Operating Instructions
CD Stereo System
Model No. SC-PM41
RQT8043-2B
Note:
“EB” on the packaging indicates the United Kingdom.
Before connecting, operating or adjusting this product, please read
these instructions completely. Please keep this manual for future
reference.
Operations in these instructions are described mainly using
remote control, but you can do the operations on the main unit if
the controls are the same.
Unless otherwise indicated, illustrations in these operating
instructions are of the unit for the United Kingdom and Continental
Europe.
EEBGN
The above illustration of the unit is an example for the United Kingdom
and Continental Europe.
Table of contents
Safety precautions ........................... 2
Caution for AC Mains Lead.............. 3
Supplied accessories....................... 3
Placement of speakers .................... 3
Getting started.................................. 4
Step 1 - Making the connections
Step 2 - Inserting batteries into the remote control
Step 3 - DEMO function
Overview of controls........................ 6
Main unit
Remote control
CDs and MP3 – Play ......................... 7
Playing a disc
Advanced CDs and MP3 functions
Cassette tape – Play and record ..... 12
Basic play
TPS (Tape Program Sensor)
Before recording
Recording the radio
Recording CDs
Other basic operations
Radio – Tune ..................................... 14
Manual tuning
Memory preset
AM allocation setting
Timer.................................................. 15
Setting the clock
Using the sleep timer
Using the play or record timer
Sound adjustment ............................ 17
Selecting sound effects
Enhancing the bass
Enjoying surround sound
External unit...................................... 17
Connecting external unit
Playing or recording from an external unit
Troubleshooting guide..................... 18
Specifications ................................... 20
Maintenance
When moving the unit
PM41_8043-2B.indd 1PM41_8043-2B.indd 1 3/11/05 5:23:36 PM3/11/05 5:23:36 PM

2
RQT8043
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these
instructions carefully.
These operating instructions are applicable to the following
system.
System SC-PM41
Main unit SA-PM41
Speakers SB-PM41
Side of product
Inside of product
Tuotteen sisällä
Produktets innside
THIS UNIT IS INTENDED FOR USE IN MODERATE
CLIMATES.
TÄMÄ LAITE ON TARKOITETTU KÄYTETTÄVÄKSI
LEUDOSSA ILMASTOSSA.
DETTE APPARATET ER BEREGNET TIL BRUK UNDER
MODERATE KLIMAFORHOLD.
This product may receive radio interference caused by
mobile telephones during use. If such interference is
apparent, please increase separation between the product
and the mobile telephone.
The socket outlet shall be installed near the equipment and
easily accessible or the mains plug or an appliance coupler
shall remain readily operable.
Laite tulee asettaa lähelle verkkopistorasiaa ja pistokkeen
täytyy olla sellaisessa asennossa, että siihen on helppo
tarttua ongelman sattuessa.
Utstyret bør plasseres i nærheten av AC-stikkontakten,
og støpslet må være lett tilgjengelig hvis det skulle oppstå
problemer.
Safety precautions
Placement
Set the unit up on an even surface away from direct
sunlight, high temperatures, high humidity, and excessive
vibration. These conditions can damage the cabinet and
other components, thereby shortening the unit’s service life.
Place it at least 15 cm away from wall surfaces to avoid
distortion and unwanted acoustical effects.
Do not place heavy items on the unit.
Voltage
Do not use high voltage power sources. This can overload
the unit and cause a fire.
Do not use a DC power source. Check the source carefully
when setting the unit up on a ship or other place where DC
is used.
AC mains lead protection
Ensure the AC mains lead is connected correctly and not
damaged. Poor connection and lead damage can cause fire
or electric shock. Do not pull, bend, or place heavy items on
the lead.
Grasp the plug firmly when unplugging the lead. Pulling the
AC mains lead can cause electric shock.
Do not handle the plug with wet hands. This can cause
electric shock.
Foreign matter
Do not let metal objects fall inside the unit. This can cause
electric shock or malfunction.
Do not let liquids get into the unit. This can cause electric
shock or malfunction. If this occurs, immediately disconnect
the unit from the power supply and contact your dealer.
Do not spray insecticides onto or into the unit. They contain
flammable gases which can ignite if sprayed into the unit.
Service
Do not attempt to repair this unit by yourself. If sound is
interrupted, indicators fail to light, smoke appears, or any
other problem that is not covered in these instructions occurs,
disconnect the AC mains lead and contact your dealer or
an authorized service center. Electric shock or damage to
the unit can occur if the unit is repaired, disassembled or
reconstructed by unqualified persons.
Extend operating life by disconnecting the unit from the
power source if it is not to be used for a long time.
■Sales and Support Information
(For the United Kingdom and Republic of Ireland)
Customer Care Centre
• For UK customers: 08705 357357
• For Republic of Ireland customers: 01 289 8333
• Visit our website for product information
• E-mail: [e-mail]
Direct Sales at Panasonic UK
• Order accessory and consumable items for your product with ease
and confidence by phoning our Customer Care Centre Monday-
Friday 9:00am-5:30pm. (Excluding public holidays)
• Or go on line through our Internet Accessory ordering application
at www.panasonic.co.uk
• Most major credit and debit cards accepted.
• All enquiries transactions and distribution facilities are provided
directly by Panasonic UK Ltd.
• It couldn’t be simpler!
• Also available through our Internet is direct shopping for a wide
range of finished products, take a browse on our website for further
details.
PM41_8043-1B.indd 2PM41_8043-1B.indd 2 2/21/05 9:18:12 AM2/21/05 9:18:12 AM

