Panasonic SB-WA1501EB User manual

ORDERNO. MD0406274C2
Active Subwoofer System
SB-WA1501EB / SB-WA1501EG
Colour
(S)... Silver Type
SPECIFICATIONS
Specification
1

SPEAKER SECTION
Type 1way, 1speaker system, Bass-
ref.
Woofer 17 cm conetype
Output sound pressure 80 dB/W(1m)
Frequencyrange 40-220 Hz (at -16 dB)
45-180 Hz (at -10 dB)
Dimensions(WxH xD) 209 x361 x463 mm
Mass Approx. 11.7kg
GENERAL
Power supply AC 230-240 V, 50Hz (EB)
AC 230 V, 50Hz (EG)
Power consumption 230 W
Note:
Specificationsare subject tochangewithout notice.
Mass and dimensionsare approximate.
SB-HT1501E-S consistsof :
SB-FS1501E-S x2, SB-PS1501E-S x2and SB-PC1501E-S x1
System : SC-HT1500 (EB) MusicCenter: SA-HT1500 (EB)
SatelliteSpeakers: SB-HT1501 (E)
ActiveSubwoofer: SB-WA1501 (EB)
System : SC-HT1500 (EG) MusicCenter: SA-HT1500 (EG)
SatelliteSpeakers: SB-HT1501 (E)
ActiveSubwoofer: SB-WA1501 (EG)
2004 PanasonicAVCNetworks Singapore Pte. Ltd. (RCB
Registration Number: 197701580H)All rights reserved.
Unauthorized copying and distribution isaviolation of law.
1. Safety Precautions
1.1. GENERALGUIDELINES
1. When servicing, observe the original lead dress. Ifashort circuit
isfound, replace all parts which have been overheated or
damaged bythe short circuit.
2. After servicing, see to itthat all the protective devices such as
2

insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following leakage current checks to
prevent the customer from being exposed to shock hazards.
1.1.1. LEAKAGE CURRENTCOLD CHECK
1. Unplug the AC cord and connect ajumper between the two
prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between the
jumpered AC plug and each exposed metalliccabinet part on the
equipment such as screwheads, connectors, control shafts, etc.
When the exposed metallicpart has areturn path to the chassis,
the reading shouldbe between 1M and 5.2 . / When the
exposed metal does not have areturn path to the chassis, the
reading must be . Fig. 1
1.1.2. LEAKAGE CURRENTHOTCHECK (See Figure1.)
1. Plug the AC cord directlyinto the AC outlet. Don not use an
isolation transformer for thischeck.
2. Connect a1.5k , 10 watts resistor, inparallel with a0.15 F
capacitors, between each exposed metallicpart on the set and a
good earth ground such as awater pipe, as showninFigure 1.
3. Use an AC voltmeter, with 1000 ohms/voltor more sensitivity, to
measure the potential across the resistor.
4. Check each exposed metallicpart, and measure the voltage at
each point.
5. Reverse the AC plug inthe AC outlet and repeat each of the above
measurements.
6. The potential at anypoint shouldnot exceed 0.75 volts RMS. A
3

leakage current tester (Simpson Model 229 or equivalent) maybe
used to make the hot checks, leakage current must not exceed 1/2
milliamp. Incase ameasurement isoutside of the limits specified,
there isapossibilityof ashock hazard, and the equipment should
be repaired and rechecked before itisreturned to the customer.
2. Handling the Lead-free Solder
2.1. About lead free solder (PbF)
Distinction of PbF P.C.B. :
P.C.B.s (manufactured) using leadfree solderwill have a PbF stampon the P.C.B.
Caution:
-Pb free solder has ahigher melting point that standard solder;
Typicallythe melting point is50 -70°F (30 -40°C)higher. / Please
use ahigh temperature soldering iron. Incase of the soldering
iron with temperature control, please set itto 700 ± 20°F (370 ±
10°C).
-Pb free solder will tend to splash when heated too high (about
1100°F/600°C).
-When soldering or unsoldering, please completelyremove all of
the solder on the pins or solder area, and be sure to heat the
soldering points with the Pb free solder until itmelts enough.
3. Before Repair and Adjustment
Disconnect AC power, discharge PowerSupplyCapacitors C546, C547, C548, C549 through a
10 , 1 W resistortoground.
DO NOTSHORT-CIRCUITDIRECTLY (witha screwdriverblade, forinstance), as this may
destroysolidstate devices.
Afterrepairs are completed, restore powergraduallyusing a variac, toavoidovercurrent.
Current consumption at AC 230~240V, 50Hz inNO SIGNALmode shouldbe ~250 mA (EB).
Current consumption at AC 230V, 50Hz inNO SIGNALmode shouldbe ~250 mA (EG).
4. Protection Circuitry
The protection circuitrymayhave operatedif eitherof the following conditions are noticed:
-Nosound isheard when the power isturned on.
-Stops during aperformance.
The function of this circuitryis toprevent circuitrydamage if, forexample, the positive and
negative speakerconnection wires are “shorted”, orif speakersystems withanimpedance less
thanthe indicatedratedimpedance of the amplifierare used.
If this occurs, followthe procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
4

