Order Number: PMMA091040CE
MC-UL592/MC-UL594
Vacuum Cleaner
SPECIFICATION
© 2009 Panasonic Manufacturing Malaysia Berhad
(6100-K). Unauthorized copying and distribution is a
violation of law.
MODEL MC-UL592 MC-UL594
POWER SOURCE
MAX INPUT 1400 W 1500 W
NOMINAL INPUT
DIMENSIONS (W x L x H)
NETT WEIGHT (kg) 8.6 kg 8.8 kg
EXTENSION WANDS
FLOOR NOZZEL - BOTTOM PLASTIC
ATTACHMENTS Hose, Extension Wand, Floor Nozzle
(
UL594
)
, Curved Wand, Crevice, Dustin
g
Brush
230V - 240V ~ 50 Hz
375mmX360mmX1120mm
PLASTIC
1200 - 1300 W

3
HOW TO ASSEMBLE YOUR CLEANER
A) HANDLE ASSEMBLY / HOSE ASSEMBLY / MAINS LEAD STORAGE
Set the hose around the hose
hook and insert the curved wand
to the curved wand holder.
4. Turn the upper cord storage
hook in the upright position and
wind the mains lead around the
upper and lower cord storage
hooks.
5. Insert the tools to its location as shown.
6.
Remove tape and
screw from the
body.
1. Insert the base of
the handle into the
top of the vacuum
cleaner body as
shown. Push in
handle and tighten
the screw.
2. Insert the connection
pipe to suction inlet.
Ensure that the 2 hooks
of the connection pipe
are completely fitted into
the suction inlet.
3.
Connection
Pipe
Hook
Tape
Suction Inlet
Dusting
Brush
Crevice
Mini Turbine
Nozzle
Extension
Wand
IMPORTANT:
Do not overtighten the screw.
Hose Hook
Curved Wand
Curved Wand
Holder
Upper Cord
Storage Hook
Lower Cord
Storage Hook /
Carrying
Handle
Extension
Wand Holder
Curved Wand
Holder

4
MAINTAINING THE HEPA FILTER UNIT
TO CLEAN THE PRE-FILTER
Check HEPA filter unit frequently and clean when dirty.
Remove HEPA filter unit from dust bin by pulling both buckle as shown.
Clean HEPA filter unit by gently tapping over a rubbish container.
Tap on several sides to ensure best cleaning.
DO NOT clean the HEPA filter unit by brush or clean it with water.
Reinstall the HEPA filter unit as per reverse procedure.
Remove HEPA filter unit from dust bin. Refer to maintaining the HEPA
filter unit (as above).
Press the latch to open the dust bin plate.
Grasp the pre-filter and turn it clockwise and pull the pre-filter out.
Clean by gently tapping over a rubbish container.
Install the pre-filter to the dust bin, aligning the pre-filter tabs to the dust
bin slots. Each Pre Filter Tabs is different shape and adjust it to match
Dust Bin Slot, then turn counter-clockwise to the lock position until you hear
a “click” sound.
After the dust bin is empty of dust, firmly close the dust bin plate.
Make sure you hear a “click” sound to indicate that the dust bin plate is
fully latched.
Reassemble the HEPA filter unit. Place dust bin unit back into vacuum
cleaner by inserting the bottom first and tilting back.
Refer to dust bin cleaning.
Pull to release Pull to release
Buckle
Lid
Dust Bin
HEPA Filter
Unit
Pre-Filter
Dust Bin Slot
Pre-Filter Tab

5
REPLACING HEPA EXHAUST FILTER
The HEPA exhaust filter removes dirt from exhaust air.
Check HEPA exhaust filter after emptying dust bin.
Replace when dirty.
Lay down the vacuum cleaner as shown.
To remove filter cover, slide upwards the buckle as shown.
By holding the filter cover as shown, pull it out towards you.
Grasp the HEPA exhaust filter and pull out to remove it.
To install back the HEPA exhaust filter, put it into its original position.
Place the filter cover to the body as shown and press into its original location.
Slide down the buckle as shown.
WARNING
Do not operate vacuum cleaner with a clogged exhaust filter or
without the exhaust filter cover properly installed.
Important:
If HEPA Exhaust Filter become too dirty, it causes that air suction fall down.
HEPA Exhaust Filter cannot be cleaned and should be replaced at least
once a year.
Filter Cover
Filter Cover
HEPA
Exhaust Filter
HEPA
Exhaust Filter
Buckle

