Panasonic TX-33AK10P User manual

Service Support
Service and repair of this
product is supported by
Panasonic's LUCI interface.
This interface provides
a link between the TV and
a standard PC to allow a
number of diagnostic and
control functions to be
performed.
For more details contact
your local Panasonic company.
TX-33AK10P Service Manual
Specifications Parts List
Safety Block
Diagrams
Exploded
View
PCB
Views
Service
Information
Schematic
Diagrams
BACK
EXIT

Colour Television
TX-33AK10P
EURO-5 Chassis
SPECIFICATIONS
Power Source: 220-240V a.c., 50Hz
Power Consumption: 290W
Stand-by Power
Consumption: 1,9W
Aerial Impedance: 75Ωunbalanced, Coaxial Type
Receiving System: PAL B/G, H, D/K, PAL-525/60
SECAM B/G, D/K
M.NTSC
NTSC (AV only)
Receiving Channels:
VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV S1-S10 (M1-M10)
CATV (S01-S05) CATV S11-S20 (U1-U10)
CATV S21-S41 (HYPERBAND)
Intermediate Frequency:
Video/Audio
Video 38,9MHz
Audio 32,9MHz, 33,16MHz, 33,4MHz
40,4MHz, 32,4MHz (A2 STEREO)
33,05MHz (NICAM)
32,66MHz, 32,4MHz (CZECH STEREO)
Colour 34,47MHz (PAL)
34,5MHz, 34,65MHz (SECAM)
Terminals:
AV1 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin)
AV1 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV2 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
S-Video IN Y: 1V p-p 75Ω
(21-pin) C:0,3V p-p 75Ω
AV2 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
Selectable output (21 pin)
AV3 IN S-Video IN Y: 1V p-p 75Ω
(4-pin) C: 0,3V p-p 75Ω
Audio (RCAx2) 500mV rms 10kΩ
Video (RCAx1) 1V p-p 75Ω
AV4 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
S-Video IN Y: 1V p-p 75Ω
(21-pin) C:0,3V p-p 75Ω
AV4 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
Dolby Surround out: 6 x Dolby Surround Out RCA
External Speaker
Connections : 2 x Rear 2 x Front
High Voltage: 32kV ±1kV
Picture Tube: M79LQM185X05 79cm
Audio Output: 2 x 20W Left/Right
14W Centre
8ΩImpedance
Headphones: 8ΩImpedance
3,5mm
Accessories
supplied : Remote Control
2 x R6 (UM3) Batteries
Dimensions:
Height: 651mm
Width: 790mm
Depth: 555mm
Net weight: 66kg
Specifications are subject to change without notice.
Weights and dimensions shown are approximate.
NOTE: This Service Manual should be used in conjunction with
the EURO-5 Technical guide.
ORDER No. SM-99061

CONTENTS
SAFETY PRECAUTIONS..........................................................................................................................................................2
SERVICE HINTS.......................................................................................................................................................................3
SERVICE POSITION.................................................................................................................................................................4
ADJUSTMENT PROCEDURE AND SELF CHECK...................................................................................................................5
WAVEFORM PATTERN TABLE ...............................................................................................................................................6
ALIGNMENT SETTINGS...........................................................................................................................................................7
BLOCK DIAGRAMS..................................................................................................................................................................8
PARTS LOCATION.................................................................................................................................................................12
REPLACEMENT PARTS LIST................................................................................................................................................13
SCHEMATIC DIAGRAMS.......................................................................................................................................................33
CONDUCTOR VIEWS.............................................................................................................................................................41
SAFETY PRECAUTIONS
GENERAL GUIDE LINES
1. It is advisable to insert an isolation transformer in the
a.c. supply before servicing a hot chassis.
2. When servicing, observe the original lead dress in the
high voltage circuits. If a short circuit is found, replace
all parts that have been overheated or damaged by
the short circuit.
3. After servicing, see that all the protective devices
such as insulation barriers, insulation papers, shields
and isolation R-C combinations are correctly
installed.
4. When the receiver is not being used for a long period
of time, unplug the power cord from the a.c. outlet.
5. Potentials as high as 33kV are present when this
receiver is in operation. Operation of the receiver
without the rear cover involves the danger of a shock
hazard from the receiver power supply. Servicing
should not be attempted by anyone who is not
familiar with the precautions necessary when working
on high voltage equipment. Always discharge the
anode of the tube.
6. After servicing make the following leakage current
checks to prevent the customer from being exposed
to shock hazard.
LEAKAGE CURRENT COLD CHECK
1. Unplug the a.c. cord and connect a jumper between
the two prongs of the plug.
2. Turn on the receiver’s power switch.
3. Measure the resistance value with an ohmmeter,
between the jumpered a.c. plug and each exposed
metallic cabinet part on the receiver, such as screw
heads, aerials, connectors, control shafts etc. When
the exposed metallic part has a return path to the
chassis, the reading should be between 4M ohm and
20M ohm. When the exposed metal does not have a
return path to the chassis, the reading must be
infinite.
LEAKAGE CURRENT HOT CHECK
1. Plug the a.c. cord directly into the a.c. outlet. Do not
use an isolation transformer for this check.
2. Connect a 2kΩ10W resistor in series with an
exposed metallic part on the receiver and an earth,
such as a water pipe.
3. Use an a.c. voltmeter with high impedance to
measure the potential across the resistor.
4. Check each exposed metallic part and check the
voltage at each point.
5. Reverse the a.c. plug at the outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed
1,4Vrms. In case a measurement is outside the limits
specified, there is a possibility of a shock hazard, and
the receiver should be repaired and rechecked before
it is returned to the customer.
X-RADIATION WARNING
1. The potential sources of X-Radiation in TV sets are
the high voltage section and the picture tube.
2. When using a picture tube test jig for service, ensure
that the jig is capable of handling 33kV without
causing X-Radiation.
NOTE: It is important to use an accurate periodically
calibrated high voltage meter.
1. Set the brightness to minimum.
2. Measure the high voltage. The meter should indicate.
32kV ± 1kV.
If the meter indication is out of tolerance, immediate
service and correction is required to prevent the
possibility of premature component failure.
3. To prevent any X-Radiation possibility, it is essential
to use the specified tube.
HOT CHECK CIRCUIT
a.c. VOLTMETER
WATER PIPE
(EARTH)
TO INSTRUMENT’S EXPOSED
METALLIC PARTS Fig. 1.
2kΩ10 Watts
2

SERVICE HINTS
How to remove the rear cover
1. Remove the 10 screws as shown in Fig.2.
LOCATION OF CONTROLS
3
SCREWS
(A) SCREWS
(A)
Fi
g
.2.
Y-Board
E-Board D-Board
Z-Board
H-Board
F-Board
Q-Board
M-Board
V-Board
N-Board
Screen
Focus
Concentration
K-Board
G-Board

