TC-60AS800U
TC-55AS800U
e HELP
English

- 2 -
Using my Home Screen
my Home Screen
•Features 9
•How to use 10
•Settings 11
Using Apps list
•Features 13
•How to use 14
•Settings 15
Watching TV
Cable / Satellite / Fiber Optic box
•Initial setting 16
Antenna / Cable service without a box
•Initial setting 17
•Select channels 18
•Favorite channels 19
•Closed Caption 20
•SAP 21
•Other 22
Blu-ray, DVD, Game Console, etc.
•Connecting and viewing 23
•Example of AV connections 24
•HDMI connection notice 26
•HDMI connection caution 27
•Input signal 28
For best picture
•Picture mode 29
•Auto brightness (ECO) 31
•Aspect setting 32
•Screen mode 33
•Zoom adjustments 35
•Lock settings 36
•Copy adjustments 37

- 3 -
For best audio
•Sound mode 38
•DIGITAL AUDIO OUT terminal 39
Viewing 3D images
•Notice 40
•Viewing 3D 41
•Change 3D↔2D 42
•Adjust 3D images 43
Network services
Connect to network
•Network connections 44
•Network connection types 45
Network settings
•Setting the menu 47
•Network connection/Network status 48
•my Home Cloud settings 49
•VIERA network name 50
•TV remote App settings 51
•Network link 52
•File sharing settings 53
•Software update 54
•New software notice 55
How to use
•Operate 56
Home network “DLNA”
Get started
•Information 57
Photos
•Viewing Photos 58
•Photo view 59
•Options menu 60
•Using slideshow 61
•Slideshow settings 62

- 4 -
Videos
•Viewing Videos 63
•Video view 64
•Options menu 65
Music
•Playing Music 66
•Music view 67
•Options menu 68
Media player
Get started
•Information 69
•Media warning messages 70
•SD card handling cautions 71
•File sharing 72
•Notice 73
Photos
•Viewing Photos 74
•Photo View 75
•Sort the photos 76
•Options menu 77
•Multi shot 3D 78
•Thumbnails size 79
•Using slideshow 80
•Slideshow settings 81
•Soundtrack settings 83
Videos
•Viewing Videos 84
•Video view 85
•Options menu 86
Music
•Playing Music 87
•Music view 88
•Options menu 89

- 5 -
Convenience features
Eco navigation
•Eco navigation 90
Timer
•Setting the menu 91
Parental control
•Setting the menu 92
•Password setting 93
•Parental control ratings 94
Closed Caption
•Setting the menu 96
•Closed Caption notice 97
VIERA Link ™ “HDAVI Control ™”
•Basic feature 98
•Connecting note 99
•VIERA Link connections 101
•VIERA Link settings 103
•VIERA Link settings feature 104
•VIERA Link 106
•VIERA Link menu 107
User profile
•Setting the menu 109
•my Stream 110
Info Bar
•Features 111
•Setting the menu 113
Using Voice guidance
•Voice guidance 114
Using Voice control
•Voice control 115
•How to use the voice control 116
Using Built-in camera
•Built-in camera 117
Using Touch Pad Controller

- 6 -
•Features 118
•My button 119
•Setting the menu 120
Using Bluetooth devices
•Settings 121
Control by Smartphone, etc.
•Smartphone remote 122
•Turn on the TV via IP 123
Using USB Keyboard
•Keyboard 124
All settings
How to use
•Setting the menu 125
•Basic settings 126
•Pro settings 129
•Advanced picture 133
•Screen settings 135
•3D settings 137
•Other settings 139
Sound
•Basic settings 140
•Advanced settings 142
•Voice guidance settings 145
Network
•Network settings 146
Timer
•Sleep (Off timer) 149
•Timer (On/Off timer) 150
•Clock settings 151
•Auto turn off settings 152
Setup
•Eco navigation 153
•Voice control settings 154