3
RQT8043
Caution for AC Mains Lead
(For United Kingdom)
(“EB” area code model only)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin mains plug for your
safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the replacement
fuse has a rating of 5-ampere and that it is approved by ASTA or BSI to
BS1362.
Check for the ASTA mark mor the BSI mark oon the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it is
refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a replacement
cover is obtained.
A replacement fuse cover can be purchased from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET
OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED
AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT
OFF PLUG IS INSERTED INTO ANY 13-AMPERE SOCKET.
If a new plug is to be fitted please observe the wiring code as stated
below.
If in any doubt please consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following
code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured Blue must be connected to the terminal which
is marked with the letter N or coloured Black or Blue.
The wire which is coloured Brown must be connected to the terminal which
is marked with the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER WIRE TO THE EARTH
TERMINAL WHICH IS MARKED WITH THE LETTER E, BY THE EARTH
SYMBOL nOR COLOURED GREEN OR GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF—KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of AC mains plug
(figures A and B). Confirm the AC mains plug fitted and follow the
instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
Fuse cover
Figure A Figure B
2. Replace the fuse and close or attach the fuse cover.
Fuse
(5 ampere)
Fuse
(5 ampere)
Figure A Figure B
Supplied accessories
Please check and identify the supplied accessories.
Use numbers indicated in parentheses when asking for
replacement parts. (As of January 2005)
1 x Remote Control
(For Australia and N.Z.:
N2QAJB000133
For others:
N2QAJB000137)
1 x AC mains lead
(For U.K.: RJA0053-3X)
1 x FM indoor antenna
(RSA0007-L)
(For Australia and N.Z.:
K2CJ2DA00010)
1 x Antenna plug adaptor
(For U.K.: K1YZ02000013) (For others:
K2CQ2CA00002)
2 x Remote control
batteries 1 x AM loop antenna
(N1DAAAA00001)
Placement of speakers
Tweeter
Place the speakers so that the tweeter is on the inside.
• These speakers do not have magnetic shielding. Do not
place them near televisions, personal computers or other
devices easily influenced by magnetism.
• To avoid damage to the speakers, do not touch the speaker
cones if you have taken the nets off.
Note
• Keep your speakers at least 10mm away from the system
for proper ventilation.
Use only the supplied speakers.
• The combination of the main unit and speakers provide
the best sound. Using other speakers can damage the unit
and sound quality will be negatively affected.
Caution
• Use the speakers only with the recommended
system. Failure to do so can damage the amplifier
and speakers, and can cause fire. Consult a
qualified service person if damage occurs or if a
sudden change in performance is apparent.
• Do not attach these speakers to walls or ceilings.
PM41_8043-1B.indd 3PM41_8043-1B.indd 3 2/21/05 9:18:14 AM2/21/05 9:18:14 AM

4
RQT8043

2 ,
()'(
 
,/7
 



Red
Black
White
Blue
Grey (+)
Blue (–)
Black (–)
Red (+)
To household
mains socket
2 Connect the FM indoor antenna.
Adhesive
tape
FM indoor
antenna
Tape the antenna to a wall or column, in a position with
least amount of interference.
FM ANT
75
Getting started
3 Connect the speaker cords.
Step
Step
1
1
- Making the connections
- Making the connections
Connect the AC power supply cord only after all other connections have been made.
Preparation
Twist and pull off the vinyl tip of the speaker cords.
OR
If the speaker cords do not have vinyl tips, directly connect them to the terminals.
AM ANT
EXT LOOP
AM loop antenna
1 Connect the AM loop antenna.
Stand the antenna up on its base. Keep loose antenna
cord away from other wires and cords.
Cords with white and blue tags are for high frequency.
Cords with red and black tags are for low frequency.
Incorrect connection can damage the unit.
4 Connect the AC mains lead.
FOR THE UNITED KINGDOM ONLY
READ THE CAUTION FOR THE AC MAINS LEAD
ON PAGE 3 BEFORE CONNECTION.
• The included AC mains lead is for use with this unit only.
Do not use it with other equipment.
Insertion of connector
Connector
Approx. 3.5 mm
Even when the connector is perfectly inserted, depending
on the type of inlet used, the front part of the connector
may jut out as shown in the drawing. However there is no
problem using the unit.
Appliance inlet
PM41_8043-2B.indd 4PM41_8043-2B.indd 4 3/11/05 5:23:43 PM3/11/05 5:23:43 PM

5
RQT8043
Optional antenna connections
Optional antenna connections
FM outdoor antenna AM outdoor antenna
AM ANT FM ANT
EXT LOOP 75
/NLYFORTHE5+
5SETHEANTENNA
PLUGADAPTOR
INCLUDED
FM outdoor antenna
(not included)
75 coaxial
cable
(not included)
AM ANT FM ANT
EXT LOOP 75
M
AM outdoor antenna
(not included)
AM loop antenna
(included)
• Never use an outdoor antenna during a lightning storm.
• You can connect the FM outdoor antenna for better reception. Please consult your dealer for installation.
• Disconnect the FM indoor antenna if an FM outdoor antenna is installed.
• Connect the AM outdoor antenna without removing the AM loop antenna. Run 5 to 12 m of vinyl-covered wire horizontally
along a window or other convenient location.
Step 2
Step 2
- Inserting batteries into the remote control
- Inserting batteries into the remote control




!!2,2
■Batteries
• Insert so the poles (+ and –) match those in the remote control.
• Remove if the remote control is not going to be used for a long period of
time. Store in a cool, dark place.
• Do not use rechargeable type batteries.
• Mishandling of batteries can cause electrolyte leakage which can damage
items the fluid contacts and may cause a fire.
Do not:
• mix old and new batteries.
• use different types at the same time.
• heat or expose to flame.
• take apart or short circuit.
• attempt to recharge alkaline or manganese batteries.
• use batteries if the covering has been peeled off.
■Use
• Aim at the remote control sensor, avoiding obstacles, at a maximum range
of 7 m directly in front of the unit.
Refer to page 6 for the remote control sensor position.
S
S
tep
tep
3
3
-
-
DEMO function
DEMO function
When the unit is first plugged in, a demonstration of its functions may be shown
on the display.
If the demo setting is off, you can show a demonstration by selecting “DEMO
ON”.
Press and hold [STOP 7, –DEMO].
The display change each time the button is held down.
DEMO OFF DEMO ON
While in standby mode, select “DEMO OFF” to reduce power consumption.
PM41_8043-1B.indd 5PM41_8043-1B.indd 5 3/1/05 4:53:58 PM3/1/05 4:53:58 PM

6
RQT8043
Overview of controls
Main unit
Main unit
Refer numbers in parentheses for page reference.
Top of the unit
Remote control sensor
Headphone jack (PHONES)
Avoid listening for prolonged
periods of time to prevent
hearing damage.
Plug type: 3.5 mm stereo (not
included)
Cassette open (12)
Display panel
Album/menu selection, treble/bass
adjustment (7, 9, 10, 17)
9Return (10)
"Volume control (7)
CD tray open/close (7)
CD selection (7)
7H.Bass (17)
AC supply indicator (AC IN)
This indicator lights when the
unit is connected to the AC
mains supply.
2Bass and treble (17)
Recording start/pause (12, 13, 17)
3Aux (17)
4Tuner/Band selection (14)
Checking CD position (8)
5Tape play (12, 13)
CD trays (7)
!CD skip/search, tape fast-forward/
rewind, tune/preset channel selection,
time adjustment (7, 8, 9, 10, 11, 12, 14,
15, 16)
CD change (7)
#CD play/pause (7, 8, 9, 10, 11, 13)
Cassette lid (12)
Stop/Demo (5, 10, 13)
6Play list (10)
8Enter (8, 9, 10, 11)
1Standby/on switch (y/l) (7, 16)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
Remote control
Remote control
Buttons such as 1function the same as the controls on the main unit.
Clock/timer (15, 16)
Play timer/record timer (16)
Display (8, 14)
Dimmer
Numeric, characters
(7, 8, 9, 10, 11, 14)
Delete (8, 9, 11)
!
#
Clear, stop (7, 8, 9, 10, 11, 12, 13)
Title search (11)
Marker (10)
Muting
Surround (17)
1
Sleep timer/Auto off
(15)
Title in (8)
Disc (7, 9)
Program (9, 14)
Play mode
(7, 12, 13, 14)
Repeat (10)
Album selection
(7, 9, 10)
5
4
"Treble/bass adjustment, play
list selection (10, 17)
7
Intro (10)
2
Preset EQ (17)
3
This auto off function allows
you to turn off the unit in CD
or tape mode only after left
unused for 10 minutes.
• Press and hold [SLEEP,
–AUTO OFF] to activate the
function.
• Press and hold [SLEEP,
–AUTO OFF] again to
cancel.
• The setting is maintained
even if the unit is turned off.
To dim the display panel.
To mute the sound.
• Press the button to activate.
• Press again to cancel.
69
8
PM41_8043-1B.indd 6PM41_8043-1B.indd 6 2/21/05 9:18:26 AM2/21/05 9:18:26 AM