HOW TO MOVE THE CHASSIS INTO SERVICE POSITION
1. Remove the bead clamper from the mains lead and affix, using back cover screw, into top right-hand cabinet rib (A),
shown in Fig.3.
2. Remove 2 screws (B), as shown in Fig.4, and remove speaker assembly.
3. Hold and lift the rear of the chassis and gently pull the chassis toward you, as shown in Fig.3.
4. Release the respective wiring clips and rotate the chassis vertically through 90°, anti-clockwise.
5. Locate the base of the chassis frame into location (C), shown in Fig.5 / Fig.7.
6. Clip the chassis frame onto the bead clamper, shown in Fig.5 / Fig.6.
7. After servicing replace the bead clamper and speaker, and ensure all wiring is returned to its original position before
returning the receiver to the customer.
4
Fig.3.
Fig.6.
(A)
Fig.7.
Fig.4.
Screws
Vis
(B)
Fig.5. (C)

ADJUSTMENT PROCEDURE
Item / Preparation Adjustments
+B SET-UP
1. Receive a Greyscale signal.
2. Set the controls :-
Brightness Minimum
Contrast Minimum
Volume Minimum
1. Set the +B voltage up as follows:-
Adjust R811 so that B2 shows 148V±1V.
Confirm the following voltages.
D3 PIN5 147V ± 3V U8A E19-PIN8 8V ± 0,5V
D12 PIN5 5V ± 0,3V U9 IC3801-PIN3 9V ± 0,5V
D13 PIN1 40V ± 4V U12 E22-PIN8 12V ± 0,5V
D3 PIN4 225V ± 10V STD5V E26-PIN4 5V ± 0,5V
D14 PIN5 5V ± 0,5V U15 E23-PIN8 15V ± 1V
D12 PIN7 15V ± 2V -U15 E23-PIN9 -15V ± 2V
D12 PIN9 -15V ± 2V U33 E22-PIN10 33V ± 4V
D11 PIN8 12V ± 2V U40 E24-PIN1 40V ± 3V
D11 PIN10 33V ± 3V U5B E19-PIN5 5V ± 0,5V
Cut-Off
1. Receive a Greyscale signal.
2. Degauss the tube externally.
3. Set the TV into Service Mode 1.
4. Select Cut off mode.
Adjust the screen VR until the display shows "O.K."
SELF CHECK
Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To get into the Self-Check mode
press the down (-/v) button on the customer controls at the front of the set, at the same time pressing the STATUS
button on the remote control, and the screen will show: -
If the CCU ports have been checked and found to be incorrect or not located then " - - " will appear in place of "O.K.".
Service Aids
To aid in the service of our current chassis there are a number of Service Aids which have been made available.
•LUCI interface kit (Linked Utility Computer Interface)
Part number: TZS6EZ002
This contains interface and cables for connecting TV service connector and a PC as well as diagnostic software. As new
models are introduced upgrade software will become available.
•VICI (Visual Interactive Computer Information)
These C.D.'s contain multimedia documentation providing quick access to service information.
Part No. TZS7EZ006, TZS7EZ005 & TZS8EZ001
1. Service Manuals
2. Instruction Books
3. Technical Information
•TASMIN (Technically Advanced System for Multimedia Interactive Notes)
As well as providing a first step towards more interactive training this product also achieves quick access to Technical
Information.
5
VPC O.K.
TUN O.K.
E2 O.K.
DPL O.K.
CIP1 O.K.
CIP2 O.K.
VP O.K.
DFU O.K.
COL - -
PIP - -
DIS O.K.
PCB O.K.
Cab O.K.
Sum Factory use only
OPTION 1 BD
OPTION 2 3C
OPTION 3 1F
OPTION 4 67
OPTION 5 FF
OPTION 6 63

WAVEFORM PATTERN TABLE
6
B - Out
IC601 Pin 42
2.2V
32µS
R - Out
IC601 Pin 40
32µS
2.2V
G - Out
IC601 Pin 41
2.2V
32µS
Vert Drive
IC451 Pin 2
8mS
63V
Vert Out
IC601 Pin 1
8.6mS
0.6V
VFLB
IC451 Pin 5
1V
8.6mS
Video In
IC1101 Pin 68
0.9V
64µS
H - Out
IC601 Pin 8
3.9V
32µS
HFLB
IC601 Pin 13
32µS
7V
32µS
1V
R - Y
IC601 Pin 26
Luminance In
IC601 Pin 28
0.9V
32µS
B - Y
IC601 Pin 27
32µS
1.3V
28µS
6V
H - Out
IC3901 Pin 3 V - Out
IC3901 Pin 21
0.1V
32µS
E/W - Out
IC601 Pin 3
280mV
8.5mS
NOTE: All waveforms have been taken using a standard colour bar pattern.

ALIGNMENT SETTINGS:
(The figures below are nominal and used for representative purposes only.)
1. Set the Bass to maximum position, set the Treble to minimum position, press the down button (- / v) on the customer
controls at the front of the TV and at the same time press the INDEX button on the remote control, this will place the TV
into the Service Mode.
2. Press the RED / GREEN buttons to step up / down through the functions.
3. Press the YELLOW / BLUE buttons to alter the function values.
4. Press the STR button after each adjustment has been made to store the required values.
5. To exit the Service Mode, press the "N" button.
Alignment Function Settings / Special features
Horizontal Position H-Pos
+020 Optimum setting.
Vertical Position V-Pos
+024 Optimum setting.
Horizontal Amplitude H-Amp
+049 Optimum setting.
Vert. Amplitude V-Amp
+029 Optimum setting.
EW-amplitude E/W-Amp1
+022 Optimum setting.
EW-amplitude E/W-Amp2
+000 Optimum setting.
Trapezium-comp Trapez-1
+033 Optimum setting.
Horizontal-Parallel H-Parallel
+032 Optimum setting.
Vertical Linearity V-Lin
+004 Optimum setting.
DVCO DVCO
000
Receive a PAL Colour Bar Pattern. For
DVCO alignment press "Blue" button, wait
until the colours are stable and press
"STR".
Cut-off DC Cut-off
O.K.
To adjust Cutoff adjust the screen VR until
the display shows "O.K."
Highlight High 0031 0031 0031
Contrast Maximum
A.I. Off
Optimum setting.
Sub-Brightness Sub-Brightness
000 Optimum setting.
7

, &    
$9 &LQ
0DLQ <9 $9 2XW 0DLQ &RXW 9RXW &RXW $9
79,Q
$9

,Q $9 9LQ $9 &LQ $9 9LQ $9 &LQ $9 9LQ
       
         

4    
 
 


4    
4    
4     4    4
   
4    
4    
, &    
& 9 % 6
, Q5
* %
 
    
     
 

  
 
 
 
 
 
 



 



 
  
 
   



(  
( 

(  
(  
(  
      

      

 

(  
   

, &   
5 *
%

< %    <
5    <5
R*
R%
R
)  
   