3. Turn on the power once againafter one minute.
Note:
Whenthe protection circuitryfunctions, the unit will not operate unless the poweris first turned
off and thenon again.
5. Connection of the Speaker Cables
-Besure to connect speaker cables before connecting the AC
mains lead.
-The load impedance of anyspeaker used with thisunitmust be 6 .
1. Connect with the included monaural connection cableto the
receiver or amplifier’ssubwoofer output terminal.
2. Connect the AC mains lead to the householdAC outlet.
6. Disassembly Procedure
“ATTENTION SERVICER”
Some chassis components mayhave sharpedges.
Be careful whendisassembling and servicing.
1. Thissection describes procedures for checking the operation of
the major printed circuitboards and replacing the main
5

components.
2. For reassemblyafter operation checks or replacement, reverse
the respective procedures.
Special reassemblyprocedures are described onlywhen required.
3. Select items from the following index when checks or
replacement are required.
6.1. Disassemblyflow chart
The following chart is the procedure fordisassembling the casing and inside parts forinternal
inspection whencarrying out the servicing.
To assemble the unit, reverse the steps showninthe chart below.
6.2. Disassemblyof the Speaker Unitand checking of the P.C.B.
6

6.2.1. Removal of the Subwooferand PowerAmpUnit
Step1: Remove all the screws.
Step2: Remove the stand base.
Step3: Remove all the screws fromthe bottomof the speakerunit.
Step4: Remove all the screws fromthe rearpanel’s speakerunit guide.
7

Step5: Remove the screws fromthe subwoofer.
Step6: Remove the 2 screws fromthe PowerAmpunit.
Step7: Pull out the PowerAmpunit as arrowshown.
(Note: Be careful of the attachwire at CN506).
Step8: Disconnect the connectorCN506.
8

6.2.2. Checking forthe majorPCBs
-Follow Steps 1to 8described inItem 8.2.1.
Steps 9 & 10: Remove 7 screws fromthe rearpanel.
Step11: Release the connectorCN507 and remove the rearpanel.
Step12: Remove the screws.
9

Steps 13 & 14: Remove the screws.
Step15: Place the PowerP.C.B and AC Inlet P.C.B. as shownforchecking.
-Checking for the Transformer P.C.B.
Step16: Remove the screws.
10

Step17: Place the P.C.B.s as shownforchecking.
6.3. MainComponent Replacement Procedures
6.3.1. Replacement of the PowerIC and Transistor
-Follow Steps 1to 8described inItem 8.2.1.
-Follow Steps 9to 17 described inItem 8.2.2.
Step1: Desolderthe PowerIC terminal and Transistorterminal.
11

Step2: Remove the screws fromthe IC501.
Step3: Remove the screwfromthe transistor.
Step4: Replacement of the PowerIC and Transistor.
12

6.4. Assemblyof the Power Amp Unit
Step1: Openthe magnet case and place the speakercable as shown.
Step2: Close the magnet case.
Step3: Use the himelon forwrapping.
13

Step4: Use binding wire tofix the speakercable and motorcable. The position shouldbe higher
thanCement (White) register.
Step5: Lowerthe magnet tothe binding wire and use anotherbinding wire tofix the magnet
withmotorcable and speakercable.
14

