Panasonic SC-AKX320 User manual

D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Operating Instructions
Инструкция по эксплуатации
Інструкція з експлуатації
CD Stereo System
CD-cтереосистема
CD-стереосистема
Model No. SC-AKX320
Дякуємо Вам за придбання цього пристрою.
Щоб забезпечити найбільш оптимальну та безпечну роботу, будь ласка, уважно ознайомтеся з цими інструкціями.
Збережіть цей посібник для майбутнього використання.
Panasonic Corporation
Web Site: http://www.panasonic.com
© Panasonic Corporation 2019
TQBJ2173
L0519LC1049
UrRu
GS En
Благодарим Вас за покупку данного изделия.
Для обеспечения оптимальной и безопасной pаботы системы внимательно пpочтите данную инстpукцию.
Сохраните инструкцию для дальнейших справок.
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions carefully.
Please keep this manual for future reference.
SC-AKX320 GS TQBJ2173 En.fm Page 1 Friday, April 5, 2019 5:25 PM

2
TQBJ2173
2
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
These operating instructions are applicable to the
following system.
Your system and the illustrations can look differently.
The symbols on this product (including the accessories)
represent the following:
Table of contents
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Note on AC mains lead . . . . . . . . . . . . . . . . . . . . . . . . . . 3
References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Supplied accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Preparing the remote control . . . . . . . . . . . . . . . . . . . . . 4
Placement of speakers . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Making the connections . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview of controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preparing media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Media playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Sound effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
DJ functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Clock and timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
External equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Safety precautions
WARNING!
Unit
• To reduce the risk of fire, electric shock or product
damage,
– Do not expose this unit to rain, moisture, dripping or
splashing.
– Do not place objects filled with liquids, such as vases,
on this unit.
– Use the recommended accessories.
– Do not remove covers.
– Do not repair this unit by yourself. Refer servicing to
qualified service personnel.
– Do not let metal objects fall inside this unit.
CAUTION!
Unit
• To reduce the risk of fire, electric shock or product
damage,
– Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure this unit
is well ventilated.
– Do not obstruct this unit’s ventilation openings with
newspapers, tablecloths, curtains, and similar items.
– Do not place sources of naked flames, such as lighted
candles, on this unit.
• This unit is intended for use in moderate and tropical
climates.
• This unit may receive radio interference caused by
mobile telephones during use. If such interference
occurs, please increase separation between this unit
and the mobile telephone.
• This unit utilizes a laser. Use of controls or adjustments
or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
• Set the unit up on an even surface away from direct
sunlight, high temperatures, high humidity, and
excessive vibration.
• This system might get warm after prolonged usage. This
is normal. Do not be alarmed.
AC mains lead
• The mains plug is the disconnecting device. Install this
unit so that the mains plug can be unplugged from the
socket outlet immediately.
System SC-AKX320
Main unit SA-AKX320
Speakers SB-AKX220
AC
Class II equipment (The construction of the
product is double-insulated.)
ON
Standby
For Thailand
This telecommunication equipment conforms to
NTC/NBTC technical requirement.
SC-AKX320 GS TQBJ2173 En.fm Page 2 Thursday, March 14, 2019 9:56 AM

3
TQBJ2173
3
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Battery
• Danger of explosion if battery is incorrectly replaced.
Replace only with the type recommended by the
manufacturer.
• When disposing of the batteries, please contact your
local authorities or dealer and ask for the correct
method of disposal.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct
sunlight for a long period of time with doors and
windows closed.
• Do not break open or short-circuit the battery.
• Do not charge the alkaline or manganese battery.
• Do not use the battery if the cover has peeled off.
• Remove the battery if you do not use the remote control
for a long period of time. Keep in a cool, dark area.
Note on AC mains lead
(For the AC mains plug of three pins)
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of AC
mains plug (figures A and B). Confirm the AC mains plug
fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse cover.
References
About Bluetooth
®
Frequency band
• This system uses the 2.4 GHz frequency band.
Certification
• This system conforms to the frequency restrictions and
has received certification based on frequency laws.
Thus, a wireless permit is not necessary.
• The actions below are punishable by law in some
countries:
– Taking apart or modifying the main unit.
– Removing specification indications.
Restrictions of use
• Wireless transmission and/or usage with all Bluetooth®
equipped devices is not guaranteed.
• All devices must conform to standards set by the
Bluetooth SIG, Inc.
• Depending on the specifications and settings of a
device, it can fail to connect or some operations can be
different.
• This system supports Bluetooth® security features. But
depending on the operating environment and/or
settings, this security is possibly not sufficient. Transmit
data wirelessly to this system with caution.
• This system cannot transmit data to a Bluetooth®
device.
Range of use
• Use this device at a maximum range of 10 m.
• The range can decrease depending on the environment,
obstacles or interference.
Interference from other devices
• This system may not function properly and troubles
such as noise and sound jumps may arise due to radio
wave interference if this unit is located too close to other
Bluetooth® devices or the devices that use the 2.4 GHz
band.
• This system may not function properly if radio waves
from a nearby broadcasting station, etc. is too strong.
Intended usage
• This system is for normal, general use only.
• Do not use this system near an equipment or in an
environment that is sensitive to radio frequency
interference (example: airports, hospitals, laboratories,
etc.).
Figure A Figure B
Figure A Figure B
Fuse cover
Fuse (5 ampere)
Fuse (5 ampere)
Panasonic bears no responsibility for data and/or
information that is compromised during a wireless
transmission.
ENGLISH
SC-AKX320 GS TQBJ2173 En.fm Page 3 Thursday, March 14, 2019 9:56 AM