4    
4    
   
9 L Q 
& L Q 
3 L Q V       
      
3 L Q V       
      
9 3 &
, &    
)  
 

4    
4    
4    
4    
4    
4    
3 L Q V        3 L Q V       
5 * %
   
 
3 L Q V         
        
3 L Q V       
        
& , 3
, &    
      
3 L Q V         
        
3 L Q V         
9 3  6
, &    
3 L Q V       
3 L Q V       
' ) 8
, &    
              
3 L Q V
0 H P R U \
, &    
     
3 L Q V
 Q G & , 3
, &    
              
              
           
3 L Q V
         
      
3 L Q V
    
      
         
3 L Q V
     
      
3 L Q V
     
        
3 L Q V
     
3 L Q V
      
      
3 L Q V
3 L Q V       
      
3 L Q V       
      
  
      
3 L Q V
      
4    
4    
4    
4     4    
4    
4    
4    
4    
+  

      

+  
      
   
 
 
$ 9 
   
4    
4    
 
      
$ 9 
$ 9 

0  
 
9 &
< $ 9 
< 

 

, &   
5 R X W
, &   
% R X W
, &   
* R X W
 

 

4    
4    
&     &  <     < 
8 9     8 9 
<     < 
<     < 
8 9     8 9 
8 9     8 9 
<     < 
+ ' 5 L Q      
/ ' 5 R X W     
/ ' 5 L Q      
< R X W 8 R X W
9 R X W
0    % R D U G
+    % R D U G
<    % R D U G
(    % R D U G
)    % R D U G
        
4    
9 L Q & L Q
9 R X W
9 L Q & L Q
9 R X W
9 L Q
5 L Q 9 R X W * L Q % L Q
7 X Q H U  , )
& 5 7

9,'(2 %/2&. ',$*5$0


, &     0 6 3
,6&/ ,6:6 ,6', ,6'2 +3B5
+3B/
63.
 
6& 6&
 
 
 
 
   
 
4   




(  
(  
  
 
(  
 
(  
(  
 
      
*  
  
 
  
*  
 
, &    


$ 9 
 
0  
  
5
/ $ 9 
0    % R D U G
*    % R D U G
(    % R D U G
       
 
 
 
 
 
 
       
5 63. /
6& 6&
6& 6&
6& 6& 6&
/LQ
5LQ /LQ 5LQ /LQ 6& 5LQ 6& /LQ 6& 5LQ 0RQR 063
5RXW /RXW
/RXW 5RXW
4   
4   

   
 


 
           
 
 
  
  


 
 
 
 
 

    
, &   
/LQ
5LQ 5RXW
/RXW
4    
4    
4   
4   
  ( 
7 R 6 3 .
     
, &    
/LQ
5LQ 5RXW
/RXW
4    
4    
 
 
 
   +
 3 
 
 
 
 
 
 
 
         
,6&/
,6:6
,6'2
,6',
4    
4    
4    
6/$
&$
:RRIHU
' 3 /
 
 
 
 
 
   
 
+  
         
 
 
+  
          
 




$ 9 




$ 9 





   
   
 
 



  
     


   
  
   
 

4    
4    
4    
4    
4    
, &    
, &    
6 5 6 /
/ 5
&6
:
  ( 
  +    + 
  + 
(  

.  
  . 
, &    
, &    
, &    
, &    
, &    
 
 
 
 
 

. 
4    
4    
4    
4    
4    
4    
7 R  '
6 3 .
/
5
& H Q W U H    /
6 5
6 / : R R I H U
7 R 6 X U U R X Q G
6 3 .
- .    
6 :
5 5 5 /
&
5
/
- .     - .    
/ 5
5 R
5 L / L
/ R
5 R
5 L / L
/ R
5 R
5 L / L
/ R
+    % R D U G
.    % R D U G
/
5
6    
4    
7 X Q H U  ,  ) 
;   
;   
= 
= 




, &    
, &    
/5
 


 


=    % R D U G
=  = 
 
5 0 L F  , Q
/ 0 L F  , Q
(  
(  
   
& H Q W U H    5
$8',2 %/2&. ',$*5$0

(  
(  
 (  
 
(  
(  
     
   
*  

*  
 
+  

 

+  
     
  
$ 9 


 
 
$ 9 
$ 9 

0  

0    % R D U G
+    % R D U G

, &    
4   

 
5HVHW
'.,

:5
5'

$     $  
36(1
 
     
      
      
 
    
'     ' 
 
)  % / .
     
 
     
 
$     $  
 
: 5
 
      
      5
'
4     4 
, &    
6 5 $ 0
     
 
     
$     $  
3 6 ( 1

      
      
4     4 
, &    
( 3 5 2 0
   
 
 
//
3261(*
/('
+392/
//
31
7 X Q H U
 
, &    

+ 3  $ 0 3
9 R O
 

6 ' $ 
6 & / 
 

6 ' $ 
6 & / 
6&/
6'$
 
 
4    
4    
, &   
, &    
, &    
, &    
6 0 R G H

* ( 2 0 $ *
 
3 U R W H F W

5 &
 
$ 9 / L Q N , Q

$ 9 / L Q N 2 X W

6 O R Z 
 
$)&
.H\6FDQ
   
6ORZ
 
6ORZ
9'HW
 
 
567
 
21
 
)6:
 
6&/
 
6'$
 
567

 
6&/
6'$
 


6&/
6&/
6'$
6'$
4    

, &    
$)&
6'$
6&/
4    
4    
4    
4    
, &    
'   
(  
 
 

 
(  
)  

)  
 
(  
 

(  
 






, &    

4    
4    
4   
4    
4    
9  3 U R W
  9 3 U R W 
 9 3 U R W
0 L F U R S U R F H V V R U
, &    
 
 


*    % R D U G
, &    
 
567
 
 
6&/
6'$
, &    
 
567
 
 
6&/
6'$
, &    
  
567
   
6&/
6'$
, &    
567
 
, &    
 
567


6&/
6'$
, &    
 
567
 
 
6&/
6'$
)    % R D U G
4   
4    4   
'    % R D U G
(    % R D U G
4    
0  
    9
3 U R W H F W L R Q
' $ )
4    
3 U R W H F W L R Q
4   
     9 3 U R W
      
6 O R Z 6 :
6 O R Z
6 :
$ 9/
L Q N
6 O R Z6
:
6 ' $  6 & / 

, &    
 Y
1    % R D U G
'    
6 Z L W F K L Q J
0 D W U L [
9 

1 

4    
 
0  
1 
9    % R D U G
 
&21752/ %/2&. ',$*5$0

32:(5 6833/<  '()/(&7,21 %/2&. ',$*5$0

0   
0  
9 & &
1  
9  
1  
) U R P (  
, &    
9   % R D U G
1 1

$ & , Q
(   
=   % R D U G
= 

, &    
'    
4   
4   
4   
4   
4   
4    
4    
4    
4    
4    
4    
4    
4    
4   
4   
4   
4   
4    4   
4   
4   4
   
