Panasonic SC-CH11 User manual

Panasonic
CD Stereo System
SC-CH11
Operating Instructions
DIGITAL AUDIO
Notes:
•Specifications differ according to the area code.
•The "EB" area code, for example, indicates United Kingdom
specifications.
•The "EB" indication is shown on the packing case and serial
number tag.
Before connecting, operating, or adjusting this product, please read
these instructions completely and carefully.
ii ,RQT1537-1B
EB GN Printed in Singapore F0392P0

Thank you for purchasing this product.
For optimum performance and safety, please read
these instructions carefully.
Table of Contents
Suggestions for Safety 3
For United Kingdom 3
Concerning the Remote Control 4
Preparations 5
Front Panel Controls and Functions 8
Remote Control Unit Controls and
Functions 13
Setting the Time of Day 15
Basic Operating Procedure 16
Listening to Radio Broadcasts 17
Listening to Compact Discs 22
Listening to Tapes 31
Making aRecording 35
Edit-Recording from Compact Discs 38
Changing the Tone Quality 44
Using the Timer 46
Using an External Unit 53
Care &Use 54
Troubleshooting Guide 57
Technical Specifications 59
CAUTION!
THIS PRODUCT UTILIZES ALASER.
USE OF CONTROLS OR ADJUSTMENTS OR PER-
FORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOUR-
SELF. REFER SERVICING TO QUALIFIED PERSONNEL. (Back of product)
DANGER-lnvisibia
laser radiation whan
opaii.
AVOID DIRECT EX-
POSURE TO BEAM.
(Inside of product)
THIS MUSIC SYSTEM IS CAPABLE OF RE-
CEIVING THE NEW AM STEREO BROADCASTS
FROM THE AM BAND RADIO STATIONS.
HOWEVER LIKE MANY MUSIC SYSTEM CUR-
RENTLY AVAILABLE ON THE MARKET IT WILL
REPRODUCE THIS AM STEREO SIGNAL ONLY
IN AM MONO, WHICH, IN EFFECT, IS OF NO
LESSER QUALITY THAN YOUR EXISTING AM
MONO MUSIC SYSTEM.
2

Suggestions for Safety
Use astandard AC wall outlet
1. Use from an AC power source of high voltage, such as that
used for an air conditioner, is very dangerous.
Afire might be caused by such aconnection.
2. ADC power source cannot be used.
Be sure to check the power source carefully, especially on a
ship or other place where DC is used.
Grasp the plug when disconnecting the power
supply cord
1.Wet hands are dangerous.
Adangerous electric shock may result if the plug is touched by
wet hands.
2. Never place heavy items on top of the power supply cord,
nor force it to bend sharply.
Place the unit where it will be well ventilated
Place this unit at least 10 cm (4") away from wall surfaces, etc.
Avoid places such as the following:
In direct sunlight or in other places where the temperature is
high.
In places where there is excessive vibration or humidity.
Such conditions might damage the cabinet and/or other component
parts and thereby shorten the unit's service life.
Be sure to place the unit on aflat, level surface
If the surface is inclined, amalfunction may result.
Never attempt to repair nor reconstruct this
unit
Aserious electric shock might occur if this unit is repaired, dis-
assembled or reconstructed by unauthorized persons, or if the
internal parts are accidentally touched.
Take particular care if children are present
Never permit children to put anything, especially metal, inside this
unit. Aserious electric shock or malfunction could occur if articles
such as coins, needles, screwdrivers, etc. are inserted through the
ventilation holes, etc. of this unit.
If water is spilled on the unit
Be extremely careful if water is spilled on the unit, because afire or
serious electric shock might occur. Immediately disconnect the
power cord plug, and consult with your dealer.
Avoid spray-type insecticides
Insecticides might cause cracks or "cloudiness" in the cabinet and
plastic parts of this unit. The gas used in such sprays might,
moreover, be ignited suddenly.
Never use alcohol or paint thinner
These and similar chemicals should never be used, because they
might cause flaking or cloudiness of the cabinet finish.
Disconnect the power supply cord if the unit
will not be used for a long time
If the unit is left for along time with the power ON, this not only will
shorten its useful operation life, but also may cause other trouble.
If trouble occurs
If, during operation, the sound is interrupted or indicators no longer
illuminate, or if an abnormal odour or smoke is detected, imme-
diately disconnect the power cord plug, and contact with your
dealer or an Authorized Service Center.
For United Kingdom
("EB" area code model only)
The "EB" indication is shown on the serial number tag.
Important
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCOR-
DANCE WITH THE FOLLOWING CODE.
BLUE: NEUTRAL
BROWN: LIVE
As the colours of the wires in the mains lead of this apparatus may
not correspond with the coloured markings identifying the terminals
in your plug proceed as follows. The wire which is coloured BLUE
must be connected to the terminal which is marked with the letter N
or coloured BLACK.
The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter Lor coloured RED.
Under no circumstances must either of the above wires be con-
nected to the earth terminal of athree pin plug.