7
RQT8043
Numeric
buttons
CD trays
Playing a disc
Playing a disc
1Press [y] to turn the unit on.
2Press [CD 1 ~ CD 5] to select your desired tray.
3Press [0OPEN/CLOSE] to open the disc tray and
then load the disc. Press [0OPEN/CLOSE] again to
close the tray.
Label must face upward
Disc tray Tray
number
4Press [CD 6] to start play.
5Adjust the volume.
Other basic operations
Other basic operations
To Action
stop the disc Press [CLEAR 7].
pause play Press [CD 6]. Press again to
resume play.
skip tracks Press [4/REW/4] or [3/FF/¢].
search through tracks
(CD-DA only) Press and hold [4/REW/4] or [3/FF/¢] during play or pause.
direct play If the unit is on standby mode and a
CD is loaded, press [CD 6] or
[CD 1 ~ CD 5] to start play.
skip album
(MP3 only) Press [ALBUM or ] in the play
mode.
Press [ALBUM or ] once and
then the numeric buttons in the stop
mode.
Changing disc (CD CHANGE)
Changing disc (CD CHANGE)
While one CD is playing, you can change the CDs in other
trays (except in All-Disc random play and program play).
1Press [0CD CHANGE].
2Press [CD 1 ~ CD 5] to select the tray.
3Change the CD.
4Press [0CD CHANGE] again to close the tray.
Play Mode function
Play Mode function
1Press [CD 6] and then [CLEAR 7].
2Press [DISC] and (within 10 seconds) press [1] ~ [5]
to select the disc.
3Press [PLAY MODE] repeatedly to select the desired
mode.
Mode To play
1 DISC
1DISC
one selected disc.
ALL DISC
ALL DISC
all discs in trays, e.g., 4→5→1→2→3.
1 TRACK
1TR
one selected track on the selected
disc.
Press the numeric buttons to select
the track.
1-RANDOM
1DISC RND
(CD-DA only)
one selected disc randomly.
A-RANDOM
ALL DISC RND
(CD-DA only)
all loaded discs randomly.
1 ALBUM
1ALBUM
(MP3 only)
one selected album on the selected
disc.
Press [ALBUM or ] to select
the album.
1 DISC RANDOM
1DISC RND
(MP3 only)
one selected disc randomly.
1 ALBUM RANDOM
1ALBUM RND
(MP3 only)
all tracks in one selected album
randomly.
Press [ALBUM or ] to select
the album.
• During any random play, you cannot skip to tracks which have been
played.
• During 1-RANDOM or A-RANDOM play, you can search forward or
backward only within the current track.
CDs and MP3 – Play
(Continued on next page)
PM41_8043-1B.indd 7PM41_8043-1B.indd 7 2/21/05 9:18:29 AM2/21/05 9:18:29 AM

8
RQT8043
C
C
hecking which CDs are in the trays
hecking which CDs are in the trays
(CD CHECK)
(CD CHECK) CD-DA MP3
1Press [CD CHECK].
2Press the button again to close the trays.
• The tray with a CD being played will not open.
• If the player is stopped, all trays will open.
• Do not remove or insert CDs during a CD check.
• Do not pull out the trays during a CD check.
• 8 cm CDs cannot be checked.
CD display
CD display
This function allows you to display the information
on the current track.
Press [DISPLAY] repeatedly during play or pause mode.
CD-DA
Elapsed play time Remaining play time
MP3
Elapsed time Remaining play time
ID3 (Artist) ID3 (Track) ID3 (Album)
• Maximum number of displayable characters: approximate 30
• This unit supports ver. 1.0 & 1.1 ID3 tags. Text data that is not
supported will not be displayed.
• ID3 is a tag embedded in MP3 track to provide information about
the track.
• When track number 25 or greater is playing, remaining play time
display shows “– –:– –” (CD-DA only).
Advanced CDs and MP3 functions
Advanced CDs and MP3 functions
Creating your CD titles
Creating your CD titles CD-DA
This function allows you to key in disc, artist and
track titles.
• If you wish to enter the titles for commercial CDs.
• The unit can record the titles for 100 CDs, until the 25th
track per CD.
1Press [CD 6] and then [CLEAR 7].
2Press [TITLE IN].
3Press [4/REW/4] or [3/FF/¢] to select the title
type, then press [ENTER].
DISC TITLE Disc title
ART NAME Artist name
TR TITLE Track title
4Enter titles (refer “Entering characters” on page 9).
5Press [ENTER].
• “TITLE WRT” is displayed after completing every title’s
entry.
• Repeat steps 3 to 5 to enter another title.
6Press [TITLE IN].
Other basic operations
Other basic operations
To Action
change a title Repeat steps 1-6.
check titles Press [DISPLAY] while stopped.
Disc title ↔Artist name
Track titles appear during play or when you
skip tracks while stopped.
delete titles 1) Press [DEL] in the stop mode.
“TITLE ERASE?” appears.
2) Press [ENTER].
Press [5] or [∞] to select the desired
CD title, then press [ENTER] twice.
All titles entered in the selected disc are
deleted. Repeat this step to delete titles
on the other CDs.
To cancel, press [CLEAR 7].
CDs and MP3 – Play (Continued)
PM41_8043-1B.indd 8PM41_8043-1B.indd 8 2/21/05 9:18:32 AM2/21/05 9:18:32 AM

