Pandora NAV-X User manual

Our web site: pandorainfo.com
Customer support: [email protected]
Product is in conformity with Electromagnetic
Compatibility
Directive EMC 2004/108/EC and R&TTE Directive
1999/5/EC
Pandora would like to thank you for choosing
our telemetric module
NAV-X

TELEMETRY MODULE PANDORA NAV-X USER MANUAL2 3
GENERAL INFORMATION
The Pandora NAV-X is an autonomous compact module
designed to add telemetry and service functions to Pandora
service-security systems. The module can expand the system
features with the following functions: web-service pandora-on.
com and mobile applications Pandora Online | Pandora Pro – full
access to remote control and monitoring functions, display of
current coordinates, event history; DTMF-commands to control
the system by phone; voice and SMS notications; listening
function.
Small dimensions and wireless connection with a security
system allow you to make high secrecy installation.
TABLE OF CONTENTS
SYSTEM SET 4
FEAUTERS 4
OWNER’S CARD 6
CONTROL 7
Web-service and mobile application 8
Control using a phone 9
Changing settings by a phone 13
SETTINGS 15
General information 15
Entering the programming mode/
entering the “Service PIN-code” 15
Programming menu 16
Programming and updating 19
Step by step example 19
INSTALLATION 22
General installation requirements 22
Main power supply connection 23
Module placing 24
WARRANTY OBLIGATIONS 25
Acceptance certicate 28
Warranty card 28

TELEMETRY MODULE PANDORA NAV-X USER MANUAL4 5
SYSTEM SET
1. Telemetry module 1
2. Owner’s card 1
3. User manual 1
4. Packaging 1
NOTE! The manufacturer reserves the right to change the set
and construction of the product to improve its technological and
operational parameters without notication.
FEATURES
• Built-in GSM modem (GPRS/SMS/LBS-services)
• Built-in nano-SIM slot
• Built-in GPS/GLONASS receiver
• Built-in radio interface 2.4 GHz (BLE4.2)
• Built-in micro-USB port
The VALET button is a multifunctional button located on the
device. The button is used to change the settings of the module.
The LED indicator is an informational red and green LED
indicator. The LED displays the current state of the module.
The microphone is a built in electroacoustic device required for
the “Listening”function.
The fastening is side fasteners for xing the module on a hard
surface with clamps or ties.
PIN-codes of the telemetric module
Secret PIN-code
(is written on the Owner’s card)
Service PIN-code
(default value is 1-1-1-1)
Guest PIN-code
(default value is 1-2-3-4)
WARNING! WE RECOMMEND THAT YOU CHANGE THE
DEFAULT VALUE, WRITE DOWN AND REMEMBER VALUE
OF ALL PIN-CODES. ELIMINATE THIRD-PARTY ACCESS TO THIS
INFORMATION.
CANNOT BE CHANGED

TELEMETRY MODULE PANDORA NAV-X USER MANUAL6 7
OWNER’S CARD
The owner’s code card contains private information under a
protective layer.
WARNING! CAREFULLY REMOVE THE PROTECTIVE LAYER,
DO NOT USE SHARP OBJECTS TO AVOID DAMAGING OF
THE HIDDEN INFORMATION UNDER THE PROTECTIVE LAYER.
THE HIDDEN INFORMATION UNDER THE PROTECTIVE LAYER IS
INTEDED ONLY FOR THE OWNER. THE OWNER’S PERSONAL CARD
AND THE HIDDEN INFORMATION CANNOT BE RESTORED
• LOGIN is a 10-digit number.
This information is used to add
the module to the web service
and mobile applications. This
information cannot be changed
or restored.
• PASS contains 8 characters and
can consist of digits, lower and
upper case letters. This information is used to add the module to
the web service and mobile applications. This information cannot
be changed or restored.
+7-9хх-ххх-хх-хх
1070000000 / Y34aC4vJ
LOGIN / PASS
PIN 1-1-1-1 PHONE NUMBER
• PIN (“Secret PIN-code”) is a 4-digit number. This code is used to
switch o radio tags, switch on“Service mode”, disable engine
blocking (see the “Control using a phone”section). This information
cannot be changed or restored.
• Phone number is a number of the SIM-card supplied with the
module. This number is not used if you change the SIM-card.
CONTROL
The Pandora NAV-X telemetry module is used for remote
control and monitoring of a vehicle using a security-service
system. To provide these functions, the module has a SIM-card
with access to the Internet and GSM-communication:
• the Internet provides the work with the mobile applications and
web-service;
• GSM-communication provides possibility to control a vehicle
using a phone and to receive SMS notications.
WARNING! FOR THE CORRECT OPERATION OF GSM
FUNCTIONS, AN OWNER SHOULD MONITOR THE STATUS/
BALANCE OF THE SIM CARD INSTALLED IN THE MODULE. IF THE
SIM CARD IS BLOCKED OR DEFECTIVE, GSM FUNCTIONS OF THE
SYSTEM WILL BE UNAVAILABLE.