4
TQBJ2173
4
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Licenses
Supplied accessories
Check and identify the supplied accessories.
3 AC mains leads
For Saudi Arabia
1 AM loop antenna
1 FM indoor antenna
1 Remote control
(N2QAYB001215)
1 Remote control battery
Note:
Use the AC mains lead that is suitable for your household
mains socket.
Preparing the remote control
Use alkaline or manganese battery.
Install the battery so that the poles (+ and –) align with
those in the remote control.
Placement of speakers
The left and right speakers are the same.
Use only the supplied speakers.
You can cause damage to the system and decrease the
sound quality if you use other speakers.
Note:
• Keep your speakers more than 10 mm from the main unit for
ventilation.
• Put the speakers on a flat safe surface.
• These speakers do not have magnetic shielding. Do not put
them near TVs, PCs or other equipment easily influenced by
magnetism.
• When you play at high levels for a long period, it can cause
damage to the speakers and decrease the life of the
speakers.
• Decrease the volume in these conditions to prevent
damage:
– When the sound is distorted.
– When you adjust the sound quality.
Maintenance
Disconnect the AC mains lead before maintenance.
Clean this system with a soft, dry cloth.
• Never use alcohol, paint thinner or benzine to clean this
system.
• Before using chemically treated cloth, read the
instructions that came with the cloth carefully.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by Panasonic Corporation is under license.
Other trademarks and trade names are those of their
respective owners.
Android and Google Play are trademarks of Google
LLC.
CAUTION!
•Use the speakers only with the recommended
system. If not, you can cause damage to the
amplifier and speakers and can cause a fire.
Consult an approved service personnel if damage
occurs or if there is a sudden apparent change in
performance.
•Do not modify the speaker or speaker wires as this
can cause damage to the system.
•Do the procedures included in these instructions
when you attach the speakers.
•Do not touch the speaker cone’s reverberating
surfaces:
–This may damage the speaker cone.
–The speaker cone may be hot.
SC-AKX320 GS TQBJ2173 En.fm Page 4 Thursday, March 14, 2019 9:56 AM

5
TQBJ2173
5
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Making the connections
Connect the AC mains lead only after all the other connections have been made.
1Connect the AM loop antenna.
Stand the antenna up on its base until it clicks.
2Connect the FM indoor antenna.
Put the antenna where reception is best.
3Connect the speakers.
Connect the speaker cables to the corresponding
terminals.
4Connect the AC mains lead.
Do not use any other AC mains leads except the
supplied one.
Conserving power
The system consumes a small amount of power even
when it is in standby mode. Disconnect the power
supply if you do not use the system.
Some settings will be lost after you disconnect the
system. You have to set them again.
Note:
Keep the antennas away from the speaker cables and the AC
mains lead to avoid picking up noise.
Adhesive tape
(not supplied)
To household
mains socket
ENGLISH
SC-AKX320 GS TQBJ2173 En.fm Page 5 Thursday, March 14, 2019 9:56 AM