4    
4   
4   
4    
4    
4    
4    
4    
4    
4   
4   
4   
'    
4    
4    
, &    
' 3 /
, &    
 Q G & , 3
, &    
' ) 8
, &    
& , 3
, &    
9 3 &
, &    
, &    
9 3 6 
, &    
0 H P R U \
, &    
, &     , &   
, &    
, &    
, &    
, &   
, &    
, &    
, &    
, &    
, &    
, &    
, &    
, &    
, &    
, &    
, &   
7 X Q H U
, &    
, &    
, &     , &    
, &     , &    
, &    
, &    
, &    
, &    , &   
, &   
, &   
, &    
, &   
, &   
7   
7   
7    
7   
7   
1   % R D U G
0   % R D U G
*   % R D U G
)   % R D U G
(   % R D U G
'   % R D U G
.   % R D U G
+   % R D U G
<   % R D U G
'   
'   
'   
W R 0  
7   

PARTS LOCATION
12
NOTE:
The numbers on the exploded view below
refer to the mechanical section of the
Replacement Parts List.
35
5
30
17
1
9
6
16
8
12
7
13
33
32
15
36
29
31
19
20
11
28
22
21
23
18
2
26
10
4
34
25
37
24
27
3
14

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Im
p
ortant Safet
y
Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
MECHANICAL PARTS
LEFT SPEAKER1 EAB10106BL RIGHT SPEAKER2 EAB10106BR CENTRE SPEAKER3 EASG12D123L2 TUNER4 ENG29505GR REMOTE CONTROL5 EUR511211 C.R.T.6 M79LQM185X05 PANASONIC BADGE7 TBMA059 POWER BUTTON8 TBXA20001 CRT FIXING SCREW9 THT1062 REAR AV COVER10 TKP8E1243 DOOR LID RIGHT11 TKPA28402 DOOR LID LEFT12 TKPA28502 FRONT PANEL13 TKPA28603 CABINET HANDLE14 TKRA14102 BACK COVER15 TKUC06603 CABINET16 TKYA11908 DEGAUSS COIL17 TLK8E05151 CONTROL BRACKET18 TMW8E040 CHASSIS FRAME19 TMX8E034 M P.C.B.20 TNP8EM019AB N P.C.B.21 TNP8EN018AD Q P.C.B.22 TNP8EQ002AA V P.C.B.23 TNP8EV004AA Z P.C.B.24 TNP8EZ001AF D P.C.B.25 TNPA0876AJ G P.C.B.26 TNPA0877AD K P.C.B.27 TNPA1046AD H P.C.B.28 TNPA1047AF F P.C.B.29 TNPA1068AC Y P.C.B.30 TNPA1353AM E P.C.B.31 TNPH0176BK MODEL LABEL32 TQF8E2826 POWER CORD33 TSX8E0033 FOCUS LEAD ASSY34 TXFYA010BXQG BATTERY COVER (REMOTE)35 UR51EC904A ANODE LEAD36 ZTBZAD650A F.B.T.37 ZTFL77002A
MISCELLANEOUS COMPONENTS
FIX CLIP31221212478 IC SOCKET832AG11D-ESL 84 PIN IC SOCKETPLCC-84-T SET FOOT (FRONT)TBLG019 SET FOOT (REAR)TBLG3020 AV PANEL LABELTBM8E1915 PRESET LABEL RIGHTTBM8E1930 PRESET LABEL LEFTTBM8E1931 LID CATCHTEK6940 CRT EARTH SPRINGTES2298 POWER BUTTON SPRINGTES8E019 FIXING SPRINGTESA031 ORNAMENTAL PANELTKPA28701
GEOMAGNETIC COILTLK8E05124 CANCELLATION COILTLK8E05150 P.C.B. BRACKETTMX8E025 POWER BUTTON JOINTTMX8E035 OUTER CARTONTPC8E4777-1 TOP CUSHIONTPD8E701 BOTTOM CUSHIONTPD8E702 BATTERY PACKUM-3DJ-2P THERMISTORR842 232266296706 THERMISTORR843 232266296706 RELAYRL801 TSE1885-1
INSTRUCTION BOOKS
BULG./ROMANIANTQB8E2746MN POLISH/HUNGARIANTQB8E2746PQ CZECH/ENGLISHTQB8E2746RU
I.C.s
AUDIO OUTPUTIC251 LA4282 RGB OUTPUTIC351 TDA6111Q-N4 RGB OUTPUTIC361 TDA6111Q-N4 RGB OUTPUTIC371 TDA6111Q-N4 REGULATORIC381 TL431ACLPM VERTICAL OUTPUTIC451 LA7845N VIDEO PROCESSORIC601 TDA9330HN1G
POWER SUPPLYIC801 AN8029 ERROR AMPLIFIERIC845 SE140N REGULATORIC852 TL431ACLPM LED RECEIVERIC1051 RPM6937-S MICRO PROCESSORIC1101 SDA5450C47-1 EAROM *IC1102 X24C0501WP SRAMIC1103 KM681000CLP EPROM *IC1104 27C2001-K06 RESETIC1105 MN1381-T(TA) RESETIC1106 MN1381-R(TA) VPCIC1502 VPC3215CB4TP CIPIC1503 MB87F1720 DFUIC1504 FJB007S VP2SIC1505 MB87F2131 3.5V REGULATORIC1506 AN77L035M-E1 MEMORYIC1507 MB87H2010 CLOCK CONVERTORIC1509 TLC2932IPWL CIPIC1510 MB87F1720 EARTH CORRECTIONIC1901 LA6515 AUDIO PROCESSORIC2101 MSP3410DPPB4 OPERATIONAL AMPLIFIERIC2201 AN6554NSF-E2 OPERATIONAL AMPLIFIERIC2221 AN6554NSF-E2 H.P. AMPLIFIERIC2351 AN7108 OPERATIONAL AMPLIFIERIC2401 AN6554NSF-E2 AMPLIFIERIC2402 BA15218F-E2 DOLBY PROCESSORIC2501 DPL3519APOA2 POWER SUPPLYIC2551 STR10006-S AUDIO AMPLIFIERIC2630 TDA2030AV AUDIO AMPLIFIERIC2640 TDA2030AV
13