TELEMETRY MODULE PANDORA NAV-X USER MANUAL8 9
Web-service and mobile applications
It is required to create an account and attach the telemetry
module to your account to start using the web service pandora-
on.com and the mobile applications Pandora Online (Android)/
Pandora Pro (iOS).
To create an account, visit the web-site or open the mobile
application and register your account. You will create the data
to sign in: LOGIN – your email, PASSWORD – a password entered
during the registration. You will receive an email with a conrmation
link. Click the link to complete the registration procedure.
Log in to the web-site or mobile application using the specied
data (email and password). In the“Add a device”or “Add a system”
window, enter the LOGIN and PASS written on your“Owner’s card”,
create a name for your car and click “Add”. After this, you will be able
to control, change setting and information about the vehicle state.
Web-service: https://pandora-on.com
Mobile applications are available in the application stores:
App Store (iOS) – Pandora Pro;
Google Play (Android) -
Pandora Online.
ATTENTION! MINIMUM REQUIREMENTS FOR MOBILE
DEVICES: ANDROID V4.4; IOS V10.
Control using a phone
The “Main owner’s number”is used for remote control by a
phone, receiving voice and SMS alerts. You can add additional
phone number for notications. To access control functions from
a phone number that is not programmed as the “Main owner’s
number”, it is required to enter the“Guest PIN-code”.
All incoming calls to the module are checked for compliance
with the “Main owner’s number”. If the incoming number is not
equal to the“Main owner’s number”, a sound signal will invite to
enter the“Guest PIN-code”.
To control a security-service system using a phone, call the
phone number of the SIM card installed in the module and dial a
command. If you call not from the“Main owner’s number”, it will
be required to enter the “Guest PIN-code”.
– Repeat voice notications of the initial menu
– Help
During a voice call, dial 9* and listen to the information about the system
control commands.

TELEMETRY MODULE PANDORA NAV-X USER MANUAL10 11
To have simple access to engine start function, create a new contact in the
contact list of your phone, name it‘Engine start’, for instance, and add the
number in the following format:
+XXXXXXXXXXX,123*,297*
where‘+XXXXXXXXXXX’– the system phone number,
‘,’- pause is a feature of the phone (can be displayed as the‘P’, see the
instructions of the phone),
‘123*’- remote engine start DTMF command,
‘297*’- end call DTMF command
Contact can be added as a speed dial to any of the free button.
To have simple access to engine start function a phone other than
the main owner’s phone, create a contact in the following format:
+XXXXXXXXXXX,1234,123*,297*
where‘1234’ – guest PIN-code.
– Turn on the built-in microphone
– Request balance of the SIM-card
The system will conrm: ‘Balance information sent via a text message’and
will send a text message with account balance information to your phone.
– System information about current rmware
version
– End a call
– Request current coordinates
– Enable radio tags (immobilizer and Anti-HiJack
functions)
ХХХХ – Disable radio tags (immobilizer and Anti-
HiJack functions). The“Secret PIN-code”(ХХХХ)
written on the Pandora NAV-X owner’s card is
required for this command
– Arming
– Silent arming
– Disarming
– Silent disarming
– Remote engine start
– Remote engine stop
– Enable automatic engine starts
– Disable automatic engine starts
– Unlock trunk
– Switch on an engine heater
– Switch on an engine heater
ХХХХ – Enable the “Service mode”. The “Secret
PIN-code”(ХХХХ) written on the Pandora NAV-X
owner’s card is required for this command
– Disable the “Service mode”
The system will conrm: ‘Current coordinate sent via a text message’and
will send a text message with coordinates and a web link to a map to your
phone.