6
TQBJ2173
6
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Overview of controls
Do the procedures with the remote control. You can also use the buttons on the main unit if they are the same.
AStandby/on switch [`], [1]
Press to switch the unit from on to standby mode or
vice versa. In standby mode, the unit is still consuming
a small amount of power.
BDecrease the brightness of the display panel
To cancel, press the button again.
CSelect the audio source
Press [SELECT <, >] (main unit: [SELECT])
repeatedly to select the source:
On the main unit:
To start Bluetooth® pairing, press and hold [ ].
DBasic playback control
EView the setup menu
FView the content information
GSelect or confirm the option
HSet the sleep timer
IAdjust the volume level
On the main unit:
Press [VOL] and then turn [VOLUME/MULTI CONTROL]
to adjust the volume.
JMute the sound
To cancel, press the button again.
“MUTE” is also cancelled when you adjust the volume
or when you switch off the system.
KView the play menu
LSelect the sound effects
MOpen or close the disc tray
NSelect MP3 album or track
Press [ALBUM/TRACK] to select album or track.
Browse tracks or albums
Turn [VOLUME/MULTI CONTROL] to browse.
To start playback from the selection, press [4/9].
ODJ function direct buttons
Press [DJ] to switch on the DJ function.
Press [DJ1] to [DJ6] to select the desired function.
To cancel, press the selected [DJ1] to [DJ6] again.
PDisc tray
QVolume or multi control knob
RRemote control sensor
Distance: Within approximately 7 m
Angle: Approximately 10° up and 30° down,
30° left and right
SDisplay panel
TUSB port ( )
USB status indicator
USelect DJ jukebox
USB A USB B CD
AUXBLUETOOTH AM
FM
SC-AKX320 GS TQBJ2173 En.fm Page 6 Thursday, March 14, 2019 9:56 AM

7
TQBJ2173
7
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Preparing media
Disc
1Press [x] to open the disc tray.
Put in a disc with the label facing up.
Press again to close the disc tray.
2Press [SELECT <, >] repeatedly to select “CD”.
USB
Preparation
Before you connect a USB device to the system, make
sure you do a backup of the data.
1Decrease the volume and connect the USB device
to the USB port.
Hold the main unit when connecting or disconnecting
the USB device.
2Press [SELECT <, >] repeatedly to select “USB A”
or “USB B”.
USB status indicator lights up in red when selected.
Note:
• Do not use a USB extension cable. The system cannot
recognise USB device connected through a cable.
• Some devices cannot be charged as the maximum USB
charging current is 0.5 A only.
Bluetooth
®
You can connect and play an audio device wirelessly
through Bluetooth®.
Preparation
• Switch on the main unit.
• Switch on the Bluetooth® feature of the device and put
the device near the system.
• Read the operating instructions of the device for details.
█ Pairing a device
Preparation
If this system is connected to a Bluetooth® device,
disconnect it (~7).
1Press [ ].
If “PAIRING” is shown, continue with step 3.
2Press [PLAY MENU] to select “PAIRING” and then
press [OK].
3Select “SC-AKX320” from the Bluetooth® menu of
the device.
If prompted for a passkey, input “0000” or “1234”.
The device connects with this system automatically
after pairing is complete.
The MAC address (example: 6C:5A:B5:B3:1D:0F)
may be shown before “SC-AKX320” is shown.
The name of the connected device is shown for a few
seconds.
Using the main unit
1Press and hold [ ] until “PAIRING” is shown.
2Select “SC-AKX320” from the Bluetooth® menu of
the device.
Note:
• You can pair up to 8 devices with this system. If a 9th device
is paired, the device that has not been used for the longest
time will be replaced.
• Depending on the searching functionality of the Bluetooth®
device and the surrounding environment, if the product
name is not shown on the Bluetooth® menu of the device,
switch off and then switch on the Bluetooth® feature of the
device repeatedly during the pairing process.
█ Connecting a device
Preparation
If this system is connected to a Bluetooth® device,
disconnect it (~7).
1Press [ ].
“BLUETOOTH READY” is shown.
2Select “SC-AKX320” from the Bluetooth® menu of
the device.
The name of the connected device is shown for a few
seconds.
3Start playback on the device.
Note:
• A device must be paired to connect.
• This system can only connect to one device at a time.
• When “BLUETOOTH” is selected as the source, this system
will automatically try to connect to the last connected device.
(“LINKING” is shown during this process.)
█ Disconnecting a device
While a Bluetooth®device is connected
1Press [PLAY MENU] repeatedly to select
“DISCONNECT?”.
2Press [R,T] to select “OK? YES” and then press
[OK].
“BLUETOOTH READY” is shown.
To cancel, select “OK? NO”.
Using the main unit
Press and hold [ ] until “PAIRING” is shown.
Note:
A device is disconnected when you:
• Select a different source.
• Move the device out of the maximum range.
• Disable the Bluetooth® transmission of the device.
• Switch off the system or the device.
ENGLISH
SC-AKX320 GS TQBJ2173 En.fm Page 7 Thursday, March 14, 2019 9:56 AM