- 7 -
•User settings 155
•Info Bar settings 156
•USB device setup 157
•VIERA Touch Pad settings 158
•Bluetooth settings 159
•Parental control 160
•ANTENNA/Cable setup 162
•Language settings 164
•Display customization 165
•Closed Caption 166
•VIERA Link settings 168
•System settings 169
•Other settings 170
Support / FAQ
Help menu
•Using Help menu 171
FAQ
•Picture - Viewing 172
•Picture - Snowy / none 173
•Picture - Distortion 174
•Picture - Continue 175
•Sound - None 176
•Sound - Unusual 177
•Networking 178
•Software update 179
•3D - Viewing 180
•3D - Format 181
•Voice guidance 182
•Voice control 183
•Built-in camera 184
•Touch Pad Controller 185
•Eco navigation 186
•Other 187
•Menu - Gray-out or missing items 188

- 8 -
•Reset to factory default 189
Information
•Data information 190
Care and Cleaning
•Display panel 192
•Cabinet 193
•Pedestal / Power cord 194
•3D Eyewear 195
Press the Remote control button
INFO Letters in box : Remote control button
Menu Letters in Cyan : Menus on screen display
References in this eHELP

- 9 -
Using my Home Screen
my Home Screen
Features
my Home Screen is a gateway to the TV, applications, and more. It provides
easy access to special features such as the Media Player, videos, games,
communication tools, etc.
■Home Screen
(Example)
HOME
OK
OK HOME
Home Screen (Full Screen TV, Various Home Screen, etc.)
Selected content screen (TV, application, etc.)
Home Screen Selection
– Choose your preferred Home Screen layout.

- 10 -
How to use
The Home Screen provides access to special features such as the Media
Player, TV, Internet content, data services, communication tools, etc.
1. Display Home Screen
HOME
●The last viewed Home Screen is displayed each time the TV is turned
on.
●Press HOME again to return to Home Screen Selection.
●You can change the default Home Screen when the TV is turned on.
Using my Home Screen > my Home Screen > Settings
2. Select a Home Screen icon using / / / and press to
access the feature.
●To watch full-screen TV
1) Select the TV window with / / /
2) Press to watch
●Also refer to Tutorial from the tool guide.

- 11 -
Settings
Select the setup menu from the tool guide on the top of the screen.
(Example)
■Home Screen Selection
1. Display Home Screen Selection with HOME
(Example)
2. Select the type of Home Screen with / and press to set.
●Full Screen TV
Exits the Home Screen and displays the TV picture in full-screen.
– To Keep Full Screen TV
While watching the TV on this full-screen, select Settings from tool
guide. Then, set the Power ON Option.
●Various Home Screens
You can change the layout of the Home Screen according to your
lifestyle and personal preferences.
■Face recognition/Voice Print Recognition
By using the built-in camera and voice control function, this TV recognizes
your face/voice and displays the registered Home Screen.
●Say “my Home Screen” into the microphone of the Touch Pad Controller to
use this function.
●To use this function, you need to set up a user profile and register face/
voice data, preferred Home Screen, etc.
All settings > Setup > User settings

- 12 -
●For details of voice control function
Convenience features > Using Voice control
●For details of the built-in camera
Convenience features > Using Built-in camera > Built-in
camera
■Settings
You can customize Home Screen. For example, you can change the
wallpaper, rename the screen, add / delete or set your preferred Home
screen, edit applications, etc.
1. Select Settings from the tool guide
2. Follow the on-screen instructions
■Search function
You can search the content of various Home screen features.
1. Select Search from the tool guide
2. Follow the on-screen instructions
●To use this function fully, you need a broadband network environment.
Ensure the network connections and network settings are completed.
●Be sure to update the software when a software update notice is
displayed on the TV screen. If the software is not updated, you will not
be able to use my Home Screen. You can update the software later
manually.
●To change the color type of on-screen displays.
All settings > Setup > Display customization

- 13 -
Using Apps list
Features
Special features (Internet contents, network contents, Media Player, etc.) can
be accessed easily from Apps (applications) list.
■APPS list
●Apps list is subject to change without notice.