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
AUDIO AMPLIFIERIC2650 TDA2030AV AUDIO AMPLIFIERIC2660 TDA2030AV AUDIO AMPLIFIERIC2670 TDA2030AV VIDEO SWITCHIC3001 TEA6415C 9V REGULATORIC3801 AN7809FLB 8V REGULATORIC3802 AN7708FLB 8V REGULATORIC3805 AN7808LB 3.5V REGULATORIC3806 SI-3033C DYNAMIC FOCUSIC3901 AN5422K
FUSES
FUSEF840 XBA2C50TH15 FUSEF845 TR5-T3150 FUSEF846 TR5-T1250 FUSE HOLDERF8401 EYF52BC FUSE HOLDERF8402 EYF52BC
DIODES
DIODED001 MA4020 DIODED002 MA4020 DIODED252 MA165TA5 DIODED253 MA700TA5 DIODED254 MA700TA5 DIODED255 MA165TA5 DIODED256 MA165TA5 DIODED287 MA4200 DIODED351 ERA15-04V3 DIODED352 ERA15-04V3 DIODED361 ERA15-04V3 DIODED362 ERA15-04V3 DIODED371 ERA15-04V3 DIODED372 ERA15-04V3 DIODED373 MTZJT-7715A DIODED374 MTZJT-7715A DIODED375 MTZJT-7715A DIODED387 MA2160LFS DIODED400 MA4104 DIODED401 MA165TA5 DIODED402 MA165TA5 DIODED404 EU02AV1 DIODED405 MA165TA5 DIODED408 MA165TA5 DIODED502 1SS254T-77 DIODED503 EU02 DIODED504 EU02 DIODED505 ERA81004V3 DIODED556 AU02V0 DIODED559 MTZJT-7736A DIODED560 1SS252T-77 DIODED563 RH3GLF102 DIODED571 FMV-3GULF730 DIODED575 1SS252T-77 DIODED601 MA29TA5 DIODED603 MA4075 DIODED605 MA4062 DIODED607 MA165TA5 DIODED610 MA4043 DIODED611 MA165TA5 DIODED612 MA165TA5 DIODED615 MA165TA5 DIODED616 MA178TA5 DIODED617 MTZJT-779.1C DIODED618 MTZJT-779.1C DIODED621 MTZJT-778.2A DIODED651 MA165TA5 DIODED652 MA165TA5 DIODED653 MA4360 DIODED654 MTZJT-777.5B
DIODED701 AU02V0 DIODED703 MA29TA5 DIODED803 MTZJT-7712C DIODED806 TF361MALF3 DIODED807 RBV-608LF-B DIODED808 MA165TA5 DIODED809 ERA22-02V3 DIODED810 MA2180BLFS DIODED812 MTZJT-775.6B DIODED813 MA700TA5 DIODED814 AU01ZV0 DIODED815 PC123FY2 DIODED817 D5L60F4015 DIODED818 TMPG10G3 DIODED819 ERA81004V3 DIODED820 MA4100 DIODED821 EU02AV0 DIODED845 MA165TA5 DIODED846 EK04V0 DIODED847 ERA15-01V3 DIODED848 EU02 DIODED849 FMGG26S DIODED850 ERB32-02E DIODED851 FMGG2CSLF116 DIODED852 MA4062 DIODED853 1N4150T-77 DIODED854 ERA15-01V3 DIODED855 D10SC6MRL DIODED856 MA165TA5 DIODED857 FML22SLF610 DIODED860 1SS254T-77 DIODED861 MTZJT-775.1C DIODED866 MTZJT-7727D DIODED901 1SS254T-77 DIODED902 1SS254T-77 DIODED903 1SS254T-77 DIODED910 R2KNLFA1 DIODED1011 LN81RPHL DIODED1102 MA4051 DIODED1103 MA4051 DIODED1104 MA165TA5 DIODED1105 MA165TA5 DIODED1107 MA165TA5 DIODED1109 MA165TA5 DIODED1110 MA165TA5 DIODED1112 MA165TA5 DIODED1501 MA151ATX DIODED2101 MTZJT-7712C DIODED2102 MTZJT-7712C DIODED2351 MTZJT-775.6B DIODED2401 MA165TA5 DIODED2403 MTZJT-7712C DIODED2404 MTZJT-7712C DIODED2405 MTZJT-7712C DIODED2406 MTZJT-7712C DIODED2407 MTZJT-7712C DIODED2408 MTZJT-7712C DIODED2551 D5L60F4015 DIODED2552 TVSEH1LF-F7 DIODED2553 MTZJT-778.2A DIODED2554 EU02 DIODED2555 EU02 DIODED2556 EG01CV0 DIODED2558 EU02 DIODED2559 RU4AMLF-M1 DIODED2560 MTZJT-7727D
14

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
DIODED2611 MA165TA5 DIODED2616 MA165TA5 DIODED2619 MA165TA5 DIODED2621 MA165TA5 DIODED2622 MA165TA5 DIODED2623 MA165TA5 DIODED2624 MA4200 DIODED2630 MA165TA5 DIODED2631 MA165TA5 DIODED2640 MA165TA5 DIODED2641 MA165TA5 DIODED2650 MA165TA5 DIODED2651 MA165TA5 DIODED2660 MA165TA5 DIODED2661 MA165TA5 DIODED2670 MA165TA5 DIODED2671 MA165TA5 DIODED2672 MA165TA5 DIODED3006 MA4100 DIODED3008 MA723TA5 DIODED3009 MA170 DIODED3011 MA858TA5 DIODED3351 1SS254T-77 DIODED3352 MA165TA5 DIODED3353 MA165TA5 DIODED3354 MA165TA5 DIODED3401 MTZJT-7712C DIODED3402 MTZJT-7712C DIODED3803 MTZJT-774.7A DIODED3804 MTZJT-778.2A DIODED3805 ERA81004V3 DIODED3901 MTZJT-779.1C DIODED3907 ERA22-06V3 DIODED3908 ERA22-06V3 DIODED3909 MA165TA5 DIODED3910 RP1HLFA5 DIODED3911 RP1HLFA5 DIODED3912 1SS254T-77 DIODED3915 MTZJT-7710D DIODED3917 MA165TA5 DIODED3990 MTZJT-7724D
TRANSISTORS
TRANSISTORQ101 BC847B TRANSISTORQ103 BC847B TRANSISTORQ104 BC847B TRANSISTORQ251 2SD1328STX TRANSISTORQ252 2SD1328STX TRANSISTORQ253 BC847B TRANSISTORQ254 BC857B TRANSISTORQ400 BC847B TRANSISTORQ401 BC847B TRANSISTORQ502 2SC2925STA TRANSISTORQ552 2SC5144LB230 TRANSISTORQ553 2SC1473-RN TRANSISTORQ554 2SC1473-RN TRANSISTORQ602 BC857B TRANSISTORQ603 BC857B TRANSISTORQ604 BC857B TRANSISTORQ607 BC857B TRANSISTORQ608 BC857B TRANSISTORQ701 2SK2538000LB TRANSISTORQ801 2SK1365LB106 TRANSISTORQ803 2SD965-R TRANSISTORQ804 2SA719-TA TRANSISTORQ845 2SA684R TRANSISTORQ846 BC847B
TRANSISTORQ847 BC857B TRANSISTORQ848 BC847B TRANSISTORQ849 2SA1018QTA TRANSISTORQ850 2SD1474PLB TRANSISTORQ852 2SC1318-S TRANSISTORQ853 BC857C TRANSISTORQ854 BC857C TRANSISTORQ902 BC847B TRANSISTORQ903 BC847B TRANSISTORQ904 BC857B TRANSISTORQ905 BC847B TRANSISTORQ906 BC847B TRANSISTORQ907 BC857B TRANSISTORQ908 2SA1535ARLB TRANSISTORQ909 2SC3944ARLB TRANSISTORQ1011 BC557B/126 TRANSISTORQ1103 BC847B TRANSISTORQ1104 BC847B TRANSISTORQ1105 BC847B TRANSISTORQ1106 BC847B TRANSISTORQ1107 BC847B TRANSISTORQ1108 BC847B TRANSISTORQ1109 BC847B TRANSISTORQ1110 BC847B TRANSISTORQ1111 BC847B TRANSISTORQ1112 BC847B TRANSISTORQ1113 BC847B TRANSISTORQ1116 BC847B TRANSISTORQ1118 BC857B TRANSISTORQ1501 BC857B TRANSISTORQ1502 BC857B TRANSISTORQ1503 BC847B TRANSISTORQ1504 BC847B TRANSISTORQ1505 BC847B TRANSISTORQ1506 BC847B TRANSISTORQ1507 BC847B TRANSISTORQ1508 BC847B TRANSISTORQ1509 BC847B TRANSISTORQ1510 BC847B TRANSISTORQ1511 BC847B TRANSISTORQ1513 BC857B TRANSISTORQ1660 BC847B TRANSISTORQ1661 BC847B TRANSISTORQ1662 BC847B TRANSISTORQ1663 BC847B TRANSISTORQ1664 BC847B TRANSISTORQ1665 BC847B TRANSISTORQ1666 BC847B TRANSISTORQ1667 BC847B TRANSISTORQ1901 BC847B TRANSISTORQ2101 BC860B TRANSISTORQ2102 BC860B TRANSISTORQ2103 BC860B TRANSISTORQ2201 BC847B TRANSISTORQ2202 BC847B TRANSISTORQ2301 BC847B TRANSISTORQ2302 BC847B TRANSISTORQ2305 BC857B TRANSISTORQ2307 BC860B TRANSISTORQ2308 BC860B TRANSISTORQ2351 BC847B TRANSISTORQ2352 BC847B TRANSISTORQ2401 BC847B TRANSISTORQ2407 BC847B TRANSISTORQ2408 BC847B TRANSISTORQ2409 BC847B
15