Concerning the Remote Control
Battery installation
1Open the cover
Press gently and slide the cover out.
2Insert the batteries included with this system.
•When you need to replace these batteries, use two UM-4
"AAA", IEC R03 (1 .5 V) or equivalent batteries.
•Be sure that you insert the batteries so that their positive (+)
and negative {-) polarities match the polarities indicated in
the compartment. Batteries installed incorrectly may leak
and cause damage.
•Refer to "Use of batteries" for additional information.
3Close the cover.
Use of batteries
•Do not mix old and new batteries or batteries of different types
(carbon and alkaline, etc.).
•The average battery life is about one year. Although the battery
life varies depending on how often the device is used, you should
generally replace the batteries about once ayear.
•Replace the batteries if commands from the remote control trans-
mitter do not operate the unit even when the transmitter is held
close to the front panel.
•Never subject batteries to excessive heat or flame; do not attempt
to disassemble them; and be sure they are not short-circuited.
•If you will not be using the remote control for along period of time,
remove the batteries and store them in acool, dark place.
•If abattery leaks, remove all batteries and dispose of them prop-
erly. Thoroughly clean the battery compartment before inserting
new batteries.
If the leaking electrolyte comes into contact with skin or clothes,
flush with water immediately.
•Keep batteries out of the reach of children.
•Do not use rechargeable-type (nickel-cadmium) batteries.
•Do not attempt to recharge alkaline or carbon batteries.
•Always remove old, weak, or worn-out batteries promptly and
dispose of them properly.
•Do not dispose of used batteries in household rubbish.
Operation notes
Aim the remote control transmission window toward the amplifier's
sensor. Avoid any obstacles.
6 meters
5
ii—\
Amplifier
dust Avoid dust
•Be sure the transmission window and the amplifier's sensor are
free from dust. Excessive dust might prevent reception.
•If direct sunlight or other strong light source strikes the remote
control signal sensor part of the amplifier, it may impair the remote
control's operation. If there is aproblem, place the amplifier away
from the light source.
•If this system is installed in arack with glass doors, the glass
doors' thickness or color might make it necessary to use the
remote-control transmitter ashorter distance from the system.
•Use the remote control within a60-degree angle of the amplifier.
The reachable distance is within 6meters directly facing toward
the amplifier.
4

Preparations
Supplied accessories
Check the packing carton for these accessories.
AC power supply cord 1pc.
Remote control transmitter
RAK-SC307WM 1pc.
LW/MW loop antenna 1pc.
FM indoor antenna 1pc.
1
Remote control batteries (UM-4, AAA, R03) 2pes.
Antenna holder 1pc.
Mounting screws 2pes.
Attachment plug 1pc.
(For United Kingdom only)
Note:
The configuration of AC power supply cord and FM indoor antenna
differ according to area.
5