6
THERMAL PROTECTOR
REMOVING AND INSTALLING LOWER PLATE
REPLACING BELT
This vacuum cleaner has a thermal protector which automatically trips to protect the vacuum cleaner from overheating.
If a clog prevents the normal flow of air to the motor, the thermal protector trips and turns the motor off automatically.
This allows the motor to cool in order to prevent possible damage to the vacuum cleaner.
TO CORRECT PROBLEMS:
Turn the vacuum cleaner off and unplug the power cord from the outlet to allow the vacuum cleaner to cool and the thermal
protector to reset automatically.
Check for and remove clogs, if necessary. Also check and replace any clogged filters and empty dust bin if necessary.
Wait approximately sixty (60) minutes and plug the vacuum cleaner in and turn back on to see if the motor protector has reset.
WARNING Electical SHock or Personal Injury Hazard
Disconnect the electrical supply before servicing or cleaning the vacuum cleaner.
Failure to do so could result in electrical shock or personal injury from vacuum cleaner suddenly starting.
Before servicing any parts, unplug the mains lead from electrical outlet.
Always place paper under nozzle whenever lower plate is removed to
protect floor.
Place body in upright position and turn vacuum cleaner over to expose
lower plate.
Release lower plate by rotating the lower plate latches to the UNLOCK
position.
Remove lower plate and remove any residue that may exist in belt area.
Reinstall lower plate by hooking front end of lower plate into slots on front
of nozzle.
Press lower plate onto nozzle and secure by rotating the lower plate
latches to the LOCK position.
Replace belt whenever a burning rubber smell caused by excessive
slippage occurs.
Remove lower plate. See “Removing and Installing Lower Plate”.
Remove beater bar by carefully lifting out.
Remove worn or broken belt.
Clean beater bar and the end caps.
Motor Shaft
Motor Shaft Belt
Beater Bar
Beater Bar
Belt Groove
End Cap
Latches
Latches Lower Plate

7
CLEANING BEATER BAR
CLEANING EXTERIOR AND TOOLS
Loop new belt around motor shaft and beater bar belt groove.
Reinstall beater bar by inserting the end cap of the beater bar to the slot
for both side.
After reinstalling the beater bar, turn it by hand to make sure that the belt is
not twisted of pinched and that all rotating parts turn freely.
Reinstall lower plate. See “Removing and Installing Lower Plate”.
Clean beater bar for Nozzle and Mini Turbine Nozzle after every five uses.
Turn vacuum cleaner over, exposing the beater bar for Nozzle.
Cut off any carpet pile and lint entangled around beater bar for Nozzle
and Mini Turbine Nozzle with a pair of scissors.
Clean exterior using a clean, soft cloth that has been dipped in a solution of mild liquird detergent and water and wrung dry.
DO NOT drip water on the vacuum cleaner and wipe dry after cleaning.
DO NOT clean tools in dishwasher or clothes washer.
DO NOT use tools if they are wet.
Wash tools in warm soapy water, rinse and air dry.

8
REPLACING MOTOR ASSY AND OVERLOAD PROTECTOR
- Following step replacing belt and Beater bar unit.
- Remove the 1 screw from the Pedal shaft to detach
the Pedal.
- Loosen 3 screw from the Lower plate.
- Pull out the pedal shaft slightly.
- Loosen 3 screw at the frame and remove together.
- Push the hook to unlock Floor nozzle upper.