8
TQBJ2173
8
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Media playback
The following marks indicate the availability of the feature.
Basic playback
CD USB BLUETOOTH
Note:
Depending on the Bluetooth® device, some operations may not
work.
Viewing available information
CD USB BLUETOOTH
You can view the available information, such as MP3
album and track number, on the display panel.
Press [DISPLAY] repeatedly.
Example: MP3 album and track number display.
Note:
• Maximum characters that can be shown: Approximately 32
• This system supports ver. 1.0, 1.1 and 2.3 ID3 tags.
• Text data that the system does not support can show
differently.
Play menu
CD USB
1CD
Press [PLAY MENU].
USB
Press [PLAY MENU] repeatedly to select
“PLAYMODE”.
2Press [R,T] to select the setting and then press
[OK].
Note:
• During random playback, you cannot skip to tracks which
have been played.
• The setting is cancelled when you open the disc tray or
disconnect the USB device.
CD :
USB :
BLUETOOTH :
CD-R/RW in CD-DA format or with MP3 files.
USB device with MP3 files.
Bluetooth® device.
Play Press [4/9].
Stop Press [8].
USB
The position is memorised.
“RESUME” is shown.
Press again to stop fully.
Pause Press [4/9].
Press again to continue playback.
Skip Press [2/3] or [5/6] to skip track.
CD USB
Press [R,T] to skip MP3 album.
Search Press and hold [2/3] or [5/6].
Album
number Track number
OFF PLAYMODE Cancel the setting.
1-TRACK
1 Play one selected track. Press [2/3] or [5/6] to
select the track.
1-ALBUM
1 Play one selected MP3 album. Press [R,T] to select the MP3
album.
RANDOM
RND
Play all tracks randomly.
1-ALBUM RANDOM
1 RND
Play all tracks in one selected MP3
album randomly.
Press [R,T] to select the MP3
album.
ALL REPEAT Repeat all tracks.
1-TRACK REPEAT
1 Repeat 1-TRACK.
1-ALBUM REPEAT
1 Repeat 1-ALBUM.
RANDOM REPEAT
RND Repeat random playback.
1-ALBUM
RANDOM REPEAT
1 RND
Repeat 1-ALBUM RANDOM.
SC-AKX320 GS TQBJ2173 En.fm Page 8 Thursday, March 14, 2019 9:56 AM

9
TQBJ2173
9
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Link mode
BLUETOOTH
You can change the link mode to suit the connection type.
Preparation
If this system is connected to a Bluetooth® device,
disconnect it (~7).
1Press [PLAY MENU] repeatedly to select
“LINK MODE”.
2Press [R,T] to select the mode and then press
[OK].
Note:
• When enjoying video contents with this function, the video
and audio output may not be synchronised. In this case,
select “MODE 1”.
• Select “MODE 1” if the sound is interrupted.
█ Note on disc
• This system can play CD-R/RW with CD-DA or MP3
format content.
• Before playback, finalise the disc on the device it was
recorded on.
• Some CD-R/RW cannot be played because of the
condition of the recording.
█ Note on USB device
• This system does not guarantee connection with all
USB devices.
• This system supports USB 2.0 full speed.
• This system can support USB devices of up to 32 GB.
• Only FAT 12/16/32 file system is supported.
█ Note on MP3 file
• Files are defined as tracks and folders are defined as
albums.
• Tracks must have the extension “.mp3” or “.MP3”.
• Tracks will not necessarily be played in the order you
recorded them.
• Some files can fail to work because of the sector size.
MP3 file on disc
• This system can access up to:
– 255 albums (including root folder)
– 999 tracks
– 20 sessions
• Disc must conform to ISO9660 level 1 or 2 (except for
extended formats).
MP3 file on USB device
• This system can access up to:
– 800 albums (including root folder)
– 8000 tracks
– 999 tracks in one album
Radio
Preparation
Press [SELECT <, >] repeatedly to select “FM” or “AM”.
Manual tuning
1Press [PLAY MENU] repeatedly to select
“TUNE MODE”.
Or press [8] on the main unit to select “MANUAL”.
Continue with step 3.
2Press [R,T] to select “MANUAL” and then press
[OK].
3Press [2/3] or [5/6] to tune in to the
station.
To tune automatically, press and hold the button until
the frequency starts changing quickly.
“STEREO” is shown when a stereo broadcast is being
received.
Memory presetting
You can preset up to 30 FM stations and 15 AM stations.
█ Automatic presetting
1Press [PLAY MENU] to select “A.PRESET”.
2Press [R,T] to select “LOWEST” or “CURRENT”
and then press [OK].
The tuner presets all the stations it can receive into the
channels in ascending order.
To cancel, press [8].
█ Manual presetting
1Press [PLAY MENU] repeatedly to select
“TUNE MODE”.
Or press [8] on the main unit to select “MANUAL”.
Continue with step 3.
2Press [R,T] to select “MANUAL” and then press
[OK].
3Press [2/3] or [5/6] to tune in to the
station.
4Press [OK].
5Press [R,T] to select a preset number and then
press [OK].
Do steps 3 through 5 again to preset more stations.
The new station replaces any station that occupies the
same preset number.
MODE 1 Emphasis on connectivity.
MODE 2 (default) Emphasis on sound quality.
LOWEST Tuning begins from the lowest
frequency.
CURRENT Tuning begins from the current
frequency.
ENGLISH
SC-AKX320 GS TQBJ2173 En.fm Page 9 Thursday, March 14, 2019 9:56 AM