Preparations
Connections
Connect the FM indoor antenna provided with
this system.
Tack or tape this antenna to awall. If you use a tack, be sure
it does not contact the internal antenna wire. Experiment with
the height and direction of the antenna until you achieve the
best reception.
For best reception and sound quality:
Use an FM outdoor antenna. If you use an FM outdoor an-
tenna, disconnect the indoor antenna.
Connecting the FM indoor antenna
FM indoor antenna (included)
Tack or
tape to wall
FM outdoor antenna (not included)
If the FM indoor antenna does not provide satisfactory reception of
FM broadcasts, use an outdoor antenna.
You may need an outdoor antenna if you use this system in a
mountainous region or inside areinforced-concrete building, etc.
An outdoor antenna should be installed by acompetent technician
only.
FM outdoor antenna (not included)
ANT—
v
^J
75-ohm coaxial
cable (not included)
For United Kingdom-
Use the attachment
plug (included).
For areas except for United Kingdom
©Remove apiece of the outer
vinyl sheath from the end.
©Bundle the shield braid, and
remove a piece of the inner
vinyl sheath covering the
core wire.
(3) Tilt the lever back and insert
the core wire and the shield
braid.
(3) Close the lever and pull the
cable gently to be sure that it
is secured.
30 mm
15mm
-FM ANT(750)
mm

Connect the LW/MW loop antenna provided
with this system.
You must connect this antenna to receive LW/MW broadcasts.
Connect the LW/MW loop antenna to the AM antenna termi-
nal. (The indication AM used here includes both MW and LW.)
You may attach the LW/MW antenna holder to the rear panel
of the system or to arack or other structure.
Clamp the antenna to the holder and position the loop for the
best reception. To minimize noise pickup, keep the loop an-
tenna away from the speaker cable, power cord, and metal
surfaces.
Rear panel
of the unit
\
LW/MW antenna holder
(included)
Screws (included)
LW/MW loop antenna
(included)
Connecting the LW/MW loop antenna:
LW/MW loop antenna
(included)
Connecting the LW/MW outdoor antenna (not included)
You may need an outdoor antenna if you use this system in a
mountainous region or inside areinforced-concrete building,
etc.
5-12 m
Connect the speaker cables [for right (R) and
left (L) channels].
Match the two wires from the left and right speaker cables with
the same colored levers of the speaker terminals, then insert
the wires into the respective terminals.
For areas except for United Kingdom
Be sure to connect the striped wire to the negative
Stripe f
terminals.
'e ©
.LOOP
ANT
AM ANT -
Run between 5and 12m
of vinyl-covered wire
horizontally along a
window or other
convenient location.
Connect an external unit, such as audio tape
deck (for playback only) or output terminals of
aVCR or TV (not included).
Connecting external units:
-AUX-
|L/AUDIO\
1RVDUT )
Stereo connection cable
(not included)
Video cassette recorder
(not included)
Notes:
•Connect speaker cables before connecting the AC power
supply.
•The load impedance of any speaker used with this unit must
be 6ohms.
Connection of speaker cables
1. Strip off the outer c
covering, and twist the
center conductor.
2. Tilt the lever back and
insert the wire.
3. Close the lever and pull
the wire gently to be sure
that it is secure.
Notes:
To prevent damage to
circuitry, never short-circuit
positive (+) terminals and
negative (-) speaker wires.
Be sure to connect only
positive (+) wires to positive
(+) terminals and negative
(-) wires to negative (-)
terminals.
15 mm Twist
X
5Connect the AC power supply cord after you
have connected all other cables and cords.
Note:
Configuration of the AC outlet and AC power supply cord
differ according to area.
For United Kingdom
/" eHousehold
AC outlet
Fit asuitable plug to the AC power
supply cord.

Front Panel Controls and Functions
The functions indicated by the numbers with black background (for
example Q) can also be activated from the remote control transmit-
ter. (See page 13.)
o®
Tuner
Tuner control
©Timer play button (PLAY TIMER)
Use for timer play (when you want play to begin automatically
at apreset time).
(2) Timer recording button (REC TIMER)
Use for timer recording (when you want to begin recording
automatically at apreset time).
0Cancel button (CANCEL)
Press to cancel the contents chosen with the jog dial.
@Set button (SET)
Press to set various functions.
©Display select button (DISPLAY)
Press to select the display (mode display, clock, tape counter,
etc.).
©Clock/timer button (CLOCK/TIMER)
Use to select the desired timer mode or to adjust the clock.
OSleep timer button (SLEEP)
Press when you want the system to turn itself off.
©Compact disc edit-recording mode select
button (CD EDIT)
Press to select the desired edit-recording mode.
©Tuning mode select button (TUNING)
Press to select the preset, manual or auto tuning mode.
®Band select button (BAND)
Press to select the LW, MWor FM radio band.
®FM mode/beat proof button (FM MODE/BP)
Press to select the FM listening mode (stereo or monaural)
during FM broadcasts or to reduce the unwanted beat signals
(whistle) during recording of aLW/MW broadcast.
©Jog dial (AIJOG)
Use to select the contents of the mode, i.e., select tracks in CD
player mode or stations in the tuner mode, as well as many
other functions.
8