7. Connection of the Speaker Wiring
8. Block Diagram
9. Schematic Diagram
(All schematic diagrams maybe modifiedat anytime withthe development of the new
technology)
Note:
-The voltage value and waveforms are the reference voltage of this
unitmeasured byDC electronicvoltmeter (high impedance) and
oscilloscope on the basisof chassis. Accordingly, there mayarise
some error involtage values and waveforms depending upon the
internal impedance of the tester or the measuring unit.
-Importance safetynotice :
Components identified bymark have special characteristics
important for safety. Furthermore, special parts which have
purposes of fire-retardant (resistors), high-qualitysound
(capacitors), low-noise (resistors), etc. are used. When replacing
anyof components, be sure to use onlymanufacturer's specified
parts showninthe parts list.
Caution !
IC, LSI and VLSI are sensitive tostatic electricity.
Secondarytrouble canbe preventedbytaking care during repair.
-Cover the parts boxes made of plastics with aluminium foil.
-Put aconductive mat on the work table.
-Ground the soldering iron.
-Donot touch the pins of IC, LSI or VLSI with fingers directly.
10. Printed Circuit Board
11. Wiring Connection Diagram
12. Illustration of IC’s, Transistors and Diodes
13. Parts Location and Replacement Parts List
Notes:
15

-Important safetynotice:
Components identified bymark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardent
(resistors), high-qualitysound (capacitors), low noise (resistors),
etc are used.
When replacing anyof these components, be sure to use only
manufacturer’sspecified parts showninthe parts list.
-The parenthesized indications inthe Remarks columns specifythe
areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
-Capacitor values are inmicrofarads ( F) unless specified
otherwise, P= Pico-farads (pF), F= Farads.
-Resistance values are inohms, unless specified otherwise, 1K=
1,000 (OHM).
-The marking (RTL) indicates that the Retention Time islimited for
thisitems. After the discontinuation of thisassemblyin
production, the item will continue to be availablefor aspecific
period of time. The retention period of aavailabilityisdependent
on the type of assembly, and inaccordance with the laws
governing part and product retention. After the end of thisperiod,
the assemblywill no longer be available.
-[M] Indicates inthe Remarks columns indicates parts supplied by
PAVCSG.
-Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It : Italian Sp:
Spanish
Cf : CanadianFrenchEn: English Ko: Korean Sw:
Swedish
Cz : Czech Fr: French Po: Polish Co:
Traditional
Chinese
Da : Danish Ge : German Ru: Russian Cn:
Simplified
Chinese
Per: Persian
13.1. Cabinet
13.1.1. Cabinet PartsLocation
16

13.1.2. Cabinet PartsList
17

Ref. No. PartNo. PartName& Description Remarks
CABINETAND CHASSIS
1RFKHBWA1501E ACTSUBWOOFER ASS’Y [M]
2RMVX0077-1J SPEAKER UNITGUARD [M]
3RMQX0088-J EVAPACKING [M]
4RGKX0255-S1J STAND ORNAMENT [M]
5RGRX033CN1AJ REAR PANEL [M]EG
5RGRX033CP1AJ REAR PANEL [M]EB
6REM0072-4 FAN [M]
7SHE187-6J PCB SUPPORT [M]
8RMN0203 PCB HOLDER [M]
9RMRX0047-2J LED HOLDER [M]
10 RKAX0018-KJ LEG CUSHION [M]
11 RMC0158-S2 TR-FIXTURE [M]
13 RHD30092 SCREW [M]
14 XTB3+16AFZ SCREW [M]
15 XTB3+20JFZ SCREW [M]
16 XTB4+15AFZ SCREW [M]
17 XTBS3+8JFZ1 SCREW [M]
18 XTS4+20JFZ SCREW [M]
19 XYC26+CJ6FZ SCREW [M]
21 RMGX0039-KJ TRANSRUBBER [M]
22 XTW3+15T SCREW [M]
23 J0KG00000013 FERRITECORE [M]
24 RMFX0028 HIMELON [M]
13.2. Electrical Parts List
Ref. No. PartNo. PartName& Description Remarks
PRINTED CIRCUITBOARD
REPX0375H POWER P.C.B./ AC INLETP.C.B./ TRANSFORMER P.C.B./ LED
P.C.B. [M]EB (RTL)
REPX0375J POWER P.C.B./ AC INLETP.C.B./ TRANSFORMER P.C.B./ LED
P.C.B. [M]EG (RTL)
INTEGRATED CIRCUITS
IC501 RSN311W64C-P IC HIC [M]
IC502 C0AABB000055 IC AMP [M]
TRANSISTORS
Q501 B1AACF000089 TRANSISTOR [M]
Q502 B1AACF000089 TRANSISTOR [M]
Q503 B1AACF000089 TRANSISTOR [M]
Q505 B1AACF000089 TRANSISTOR [M]
Q506 B1GCCFJJ0015 TRANSISTOR [M]
Q507 B1AACF000089 TRANSISTOR [M]
Q508 B1ACKD000004 TRANSISTOR [M]
Q509 B1AACF000089 TRANSISTOR [M]
Q510 B1AACF000089 TRANSISTOR [M]
Q511 B1BACG000009 TRANSISTOR [M]
18

