Paradyne Hotwire 5100 User manual

HOTWIRE 5100 DSL
ACCESS SYSTEM
CUSTOMER PREMISES
USER’S GUIDE
Document No. 5100-A2-GB21-00
November 1996

Printed on recycled paper
A 5100-A2-GB21-00
November 1996
Copyright 1996 Paradyne Corporation.
All rights reserved.
Printed in U.S.A.
Notice
This publication is protected by federal copyright law. No part of this publication may be copied or distributed,
transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form
or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the
express written permission of Paradyne Corporation, 8545 126th Avenue North, P.O. Box 2826, Largo,
Florida 33779-2826.
Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation
reserves the right to revise this publication and to make changes from time to time in the contents hereof without
obligation of Paradyne Corporation to notify any person of such revision or changes.
Changes and enhancements to the product and to the information herein will be documented and issued as a new
release to this manual.
Warranty, Sales, and Service Information
Contact your sales or service representative directly for any help needed. For additional information concerning
warranty, sales, service, repair, installation, documentation, or training, use one of the following methods:
Via the Internet: Visit the Paradyne World Wide Web site at http://www.paradyne.com
Via Telephone: Call our automated call system to receive current information via fax or to speak with a
company representative.
— Within the U.S.A., call 1-800-870-2221
— International, call 813-530-2340
Trademarks
All products and services mentioned herein are the trademarks, service marks, registered trademarks or registered
service marks of their respective owners.

Important Regulatory Information
B
5100-A2-GB21-00 November 1996
Important Safety Instructions
1. Read and follow all warning notices and instructions marked on the product or included in the manual.
2. This product is intended to be used in a UL-Listed/CSA-Certified computer with a 3-wire grounding type plug (a
plug which has a grounding pin). This is a safety feature. Equipment grounding is vital to ensure safe operation.
Do not defeat the purpose of the grounding type plug by modifying the plug or using an adapter.
3. When installed in the final configuration, the product must comply with the applicable Safety Standards and
regulatory requirements of the country in which it is installed. If necessary, consult with the appropriate regulatory
agencies and inspection authorities to ensure compliance.
In addition, if the equipment is to be used with telecommunications circuits, take the following precautions:
—Never install telephone wiring during a lightning storm.
—Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
—Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the
network interface.
—Use caution when installing or modifying telephone lines.
—Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of
electric shock from lightning.
—Do not use the telephone to report a gas leak in the vicinity of the leak.

Important Regulatory Information
C 5100-A2-GB21-00
November 1996
Declaration of Conformity
This Declaration of Conformity is made by Paradyne Corporation pursuant to Parts 2 and 15 of the Federal
Communications Commission’s Rules. This compliance information statement pertains to the following products:
Trade Name: HOTWIRE
Model Numbers: 5161-B2-020
5171-B2-020
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The name, address, and telephone number of the responsible party is given below:
Paradyne Corporation
8545 126th Ave. N.
Largo, Florida 33773
Phone: [phone]

i
5100-A2-GB21-00 November 1996
Contents
About This Guide
Purpose and Audience iii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Guide Summary iii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product-Related Documents iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1About HotWire 5100 DSL Access System
What is the HotWire DSL Access System? 1-1. . . . . . . . . . . . . . . . . . . . . . . . .
Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Secured Access 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
About the HotWire Card 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Equipment and Software Requirements 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
HotWire Diagnostics Utility 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
User Interface 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Installation and Setup
Where to Begin 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Package Contents 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Order of Installation 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the HotWire Diagnostics Utility 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing the Card 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting an I/O Base Address 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the I/O Base Address 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the IRQ Switches 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inserting the Card 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power-Up Self-Test 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Network Driver 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Network Driver Using Windows for Workgroups 3.11 2-10.
Installing the Network Driver Using Windows 95 2-11. . . . . . . . . . . . . . . . .

Contents
ii 5100-A2-GB21-00
November 1996
Checking Installation 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Verifying/Changing Switch Settings in Software 2-13. . . . . . . . . . . . . . . . . .
Verifying/Changing Line Speed in Software 2-14. . . . . . . . . . . . . . . . . . . . .
Checking/Setting Protocol.ini Path (Not Applicable
to Windows 95) 2-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Saving Configuration Settings 2-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Card Status 2-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting Tips 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3Using the HotWire Diagnostics Utility
Accessing the Main Menu 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Hardware Status 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Viewing MAC Address 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Resetting the Card 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Card Status 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Viewing Transmission Statistics and Network Status 3-3. . . . . . . . . . . . . . . . .
Running Loopback Tests 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Downloading Firmware 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exiting the Utility 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ALEDs
BPin Assignments
CTechnical Specifications
DI/O Base Address Switch Settings
Glossary
Index

iii
5100-A2-GB21-00 November 1996
About This Guide
Purpose and Audience
This guide describes how to install and set up the Customer Premises card of the
HotWire 5100 DSL Access System. The guide is written for users of the HotWire
DSL (Digital Subscriber Loop) access system.
Guide Summary
Section Description
Chapter 1 About HotWire 5100 DSL Access System. Provides a
high-level overview of the operation of the HotWire and lists its
hardware and software requirements for installing the card in
the PC.
Chapter 2
Installation and Setup. Describes how to install and set up the
HotWire card.
Chapter 3
Using the HotWire Diagnostics Utility. Describes how to use
the HotWire Diagnostics Utility.
Appendix A
LEDs. Provides the LED descriptions.
Appendix B
Pin Assignments. Provides the pinouts for the card.
Appendix C
Technical Specifications. Provides the specifications for the
card.
Appendix D
I/O Base Address Switch Settings. Provides a table for switch
settings for possible I/O base addresses.
Glossary Defines acronyms and terms used in this document.
Index Lists key terms, acronyms, concepts, and sections in
alphabetical order and provides page references.