TELEMETRY MODULE PANDORA NAV-X USER MANUAL12 13
– “Tow truck” mode
– Activate engine blocking
This mode is intended for car transportation with preservation of arming
function. The“Tow truck”mode can be activated only when the system is
armed, it will be deactivated automatically when disarming.
Call the module number. If the system is in PANIC mode, receive an
emergency call.
Dial 15* to enable the“Tow truck mode”, the system will disable motion,
shock and tilt sensors. To end the session, hang up the phone.
To disable this mode, disarm the system.
WARNING! THE ENGINE BLOCKING THAT WAS ENABLED
VIA A PHONE 666* CAN BE DEACTIVATED ONLY BY DIALING
999*XXXX
ХХХХ – Deactivate engine blocking. The “Secret
PIN-code”(ХХХХ) written on the Pandora NAV-X
owner’s card is required for this command
– Switch on an additional channel
– Switch o an additional channel
Changing settings by a phone
To change the system settings by a phone:
• Disarm the system;
• Call the system number and wait for the answer;
• Turn on ignition for 3-6 seconds (but no more than 7 seconds),
then switch it o.
• The module will enter settings mode
You will hear the list of commands and theirs functions after
entering setting mode (see the commands below 1 * , 2 * ).
1 * Phone number settings
1 * Main owner’s phone number
2 * Additional owner’s phone number
3 * Second additional owner’s phone number
4 * Balance inquiry number
5 * System’s phone number.
WARNING! WE RECOMMEND THAT YOU WILL LISTEN VOICE
HINTS WHILE CHANGING THE SETTINGS BY A PHONE.

TELEMETRY MODULE PANDORA NAV-X USER MANUAL14 15
2 * Additional functions
1 * Changing guest PIN-code
Write down or remember the new code
2 * Guest calls
If the setting is disabled, you can control the module only from the main
owner’s phone number. If it is enabled, you can call from any phone
number, but it will be required to enter the Guest PIN-code to control the
module.
3 * Remote engine blocking
The setting allows or doesn’t allow to block the engine by the 666* DTMF
command
4 * Listening function
The setting allows or doesn’t allow to use the 007* DTMF command.
5 * Set threshold of voltage for sending a text message
You will receive a text message when the voltage is lower than the specied
threshold.
An example of changing main owner’s phone number:
1. Enter the setting menu via a phone according to the instruction above
2. Dial the DTMF command 1 * (phone number settings) and 1 *
(owner’s system number);
3. Enter new owner’s number in the format 7*XXXXXXXXXXX #
(the system recognizes‘*’as ‘+’);
4. To conrm, dial 1 * .
NOTE! ALL OTHER PHONE NUMBERS CAN BE SET IN THE
SAME MANNER.
SETTINGS
General information
Before installation, congure the module using the Pandora Alarm
Studio, pair the module with a security-service system, change a
SIM-card (if required).
Entering the programming mode/ entering the
“Service PIN code”
To change the settings, update rmware, pair the module with a
security-service system, the module must be in the programming
mode. To enter the programming mode, it is required to enter the
“Service PIN-code”(default value is 1-1-1-1).
VALET buttonmicro-USB

TELEMETRY MODULE PANDORA NAV-X USER MANUAL16 17
Enter the‘Service PIN-code”using the VALET button:
Press the button the number of times equals to the rst digit.
Pauses between presses should not exceed 1 second. Each
pressing will be conrmed with a green ash of the LED. A pause
for more than 1 second and a red ash of the LED conrm the
input of the rst digit. Then you can enter the next digit.
Enter the other digits in the same manner. The module will
conrm the correct PIN-code with the series of red and green
ashes.
Programming menu
Some functions can be changed only by the VALET button and
the “Programming menu”.
Use the VALET button to enter the desired level number after
entering the programming mode:
Press the button the number of times equals to level number,
pauses between presses should not exceed 1 second.
Level number Module function
Level #1 Pairing the module with a security-service
system
Level #2 Changing the“Service PIN-code”
Level №1 - Pairing the module with a security-service
system
Update rmware of the security-service system (base unit
rmware and Bluetooth modem rmware) before pairing.
The external power supply of the Pandora NAV-X module must be
connected during pairing.
Pairing procedure:
Enter the Level №10 or Level №10.8 (it depeneds on a system) of
the security-service system – Recording a telemetry module. The
LED indicator of the system will light green and the system will
enter the recording of the Pandora NAV-X module.
Enter the Level №1 of the telemetry module –“Level №1 – Pairing
the module with a security-service system”. If the procedure is
done successfully, the security-service system will sound a beep
and the LED will light green.
To nish pairing, briey press the VALET button of the security-
service system and the VALET button of the Pandora NAV-X module.
WARNING! ENABLE GPS AND SET CORRECT TIMEZONE IN
THE SETTINGS OF THE SECURITY-SERVICE SYSTEM AFTER
PAIRING THE MODULE