9
RQT8043
Entering characters
Entering characters
Press the numeric buttons repeatedly to select your
desired character then press [3/FF/¢] to key in the
next character.
• You can enter up to 32 characters.
• To edit, press [4/REW/4] or [3/FF/¢] to revised any
characters.
• To delete, move the cursor over the character and then
press [DEL].
Numbered
buttons Characters Numbered buttons Characters
1 1 6 M N O 6
2 A B C 2 7 P Q R S 7
3 D E F 3 8 T U V 8
4 G H I 4 9 W X Y Z 9
5 J K L 5 0 0
h 10 space ! “ # $ % & ’ ( ) ∗+ , – . / : ; = ? _
8
Program play
Program play
This function allows you to program up to 24
tracks.
CD-DA
1Press [CD 6] and then [CLEAR 7].
2Press [PROGRAM].
3Press [DISC].
4(Within 10 seconds or so)
Press [1]~[5] to select your desired disc.
5
Press the numeric buttons to select your desired
track.
Example: Program number
Track number

Program play
indicator
6
Repeat steps 3 to 5 to program other tracks.
7Press [CD 6] to start play.
MP3
1Press [CD 6] and then [CLEAR 7].
2Press [DISC].
3(Within 10 seconds or so)
Press [1]~[5] to select your desired disc.
4Press [CLEAR 7].
5Press [PROGRAM].
6Press [ALBUM or ] to select your desired
album.
7Press [3/FF/¢] once and then the numeric buttons
to select your desired track.
8Press [ENTER].
Repeat steps 6 to 8 to program other tracks.
Example:

Album number Track number
9Press [CD 6] to start play.
To Action
cancel program
mode
Press [PROGRAM] in the stop mode.
replay the program Press [PROGRAM] then [CD 6].
check program
contents
Press [4/REW/4] or [3/FF/¢] when
“PROGRAM” is displayed in the stop mode.
To check while programming, press
[PROGRAM] twice after “PROGRAM”
appears, then press [4/REW/4] or
[3/FF/¢].
add to the program Repeat steps 3 to 5 in the stop mode for
CD-DA.
Repeat steps 6 to 8 in the stop mode for
MP3.
clear the last track Press [DEL] in the stop mode.
clear all
programmed
tracks
Press [CLEAR 7] in the stop mode. “CLEAR
ALL” is displayed. Within 5 seconds, press
the button again to clear all tracks.
• When “CD FULL” appears, you cannot program additional tracks.
• During program play for CD-DA, you can search forward or
backward only within the current track.
• During program play, skipping is always in the programmed order,
whether forward or backward.
• You cannot program CD-DA together with MP3 tracks.
• The program memory is cleared when you change a disc or open a
CD tray (MP3 only).
•
You cannot change or open other trays during program play mode.
(Continued on next page)
PM41_8043-1B.indd 9PM41_8043-1B.indd 9 2/21/05 9:18:35 AM2/21/05 9:18:35 AM

10
RQT8043
Finding your CD titles
Finding your CD titles CD-DA MP3
This function allows you to display disc, album and
track titles, then select to start play.
1Press [CD 6] and then [CLEAR 7].
2Press [PLAY LIST].
The CD selection screen appears.
3Press [5] or [∞] to select the disc title, then press
[ENTER].
4MP3
Press [5] or [∞] to select the album, then press
[ENTER].
Total tracks
CD-DA MP3
Press [5] or [∞] to select the track, then press
[ENTER].
OR
To select play list using the main unit:
1Press [CD 6] and then [STOP 7, –DEMO].
2Press [PLAY LIST].
The CD selection screen appears.
3Press [+] or [–] to select the disc title, then press
[ENTER].
4MP3
Press [+] or [–] to select the album, then press
[ENTER].
CD-DA MP3
Press [+] or [–] to select the track, then press
[ENTER].
To return to the previous display, press [RETURN].
• This function does not work during any random mode.
Repeat play
Repeat play CD-DA MP3
You can repeat program play or other selected
play mode.
Press [REPEAT] before or during play.
“REPEAT ON” and “ ” are displayed.
To cancel
Press [REPEAT] again.
“REPEAT OFF” is displayed and “ ” is cleared.
Direct access play
Direct access play
This function allows you to start play from a specific track.
CD-DA
Press the numeric buttons to select and play your
desired track.
MP3
1Press [ALBUM or ] to select the album.
2Press [3/FF/¢] once and then the numeric buttons
to select and play your desired track.
For two-digit track, press [
h 10] once then the two digits.
For three-digit track, press [ h 10] twice then the three digits.
• This function does not work during any random/program mode.
Marking a track
Marking a track CD-DA MP3
Enable you to mark one track for each loaded disc
so that you can directly play the track later.
During play, press and hold the [MARKER] until
“STORING” blinks on the display to mark your favourite
track.
Press [MARKER] during play or stop mode to recall and
play a marked track.
• The marker memory is clear when you open the CD tray.
• This function does not work during any random/program mode.
INTRO function (Album scan)
INTRO function (Album scan) MP3
This function allows you to find an album by listening
to the first track of all albums in the current disc for
10 second each.
1Press [CD 6] and then [CLEAR 7].
2Press [INTRO] to start the intro function.
3While your desired album is playing, press [CD 6].
Intro mode cancelled and the playback continues.
INTRO function is cancelled after playing the first track in
the last album.
To stop during the process, press [INTRO] or [CLEAR 7].
• This function does not work during any random/program mode.
CDs and MP3 – Play (Continued)
PM41_8043-1B.indd 10PM41_8043-1B.indd 10 2/21/05 9:18:37 AM2/21/05 9:18:37 AM

11
RQT8043
NOTE on CDs
• This unit can access up to 99 tracks.
• Choose CD with this mark.
• This unit can play MP3 files and CD-DA format audio CD-R/RW
that have been finalized.
• It may not be able to play some CD-R/RW due to the condition of
the recording.
• Do not use irregular shaped disc.
• Do not use disc with labels and stickers that are coming off or with
adhesive exuding from under labels and stickers.
• Do not attach extra labels or stickers on the disc.
• Do not write anything on the CD.
Not doing the following will cause damage to the unit.
• “GOOD BYE” is displayed when the unit turns off. Remove the
power plug after this display disappears.
• Always press [0OPEN/CLOSE] to insert or remove a disc.
• Do not push or pull out the tray by hand as this will cause an
accident.
• Place the disc correctly label-up as shown in the diagram.
• Insert one disc into the tray.
NOTE on MP3
• When “NOT MP3/ERROR1” appears on the display, an unsupported
MP3 format is being played. The unit will skip that track and play the
next one.
• Files are treated as tracks and folders are treated as albums.
• This unit can access up to 999 tracks, 255 albums and 20
sessions.
• Disc must conform to ISO9660 level 1 or 2 (except for extended
formats).
• To play in a certain order, prefix the folder and file names with 3-
digits numbers in the order you want to play them.
MPEG Layer-3 audio decoding technology licensed from
Fraunhofer IIS and Thomson multimedia.
Album/Track title search
Album/Track title search MP3
Enable you to search your desired album or track.
1Press [CD 6] and then [CLEAR 7].
2For album title search, press [TITLE SEARCH] once.
For track title search, press [TITLE SEARCH] twice.
3Press the numeric buttons repeatedly to select your
desired character then press [3/FF/¢] to key in the
next character.
• You can enter up to 10 characters.
• To edit, press [4/REW/4] or [3/FF/¢] to revise any
characters.
• To delete, move the cursor over the character and then
press [DEL].
Numbered
buttons Characters Numbered buttons Characters
1 1 6 M N O 6
2 A B C 2 7 P Q R S 7
3 D E F 3 8 T U V 8
4 G H I 4 9 W X Y Z 9
5 J K L 5 0 0
h 10 space ! “ # $ % & ’ ( ) ∗+ , – . / : ; = ? _ 8
4Press [ENTER].
Press [4/REW/4] or [3/FF/¢] to search for
previous or next match.
5Press [CD 6] to start play from the album/track
found.
• “NOT FOUND” is displayed when there is no match.
• This function does not work during any random/program mode.
PM41_8043-1B.indd 11PM41_8043-1B.indd 11 2/21/05 9:18:40 AM2/21/05 9:18:40 AM

