Panasonic MC-E3011-AP47 User manual

© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
Order No.VCB0608005S2
Vacuum Cleaner
MC-E3011-AP47
MC-E3011-RP47
Destination : UK
Subject : We herewith inform you of the new part number that represents the three
components to be supplied as a set.
(Reason: To improved the repair efficiency.)
Please file and use this supplement manual together with the service manual for Model No.MC-E3011,
Order No.ECD0603005C2

2
TABLE OF CONTENTS
PAGE PAGE
1 Specifications ------------------------------------------------------2
2 Exploded View and Replacement Parts List -------------2
2.1. New part number -------------------------------------------2
2.2. Configurafion of the new component ----------------- 2
2.3. Exploded view (Body unit)...(MC-E3011) ------------ 3
2.4. Parts list (Body unit)...(MC-E3011) -------------------- 4
1 Specifications
2 Exploded View and Replacement Parts List
2.1. New part number
2.2. Configurafion of the new component

3
2.3. Exploded view (Body unit)...(MC-E3011)
1
3
2
99
8
10
11
12
13
14 15
78
80
21
22 16
17
6
5
4
23
31 27
28
29
77
20
33
37
79
34 79 32
30
38
39
18
19
24
25
43
23
72
44
43
17
17 26
44
72
42
45
35
36
79
40
79
79
55
54
76
41
53 51
46
47
48
49 50
52
79
65
79
59
58
81
56
60
57
66
69
68
63
61
62
61
64
79
79
68
69
75
74
73

4
2.4. Parts list (Body unit)...(MC-E3011)
safety Ref.No. Part No. RePart Name & Descriptionarks Q'TY Remarks
1 AMC95B-XB0AE Handle unit 1
1 AMC95B-XB0RE Handle unit 1
2 AMC33Z-XD008 Warning label 1
3 AMC73B-XD00E Handle screw 1
4 AMC93E-XB0K8 Mains lead (Power cord) 1
5 AMC84P-XA00E Hose unit 1
6 AMC07Z-XB00E Caution label A 1
8 AMC19P-XB04E Hose cover 1
9 AMC98M-XA00E Indicator unit 1
10 AMC15M-XB00E Indicator pipe 1
11 AMC03M-XB0UE Indicator needle 1
12 AMC04M-XA00E Indicator spring 1
13 AMC27M-XB00E Indicator tube 1
14 AMC91F-XB00C PC BOARD W/Component 1
15 AMC99W-ZS00E Fuse Unit 1
16 AMC21A-XB0AE Rear body 1
16 AMC21A-XB0RE Rear body 1
17 XTN4+12BFJ Tapping screw 5
18 AMC27H-XB04E Connection wand 1
19 AMC55P-XB04E Extension wand holder 1
20 AMC01E-XB0KE ON/OFF Switch 1
21 AMC16V-ZS00E P.C.B holder A 1
22 AMC59V-ZS00E P.C.B holder 1
23 AMC66K-XB00E Dust cover packing 2
24 AMC61R-XB04E Crevice nozzle 1
25 AMC40P-XB04E Extension wand 1
26 AMC88R-XD04E Dusting brush unit 1
27 AMC18M-XB0AE Protector Supporter 1
27 AMC18M-XB0RE Protector Supporter 1
28 AMC70K-XA00E Protector Spring 1
29 AMC03M-XL00E Indicator needle 1
30 AMC68K-XB0AE Protector case 1
30 AMC68K-XB0RE Protector case 1
31 AMC85E-XB0AE Switch cover unit 1
31 AMC85E-XB0RE Switch cover unit 1
32 AMC81A-XB00E Tight packing 1
33 AMC61L-XB00E Packing 1
34 AMC32K-XB0KE Filter suppoter 1
35 AMC42K-XA06E Filter case 1
36 AMC38K-XA00E Exhaust filter 1 (Clean Air filter)
37 AMC92L-ZS0AE Dust box lid unit 1
37 AMC92L-ZS0RE Dust box lid unit 1
38 AMC-B1EP Dust bag(Type U-20E) 1 (Pack of 5 bag)
39 AMC19F-XB00E Motor case rubber 1
40 AMC09F-XB0AE Motor case 1
40 AMC09F-XB0RE Motor case 1
41 AMC30L-ZS00E Outlet filter 1
42 AMC16C-XB00E Roller shaft 1
43 AMC01C-XD04E Wheel 2
44 XUB7FP Fixing washer 2
45 AMC64H-XB00E Suction inlet packing 1 (Central filter)
46 AMC10G-XB00E Noise absorber 1
47 AMC92F-XB00C Fan motor unit 1
48 AMC27F-XL00E Carbon brush 2
49 AMC75Z-XB00E Cushion plate 1
50 AMC03F-XB00E Motor support rubber(rear) 1
51 AMC02F-XB00E Motor support rubber(front) 1
52 AMC67V-ZS00E Lead wire A unit 1
53 AMC98R-XB0AE Floor nozzle upper unit 1
53 AMC98R-XB0RE Floor nozzle upper unit 1
54 AMC31A-XB05E Furniture guard 1
55 AMC25S-XD00E Plastic holder 1
56 AMC90S-XB00E Idler pulley 1
57 AMC68A-XD00E Screw 2
58 AMC47A-XB04E Pedal left/handle release 1
59 AMC51A-XB00E Pedal shaft 1
60 AMC58A-XB00E Pedal spring right 1
61 AMC54R-XB04E End plate 2
62 AMC06R-XD00E Pipe felt 1
63 AMC79A-XD00E Body packing 1
64 AMC52P-XB00E Connector pipe 1

5
65 AMC97R-ZS00E Floor nozzle lower unit 1
66 AMC42D-XB00E Bolt A 1
68 AMC50R-XD00E Floor nozzle roller shaft 2
69 AMC90Q-XD00E Nozzle roller 2
72 XWG7F135FJ Plain washer 2
73 AMC95S-XD00E Belt Kit Assy 1
74 AMC28S-XD00E Belt 1
75 AMC39S-XD00E Belt B 1
76 AMC92S-XD00E Beater bar unit 1
77 AMC28H-XB00E Elbow packing 1
78 AMC04Z-XD00E Sticker 1
79 XTN4+18BFJ Tapping screw 16
80 DS-250PU Insulation tube 1
81 AMC80A-XB04E Pedal Unit 1
safety Ref.No. Part No. RePart Name & Descriptionarks Q'TY Remarks