TELEMETRY MODULE PANDORA NAV-X USER MANUAL18 19
Level №2 - Changing the “Service PIN-code”
Prepare a new value of the “Service PIN-code”, it should consist of
4 digits (from 1 to 9). We recommend that you write down and
remember the new value.
Changing the“Service PIN-code” procedure:
Enter the level №2, the module will enter the“Changing the
Service PIN-code”mode.
Press the VALET button the number of times equals to the rst
digit of a new code. Pauses between presses should not exceed
1 second, every pressing will conrm with a green ash of the
LED. A pause for more than 1 second and a red ash of the LED
conrms the input of the rst digit. Then you can enter the next
digit.
Enter the other digits in the same manner. The input of the fourth
digit will be conrmed by the series of red and green ashes of
the LED. The system will wait for PIN-code re-entering.
Enter all four digits again.
If you were able to correctly enter the“Service PIN-code“ twice,
the LED indicator will produce the series of red and green ashes,
the new PIN-code will be recorded, the system will return to the
programming mode.
In case of the incorrect code input, the LED indicator will be lit red,
the system will return to programming mode.
Programming and updating
Programming and updating of the module software is performed
using the Pandora Alarm Studio.
Download the Pandora Alarm Studio to a PC with Windows
XP/Vista/7/8/10;
Extract the program from the archive and run the le AlarmStudio.
exe;
Connect the module to a PC via a USB cable;
Enter the“Service PIN-code”using the VALET button, the Pandora
Alarm Studio will automatically connect to the module.
NOTE! It is recommended that you update rmware of the
module before installing and programming.
Step by step example
ATTENTION! POWER SUPPLY MUST BE DISCONNECTED
(BATTARIES MUST BE REMOVED AND EXTERNAL POWER
MUST BE OFF) WHEN YOU CONFIGURE THE MODULE.
STEP №1.0 – Preparing for programming
Carefully remove the battery cover and the cover of the external

TELEMETRY MODULE PANDORA NAV-X USER MANUAL20 21
power connector. To do this, unscrew all screws using a“Philips“:
screwdriver.
STEP №1.1 – Changing a SIM-card
Carefully perform the following actions:
Make sure that a new SIM-card is working. Insert the SIM into
your mobile phone and check the following services: voice
communication, SMS, internet connection (check in 2G mode).
Disable PIN request of the SIM.
Remove the old SIM from the slot and insert a new one.
ATTENTION! THE SIM-CARD INSTALLED FROM THE
FACTORY IS LINKED TO THE MODEM OF THE MODULE AND
CANNOT WORK WITH OTHER DEVICES.
STEP №2.0 – Module setup
Make the following settings using the Pandora Alarm Studio:
“Main owner’s number” setting – enter the owner’s phone number
in the following format: +xxxxxxxxxxx. The module will sent SMS
and voice notications to this phone number. You can also control
the module using DTMF commands without the“Guest PIN-code”
when you call from this phone number.
“Guest PIN-code”setting – change the default value of the PIN
(1-2-3-4). The“Guest PIN-code” is required if you call not from the
“Main owner’s number”.
“Additional phone numbers”– specify additional phone numbers.
The module will sent SMS and voice notications to these phone
numbers.
“Time zone shift relative to UTC” - specify the current time zone
oset. It is required for accurate time determination by a GPS/
GLONASS receiver.
Make additional settings if required “Guest login”, “Control via
GPRS”,“Control via GSM”, “Voice and text notications”.
STEP №2.1 – Additional settings when changing the SIM card
Make the following settings if you have changed the SIM card:
“System phone number” setting – specify a new number of the
installed SIM card in the format +xxxxxxxxxxx.
“Balance inquiry number” setting – Specify a command of the
“Balance request” corresponding to a carrier.
“ GPRS (APN) operator access point”, “GPRS operator username”,
“GPRS operator password”– enter APN settings of your carrier.
STEP №2.2 – Finishing setup
Save the changed data in the Pandora Alarm Studio and
disconnect the USB cable after you nish setting up the module.