12
RQT8043
Cassette tape – Play and record
TPS (Tape Program Sensor)
TPS (Tape Program Sensor)
This function enables you to search the beginning of a track,
up to a maximum of 9.
Press [4/REW/4] or [3/FF/¢] during play.
Play resumes from the track found.
TPS may not function properly with:
• Short silent parts
• Noise occurs between tunes
• Silent parts found within tunes
Before recording
Before recording
Preparation
Wind up the leader tape so that recording can begin
immediately.
• Use normal position tape.
• High position and metal position tape can be used, but this unit will
not be able to record or erase them correctly.
Preparatory steps
Preparatory steps
For the United Kingdom and Continental Europe.
1Insert the cassette to be recorded on.
"
"
Insert inside the
guides
Forward side
The tape direction is automatically set to “3”.
To record on the reverse side
Press [TAPE `] twice, then press [CLEAR 7].
2Press [PLAY MODE] to select the reverse mode.
Each time you press the button:
==
One side only records.
Both sides are recorded (forward = reverse).
“ ” automatically changes to “ ” when you press
[¶REC/8].
For Australia and N.Z..
Insert the cassette to be recorded on.
To record on the reverse side
Turn the cassette over.
Basic play
Basic play
1Press [OPEN 0] on top of the unit.
2Insert a cassette.
"
"
Insert inside the
guides
Forward side
3Close the lid by hand.
For the United Kingdom and Continental Europe,
continue with steps 4 to 5.
For Australia and N.Z., proceed to step 6.
4Press [PLAY MODE] to select the reverse mode.
Each time you press the button:
==
One side plays.
Both sides play (forward =reverse).
Both sides are played repeatedly until you press
[CLEAR 7].
5Press [TAPE `]to start play.
Each time you press the button:
3: The forward side (front) plays.
2: The reverse side plays.
6Press [TAPE 3]to start play.
To play on other side of the cassette, turn the cassette
over.
To Action
stop tape playback Press [CLEAR 7].
start one touch play Press [TAPE `] when the system is OFF
with the cassette loaded.
fast-forward and
rewind
Press [4/REW/4] or [3/FF/¢] in the
stop mode.
Top of the unit
Cassette lid
PM41_8043-1B.indd 12PM41_8043-1B.indd 12 2/21/05 9:18:42 AM2/21/05 9:18:42 AM

13
RQT8043
Recording the radio
Recording the radio
1Do the preparatory steps (refer page 12).
2Tune to the required station (refer page 14).
3Press [¶REC/8] to start recording.
Recording CDs
Recording CDs
1Do the preparatory steps (refer page 12).
2Press [CD 6] and then [STOP 7, –DEMO].
3Press [0OPEN/CLOSE] to insert the CD.
Press again to close.
4Press [PLAY MODE] to select your desired mode
(refer page 7).
5Press [¶REC/8] to start recording.
Recording programmed tracks
Recording programmed tracks
1Program the tracks you want (refer page 9).
2Press [¶REC/8] to start recording.
Other basic operations
Other basic operations
To Action
erase a recorded
sound
1) Insert the cassette to be recorded on.
2) Press [TAPE `] and then [CLEAR 7].
3) Press [¶REC/8].
stop recording Press [CLEAR 7].
stop recording
temporarily
1) Press [¶REC/8].
2) Press again to resume recording.
Your attention is drawn to the fact that recording pre-
recorded tapes or discs or other published or broadcast
material may infringe copyright laws.
Erasure prevention
Erasure prevention
The illustration shows how to remove the tabs to prevent
recording. To record on the tape again, cover as shown.
Side A
Tab for side ATab for side B
To re-record
Normal tape
Adhesive tape
PM41_8043-1B.indd 13PM41_8043-1B.indd 13 2/21/05 9:18:46 AM2/21/05 9:18:46 AM

14
RQT8043
Numeric
buttons
Radio – Tune
Memory preset
Memory preset
Up to 15 stations each can be set in the FM and AM bands.
Preparation
Press [TUNER/BAND] to select “FM” or “AM”.
Automatic presetting
Automatic presetting
Press and hold [PROGRAM] to start presetting.
Manual presetting
Manual presetting
1Press [PLAY MODE] to select “MANUAL”.
2Press [4/REW/4] or [3/FF/¢] to tune to the
required station.
3Press [PROGRAM].
4Press numeric buttons to select a channel.
• The station occupying a channel is erased if another
station is preset in that channel.
Selecting a preset station
Selecting a preset station
Press numeric buttons to select the channel.
• For channels 10 to 15 press [ h 10], then the two digits.
OR
1Press [PLAY MODE] to select “PRESET”.
2Press [4/REW/4] or [3/FF/¢] to select the
channel.
AM allocation setting
AM allocation setting
By main unit only
• This system can also receive AM broadcasts allocated in
10 kHz steps.
To change the step from 9 kHz to 10 kHz
1Press and hold [TUNER/BAND].
• After a few seconds the display changes to a flashing
display of the current minimum frequency.
2Continue to hold down [TUNER/BAND].
• When the minimum frequency changes, release the
button. To return to the original step, repeat the above
steps.
• After changing the setting, previously preset frequency
will be cleared.
Manual tuning
Manual tuning
1Press [TUNER/BAND] to select “FM” or “AM”.
2Press [PLAY MODE] to select “MANUAL”.
3Press [4/REW/4] or [3/FF/¢] to select the
frequency of the required station.
• “ ” is displayed when a stereo FM broadcast is being
received.
To tune automatically
Press [4/REW/4] or [3/FF/¢] for a moment until the
frequency starts changing rapidly. The unit begins auto
tuning, stopping when it finds a station.
• Auto tuning may be interrupted when there is excessive
interference.
• To cancel auto tuning, press [4/REW/4] or [3/FF/¢]
once again.
To improve FM sound quality
To improve FM sound quality
Press and hold [PLAY MODE] to display “MONO”.
To cancel
Press and hold [PLAY MODE] again until “MONO”
disappear.
• MONO is also cancelled if the frequency is changed.
• Turn off “MONO” for normal listening.
RDS broadcasting (For Europe)
RDS broadcasting (For Europe)
Enable you to display the name of a broadcasting station or
a program type.
Press [DISPLAY] to display:
Station Name (PS) Program Type (PTY)
Frequency display
• RDS displays may not be available if reception is poor.
Program type displays
NEWS
AFFAIRS
INFO
SPORT
EDUCATE
DRAMA
CULTURE
SCIENCE
VARIED
POP M
ROCK M
M.O.R.M
LIGHT M
CLASSICS
OTHER M
WEATHER
FINANCE
CHILDREN
SOCIAL A
RELIGION
PHONE IN
TRAVEL
LEISURE
JAZZ
COUNTRY
NATIONAL
OLDIES
FOLK M
DOCUMENT
TEST
ALARM
M.O.R.M = “Middle of the road music”
PM41_8043-1B.indd 14PM41_8043-1B.indd 14 2/21/05 9:18:47 AM2/21/05 9:18:47 AM