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
TRANSISTORQ2410 BC847B TRANSISTORQ2411 BC847B TRANSISTORQ2412 2SD1328STX TRANSISTORQ2502 BC857B TRANSISTORQ2506 BC857B TRANSISTORQ2507 BC857B TRANSISTORQ2554 2SA684R TRANSISTORQ2555 BC557B/126 TRANSISTORQ2610 2SD1328STX TRANSISTORQ2611 BC857B TRANSISTORQ2615 2SD1328STX TRANSISTORQ2616 BC857B TRANSISTORQ2620 2SD1328STX TRANSISTORQ2621 BC857B TRANSISTORQ3001 BC857B TRANSISTORQ3002 BC847B TRANSISTORQ3003 BC847B TRANSISTORQ3005 BC847B TRANSISTORQ3006 BC847B TRANSISTORQ3007 BC847B TRANSISTORQ3008 BC847B TRANSISTORQ3010 BC857B TRANSISTORQ3011 BC857B TRANSISTORQ3012 BC847B TRANSISTORQ3013 BC847B TRANSISTORQ3014 BC847B TRANSISTORQ3351 BC847B TRANSISTORQ3352 BC857B TRANSISTORQ3401 BC847B TRANSISTORQ3402 BC847B TRANSISTORQ3403 BC847B TRANSISTORQ3404 BC847B TRANSISTORQ3405 BC847B TRANSISTORQ3406 BC847B TRANSISTORQ3801 2SD1474PLB TRANSISTORQ3901 BC847B TRANSISTORQ3902 BC847B TRANSISTORQ3903 BC847B TRANSISTORQ3904 BC857B TRANSISTORQ3905 2SK1006RF122 TRANSISTORQ3906 2SC4572RB TRANSISTORQ3907 BC847B TRANSISTORQ3908 BC847B TRANSISTORQ3911 BC847B TRANSISTORQ3912 BC847B TRANSISTORQ3990 BC847B
TRANSFORMERS
TRANSFORMERT501 ETH19Y187AY TRANSFORMERT801 ETP35KAN619U TRANSFORMERT802 ETS49AH1W7AD TRANSFORMERT2552 ETS35AA457AD TRANSFORMERT3901 ETF18L37B
COILS
COILJ5 ELESN2R2KA COILJ341 EXCELSA39V COILJ361 EXCELSA39V COILJA1 ELJFC2R2KF COILJA10 ELJFC2R2KF COILL002 EXCELDR35V COILL003 EXCELDR35V COILL004 EXCELSA35T COILL005 TLT100K991R COILL007 EXCELDR35V COILL008 ELJFC2R2KF COILL009 ELJFC2R2KF COILL251 EXCELSA35T
COILL252 EXCELSA35T COILL253 EXCELSA35T COILL254 EXCELSA35T DELAY LINEL351 ELB4C070B DELAY LINEL361 ELB4C070B DELAY LINEL371 ELB4C070B COILL381 TLT220K991R COILL383 EXCELSA35T COILL501 ELELN101KA COILL554 EXCELSA35T COILL555 EXCELDR35V COILL556 EXCELDR35C COILL557 EXCELDR35C COILL572 ELHKLB061B COILL573 ELHKLB062B COILL575 ELC18B331F COILL601 EXCELDR25V COILL602 EXCELDR35V COILL603 TLT033K991R COILL604 ELEXT2R7KA COILL605 ELEXT2R7KA COILL606 ELEXT2R7KA COILL607 ELEXT2R7KA COILL701 ELC18B801L COILL806 EXCELSA39V COILL808 EXCELSA39V COILL809 EXCELDR35C COILL810 EXCELSA39V COILL811 EXCELSA39V COILL812 EXCELDR35V COILL813 EXCELDR35V COILL817 EXCELDR35V COILL819 EXCELSA39V COILL845 EXCELSA35T COILL847 EXCELSA35B COILL849 EXCELSA35T COILL854 ELEIE150KA COILL859 EXCELSA35T COILL860 EXCELSA35T COILL861 EXCELSA35T COILL910 EXCELSA35T COILL911 EXCELSA35T COILL912 EXCELSA35T COILL1101 EXCELDR35V COILL1103 TLT047K991R COILL1104 EXCELDR35V COILL1105 EXCELDR35V COILL1106 TLT047K991R COILL1507 TLT018K991R COILL1508 TLT033K991R COILL1509 EXCELDR35V COILL1510 EXCELDR35V COILL1511 TLT018K991R COILL1516 EXCELDR35V COILL1519 EXCEMT103DTM COILL1523 EXCEMT103DTM COILL1525 EXCEMT103DTM COILL1527 EXCEMT103DTM COILL1528 EXCELDR35V COILL1529 EXCELDR35V COILL1532 EXCELDR35V COILL1533 EXCELDR35V COILL1534 EXCELDR35V COILL1535 EXCELDR35V COILL1536 EXCELDR35V COILL1537 TLT100K991R
16