9
- Trun back the set.
- Open the cover of Floor nozzle upper.
- Pull the Nozzle hose from the Extention wand holder.
- Take out the Floor nozzle upper and remove nicely.
- Can see the Overload protector and Motor cap.
- Loose 4 screw at Motor cap and remove.
- Motor Support plate and take out the Motor assy.
- After open or take out the wire connector please
make sure the colour of wire must correctly and
same to the original.
A) Brown wire
B) Black wire
OVERLOAD PROTECTOR
AB

10
REPLACING FAN MOTOR UNIT, CAPACITOR AND FUSE ASSY
IMPORTANT : Before replacing any part always DISCONNECT FROM THE ELECTRICITY SUPPLY.
- Pull out the Handle from Body assy and move up the
Dust compartment assy.
- Turn back the set.
- Loosen 2 screw at the Rear body assy.
- Turn back to normal.
- Push up the Buckle to open the Filter cover.
- Take out the Filter cover.
- Loosen 10 screw at the Front body and take out.

11
- Make sure all the part place before dismantle or
change to new part.
- Location of Safety part.
- Pull out the connector Capacitor from Fan Motor unit.
- Pull out the connector wire from Fan motor unit.
- After that move up the Fan motor unit.
- Make sure the wire colour before pull out the
connector wire from the Switch.
(Red wire and Brown wire).
A) Brown wire
B) Red wire
- Position of Fuse assy.
A
B

12
REPLACING ON/OFF SWITCH
IMPORTANT : Before replacing any part always DISCONNECT FROM THE ELECTRICITY SUPPLY.
- Loosen 3 screw back the set at Handle.
- Turn back the set.
- Open the Handle.
- Please make sure wire connection and wire colour
connect to Switch.
(Have two Red wire different tickness)
A) Red wire AWG 20 (larger diameter)
B) Black wire
C) Red wire AWG 18 (smaller diameter)
D) Brown wire
A
B
C
D
}
}
Switch top position
Switch lower position

13
TROUBLE SHOOTING GUIDE
Motor fails to rotate
(no noise is heard
at all).
Motor runs but
there is no suction.
Noise or vibration.
Beater bar unit
does not rotate.
Belt.
Motor fan.
Carbon brushes.
Beater bar unit
Beater bar unit (bearings)
HEPA filter,
Exhaust filter.
Hose or connector pipe.
Carbon brush is in contact
with the commutator.
ON / OFF Switch.
Motor continuity.
Power cord.
Plug (fuse-link)
(UK, Ireland only)
CONDITION CHECKPOINT METHOD OF INSPECTION CAUSE / REMEDY
Check fuse continuity.
Check power cord continuity.
Check continuity between motor and lead wires.
Check continuity across the switch terminals.
Check clogs in hose or connector pipe.
Check if filter are choked up.
Check dust accumulated in motor fan. (It could
happen if the v.c has been used with a filter.
Check if there is gap between carbon brush and
commutator.
Check uneven wear of carbon brushes.
Remove the Beater bar unit and check if the each
bearing support is broken or deformed.
Place the Beater bar unit on a flat surface and turn
the rotary brush to check bearing noise or distance.
Remove base plate (Floor nozzle lower unit) and
check if the belt is broken or loose.
If the belt is broken, replace it.
If there is bearing noise or distance,
replace the Beater bar unit.
If each of them is deformed or broken,
replace the beater bar unit.
If choked up, replace it. If filter is dirty, clean
or replace it.
If there is no continuity, replace it.
If there is no continuity, replace it.
If there is no continuity, replace it.
If there is no continuity, replace the switch.
If there is a clog, remove it.
If there is gap between carbon brush and
commutator.
Replace the motor.
Replace the motor and check filter
condition. (never dismantle the motor fan).

4
3
2
1
17
PACKING INSTRUCTIONS
5
6
7
PACKING LIST
REF. NO. PART NAME PART NO. REMARKS
MC-UL592 MC-UL594
1 CUSHION A YMV69Z95000 1 1
2 ATTACHMENT PART CASE YMC54Z95000 1 1
3 CUSHION B YMV70Z95000 1 1
4 CUSHION C YMV0TZ95000 1 1
5 INSTRUCTION BOOK YMV01Z95000 1 1
6 POS LABEL YMV29T95008 - 1
6 POS LABEL YMV29T96008 1 -
7 INDIVIDUAL CARTON YMV61Z96000 1 -
7 INDIVIDUAL CARTON YMV61Z95000 - 1