15
RQT8043
Setting the clock
Setting the clock
This is a 24-hour clock.
1Press [CLOCK/TIMER] to select “CLOCK”.
Each time you press the button:
CLOCK ˚PLAY
Original display
˚REC
2Within 7 seconds, press [4/REW/4] or
[3/FF/¢] to set the time.
3Press [CLOCK/TIMER] again to confirm.
Displaying the clock
Press [CLOCK/TIMER] to display the clock for few seconds.
• The clock may lose or gain some time over a period. Readjust if
necessary.
Using the sleep timer
Using the sleep timer
This function enables you to turn off the unit automatically
after the set time.
Press [SLEEP, –AUTO OFF] to select your desired time.
SLEEP 30 SLEEP 60 SLEEP 90
SLEEP 120SLEEP OFF
Sleep timer indicator
To cancel
Press [SLEEP, –AUTO OFF] to select “SLEEP OFF”.
Changing the remaining time
Press [SLEEP, –AUTO OFF] to show the remaining time and
press [SLEEP, –AUTO OFF] again to select your desired
time.
• The play and sleep timer or the record and sleep timer can be used
together.
• The sleep timer always has priority. Be sure not to overlap timer
settings.
• The sleep timer turns off when you start recording a disc.
Timer
(Continued on next page)
PM41_8043-1B.indd 15PM41_8043-1B.indd 15 2/21/05 9:18:50 AM2/21/05 9:18:50 AM

16
RQT8043
Using the play or record timer
Using the play or record timer
You can set the timer to come on at a certain time to wake
you up (play timer) or to record from the radio or an aux
source (record timer).
Turn the unit on and set the clock.
Timer Action
Play timer Prepare the music source you want to listen to;
tape, CD number (1~5), radio or AUX, and set the
volume.
Record timer Check the cassette’s erasure prevention tabs
(refer page 13), insert the cassette and tune to
the radio station (refer page 14) or select the aux
source (refer page 17).
1Press [CLOCK/TIMER] to select your desired timer.
Each time you press the button:
CLOCK ˚PLAY
Original display
˚REC
2Within 7 seconds, press [4/REW/4] or [3/FF/¢]
to set the starting time.
Play timer indicator Start time
Record timer indicator
3Press [CLOCK/TIMER] to confirm.
4Repeat steps 2 to 3 to set the finishing time.
Finish time
To activate the timer
5Press [˚PLAY/REC] to turn on your desired timer.
˚PLAY no display (off)˚REC
6Press [y] to turn off the unit.
The unit must be off for the timers to operate.
To enjoy the desired source after the timer setting is
completed.
The volume level (for play timer) and music source are stored
in the timer memory and the timer will start in these preset
conditions. However, the CD numbers do not get stored in
the timer memory.
1. After step 5, start playing the desired source.
2. Reset the CD numbers if you have changed any of them,
confirm that a CD or cassette is inserted, then press [y] to
put the unit on standby.
Other basic operations
Other basic operations
To Action
change the settings Repeat steps 1 to 4 and 6 on the left.
change the source
or volume
1) Press [˚PLAY/REC] to clear the timer
indicator from the display.
2) Make changes to the source or
volume.
3) Do steps 5 to 6 as on the left.
check the settings
(when the unit is in
standby mode)
Press [CLOCK/TIMER] repeatedly to
select ˚PLAY or ˚REC.
cancel Press [˚PLAY/REC] to clear the timer
indicators from the display.
• Play timer and record timer cannot be used together.
• The play timer will start at the preset time with volume increasing
gradually to preset level.
• The record timer will start 30 seconds before the set time with the
volume muted.
• The timer comes on at the set time everyday if the timer is on.
• The unit must be in the standby mode for the timer to function.
• If you turn the unit off and on again while a timer is functioning, the
finish time setting will not be activated.
• If AUX is selected as the source, when the timer comes on, the
system turns on and engages AUX as the source. If you want to
playback or record from a connected unit, set the other unit’s timer
to the same time. (See the other unit’s instruction manual.)
Timer (Continued)
PM41_8043-1B.indd 16PM41_8043-1B.indd 16 2/21/05 9:18:51 AM2/21/05 9:18:51 AM

17
RQT8043
Sound adjustment
External unit
Connecting external unit
Connecting external unit
Preparation
• Make sure that the power supply for all components has
been turned off before making any connections.
• For details, refer to the operating instructions of the unit
which is to be connected.
• All peripheral components and cables sold separately.
Connecting analogue equipment
Connecting analogue equipment
This example shows how to connect an analogue player with
a PHONO OUT/LINE OUT switch.
When units other than those described are to be connected,
please consult your dealer.
AUX
R L
(R)
(L)
“LINE OUT”
position
Analogue player (not included) Rear panel of this unit
• An analogue player with a built-in phono equalizer can be
connected.
• Set the switch to the “LINE OUT” position at the back of the
analogue player.
Playing or recording from an external
Playing or recording from an external
unit
unit
1Press [AUX].
2For listening : Proceed to step 3.
For recording : Do the preparatory steps (refer page
12).
Press [¶REC/8] to start recording.
3Start playback from the external source. (For details,
refer to the external unit’s instruction manual.)
Selecting sound effects
Selecting sound effects
You can change the sound effect by selecting Preset EQ or
adjusting the bass or treble effect.
Preset EQ
Preset EQ
Press [PRESET EQ] repeatedly to select your desired
setting.
HEAVY → CLEAR → SOFT → VOCAL → OFF
Setting Effect
HEAVY Adds punch to rock
CLEAR Clarifies higher frequencies
SOFT For background music
VOCAL Adds gloss to vocal
OFF No effect
Bass or treble
Bass or treble
Enable you to enjoy the lower or higher pitch sound.
1Press [BASS/TREBLE] repeatedly to select your
desired setting.
Setting Effect
BASS For lower pitch sound
TREBLE For higher pitch sound
2Press [∞] or [5] to adjust the level.
OR
To select bass or treble using the main unit:
1Press [BASS] or [TREBLE] to select your desired
setting.
2Press [–] or [+] to adjust the level.
• The tone level can be varied within –3 to +3.
Enhancing the bass
Enhancing the bass
Enable you to enjoy the powerful bass effect.
Press [H.BASS] repeatedly to select your desired setting.
LEVEL1 → LEVEL2 → OFF
Note
The actual effect depends on the disc.
Enjoying surround sound
Enjoying surround sound
Enable you to add natural width and depth to the stereo
sound.
To activate
Press [SURROUND] to display “ ” indicator.
To cancel
Press [SURROUND] again to clear “ ” indicator.
• Surround sound is less discernible when listening through
headphones.
• If interference in FM stereo reception increases, cancel the
surround sound effect.
PM41_8043-1B.indd 17PM41_8043-1B.indd 17 2/21/05 9:18:53 AM2/21/05 9:18:53 AM