TELEMETRY MODULE PANDORA NAV-X USER MANUAL22 23
STEP №3 – Pairing the module with a security-service system
Pair the module with a security-service system (see “Level №1 -
Pairing the module with a security-service system”).
STEP №4 – Module checking
Connect the main power and check the module functions
before installation: control by a phone, web-interface, mobile
applications, voice and SMS notications, and request current
coordinates 500*, request balance of the SIM-card 100*.
INSTALLATION
Congure and check the module before installation.
General installation requirements
The module must be rigidly xed in order to avoid damage and
movement while driving.
The device must be installed in places where there is no any
liquids, condensate and high temperature.
The module installation must be performed when the module
connectors and the negative battery terminal are disconnected.
Wire connections and insulation must be performed in accordance
with the requirements of car manufacturers. Avoid contact of wires
with sharp elements and moving parts of the car. Wiring through
holes must be done using special rubber bushings.
To avoid the destruction of compounds by car vibration, ensure
that there is a bit of free length to the wiring, providing enough
sagging.
Main power supply connection
Connect power supply wires:
Black wire (–) –“Ground” of the module. It connects to the car
“ground”. This wire must be connected rst during installation
Red wire (+12V) – Power of the module. It connects to reliable
conductor with constant voltage of +12V.
Connect the connectors and check it.
1 Red
2 Black
(+)
(-)
MODULE PLACING
2.4GHz antenna
(BLE4.2)
GPS/GLONASS antenna GSM antenna

TELEMETRY MODULE PANDORA NAV-X USER MANUAL24 25
Module placing
The following conditions must be considered when installing the
module:
Good conditions for signals of the GPS/GLONASS receiver, GSM
modem, 2.4GHz radio interface (BLE4.2);
WARNING! IT IS PROHIBIT TO CONNECT THE MODULE TO
CAR WIRES WITH NORMAL VOLTAGE OTHER THAN 12V.
The module should be installed the front side up (the side with
the VALET button and the LED). Satellite GPS/GLONASS signal
can pass through plastic, glass, but it can’t pass through metal
surfaces.
WARRANTY OBLIGATIONS
The manufacturer guarantees correct operation of the
service-security system if exploitation, installation, storage and
transportation conditions described in this manual were met. The
device should only be used according to installation scheme and
user manuals.
Parts malfunctioning during warranty period on the fault of the
manufacturer should be repaired or replaced by the installation
center of the manufacturer or by certied service center.
The user loses the right for warranty services in the following
cases:
• when warranty period expires
• if exploitation, installation, storage or transportation conditions
were not met;
• if there is mechanical damage of the external parts of the system
after it is sold. This includes: re damage, consequential damage
in case of car accident, aggressive liquids and water seeping
damage, damage caused by improper use;
• if the damage was caused with incorrect settings and parameter
adjustment;
• if there is no properly lled warranty card.
Warranty period is 3 years since the moment of purchase, but
no more than 3,5 (three and a half ) years since the moment of

TELEMETRY MODULE PANDORA NAV-X USER MANUAL26 27
production. This warranty does not include batteries, as they have
their own service lifetime. Maintenances and repairs of the system
with expired warranty period are carried out at the expense of the
user on a separate contract between the user and the installer/
service center.

TELEMETRY MODULE PANDORA NAV-X28
Warranty card
Model Pandora NAV-X
Serial number
Date of purchase «______»______________20 y.
Seller’s stamp
Seller’s signature ____________________________________
Acceptance certicate
The Pandora NAV-X is in conformity with Electromagnetic
Compatibility Directive EMC 2004/108/EC and R&TTE Directive
1999/5/EC.
Serial number
Date of production «______»______________20 y.
Responsible person’s signature ______________(stamp)
Packager ____________________ Signature______________
(personal stamp)