Ref. No. PartNo. PartName& Description Remarks
Q513 B1AACF000089 TRANSISTOR [M]
Q514 B1AACF000089 TRANSISTOR [M]
Q515 B1AACF000089 TRANSISTOR [M]
Q519 B1AACF000089 TRANSISTOR [M]
Q520 B1GCCFJJ0015 TRANSISTOR [M]
DIODES
D500 B0AACK000004 DIODE [M]
D501 B0JAPG000019 DIODE [M]
D502 B0JAPG000019 DIODE [M]
D503 MA2C700A0F DIODE [M]
D504 B0AACK000004 DIODE [M]
D505 B0AACK000004 DIODE [M]
D506 B0AACK000004 DIODE [M]
D507 B0AACK000004 DIODE [M]
D508 B0AACK000004 DIODE [M]
D509 B0BA5R100013 DIODE [M]
D510 B0BA9R600002 DIODE [M]
D511 B0HARM000017 DIODE [M]
D512 B0HARM000017 DIODE [M]
D513 B0HARM000017 DIODE [M]
D514 B0HARM000017 DIODE [M]
D515 B0EAKM000122 DIODE [M]
D516 B0EAKM000122 DIODE [M]
D517 B0HARM000017 DIODE [M]
D518 B0HARM000017 DIODE [M]
D519 B0AACK000004 DIODE [M]
D524 B3ABA0000397 DIODE [M]
D533 B0BA5R100013 DIODE [M]
CONNECTORS
CN501 K1FB125B0095 SYSTEMCONNECTOR [M]
CN502 K1KB07B00020 2PCONNECTOR [M]
CN503 K1KA12A00066 12PCONNECTOR [M]
CN506 K1KA03A00006 3PCONNECTOR [M]
CN507 K1KA02A00008 2PCONNECTOR [M]
CP502 K1KA07A00123 2PCONNECTOR [M]
COILS& TRANSFORMERS
L500 ELF15N035AN LINEFILTER [M]
L501 G0AR76Y00001 CHOKECOIL [M]
L502 G0AR76Y00001 CHOKECOIL [M]
L503 G0AR76Y00001 CHOKECOIL [M]
L504 G0AR76Y00001 CHOKECOIL [M]
L505 G0AR76Y00001 CHOKECOIL [M]
T501 G4C7AGK00003 POWER TRANSFORMER [M]
COMPONENTCOMBINATION
19

Ref. No. PartNo. PartName& Description Remarks
Z501 ERZV10V511CS ZENER [M]
SPEAKER
SP1 L0AA17A00003 WOOFER [M]
RELAY
RLY501 K6B1AEA00003 MAGNETRELAYS [M]
FUSES
F1 K5D202BK0005 250V2AFUSE [M]
FUSE HOLDERS
FC501 EYF52BC FUSE HOLDER [M]
FC502 EYF52BC FUSE HOLDER [M]
HOLDERS
H500 K1YF12000002 12PWIREHOLDER [M]
H505A K1YZ03000010 3PCABLEHOLDER [M]
H505B K1YZ03000010 3PCABLEHOLDER [M]
JACKS
JK500 K2AA2B000004 JK AC INLET [M]
JK501 K4BC06B00022 JK TERMINAL/TERMINAL [M]
JK502 K4BC04B00051 JK SPEAKER [M]
EARTH TERMINAL
E500 K4CZ01000027 TERMINAL [M]
E501 K4CZ01000027 TERMINAL [M]
WIRES
W1 REE1205 WIREUNIT [M]
W2 REE1204 WIREUNIT [M]
W500 REX1146 WIREUNIT [M]
W505 RWJ1103280XX 3PWIRE [M]
RESISTORS
R401 ERDS2TJ224T 220K 1/4W [M]
R402 ERDS2TJ102T 1K 1/4W [M]
R403 ERDS2TJ104T 100K 1/4W [M]
R501 ERDS2TJ472T 4.7K 1/4W [M]
R502 ERDS2TJ472T 4.7K 1/4W [M]
R503 ERDS2TJ153T 15K 1/4W [M]
R504 ERDS2TJ153T 15K 1/4W [M]
R505 ERDS2TJ153T 15K 1/4W [M]
20