18
RQT8043
Troubleshooting guide
Before requesting service, make the below checks. If you can’t fix the system as described below, or if something not
listed here occurs, refer to the enclosed directory to locate an Authorized Service Center convenient to you or contact your
dealer.
Common problems
No sound. Turn the volume up.
The speaker cords may not be connected properly. Turn the unit off, check and correct the
connections and turn the unit on (refer page 4).
Sound is unfixed, reversed or comes
from one speaker only. Check the speaker connections (refer page 4).
Humming heard during play. An AC power supply cord or fluorescent light is near the cables. Keep other appliances and
cords away from this unit’s cables.
“ERROR” is displayed. Incorrect operation performed. Read the instructions and try again.
“– –:– –” appears on the display. You plugged the AC power supply cord in for the first time or there was a power failure
recently.
Set the time (refer page 15).
“F61” is displayed. Check and correct the speaker cord connections (refer page 4).
If this does not fix the problem, there is a power supply problem. Consult the dealer.
Listening to the radio
Noise is heard.
The stereo indicator flickers or doesn’t
light.
Sound is distorted.
Use an outdoor antenna (refer page 5).
A beat sound is heard. Turn the TV off or separate it from the unit.
A low hum is heard during AM
broadcast. Separate the antenna from other cables and cords.
When there is a television set nearby
The picture on the TV disappears or
stripes appear on the screen. The location and orientation of the antenna are incorrect. If you are using an indoor antenna,
change to an outdoor antenna (refer page 5).
The TV antenna wire is too close to the unit. Separate the antenna wire of the TV set from
the unit.
Using the cassette deck
Recording is not possible. If the erasure prevention tabs have been removed, cover the holes with adhesive tape (refer
page 13).
Playing discs
The display is wrong or play won’t
start. The disc may be upside down (refer page 7).
Wipe the disc.
Replace the disc if it is scratched, warped, or non-standard.
Condensation may have formed inside the unit due to a sudden change in temperature. Wait
about an hour for it to clear and try again.
The total number of tracks displayed
differs each time the same disc is
inserted.
Unusual sound is heard.
The disc may be scratched, or its data may be defective. Replace the disc.
CD-RW cannot be read. The disc was incompletely formatted. Use the recording equipment to fully format the disc
before recording.
“VBR–” is displayed instead of the
remaining play time. The unit cannot display the remaining play time for variable bit rate (VBR) tracks.
“TAKE OUT/DISC” appears on the
display. There is a problem with the disc mechanism. (A power failure may have occurred.)
The tray will open automatically. Remove the disc from the tray, and after ensuring there is
no disc in the tray, close it. The unit will make the disc changing noises for a few moments
and then it should operate normally.
The remote control
Remote control doesn’t work. Check that the batteries are inserted correctly (refer page 5).
Replace the batteries if they are worn.
PM41_8043-1B.indd 18PM41_8043-1B.indd 18 2/21/05 9:18:55 AM2/21/05 9:18:55 AM

