POWER] button

6.2. Doctor Mode Table
6.2.1. Doctor Mode Table 1
FL Display
Key Operation
Front Key
Item
DescriptionMode Name
Doctor Mode
Micro-P Version
Display
Jupiter
Micro-P
Version
To enter into Doctor Mode
1.In CD Mode:
Press [ ] button on main
unit follow by [4] and [7] on
remote control.
2.To exit, press [OK] button on
remote control or press
[POWER, /I] button on main
unit or remote control.
In Doctor Mode:
1.Press [2] button on
remote control.
Display 1:
Display 2:
To check the firmware version
for Jupiter & Microprocessor IC.
Display 1 will display for 2 secs,
followed by display 2.
Micro-processor
Version

6.2.2. Doctor Mode Table 2
FL Display
Key Operation
Front Key
Item
DescriptionMode Name
Cold Start
Volume Setting
Check
FL Display
Check
To active cold start upon next AC
power up when reset start is execute
the next time.
To check the volume setting of a main
unit.
To check the FL segment display
All segment will light up while all LED
blink at 0.5s,intervals.(if any)
In Doctor Mode:
1. Press [DISPLAY/-DIMMER]
button on remote control.
In Doctor Mode:
1. Press [7],[8],[9],
[PLAY MENU/RADIO
MENU] button on remote
control.
In Doctor mode:
1. Press [1] button on
remote control.
CD Open
Check
To excute CD Open operation. In Doctor mode:
1. Press [DEL] button on
remote control.
Press [7]: VOL50
Press [8]: VOL35
Press [9]: VOL0
Press [PLAY/RADIO MODE]: VOL30
Volume
In this mode, the tray will open &
close.
Note: Refer to Section 6.3 Fig 1 for
process flow.
The counter will
increment by one.
When reach 9999
will change to 0000
Cancellation Display
BRS1C Reliability
Test (Loading)
To determine CD Mechanism Unit
(BRS1C) Open/Close operation.
Note: Refer to Section 6.3 Fig 2. for
process flow.
The counter will
increment by one.
When reach 9999
will change to 0000
Cancellation Display
BRS1C Reliability
Test (Traverse)
To determine CD Mechanism BRS1C
Access Inner & Outer disc operation.
Note: Refer to Section 6.3 Fig 3. for
process flow.
The counter will
increment by one.
When reach 9999
will change to 0000
Cancellation Display
BRS1C Reliability
Test
(Combination)
In this mode,ensure the CD is in the
main unit.
To determine CD Mechanism Unit
(BRS1C) Open/Close & Access Inner &
Outer Disc Operation.
In this mode,ensure the CD is in the
main unit.
In Doctor Mode:
1. Press [10] [2] [1] button
on remote control.
2. To cancel, press [0]
on remote control.
In Doctor Mode:
1. Press [10] [1] [2] button
on remote control.
2. To cancel, press [0]
on remote control.
In Doctor Mode:
1. Press [10] [1] [5] button
on remote control.
2. To cancel, press [0]
on remote control.

6.3. Reliability Test Mode (CD Mechanism Unit (BRS1C))
Below is the process flow chart of the aging test for the CD Mechanism Unit (BRS1C).
Fig. 1. Reliability Test (Loading)
Fig. 2. Reliability Test (Traverse)
Fig. 3. Reliability Test (Combination)
OPEN
Operation
OPEN wait
fot 1 s
CLOSE
Operation
CLOSE wait
for 4s
Count up
First Track
Access
First Track
Play 5 s
Last Track
Access
Last Track
Play 5 s
Count up
First Track
Access
First Track
Play 10 s
Last Track
Access
Last Track
Play 10 s
Open
Operation
Open wait
for 1 s
CLOSE
Operation Count up

6.4. Self-Diagnostic Mode
Service Mode To enter into Service Mode
Checking the records for Error Code.
If there’s no error code.Display will
remain as [T ]
In Service Mode:
1.Press button [1] on remote control.
2.To clear history,press & hold [0] for
5 seconds or more
In Service Mode:
1.Press button [2] on remote control.
In Service Mode:
1.Press button [5] on remote control.
2.To clear history,press & hold [0] for
5 seconds or more.
2.Press button [2] on remote control.
3.Press button [2] button on remote
control.
To check for USB error Codes.
Error Code
History
USB Error
Code History
Software
Display
Version.
/l
To check for following:
1)System Version.
2)Jupiter Micro-processor Version.
3) Opecon Version.
In CD Mode:
1.Press and hold [ ] button on
main unit for 2 secs.
2.Do not release [ ] button, press
and hold [ / ] on the remote
control for 2 secs.
3.To exit, press [POWER, ]
button on main unit.
History
number
Display of AD
value of main
body key
To check the AD input value In Service Mode:
1.Press button [ 4 ] on remote
control for 2 secs.
XX: AN2 input value (2 hexadecimal
value digits) --> KEY1
YY: AN3 input value (2 hexadecimal
value digits) --> KEY2
ZZ: AN4 input value (2 hexadecimal
value digits) --> KEY3
AN4AN3AN2
