P&G Oral-B iO 4 User manual

TM
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 190234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 1 26.10.21 09:4326.10.21 09:43
Stapled booklet, 75 x 155 mm, 102 pages (incl. 6
pages cover), Cover 4c, Inhalt = black + PMS 288 C

7
4
6
5
3
2
1
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 290234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 2 26.10.21 09:4326.10.21 09:43

8
9
10
11
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 390234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 3 26.10.21 09:4326.10.21 09:43

a b
cd
ehgf
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 490234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 4 26.10.21 09:4326.10.21 09:43

5
Description
1 Brush head
2 Brush head identification symbol
3 Smart Pressure Sensor / Light Ring
4 Interface
5 Bluetooth
®
6 Handle
7 Charger
8 On/off button
9 Mode switch button
10 Low charge indicator
11 Brush Replacement Reminder
Features & Accessories (depending on model):
aSmart Pressure Sensor
b2-minutes brushing reward illumination
cBrush head holder with cap
dTravel case
eBrush head holder stand
fBrush head «Ultimate Clean»
gBrush head «Gentle Care»
hBrush head «Radiant White»
Oral-B App:
iDownload Oral-B App and connect to Bluetooth
(see back page)
Note: Content may vary based on model purchased.
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 590234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 5 26.10.21 09:4326.10.21 09:43

6
English
Welcome to Oral-B!
Before operating this toothbrush, please read these
instructions and save this manual for future reference.
IMPORTANT
• Periodically check the entire product/
cord/accessories for damage. A
damaged or non-functioning unit
should no longer be used. If the
product/accessory is damaged, take it
to an Oral-B Service Centre. The
supply cord cannot be replaced. If the
cord is damaged the appliance should
be scrapped. Do not modify or repair
the product. This may cause fire,
electric shock or injury.
• Never insert any object into any
opening of the appliance.
• Usage by children under age 3 is not
recommended. Toothbrushes can be
used by children and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge, if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
• Cleaning and maintenance shall not be
performed by children.
• Children shall not play with the
appliance.
• For tooth brushing only. Do not chew
or bite on brush. Do not use as a toy or
without adult supervision.
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 690234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 6 26.10.21 09:4326.10.21 09:43

7
• Use this product only for its intended
use as described in this manual. Do not
use attachments which are not
recommended by the manufacturer.
• Only use the charger provided with
your appliance.
WARNING
•Do not place the charger in water or liquid or store where it
can fall or be pulled into a tub or sink. Do not reach for it
when fallen into water. Unplug immediately.
•Avoid sharp bending, jamming or squeezing of the cord.
•This appliance contains batteries that are non-replaceable.
Do not open and disassemble device. For battery recycling
please dispose whole device according to local environ-
mental regulations. Opening the handle will destroy the
appliance and invalidate the warranty.
•When unplugging, always pull the power plug instead of the
cord. Do not touch the power plug with wet hands. This can
cause an electric shock.
•If you are undergoing treatment for any oral care condition,
consult your dental professional prior to use.
•This toothbrush is a personal care device and is not intended
for use on multiple patients in a dental practice or institution.
For hygienic reasons we recommend the use of individual
brush handles and brush heads for each family member.
•Small parts may come off, keep out of reach of children.
To avoid brush head breakage which may generate a small
parts choking hazard or damage teeth:
•Prior to each use, ensure the brush head fits well. Discon-
tinue use of the toothbrush, if brush head no longer fits
properly. Never use without a brush head.
•If the toothbrush handle is dropped, the brush head should
be replaced before the next use even if no damage is visible.
•Replace brush head every 3 months or sooner if brush head
becomes worn.
•Clean brush head properly after each use (see «Cleaning
recommendations» paragraph). Proper cleaning ensures
the safe use and functional life of the toothbrush.
Important Information
•This toothbrush and pouch (accessory) contains NdFeB
magnets and generate magnetic fields. If you use a medical
device or have an implanted medical device, consult with
the medical device manufacturer or a physician, if you have
questions about safely using your Oral-B iO toothbrush.
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 790234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 7 26.10.21 09:4326.10.21 09:43