Front Panel Controls and Functions
(continued)
Amplifier
Amplifier controls
©Power "STANDBY (!) /ON" switch and indica-
tor (POWER STANDBY (!)/ON)
This switch switches ON and OFF the secondary circuit power
only. The unit is in the "standby" condition when this switch is
set to the STANDBY (1) position. Regardless of the switch
setting, the primary circuit is always "live" as tong as the
power cord is connected to an electrical outlet.
•The indicator will illuminate when the unit is in "STANDBY"
condition.
@Equalizer controls
(GRAPHIC EQUALIZER LEVEL)
Use to adjust the equalization level.
These controls are for compensation of tonal quality. By sliding
the controls at each of the indicated frequencies in the "+"
direction, the tonal quality is increased, and by sliding them in
the "-" direction, the tonal quality is decreased.
(See page 44.)
©Super bass button (SUPER BASS)
Press to boost the dynamic low-frequency ranges.
©Volume level control (VOLUME)
Turn to adjust the volume level.
When turning the control, the alphanumeric display shows the
volume level.
Note that —dB is the lowest volume setting and 0dB is the
highest.
@Volume preset button (VOL PRESET)
Use to preset volume for timer play.
@Remote control signal sensor (SENSOR)
Receives the signals from the remote control.
@Input select buttons (TAPE, AUX, CD, TUNER)
Press to select the sound source.

©© © @© @
triMO DOUtLC »MirfIOfC«
.utcT ny\ yor-
Cassette deck
@Deck 1cassette holder
©Reverse-side playback button (<)
Press to start the playback or recording (deck 2) in the reverse
direction.
©Stop button ()
Press to stop the tape.
©Forward-side playback button (>)
Press to start the playback or recording (deck 2) in the forward
direction.
@Deck 2cassette holder
©Record/record standby button (REC PAUSE)
Press to put deck 2into the record standby mode.
®Tape counter reset button (COUNTER RESET)
Press to reset the tape counter indicator to 000.
®Deck 1cassette eject button {A EJECT)
Press to open the deck 1cassette holder.
©Deck 1/deck 2select button (DECK 1/2)
Press to select the deck to be operated.
©One-touch tape edit buttons
(ONE TOUCH TAPE EDIT)
Press to start the tape-to-tape recording.
©Fast-forward/rewind/tape program sensor
(TPS) buttons [« (TPS), (TPS) ]
Press to advance or rewind the tape, or to quickly search for
the beginning of atrack while the tape is being played.
@Dolby noise reduction button (DOLBY NR)
Use to reduce the hissing noise heard from the tape. This
system has the Dolby B-type noise reduction system.
©Reverse mode select button
(REVERSE MODE)
Press to select the reverse mode (for playback and recording).
®Deck 2cassette eject button (± EJECT)
Press to open the deck 2cassette holder.