10
TQBJ2173
10
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
█ Selecting a preset station
1Press [PLAY MENU] repeatedly to select
“TUNE MODE”.
Or press [8] on the main unit to select “PRESET”.
Continue with step 3.
2Press [R,T] to select “PRESET” and then press
[OK].
3Press [2/3] or [5/6] to select the preset
station.
Improving the sound quality
When “FM” is selected
1Press [PLAY MENU] repeatedly to select
“FM MODE”.
2Press [R,T] to select “MONO” and then press
[OK].
To cancel, select “STEREO”.
“MONO” is also cancelled when you change the
frequency.
To memorise the setting
Continue with step 4 of “Manual presetting” (~9).
When “AM” is selected
1Press [PLAY MENU] repeatedly to select
“B.PROOF”.
2Press [R,T] to select the setting that provides the
best reception and then press [OK].
Checking the signal status
When “FM” is selected
Press [DISPLAY].
AM allocation setting
This system can also receive AM broadcasts allocated in
10 kHz steps.
When “AM” is selected
Press and hold [4/9] on the main unit.
After a few seconds, the display panel shows the current
minimum radio frequency. Release the button when the
minimum frequency changes.
• To go back to the initial setting, do the above steps
again.
• Preset frequencies are erased after you change the
setting.
Sound effects
1Press [SOUND] repeatedly to select the effect.
2Press [R,T] to select the setting and then press
[OK].
Or turn [VOLUME/MULTI CONTROL] to select the
setting.
DJ functions
You can use the DJ functions to add sound effects
between songs.
DJ jukebox
USB
You can use the DJ jukebox function to add cross-fade
effect between songs.
1Press [PLAY MENU] to select “JUKEBOX”.
2Press [R,T] to select the setting and then press
[OK].
FM – – – – The FM signal is weak.
The system is not tuned in to a station.
FM ST The FM signal is in stereo.
FM MONO “MONO” is selected as the “FM MODE”.
The FM signal is in monaural.
PRESET EQ “ROCK”, “POP”, “AFRO BEAT”,
“ARABIC”, “PERSIAN”, “INDIA
BASS”, “DANGDUT”, “MALAY
POP”, “ELECTRONICA”,
“REGGAETON”, “SALSA”,
“SAMBA”, “FOOTBALL” or “FLAT”
BASS/MID/TREBLE –4 to +4
Note:
These settings can change when you
select a PRESET EQ setting.
SURROUND “ON SURROUND” or
“OFF SURROUND”
D.BASS LEVEL “OFF”, “LEVEL 1” to “LEVEL 6”
D.BASS BEAT “ON D.BASS BEAT” or
“OFF D.BASS BEAT”
Note:
• This function emphasises the attack
level of the drumbeat and produces
a punchy sound. Depending on the
track, the effect may be small.
• This function does not work when
“D.BASS LEVEL” is set to “OFF”.
Using the “Panasonic MAX Juke” app
You can download and install the free Android™ app
“Panasonic MAX Juke” on Google Play™ for additional
features, such as to request song playback from multiple
devices simultaneously. You can also call up the tracks
you want to play through the app. For details on the app,
refer to the site below.
http://av.jpn.support.panasonic.com/support/global/
cs/audio/app/
(This site is in English only.)
SC-AKX320 GS TQBJ2173 En.fm Page 10 Thursday, March 14, 2019 9:56 AM