19
RQT8043
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
CAUTION!
• DO NOT INSTALL OR PLACE THIS UNIT IN A
BOOKCASE, BUILT-IN CABINET OR IN ANOTHER
CONFINED SPACE. ENSURE THE UNIT IS WELL
VENTILATED. TO PREVENT RISK OF ELECTRIC
SHOCK OR FIRE HAZARD DUE TO OVERHEATING,
ENSURE THAT CURTAINS AND ANY OTHER
MATERIALS DO NOT OBSTRUCT THE VENTILATION
VENTS.
• DO NOT OBSTRUCT THE UNIT’S VENTILATION
OPENINGS WITH NEWSPAPERS, TABLECLOTHS,
CURTAINS, AND SIMILAR ITEMS.
• DO NOT PLACE SOURCES OF NAKED FLAMES,
SUCH AS LIGHTED CANDLES, ON THE UNIT.
• DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY
FRIENDLY MANNER.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK
OR PRODUCT DAMAGE, DO NOT EXPOSE THIS
APPARATUS TO RAIN, MOISTURE, DRIPPING OR
SPLASHING AND THAT NO OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON
THE APPARATUS.
SUOMI
VAROITUS!
LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
VAROITUS!
• ÄLÄ ASENNA TAI LAITA TÄTÄ LAITETTA
KABINETTITYYPPISEEN KIRJAKAAPPIIN TAI MUUHUN
SULJETTUUN TILAAN, JOTTA TUULETUS ONNISTUISI.
VARMISTA, ETTÄ VERHO TAI MIKÄÄN MUU
MATERIAALI EI HUONONNA TUULETUSTA, JOTTA
VÄLTETTÄISIIN YLIKUUMENEMISESTA JOHTUVA
SÄHKÖISKU- TAI TULIPALOVAARA.
• ÄLÄ PEITÄ LAITTEEN TUULETUSAUKKOJA
SANOMALEHDELLÄ, PÖYTÄLIINALLA, VERHOLLA
TAI MUULLA VASTAAVALLA ESINEELLÄ.
• ÄLÄ ASETA PALAVAA KYNTTILÄÄ TAI MUUTA
AVOTULEN LÄHDETTÄ LAITTEEN PÄÄLLE.
• HÄVITÄ PARISTOT LUONTOA
VAHINGOITTAMATTOMALLA TAVALLA.
VAROITUS:
TULIPALO-, SÄHKÖISKUVAARAN TAI TUOTETTA
KOHTAAVAN MUUN VAHINGON VÄHENTÄMISEKSI EI
LAITETTA SAA ALTISTAA SATEELLE, KOSTEUDELLE,
VESIPISAROILLE TAI ROISKEELLE, EIKÄ NESTETTÄ
SISÄLTÄVIÄ ESINEITÄ, KUTEN ESIMERKIKSI
MALJAKOITA, SAA ASETTAA LAITTEEN PÄÄLLE.
NORSK
ADVARSEL!
DETTE PRODUKTET ANVENDER EN LASER.
BETJENING AV KONTROLLER, JUSTERINGER
ELLER ANDRE INNGREP ENN DE SOM ER
BESKREVET I DENNE BRUKSANVISNING, KAN
FØRE TIL FARLIG BESTRÅLING.
DEKSLER MÅ IKKE ÅPNES, OG FORSØK ALDRI
Å REPARERE APPARATET PÅ EGENHÅND. ALT
SERVICE OG REPARASJONSARBEID MÅ UTFØRES
AV KVALIFISERT PERSONELL.
ADVARSEL!
• APPARATET MÅ IKKE PLASSERES I EN BOKHYLLE,
ET INNEBYGGET KABINETT ELLER ET ANNET
LUKKET STED HVOR VENTILASJONSFORHOLDENE
ER UTILSTREKKELIGE. SØRG FOR AT
GARDINER ELLER LIGNENDE IKKE FORVERRER
VENTILASJONSFORHOLDENE, SÅ RISIKO FOR
ELEKTRISK SJOKK ELLER BRANN FORÅRSAKET
AV OVERHETING UNNGÅS.
• APPARATETS VENTILASJONSÅPNINGER MÅ IKKE
DEKKES TIL MEDAVISER, BORDDUKER, GARDINER
OG LIGNENDE.
• PLASSER IKKE ÅPEN ILD, SLIK SOM LEVENDE LYS,
OPPÅ APPARATET.
• BRUKTE BATTERIER MÅ KASSERES UTEN FARE
FOR MILJØET.
ADVARSEL:
FOR Å REDUSERE FAREN FOR BRANN, ELEKTRISK
STØT ELLER SKADER PÅ PRODUKTET, MÅ DETTE
APPARATET IKKE UTSETTES FOR REGN, FUKTIGHET,
VANNDRÅPER ELLER VANNSPRUT. DET MÅ HELLER
IKKE PLASSERES GJENSTANDER FYLT MED VANN, SLIK
SOM BLOMSTERVASER, OPPÅ APPARATET.
PM41_8043-1B.indd 19PM41_8043-1B.indd 19 2/21/05 9:18:56 AM2/21/05 9:18:56 AM

Matsushita Electric Industrial Co., Ltd.
Web Site: http://www.panasonic.co.jp/global/ RQT8043-2B
L0205CP2035
En
Specifications
AMPLIFIER SECTION
RMS Output power both channel driven
10% total harmonic distortion
1 kHz
(Low channel) SC-PM19 41 W per channel (6 Ω)
8 kHz
(High channel) SC-PM19 39 W per channel (6 Ω)
Total Bi-Amp power SC-PM19 80 W per channel
Input Impedance SC-PM19250 mV
Output Impedance
Headphone 16 Ω– 32 Ω
FM TUNER SECTION
Frequency range
87.50
MHz – 108.00 MHz (50 kHz steps)
Sensitivity 1.02 µV (IHF)
S/N 26 dB 1.00 µV
Antenna terminals 75 Ω(unbalanced)
Preset station 15
AM TUNER SECTION
Frequency range
522 kHz – 1629
kHz (9 kHz steps)
520 kHz – 1630 kHz (10 kHz steps)
Sensitivity
S/N 20 dB (at 999 kHz) 900 µV/m
Preset station 15
CASSETTE DECK SECTION
Track system 4 track, 2 channel
Heads
Record/playback Solid permalloy head
Erasure Double gap ferrite head
Motor DC servo motor
Recording system AC bias 100
kHz
Erase system AC erase 100 kHz
Tape speed 4.8 cm/s
Overall frequency response (+3 dB, –6 dB) at DECK OUT
NORMAL 35 Hz – 14 kHz
S/N RATIO 42.64 dB (A weighted)
Wow and flutter 0.08% (WRMS)
Fast forward and rewind time
Approx. 120 seconds with C-60 cassette tape
CD SECTION
Disc
CD, CD-R, CD-RW, MP3 8 cm/12 cm
Sampling frequency
CD 44.1
kHz
MP3 32 kHz, 44.1 kHz, 48 kHz
Bit rate 32 kbps – 320 kbps
Decoding 16/20/24 bit linear
Pick up
Beam source/wavelength Semiconductor laser/780 nm
(For Norge)
Bølgelengde 780 nm
Laserstyrke Ingen farlig stråling sendes ut
Number of channels Stereo
Frequency response 20 Hz – 20 kHz (+1dB, –2 dB)
Wow and flutter Below measurable limit
Digital filter 8 fs
D/A converter MASH (1 bit DAC)
SPEAKER SECTION
Type 3 way, 3 speaker system
Speaker(s)
Woofer 10 cm cone type (6 Ω)
Tweeter 6 cm cone type (6 Ω)
Super tweeter piezo type
Impedance 6 Ω
Input power (IEC)
HIGH 80 W (Max)
LOW 80 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Cross over frequency 3 kHz, 10 kHz
Frequency range 42 Hz – 50 kHz (–16 dB)
50 Hz – 45 kHz (–10 dB)
Dimensions (WxHxD) 145 mm x 247 mm x 230 mm
Mass 2.20 kg
GENERAL
Power supply
For Continental Europe AC 230 V, 50 Hz
For United Kingdom, Australia and N.Z.
AC 230 – 240 V, 50 Hz
Power consumption 130
W
Dimensions (WxHxD) 175 mm x 254 mm x 391 mm
Mass
For Continental Europe and United Kingdom 5.8 kg
For Australia and N.Z. 5.6 kg
Power consumption in standby mode 0.6 W
Notes:
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
3. The labels “HIGH” and “LOW” on the rear of the speakers refer to
High frequency and Low frequency.
Maintenance
Maintenance
If the surfaces are dirty
If the surfaces are dirty
To clean this unit, wipe with a soft, dry cloth.
• Never use alcohol, paint thinner or benzine to clean this
unit.
• Before using chemically treated cloth, read the instructions
that came with the cloth carefully.
For a cleaner crisper sound
For a cleaner crisper sound
Clean the heads regularly to assure good quality playback
and recording.
Use a cleaning tape (not included).
When moving the unit
When moving the unit
1Remove all discs.
2Press [y/I] to turn the unit off.
3Disconnect the AC power supply cord.
PM41_8043-2B.indd 20PM41_8043-2B.indd 20 3/11/05 5:23:59 PM3/11/05 5:23:59 PM