Front Panel Controls and Functions
(continued)
•OPE* CLOSE
|ob| ol
Panasonic
Compact disc player
@Disc tray
©Stop button ()
Press to stop the disc play.
©Disc tray open/close button (± OPEN/CLOSE)
Press to open and close the disc tray.
©Play button (>)
Press to start disc play.
©Headphones jack (PHONES)
Plug headphones cord into this jack.
@Skip/search buttons (W^/^ •/«)
Press to move forward or backward through the tracks on a
disc, or to hear disc sound at high speed while searching in the
play mode.
<$ Pause button (II)
Press to stop the disc play temporarily.
12
mm

Remote Control Unit Controls and
Functions
v. _J
ICommon operation controls
The function description of buttons ©, ©and ©is as described
under "Amplifier controls" on page 10.
@CD input select button (CD)
Press to select the CD source.
©Tuner Input select button (TUNER/BAND)
Press to select the tuner source.
@Muting button (MUTING -20 dB)
Press to temporarily attenuate (mute) the volume level.
Tuner controls
The function description of buttons ©and Qis as described under
"Tuner control" on page 8.
@Preset-tuning buttons (1-10/0)
Press to select the preset channel of the tuner.

Remote Control Unit Controls and
Functions (continued)
Compact disc controls
The function description of buttons <J), ©, <$), <$> and ©is as
described under "Compact disc player" on page 12.
@Numeric buttons (1-10/0, +10)
Use to specify the compact disc's track.
©Program button (PROGRAM)
Press to activate the program play mode. You can then enter
specific tracks using the numeric buttons.
®Random button (RANDOM)
Press to play the disc's tracks in random order.
®Repeat button (REPEAT)
Press to activate the repeat mode.
@Cancel button (CANCEL)
Press to change the program. (See page 27.)
Cassette deck controls
Cassette deck section
The function description of buttons <J>, ©, <£>,
described under "Cassette deck" on page 11
.
$and ®is as
14

Setting the Time of Day
These instructions explain how to set the time of 18:20.
Switch on the power.
1Press CLOCK/TIMER.
2Select the CLOCK mode by turning the Jog
dial.
The display will change to P-TIMER, R-TIMER, SLEEP, and
CLOCK.
CLOCK
The display will return to what was previously indicated if you
allow 10 or more seconds to elapse before you accomplish the
next operation.
3Press SET.
\r tnru—rrn n
L. L. uLnu.ti u
\\
Flashing
5Press SET.
6Turn the jog dial to the correct minute.
Going from 59 to 00 on the minute display will not change the
hour display.
I\'71
rinroici Dn_
l. l. ui- niore u
7Press SET.
•The display will change to the previous display.
•Pressing SET resets the clock to "0" seconds.
Note:
"E" appears on the display if the power cord has been once discon-
nected or there has been apower failure. If this happens, reset the
time.
4Turn the jog dial to the correct hour.
Turn clockwise to increase numbers and counterclockwise to
decrease.
Flashing
15

Basic Operating Procedure
(Also available from the remote control. Follow the procedure
described below.)
1
Pan
itSS
AMI 4^
a.
Headphones
(not included)
J
P^IMOnlC cm-act wic pt*»m *ora>/CLOsa
||>|
ooo
MUTING
-20dB -
ooo o.o
ooooo
ao^II o
ODD
€3
1Press POWER STANDBY (!) /ON to switch on
the power.
2Select the sound source by pressing TAPE,
CD or TUNER.
The display of the selected mode will appear. If you press a
different sound source while listening to acompact disc or
tape, the disc or tape automatically stops playing.
•When selecting the tape mode from the remote control,
press <l> on TAPE instead.
The deck will automatically start playing.
3Start the sound source.
4Adjust the volume level.
The memory backup function will retain the volume level and
sound source.
Note:
Before you set the system to the standby mode, be sure to reduce
the volume level to prevent the extremely high output from the
amplifier from damaging the speakers.
How to mute the volume
Press the muting button on the remote control.
MUTING
-20dB
The muting indicator appears on the display.
•This lowers the volume level by 20 dB (approximately Vio).
•Cancel the muted state by pressing the muting button once again
or reduce the volume levet to the minimum position and then reset
to the desired volume.
How to use headphones (not included)
Reduce the volume level.
Connect the headphones to the headphones jack.
•When you connect the headphones, the speakers will automati-
cally cut off.
•Avoid listening tor prolonged periods of time to prevent hearing
damage.
•Plug type: Stereo mini
16

tListening to Radio Broadcasts
Manual tuner operation (to tune to broadcasts by using the jog dial)
23 4
1Press the TUNER input select button.
2Press TUNING to select the MANUAL tuning
mode.
•Every time you press this button, MANUAL, PRESET and
(AUTO) modes alternately appear.
•AUTO will appear only when the FM mode is selected.
3Press the band-select button to select FM, LW
or MW.
The display will show which band you selected.
Received band Received frequencies
FMqnqn
JUMHz
MAX-
IM .SS
VOLUME
4Turn the jog dial to tune in the desired broad-
cast.
The display will show the frequency to which you have tuned.
•If you have tuned in an FM stereo broadcast, the FM stereo
indicator will appear.
Warn,
17