- 14 -
How to use
You can access special features such as Internet contents, network contents,
Media Player, etc. from Apps list (applications list).
1. Display Apps list
APPS
(Example)
●To exit Apps list
EXIT
2. Select an icon of the features with / / / and press to
access

- 15 -
Settings
You can set up Apps list manually. (For example, Screen Settings, Account
Information, restriction, etc.)
1. Display Apps list
APPS
2. Select the setup menu on Apps list with / / / and press
to access
3. Follow the on-screen instructions
●Setup items may be changed without notice

- 16 -
Watching TV
Cable / Satellite / Fiber Optic box
Initial setting
1. Connecting
Select the wiring method connecting your box to the TV, AV IN or
Antenna/Cable in.
Note:
●HDMI will provide the best HD picture
2. Change INPUT
INPUT
Press the INPUT button to select the proper connection. Wait for 2
seconds.
●The menu choices vary depending on which input is selected.
3. Power on your Cable, Satellite or Fiber Optic box
Use the box’s remote control to change channels.
●If the box is connected to the TV using a COAX cable (Antenna/Cable
in), then set the TV channel to CH3 or CH4. Note that the picture will not
be in HD.
●CC/SAP is not available when watching TV with a Cable or Satellite box
connected via HDMI.
●If you have a High Definition box, ensure that it is outputting 720p or
1080i signal.
Tip: press the TV’s INFO button to verify.
●Check your box’s “aspect” or “format” settings. It should be set to 16:9,
Widescreen or Full.
●If the audio volume is too low, check the box’s audio settings.
●Contact your Cable or Satellite provider for instructions on any box
settings.

- 17 -
Antenna / Cable service without a box
Initial setting
1. Connect coax
Connect a COAX wire from either an antenna or Basic Cable service to
the TV’s “ANTENNA/CABLE IN” screw terminal.
TV (ANTENNA/CABLE IN)
Antenna
2. Scan the channel
MENU Menu > Setup > ANTENNA/Cable setup > ANTENNA/
Cable signal, Auto program
1) Select either Cable or Antenna programming source in ANTENNA/
Cable signal.
2) Select Auto program and then the appropriate scan mode:
(All channels / Analog only / Digital only)
3) Start scanning.
●The tuner setup menu (auto scan, etc.) is only available when INPUT is
set to TV.
●If no channels are found by the end of the scan, then check the
following:
– Antenna’s position - or availability of Cable service.
– Cable, Satellite or Fiber Optic services with a box are typically
connected to the TV’s A/V inputs, preferably HDMI, for best HD
picture. In such a case, the channel scanning is not needed.

- 18 -
Select channels
■Select desired channel
or
●CH buttons are also available on the TV.
■Select desired digital channel
To directly enter a digital channel number use button to enter the dash.
(e.g.CH15-1→ )

- 19 -
Favorite channels
Channel numbers registered in Favorite are displayed on the favorite tune
screen. Select the desired broadcast station with the cursor or use the
number buttons.
●Favorite channels cannot be set when using Cable or Satellite box
■Set the Favorite channel
OPTION Options menu > Set favorite
Select the list number using / and or - / directly to
save the displayed channel.
■Delete a Favorite channel
OPTION Options menu > Set favorite
Select the list number using / and to delete.
●To change the page in Set favorite
FAVORITE or / repeatedly
■Display a Favorite channel
FAVORITE Favorite channels
Select the list number using / and or - / directly to
save the displayed channel.
●To change the page in Favorite channels
FAVORITE or / repeatedly

- 20 -
Closed Caption
■Viewing with Closed Caption
CC
Switches the Closed Caption mode.
(Off / On / On mute)
●CC is not available when watching TV with a Cable or Satellite box
connected via HDMI.
●Contact your Cable or Satellite operator for instructions on enabling CC
with their box.
●The TV’s CC button does not operate the Satellite or Cable box’s CC
function.
●For viewing the CC of digital broadcasting, set the aspect to Full (If
viewing with H-FILL, JUST, ZOOM or 4:3; characters might be cut off).
●If the CC is set to On on both the receiver and TV when the signal is
480i (except for the HDMI connection), the CC may overlap on the TV.
●If a digital program is being output in analog format, the CC data will
also be output in analog format.
●If the recorder or output monitor is connected to the TV, the CC needs to
be set up on the recorder or output monitor.