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COILL1538 TLT018K991R COILL1539 TLT033K991R COILL1540 TLT018K991R COILL1541 TLT033K991R COILL1542 TLT018K991R COILL1543 TLT033K991R COILL1901 EXCELDR25V COILL2101 TLT100K991R COILL2102 TLT039K991R COILL2103 TLT100K991R COILL2104 EXCELDR35V COILL2106 TLT068K991R COILL2201 EXCELDR35V COILL2381 EXCELSA35T COILL2382 EXCELSA35T COILL2401 EXCELSA35T COILL2402 EXCELSA35T COILL2403 EXCELSA35T COILL2404 EXCELSA35T COILL2409 EXCELSA35T COILL2410 EXCELSA35T COILL2411 EXCELSA35T COILL2412 EXCELSA35T COILL2413 EXCELSA35T COILL2414 EXCELSA35T COILL2502 EXCELDR35V COILL2503 EXCELDR35V COILL2504 EXCELDR35V COILL2505 EXCEMT103DTM COILL2506 EXCEMT103DTM COILL2551 EXCELSA35T COILL2552 EXCELSA35T COILL2553 EXCELSA35T COILL2555 EXCELSA35T COILL2556 EXCELSA35T COILL2560 EXCELSA35T COILL2561 EXCELSA35T COILL2670 5770206400 COILL2671 5770206400 COILL3001 TLT100K991R COILL3205 EXCELDR35V COILL3281 EXCELSA35T COILL3282 EXCELSA35T COILL3401 TLT015K991R COILL3402 TLT015K991R COILL3403 TLT015K991R COILL3404 TLT015K991R COILL3405 TLT015K991R COILL3406 TLT015K991R COILL3407 TLT015K991R COILL3408 TLT015K991R COILL3409 TLT100K991R COILL3410 TLT015K991R COILL3411 TLT015K991R COILL3412 TLT015K991R COILL3413 TLT015K991R COILL3801 EXCELDR35V COILL3901 EXCELSA35T COILL3902 ELC08D102E
FILTERS
LINE FILTERL840 ELF18N016A LINE FILTERL841 ELF18N016A LINE FILTERT803 ETQ24K37AY FILTERX101 EFCT6504BF CERAMIC FILTERX102 EFCT7004BF
CRYSTALS
CRYSTALX601 TSSA010 CRYSTALX1101 TSSA121 CRYSTALX1501 TSS2169-B CRYSTALX2101 4730007158 CRYSTALX2501 4730007158
RESISTORS
METALD2201 ERQ14AJW220 0.25W 5% 22
S.M.CARBJA1 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA1 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA2 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA2 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA3 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA3 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA4 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA4 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA5 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA5 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA6 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA6 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA7 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA8 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA8 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA9 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA10 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA11 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA12 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA13 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA13 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA14 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA14 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA15 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA16 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA18 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA19 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA20 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA21 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA23 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA24 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA26 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA27 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA29 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA30 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA31 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA33 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA35 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA36 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA37 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA38 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA39 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA40 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA41 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA42 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJC1 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE004 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE009 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE011 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE025 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE026 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE032 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE044 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE050 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJSE055 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF001 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF005 ERJ6GEY0R00 0.1W 5% 0
17

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBJSF006 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF007 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF009 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF010 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF013 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF015 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF017 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF018 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF019 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF020 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF021 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF022 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF023 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF024 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF025 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF026 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF027 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF028 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF029 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF032 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF034 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF037 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF039 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF041 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF042 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSF043 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSG9 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSG10 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSG14 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSH002 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSH009 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSK021 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSY03 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSY04 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSZ001 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSZ003 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSZ005 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR001 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR002 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR003 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR101 ERJ6GEYJ561 0.1W 5% 560
S.M.CARBR102 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR103 ERJ6GEYJ563 0.1W 5% 56K
S.M.CARBR104 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR105 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR106 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR107 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR109 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR110 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR111 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR251 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR252 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR253 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR254 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR255 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR256 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR257 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR258 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR259 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR260 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR261 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR262 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR263 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR264 ERJ6GEYJ473 0.1W 5% 47K
CARBONR265 ERDS1TJ2R2 0.5W 5% 2R2
CARBONR266 ERDS1TJ2R2 0.5W 5% 2R2
S.M.CARBR269 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR270 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR271 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR272 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR273 ERJ6GEYJ331 0.1W 5% 330
CARBONR299 ERD25TJ225 0.25W 5% 2M2
METALR350 ERQ12AJ331P .125W 5% 330
S.M.CARBR351 ERJ6GEYJ911 0.1W 5% 910
S.M.CARBR352 ERJ6GEYJ102 0.1W 5% 1K
METALR354 ERO25CKF4122 0.25W 5% 1K2
METALR355 ERG2FG823H 2W 5% 82K
S.M.CARBR356 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR357 ERJ6GEY0R00 0.1W 5% 0
SOLIDR358 ERC12GK471C 0.5W 5% 470
METALR360 ERO50PKF8251 0.5W 5% 8M2
S.M.CARBR361 ERJ6GEYJ911 0.1W 5% 910
S.M.CARBR362 ERJ6GEYJ102 0.1W 5% 1K
METALR364 ERO25CKF4122 0.25W 5% 1K2
METALR365 ERG2FG823H 2W 5% 82K
S.M.CARBR366 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR367 ERJ6GEY0R00 0.1W 5% 0
SOLIDR368 ERC12GK471C 0.5W 5% 470
S.M.CARBR369 ERJ6GEY0R00 0.1W 5% 0
METALR370 ERQ2CJP2R2 2W 5% 2R2
S.M.CARBR371 ERJ6GEYJ911 0.1W 5% 910
S.M.CARBR372 ERJ6GEYJ102 0.1W 5% 1K
METALR374 ERO25CKF4122 0.25W 5% 1K2
METALR375 ERG2FG823H 2W 5% 82K
S.M.CARBR376 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR377 ERJ6GEY0R00 0.1W 5% 0
SOLIDR378 ERC12GK471C 0.5W 5% 470
S.M.CARBR379 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR383 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR391 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR392 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR393 ERJ6GEYJ821 0.1W 5% 820
S.M. CARR394 ERJ6ENF1021 0.1W 5% 1K
S.M. CARR395 ERJ6ENF2370 0.1W 5% 37
S.M. CARR396 ERJ6ENF1021 0.1W 5% 1K
S.M. CARR397 ERJ6ENF2370 0.1W 5% 37
S.M. CARR398 ERJ6ENF1021 0.1W 5% 1K
S.M. CARR399 ERJ6ENF2370 0.1W 5% 37
S.M.CARBR401 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR402 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR403 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR404 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR416 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR418 ERJ6GEYJ682 0.1W 5% 6K8
METALR419 ERG3FJ471 3W 5% 470
S.M.CARBR420 ERJ6GEYJ563 0.1W 5% 56K
S.M.CARBR421 ERJ6GEYJ224 0.1W 5% 220K
S.M.CARBR441 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR442 ERJ6GEYJ123 0.1W 5% 12K
CARBONR451 ERDS1TJ3R3 0.5W 5% 3R3
CARBONR452 ERDS1TJ3R3 0.5W 5% 3R3
S.M.CARBR453 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR454 ERJ6GEYJ123 0.1W 5% 12K
S.M.CARBR457 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR458 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR470 ERJ6GEYJ682 0.1W 5% 6K8
CARBONR471 ERDS1FJ1R0 0.5W 5% 1
CARBONR504 ERD25TJ271 0.25W 5% 270
CARBONR506 ERDS1TJ681 0.5W 5% 680
CARBONR507 ERDS1TJ681 0.5W 5% 680
METALR554 ERX3FJR33H 3W 5% R33
CARBONR556 ERDS1TJ223 0.5W 5% 22K
18