Listening to Radio Broadcasts (continued)
Automatic tuner operation only for FM
Only for FM broadcasting station, you can automatically tune in the
FM station by simply turning the jog dial.
e
e
7T-
1Press the TUNER input select button.
2Press the band-select button to select FM.
3Press TUNING to select the AUTO tuning
mode.
Every time you press this button, MANUAL, PRESET and
AUTO modes alternately appear.
4Turn the Jog dial clockwise or counterclock-
wise and then release it.
The display frequency begins to change.
(y :Clockwise for the frequency upward.
^:Counterclockwise for the frequency downward.
The changing of the displayed frequency wilt be automatically
stopped if the broadcast station is located.
18

Memory presetting
When you preset broadcast frequencies to the memory, you can
then easily select any of those broadcast frequencies by pressing
one of the preset-tuning buttons on the remote control or by using
the jog dial.
You can input up to 30 radio stations (10 FM, 10 LW and 10 MW)
into the tuner's preset memory.
(When you memorize anew frequency on apreset channel, it
cancels the frequency previously memorized on that preset
channel.)
Switch on the power.
1Press the band-select button to select FM, LW
or MW.
2Press TUNING to select the MANUAL or AUTO
tuning mode.
•Every time you press this button, the MANUAL, PRESET
and (AUTO) modes alternately appear.
•AUTO will appear only when the FM mode is selected.
3Tune in your favorite station using the Jog
dial.
Turn the jog dial until the correct frequency and the quartz lock
indicator appear on the display.
4Press SET to activate the program indicator.
The program indicator will flash for about 10 seconds.
4-6
5Turn the jog dial to select the desired preset
channel while the program Indicator is
flashing.
r^v :The channel number will increase from 1to 10.
:The channel number will decrease from 10 to 1
.
M
I f
-PROGRAM -88 in
IUUNI
Channel number
Press SET.
The program indicator will disappear.
Repeat steps 3through 6to memorize asta-
tion in each of the remaining preset channels.

Listening to Radio Broadcasts (continued)
Memory tuner Operation (to listen to broadcast stations preset into memory)
Switch on the power and be sure you've completed the steps of
"Memory presetting" on page 19.
e
rr
FM MODE/BP
I>
From the main unit
1Press the band-select button to select FM, LW
orMW.
2Press TUNING to select PRESET.
3Turn the jog dial to select the desired preset
channel.
The selected preset channel will appear on the display.
Fc
M
11
pcm
OUMU LOCK
rin
.tUHHl
333
MAI*
VOLUME
Preset channel
if noise is excessive in the FM mode
Press FM MODE/BP to monaural position.
FM MODE/BP
You will be in the monaural position when the FM STEREO indica-
tor goes out.
The sound will then be heard in monaural. If the broadcast signal is
weak, or if there is alarge amount of interference, you will get a
clearer sound using the FM mode/beat proof button.
20
IttK

1BCO WWD CD«10
e-ED CD
OO
e7
OAooo
I•MM
nnn
OOCAVCE. RtP£»- K»«OM
ooo
CD CD CD OCD
T.Sf
•
BECHUSC DtCKM
aa
aaaa
From the remote control
1Press TUNER/BAND to select FM, LW or MW.
2Press the numeric button corresponding to
the preset channel you wish to tune in.
Most recent memory
The most recent memory system remembers the broadcast station
last tuned to when you switch the power to standby mode or select
other functions. When you switch the tuner back on, the last tuned
station will be on.
The presets will stay in the memory for approximately 2weeks,
even if there is an interruption.
IK'
21