11
TQBJ2173
11
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Using the main unit
Press [JUKEBOX] repeatedly to select the setting.
Note:
• The system switches to repeat mode automatically when
you switch on DJ jukebox.
• DJ jukebox is switched off when you switch off the system or
change to another source.
• The cross-fade function may not work between songs that
have different sampling frequencies.
█ Changing the repeat setting
1Press [PLAY MENU] repeatedly to select
“PLAYMODE”.
2Press [R,T] to select the setting and then press
[OK].
DJ effect
(Except for AUX source)
By main unit only
You can use the DJ effect function to add sound effects.
1Press [DJ] to select “DJ EFFECT SELECT
NUMBER” or “ON DJ EFFECT”.
To cancel, select “OFF EFFECT”.
2Press [DJ1] to [DJ6] to select the effect.
To cancel, press the button again.
3Turn [VOLUME/MULTI CONTROL] to select the
setting.
Note:
DJ effect is switched off when you switch off the system or
change to AUX source.
Clock and timers
Setting the clock
This is a 24-hour clock.
1Press [SETUP] to select “CLOCK”.
2Press [R,T] to set the time and then press [OK].
To check the time
Press [SETUP] to select “CLOCK” and then press
[OK].
In standby mode, press [DISPLAY].
Note:
Reset the clock regularly to maintain accuracy.
Sleep timer
The sleep timer switches off the system after the set time.
Press [SLEEP] repeatedly to select the setting (in
minutes).
To cancel, select “OFF”.
To check the remaining time
Press [SLEEP].
Note:
• The remaining time is shown for a few seconds every
minute. “SLEEP 1” is always shown when only 1 minute
remains.
• The sleep timer always comes first. Be sure not to set an
overlap of timers.
Play timer
(Except for Bluetooth® and AUX source)
You can set the timer to come on at a certain time to wake
you up.
Preparation
Set the clock.
1Press [SETUP] repeatedly to select “TIMER ADJ”.
2Press [R,T] to set the start time and then press
[OK].
3Do step 2 again to set the end time.
4Press [R,T] to select the source you want to play
and then press [OK].
OFF CROSSFADE Cancel cross-fading.
ON CROSSFADE Add cross-fading.
OFF Switch off DJ jukebox.
RANDOM REPEAT
RND Repeat random playback.
ALL TITLE REPEAT Repeat all tracks.
[DJ1] PHASER
Add space and dimension to the sound.
[DJ2] FILTER
Enhance or filter specific ranges of the sound.
[DJ3] SOUND CHOPPER
Cut off the sound periodically.
[DJ4] ELECTRO ECHO
Add digital echo to the sound.
[DJ5] PITCH SHIFTER
Adjust the keys of the sound.
[DJ6] HARMONIZER
Add notes to the sound to create harmony.
SLEEP 30 SLEEP 60 SLEEP 90 SLEEP120
OFF
ENGLISH
SC-AKX320 GS TQBJ2173 En.fm Page 11 Thursday, March 14, 2019 9:56 AM

12
TQBJ2173
12
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
To start the timer
1Prepare the source you want to listen to (disc,
USB or radio) and set the volume.
2Press [SETUP] repeatedly to select “TIMER SET”.
3Press [R,T] to select “PLAY ON” and then press
[OK].
“#” is shown.
To cancel, select “PLAY OFF”.
The system must be switched off for the timer to
operate.
To check the setting
Press [SETUP] repeatedly to select “TIMER ADJ” and
then press [OK].
In standby mode, press [DISPLAY] two times.
Note:
• The timer starts at a low volume and increases gradually to
the preset level.
• The timer comes on at the set time every day if the timer is
on.
• If you switch off the system and then switch on again while a
timer is in operation, the timer will not stop at the end time.
External equipment
You can connect a VCR, DVD player etc., and listen to the
audio through this system.
Preparation
• Disconnect the AC mains lead.
• Switch off all equipment and read the appropriate
operating instructions.
1Connect the external equipment.
2Press [SELECT <, >] repeatedly to select “AUX”.
3Play the external equipment.
Note:
• Do not bend cables at sharp angles.
• Components and cables are sold separately.
• Sound distortion can occur when you use an adaptor.
• If you want to connect equipment other than those
described, refer to the audio dealer.
Others
Auto off
This system automatically switches off when you do not
use it for approximately 20 minutes.
1Press [SETUP] repeatedly to select “AUTO OFF”.
2Press [R,T] to select “ON” and then press [OK].
To cancel, select “OFF”.
Note:
This function does not work when you are in radio source or
when a Bluetooth® device is connected.
Bluetooth
®
standby
This function automatically switches on the system when
you establish a Bluetooth® connection from a paired
device.
1Press [SETUP] repeatedly to select “BLUETOOTH
STANDBY”.
2Press [R,T] to select “ON” and then press [OK].
To cancel, select “OFF”.
Note:
Some devices may take longer to respond. If you are
connected to a Bluetooth® device before switching off the
system, wait for a minimum of 5 seconds before connecting to
this system from your Bluetooth® device again.
Software update
Occasionally, Panasonic may release updated software
for this unit that may add or improve the way a feature
operates. These updates are available free of charge. For
more details, refer to the following website.
http://panasonic.jp/support/global/cs/
(This site is in English only.)
█ Checking the software version
1Press [SETUP] repeatedly to select “SW VER.”
and then press [OK].
The software version is shown.
2Press [OK] again to exit.
Rear panel of
this main unit
Audio cable
(not supplied)
DVD player (not supplied)
SC-AKX320 GS TQBJ2173 En.fm Page 12 Thursday, March 14, 2019 9:56 AM

