2013 AUdio
SC-MAX650
EXtrA lArgE AUdio SyStEM
ExtErnal SupEr WoofEr W/ full Digital Bi-amp
Mind blowing amplication with crystal clear sound quality.
4 Way floor StanDing SpEakErS W/ priSm-color illumination
Experience surround sound and unmatched style like never before.
uSB playBack & muSic port muSic inputS
Attach a USB or other device for easy playback.
2300 WattS total SyStEm poWEr
Awesome power to take your sound system to the next level.
1The USB playback only supports MP3 files stored in USB flash drives.
• 2300 Watts Total System Power
• Preset Equalizer
• D. Bass With Smart Control
• Maximized Bass Sound PLUS
• Nano-sized Bamboo Cone Tweeter
• High Force Magnet
• Multi-color Illumincation
(External Super Woofer/ Volume Knob)
• USB Playback*
• AUX & Music Port
• FM/AM Radio
• CD Playback

03/13 Specifications subject to change without notice.
2013 AUdio
SC-MAX650
EXtrA lArgE AUdio SyStEM
PLAYABLE DISCS
CD, CD-R/-RW CD-DA •
MP3 •
AUDIO SYSTEM
Output Channel 2ch
Power Output (RMS) Total Power 2300W
Hi: 330W x 2 (1kHz, 3ohms, 30% THD)
Mid-Low: 330W x 2 (100Hz, 3ohms, 30% THD)
Low: 490W x 2 (100Hz, 2ohms, 30% THD)
Power Output (FTC) Total Power 920W
Hi: 130W x 2 (400-20kHz, 3ohms, 1% THD)
Mid-Low: 170W x 2 (50-200Hz, 3ohms, 1% THD)
Low: 160W x 2(50-100Hz, 2ohms, 1% THD)
USB
Slot • (2)
USB Standard USB 2.0 Full Speed
Playback MP3 •
HIGH QUALITY SOUND
MAX DJ Effect •
Full Digital Amplifier • (Triple-Amp)
High-Force Magnet •
Nanosized Bamboo Cone • (Tweeter)
D.Bass with Smart Control •
Maximized Bass Sound PLUS •
Preset Equalizer •
Manual Equalizer • (Bass / Mid / Treble)
Surround •
EASY OPERATION
Rotary Music Selection while Playback •
Karaoke Function •
Display Fluorescent
Auto Power Off •
Programmable Timer PLAY / SLEEP
DESIGN
Prism Color Illumination •
Multi-Color Illumination —
SPEAKER SYSTEM
Front Conguration 4-way 4 speakers, Bass-reex
Speaker Unit Super Woofer: 15” (38cm) Cone Type
Super Woofer: 7-7/8” (20cm) Cone Type
Woofer: 4” (10cm) Cone Type
Tweeter: 2-3/8” (6cm) Cone Type
External Super Woofer Number of Super Woofer —
Conguration —
Speaker Unit —
TERMINAL
Analog Audio Input RCA • (AUX)
Music Port (3.5mm, 1/8”) •
MIC Jack (3.5mm, 1/8”) •
TUNER
Station Presets 30-FM/ 15-AM
Auto Tuning •
OTHERS
Power Supply AC 120V, 60Hz
Power Consumption Normal Use [Approx.] 195W
Standby [Approx.] 0.3W
DIMENSIONS, WEIGHT
Main Unit Dimensions (W x H x D) [Approx.] 19-1/8 x 9-1/8 x 14-7/8 inch (485 x 231 x 378 mm)
Weight [Approx.] 10.6 lbs (4.8 kg)
Front Speaker Dimensions (W x H x D) [Approx.] 22 x 31-3/8 x 20-5/8 inch (558 x 796 x 525 mm)
Weight [Approx.] 68.3 lbs (31 kg)
External Super Woofer Dimensions (W x H x D) [Approx.] —
Weight [Approx.] —
Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use.
