GLIDE-24-REC
24" BUILT-IN RANGE HOOD
PRODUCT FEATURES
•24” (60cm) stainless steel built-in glide-out range hood
•Recirculating
•LED lighting (3,200 Lumens)
•2 speed adjustment
•2 x dishwasher safe honey comb filters
•Electronic switch controls
•Quiet (7 sones/56dB) 300 CFM motor
ELECTRICAL REQUIREMENTS
•115 Volt, 60Hz, 15AMP
•P&C Range Hoods are supplied with a Canadian cord and plug
•Electrical cord located 31/8” (79mm) from the top right corner of the
unit at the rear
DIMENSIONS
•D: 11" x W: 23 1/2"
•D: 280mm x W: 598mm
Version:1.0 - Specifications are subject to change at any time without notice.
www.porterandcharles.ca
Our sleek and stylish range hoods incorporate advanced features and functionalities designed to exhaust airborne grease,
fumes, heat, steam and cooking odors quickly and easily. By removing excess heat and humidity from your kitchen, you
create a much more comfortable environment and keep your walls and cabinets clean.
DIMENSIONS
•6" Duct Adapter Included

GLIDE-24-REC
SPECIFICATIONS
PRODUCT DIMENSIONS
Version:1.0 - Specifications are subject to change at any time without notice.
www.porterandcharles.ca
CABINET BOX DESIGN - (RECIRCULATING)
31/4”
80mm
239/16”
598mm
FRONT PANEL - DUCTED
69/16”
166mm
235/8”
600mm
Shelf Supports
Range hood
81/4”
210mm
External Gable
External Gable
FRONT VIEW SIDE VIEW
235/8”
600mm
*Outside Cabinet Measurements*
FRONT PANEL INSTALALTION
•1. Pull the glide forward
•2. Remove the 4 screws holding the glide to the panel
•3. Install the matching front panel using the 4 screws
*Custom panel provided by customer
*NOTE: Removing the front stainless steel trim
•Ensure that the cabinet door panel is shortened to
accommodate the larger sized Range Hood Front
Panel
*NOTE: Cabinet Door Panel Height

GLIDE-24-REC
SPECIFICATIONS
Version:1.0 - Specifications are subject to change at any time without notice.
www.porterandcharles.ca
min.
24" (609mm)
43/4" (120mm)
Combustible
43/4" (120mm)
Combustible
36" (914mm)
FLOOR TO
COUTNER TOP
min. 12" (300mm) - max. 13" (330mm)
23/15" (55mm)
min.
RECOMMENDED CABINET MINIMUM CLEARANCE (ELECTRIC / INDUCTION COOKING SURFACES
24" (610mm)
Counter Top
To Combustible
Materials
18"
457mm
min.
top of cooktop grates

GLIDE-24-REC
SPECIFICATIONS
Version:1.0 - Specifications are subject to change at any time without notice.
www.porterandcharles.ca
min.
24" (609mm)
43/4" (120mm)
Combustible
43/4" (120mm)
Combustible
36" (914mm)
FLOOR TO
COUTNER TOP
min. 12" (300mm) - max. 13" (330mm)
23/15" (55mm)
min.
RECOMMENDED CABINET MINIMUM CLEARANCE GAS COOKING SURFACES
30" (762mm)
Counter Top
To Combustible
Materials
18"
457mm
min.
top of cooktop grates