13
TQBJ2173
13
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Troubleshooting
Before requesting service, make the following checks. If
you are in doubt about some of the check points, or if the
solutions indicated do not solve the problem, consult your
dealer for instructions.
█ Common problems
The unit does not work.
• The safety device has been activated. Do the following:
1. Press [1] on the main unit to switch the unit to standby
mode. If the unit does not switch to standby mode,
disconnect the AC mains lead and then connect it again.
2. Press [1] again to switch on the unit. If the problem
persists, consult your dealer.
The display panel lights up and changes continuously in
standby mode.
• Press and hold [8] on the main unit until “DEMO OFF” or
“SDEMO OFF” is shown.
No operations can be done with the remote control.
• Examine that the battery is installed correctly.
Sound is distorted or no sound.
• Adjust the volume of the system.
• Switch off the system, determine and correct the cause, and
then switch on again. It can be caused by straining of the
speakers through excessive volume or power, and when
using the system in a hot environment.
A humming sound can be heard during playback.
• An AC mains lead or fluorescent light is near the cables.
Keep other appliances and cords away from the cables of
this system.
The sound level reduces.
• The protection circuit has been activated due to the
continuous use at high volume output. This is to protect the
system and maintain the sound quality.
█ Disc
Display not shown correctly.
Playback does not start.
• You have not put in the disc correctly. Put it in correctly.
• Disc is dirty. Clean the disc.
• Replace the disc if it is scratched, warped, or non-standard.
• There is condensation. Let the system dry for 1 to 2 hours.
The total number of tracks shown is incorrect.
The disc cannot be read.
Distorted sound is heard.
• You put in a disc that the system cannot play. Change to a
playable disc.
• You put in a disc that has not been finalised.
█ USB
The USB device or the contents in it cannot be read.
• The format of the USB device or the contents in it are not
compatible with the system.
• USB devices with storage capacity of more than 32 GB
cannot work in some conditions.
Slow operation of the USB device.
• Large content size or large memory USB device takes
longer time to read.
█ Bluetooth
®
Pairing cannot be done.
• Check the Bluetooth® device condition.
• The device is out of the 10 m communication range. Move
the device nearer to the system.
The device cannot be connected.
• The pairing of the device was unsuccessful. Do pairing again
(~7).
• The pairing of the device has been replaced. Do pairing
again (~7).
• This system might be connected to a different device.
Disconnect the other device and try connecting the device
again.
• The system may have a problem. Switch off the system and
then switch on again.
• If “MODE 2” is selected in “LINK MODE”, select “MODE 1”
(~9).
The device is connected but audio cannot be heard
through the system.
• For some built-in Bluetooth® devices, you have to set the
audio output to “SC-AKX320” manually. Read the operating
instructions of the device for details.
Sound from the device is interrupted.
• The device is out of the 10 m communication range. Move
the device nearer to the system.
• Remove any obstacle between the system and the device.
• Other devices that use the 2.4 GHz frequency band
(wireless router, microwaves, cordless phones, etc.) are
interfering. Move the device nearer to the system and
distance it from the other devices.
• Select “MODE 1” for stable communication (~9).
█ Radio
Sound is distorted.
• Use an optional FM outdoor antenna. The antenna should
be installed by a competent technician.
A beat sound is heard.
• Switch off the TV or move it away from the system.
• Move mobile telephones away from the system if the
interference is apparent.
• When in AM tuner mode, select the “B.PROOF” setting that
provides the best reception.
A low hum is heard during AM broadcasts.
• Move the antenna away from other cables and cords.
ENGLISH
SC-AKX320 GS TQBJ2173 En.fm Page 13 Thursday, March 14, 2019 9:56 AM