8
•Your toothbrush can be used with your smartphone (find
details under «Connecting your toothbrush to your Smart-
phone»). To avoid electromagnetic interference and/or
compatibility conflicts, disable Bluetooth on your toothbrush
handle (6) before using it in restricted surroundings, such as
aircrafts or specially marked areas in hospitals.
•Persons with pacemakers should always keep the tooth-
brush more than 15 centimeters (six inches) from the pace-
maker while turned on. Anytime you suspect interference is
taking place disable Bluetooth.
Specifications
For voltage specifications refer to the bottom of the charging
unit.
Noise level: 64 dB (A)
Using your toothbrush
Charging and Operating
•To charge the battery place the toothbrush on the
plugged-in charger (7).
•During charging the on/off button is blinking white. Once it
is fully charged the indicator light turns off. A full charge typ-
ically takes 16 hours.
•If the battery is running low the low charge indicator (10)
blinks in red. Once the battery is empty, the motor stops. To
charge the battery please put the brush on the charger.
•The toothbrush can be stored on the plugged-in charger to
maintain it at full charge; a battery overcharge is prevented
by the device. However, for environmental purposes we rec-
ommend to keep charger in the power socket during charg-
ing only.
•The toothbrush switches off when exceeding the outside
operating limits and/or standard battery current. To enable
operation the toothbrush needs to be put on the charger.
Caution: This toothbrush contains a Li-Ion battery. Do not
expose toothbrush to temperatures higher than 50°C / 122°F.
Note: Store the toothbrush at room temperature for optimal
battery maintenance.
Start Brushing
Place the brush head (1) on the handle (6). A small gap should
remain between handle and brush head.
Wet brush head and apply toothpaste. To avoid splashing, put
the brush head into your mouth before switching the tooth-
brush on by pressing the on/off button (8).
Guide the brush head from tooth to tooth. Brush the outsides,
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 890234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 8 26.10.21 09:4326.10.21 09:43

9
the insides and the chewing surfaces. Brush all four quadrants
of your mouth equally. You may also consult your dentist or
dental hygienist about the right technique for you.
In the first days of using any electric toothbrush, your gums
may bleed slightly. In general, bleeding should stop after a few
days. Should it persist after 2 weeks, please consult your den-
tist or dental hygienist. If you have sensitive teeth and/or gums,
Oral-B recommends using the «Sensitive» or «Super Sensitive»
modes (optional in combination with an Oral-B «Gentle Care»
brush head (g)). Availability of modes may vary depending on
model purchased.
Timer
The timer signals with a short stuttering sound in 30-seconds
intervals to move to the next quadrant of your mouth. A long
stuttering sound indicates the end of the professionally recom-
mended 2-minute brushing time.
The timer memorizes the elapsed brushing time, even when
the toothbrush is briefly switched off during brushing. The
timer resets if pausing longer than 30 seconds or placing the
toothbrush on the plugged-in charger.
Brushing reward illumination
The completion of a 2-minutes brushing event will be rewarded
with a colourful light ring illumination. (b)
Note: You may also customize the timer settings via Oral-B
App.
Smart Pressure Sensor/ Light Ring (a)
Your toothbrush is equipped with a Smart Pressure Sensor (3)
that has various functionalities indicated via different colours of
light (a):
White = Low pressure indicator / default setting.
Green = optimal pressure indicator
Red = high pressure indicator
Brushing with the recommended pressure is indicated via a
green light. If too much pressure is applied, a red light reminds
you to reduce pressure. If the Smart Pressure Sensor illumi-
nates in white (or your pre-selected colour), we recommend
applying more pressure.
When high pressure is applied the brush head movement will
be reduced (in «Daily Clean», «Intense» and «Sensitive»
modes). Periodically check the operation of the Smart Pressure
Sensor by pressing moderately on the brush head during use.
90234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 990234765_OP021_UI_75x155_iO4_CEUAIL_1_Y3_2D.indd 9 26.10.21 09:4326.10.21 09:43

10
Note: You can replace the white default light ring colour with a
choice of individual colours via the Oral-B App.
Brushing modes (depending on model)
Your toothbrush offers different brushing modes:
«Daily Clean» – Standard mode for daily cleaning
«Intense» – For an extraordinary clean feeling (operated with a
higher speed)
«Sensitive» – Gentle, yet thorough cleaning for sensitive areas
«Super Sensitive» – Super gentle cleaning for extra sensitive
areas
«Whiten» – Polishing for occasional or everyday use
«Tongue Clean» – Tongue cleaning for occasional or everyday
use
«Gum Care» – Gentle massage of gums
Note: The sequence and availability of brushing modes may
vary depending on model purchased.
Mode setting:
For first use the toothbrush starts with the first mode illustrated
on the package of your purchased model. To switch to other
modes, successively press the mode button (9). You may
change the modes during the brushing event. The toothbrush
automatically starts in the mode selected last.
When operating the «Tongue Clean» mode, we recommend
using a «Gentle Care» brush head (g). You can brush your
tongue either with or without toothpaste. Brush the whole area
of your tongue systematically in gentle movements. The
recommended brushing time is 30 seconds; the motor stops
after 30 seconds.
Note: You may also customize mode settings via Oral-B App.
Brush heads
Oral-B offers you a variety of different Oral-B iO brush heads
(f/g/h) that only fit your Oral-B iO toothbrush handle. These
unique brush heads are dentist-inspired to leave your mouth
feeling clean and refreshed.
When to exchange brush head
Some iO Oral-B brush heads feature INDICATOR
®
bristles to
help you monitor brush head replacement need. With thorough
brushing, twice a day for two minutes, the bristle colour will fade
halfway approximately within 3 months, indicating the need to
exchange your brush head. If the bristles splay before the colour
recedes, you may exert too much pressure on teeth and gums.
In general, we recommend replacing the brush head every
3 months.