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
CARBONR557 ERDS1TJ683 0.5W 5% 68K
CARBONR558 ERDS1TJ273 0.5W 5% 27K
S.M.CARBR560 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR562 ERJ6GEYJ393 0.1W 5% 39K
CARBONR564 ERDS1TJ394 0.5W 5% 390K
METALR567 ERG3FJ223 3W 5% 22K
CARBONR569 ERDS1TJ120 0.5W 5% 12
S.M.CARBR570 ERJ6GEYJ103 0.1W 5% 10K
METALR572 ERG3FJ821 3W 5% 820
METALR574 ERG3FJ151 3W 5% 150
S.M.CARBR579 ERJ6GEYJ274 0.1W 5% 270K
S.M.CARBR580 ERJ6GEYJ563 0.1W 5% 56K
S.M.CARBR581 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR582 ERJ6GEYJ225 0.1W 5% 2M2
S.M.CARBR583 ERJ6GEYJ225 0.1W 5% 2M2
S.M.CARBR588 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR601 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR613 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR614 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR615 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR616 ERJ6GEYJ100 0.1W 5% 10
S.M.CARBR617 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR619 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR620 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR622 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR623 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR626 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR627 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR628 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR630 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR631 ERJ6GEYJ105 0.1W 5% 1M
S.M.CARBR632 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR634 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR635 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR636 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR637 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR638 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR639 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR640 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR641 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR642 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR643 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR644 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR645 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR646 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR647 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR648 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR649 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR650 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR651 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR652 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR653 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR655 ERJ6GEYJ224 0.1W 5% 220K
S.M.CARBR657 ERJ6GEYJ750 0.1W 5% 75
S.M. CARR658 ERJ6ENF2212 0.1W 5% 220
S.M.CARBR663 ERJ6GEYJ474 0.1W 5% 470K
S.M.CARBR664 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR666 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR667 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR668 ERJ6GEYJ184 0.1W 5% 180K
S.M.CARBR674 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR675 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR676 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR677 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR678 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR679 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR680 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR681 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR682 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR683 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR684 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR685 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR686 ERJ6GEYJ102 0.1W 5% 1K
S.M. CARR688 ERJ6ENF3162 0.1W 5% 1K6
METALR701 ERQ1CJP5R6 1W 5% 5R6
CARBONR702 ERDS1TJ913 0.5W 5% 91K
S.M.CARBR703 ERJ6GEYJ123 0.1W 5% 12K
CARBONR704 ERDS1TJ330 0.5W 5% 33
S.M.CARBR705 ERJ6GEYJ472 0.1W 5% 4K7
CARBONR805 ERD25TC0T 0.25W 5% 0
S.M.CARBR806 ERJ6GEYJ101 0.1W 5% 100
CARBONR807 ERD25TJ104 0.25W 5% 100K
WOUNDR809 ERF10ZK4R7 10W 5% 4R7
S.M.CARBR810 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR811 ERJ6GEYJ391 0.1W 5% 390
CARBONR812 ERD25TJ681 0.25W 5% 680
CARBONR814 ERD25TJ392 0.25W 5% 3K9
CARBONR815 ERD25TJ100 0.25W 5% 10
CARBONR816 ERDS1TJ330 0.5W 5% 33
S.M.CARBR818 ERJ6GEYJ271 0.1W 5% 270
METALR820 ERG3FJ223 3W 5% 22K
METALR821 ERG3FJ223 3W 5% 22K
CARBONR822 ERD25TJ391 0.25W 5% 390
METALR823 ERX12SJR22 0.5W 5% R22
METALR824 ERX12SJR22 0.5W 5% R22
METALR825 ERX12SJR22 0.5W 5% R22
CARBONR827 ERDS1FJ121 0.5W 5% 120
CARBONR828 ERD25TJ103 0.25W 5% 10K
CARBONR829 ERD25TJ221 0.25W 5% 220
METALR830 ERX12SJR22 0.5W 5% R22
CARBONR831 ERD75TAJ825 0.75W 5% 8M2
METALR832 ERG3FJ331 3W 5% 330
CARBONR835 ERD25TJ220 0.25W 5% 22
CARBONR836 ERD25TJ100 0.25W 5% 10
CARBONR837 ERD25TJ183 0.25W 5% 18K
CARBONR838 ERD25TJ821 0.25W 5% 820
SOLIDR841 ERC12ZGK105D 0.5W 10% 1M
CARBONR857 ERD25TJ221 0.25W 5% 220
CARBONR862 ERD25TJ272 0.25W 5% 2K7
METALR863 ERG3FJ680H 3W 5% 68
CARBONR864 ERDS1TJ682 0.5W 5% 6K8
CARBONR867 ERD25TJ102 0.25W 5% 1K
CARBONR868 ERD25TJ151 0.25W 5% 150
CARBONR869 ERD25TJ560 0.25W 5% 56
S.M.CARBR870 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR872 ERJ6GEY0R00 0.1W 5% 0
METALR873 ERQ2CJP2R4 2W 5% 2R4
S.M.CARBR876 ERJ6GEYJ562 0.1W 5% 5K6
METALR877 ERO25CKF1022 0.25W 1% 10K2
METALR878 ERO25CKF1002 0.25W 1% 10K
S.M.CARBR883 ERJ6GEYJ103 0.1W 5% 10K
CARBONR885 ERD25TJ103 0.25W 5% 10K
METALR886 ERX3SJR47P 3W 5% R47
CARBONR888 ERDS1TJ393 0.5W 5% 39K
S.M.CARBR889 ERJ6GEYJ392 0.1W 5% 3K9
S.M.CARBR891 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR892 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR894 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR897 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR899 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR901 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR902 ERJ6GEYJ562 0.1W 5% 5K6
19