14
TQBJ2173
14
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
█ Main unit displays
“--:--”
• You connected the AC mains lead for the first time or there
was a power failure recently. Set the clock.
• Track play time is more than 99 minutes.
“ADJUST CLOCK”
• The clock is not set. Adjust the clock.
“ADJUST TIMER”
• The play timer is not set. Adjust the play timer.
“AUTO OFF”
• The system has not been used for 20 minutes and will
switch off within a minute. To cancel, press any button.
“ERROR”
• An incorrect operation was done. Read the instructions and
try again.
“F” / “F” (“” represents a number.)
• The protection circuit has been activated and the system
may be switched off automatically.
• Disconnect the AC mains lead and wait for a few seconds
before connecting it again. If the problem persists,
disconnect the AC mains lead and consult your dealer.
“NO DISC”
• You have not put in a disc.
“NO PLAY”
“UNSUPPORT”
• There is no album or track in the USB device.
• Examine the content. You can only play supported format.
• The system may have a problem. Switch off the system and
then switch on again.
“PLAYERROR”
• An unsupported MP3 file has been played. The system will
skip that track and play the next one.
“REMOTE 1”
“REMOTE 2”
• The remote control and the main unit are using different
codes. Change the code of the remote control.
– When “REMOTE 1” is shown, press and hold [OK] and [ ]
on the remote control for a minimum of 4 seconds.
– When “REMOTE 2” is shown, press and hold [OK] and [<]
for a minimum of 4 seconds.
“TEMP NG”
• The temperature protection circuit has been activated, and
the system will switch off. Let the unit cool down before
switching it on again.
• Check that the ventilation opening of the unit is not
obstructed.
• Ensure this unit is well ventilated.
“USB A NO DEVICE”
“USB B NO DEVICE”
• The USB device is not connected. Examine the connection.
“USB OVER CURRENT ERROR”
• The USB device is drawing too much power. Disconnect the
USB device, switch off the system and then switch on again.
• Check the connection, it may be caused by a faulty USB
cable.
“VBR”
• The system cannot show the remaining play time for variable
bit rate (VBR) tracks.
Remote control code
When other Panasonic equipment responds to the remote
control of this system, change the remote control code for
this system.
Preparation
Press [SELECT] repeatedly on the main unit to select
“AUX”.
█ To set the code to “REMOTE 2”
1Press and hold [SELECT] on the main unit and [<]
until “REMOTE 2” is shown.
2Press and hold [OK] and [<] for a minimum of
4 seconds.
█ To set the code to “REMOTE 1”
1Press and hold [SELECT] on the main unit and [ ]
on the remote control until “REMOTE 1” is shown.
2Press and hold [OK] and [ ] on the remote
control for a minimum of 4 seconds.
System memory reset
Reset the memory when the following situations occur:
• There is no response when buttons are pressed.
• You want to clear and reset the memory contents.
1Disconnect the AC mains lead.
2While you press and hold [1] on the main unit,
connect the AC mains lead again.
Continue to press and hold the button until
“–––––––––” is shown.
3Release [1].
All the settings are set back to the factory preset.
It is necessary to set the memory items again.
SC-AKX320 GS TQBJ2173 En.fm Page 14 Thursday, March 14, 2019 9:56 AM

15
TQBJ2173
15
D:\Publishing\Panasonic\SC-AKX520.320\SC-AKX320 GS TQBJ2173 En.fm
Specifications
█ General
Dimensions (W x H x D) 400 mm x 142 mm x 250 mm
Mass (SA-AKX320) 2.5 kg
Operating temperature range 0°C to +40°C
Operating humidity range
35% to 80% RH (no condensation)
█ Amplifier section
RMS output power stereo mode
Front Ch (both ch driven)
225 W per channel (4 Ω), 1 kHz, 30% THD
Total RMS stereo mode power 450 W
PMPO output power 4950 W
█ Tuner section
Frequency modulation (FM)
Preset memory 30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
Amplitude modulation (AM)
Preset memory 15 stations
Frequency range 522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
█ Disc section
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength 790 nm (CD)
█ Terminal section
USB port
USB standard USB 2.0 full speed
Media file format support MP3 (*.mp3)
USB device file system FAT12, FAT16, FAT32
AUX IN
Audio input Pin jack (1 system)
█ Bluetooth
®
section
Version Bluetooth® Ver. 4.2
Class Class 2
Supported profiles A2DP, AVRCP, SPP
Frequency band 2.4 GHz band FH-SS
Operating frequency 2402 MHz to 2480 MHz
Maximum power (EIRP) 10 dBm
Operation distance 10 m line of sight
Supported codec SBC
█ Speaker section
Speaker unit(s)
Woofer 16 cm cone type x 1
Tweeter 6 cm cone type x 1
Impedance 4 Ω
Dimensions (W x H x D) 199 mm x 333 mm x 210 mm
Mass 3.3 kg
Note:
• Specifications are subject to change without notice.
Mass and dimensions are approximate.
• Total harmonic distortion is measured by the digital spectrum
analyser.
Power supply AC 220 V to 240 V, 50/60 Hz
Power consumption 60 W
Power consumption in standby mode (approximate)