About This Guide
iv 5100-A2-GB21-00
November 1996
Product-Related Documents
Document Number Document Title
5100-A2-GB20 HotWire 5100 DSL Access System Central Office
User’s Guide

1-1
5100-A2-GB21-00 November 1996
About HotWire 5100 DSL Access
System 1
What is the HotWire DSL Access System?
The HotWire 5100 DSL Access System provides high-speed Internet or corporate
LAN access over traditional twisted-pair telephone wiring. Using the
HotWire modem card, you can connect to a Central Office (CO) to access
Internet service providers or corporate networks.
PC with
Internal
Hotwire
Modem PC with
Internal
Hotwire
Modem
Splitter*
Phone Splitter*
Phone
Brouter
Domain
Name Server
496-14979
To Internet
Service
Providers
Central
Office
*A splitter is an interface device installed by a CO technician
outside your premises.

About HotWire 5100 DSL Access System
1-2 5100-A2-GB21-00
November 1996
Features
HotWire has the following features:
Supports CAP Rate Adaptive Digital Subscriber Loop (CAP RADSL)
High-speed data rates varying depending on the RADSL and ADSL cards
Security features in the HotWire CO hardware that prevent remote users from
accessing another user’s PC files or LAN traffic
Prevention against degradation of telephone service while using the RADSL
card
Secured Access
To ensure file access security, the HotWire Network Access System provides
security features which prevent other users from accessing your PC files or your
LAN traffic.
About the HotWire Card
The HotWire card is an ISA 16-bit, add-on card with a 6-pin telephone modular
jack connector used for the DSL network connection. Refer to Appendix B for pin
assignments.
The card features a set of LEDs located at the top edge of the card on the
component side. These LEDs are not visible without removing the PC cover. The
LEDs:
Enable you to verify card operating status
Provide useful information for troubleshooting. Refer to Appendix A for the
descriptions of the LEDs and their operational status indications.
The PC card edge connector plugs into a 16-bit expansion slot in an
IBM-compatible 80486 (or higher) system board and conforms to ISA bus
standards.

About HotWire 5100 DSL Access System
1-3
5100-A2-GB21-00 November 1996
Equipment and Software Requirements
Verify that you have the following hardware and software before installing the
HotWire card.
Hardware Requirements
80486 (or higher) IBM PC or compatible
8 MB RAM minimum (16 MB RAM recommended)
One 1.44 MB, 3 1/2″floppy drive (for installation)
2 MB free disk storage (for program files)
Software Requirements
DOS 5.0 or later
Windows 3.1 (or later) and TCP/IP application with IP stack NDIS 2.01
compliant (see note) or Windows For Workgroups 3.11 (or later) or
Windows 95
NOTE:
If the TCP/IP software is not installed already, you will be asked to install it as
a step in the Network Driver installation process.
HotWire Diagnostics Utility
Use the HotWire Diagnostics Utility supplied with the DSL card for configuring the
card after installation, troubleshooting the card, and downloading firmware. The
Diagnostics Utility provides screen help in standard windows format. Refer to
Chapter 3 for more information on this utility.
User Interface
The Diagnostics Utility uses standard Windows user interface conventions for all
windows including Help screens.

2-1
5100-A2-GB21-00 November 1996
Installation and Setup 2
Where to Begin
1. Check your package contents.
2. Review the order of installation.
3. Begin installation.
Package Contents
Your HotWire 5100 DSL Access System package should contain the following:
HotWire 5100 DSL Access System card
Client PC HotWire Diagnostics Utility and Drivers disk
Cable

HotWire 5100 DSL Access System Customer Premises User’s Guide
Order of Installation
Install and set up your HotWire DSL card by performing the following steps in the
order listed:
1. Install the HotWire Diagnostics Utility.
2. Prepare the card for installation.
3. Install the card.
4. Install the network driver. This program is included on your HotWire
Diagnostics Utility and Drivers disk.
5. Run the Diagnostics Utility to verify/save card settings and check operation.

Installation and Setup
2-2 5100-A2-GB21-00
November 1996
Installing the HotWire Diagnostics Utility
"Procedure
To install the Diagnostics Utility:
1. Insert the HotWire Diagnostics Utility and Drivers disk in drive A.
2. Enter Windows and:
If . . . Select . . .
On the Program Manager window File, then Run.
Using Windows 95 Start, then Run.
3. Type A:\SETUP.EXE and click on OK.
4. Follow the screen instructions for installing the software. When the install
program prompts for a destination directory for the Diagnostics Utility, you
can specify a directory or click on Next to accept the default directory.
5. Click on OK when installation completes.
An icon is created for the utility. You can double-click on the icon to start the utility
when needed.
NOTE:
Some Diagnostics Utilities can interfere with network data so the Diagnostics
Utility menus should be open only when configuring or testing the card.
Preparing the Card
For the HotWire DSL card to operate properly with your PC configuration, you
need to set the following DIP switches:
HI/O Base Address
HIRQ setting

Installation and Setup
2-3
5100-A2-GB21-00 November 1996
Selecting an I/O Base Address
To assist you in selecting an available I/O base address on your system, the
HotWire Diagnostics Utility provides a selection that scans your system to obtain
unused addresses. To compose the list, however, the utility must rely on the
integrity of your installed cards to report their base address usage correctly.
Procedure
To use this feature:
1. Enter Windows.
2. Double-click on the HotWire program icon to access the main menu. For a
complete description of this menu, refer to Chapter 3.
3. Select Recommend Base Address from
the Configuration menu to display a list
of unused base addresses.
If necessary, click on to scroll
the window.
4. Make a note of an available address.
5. Click on one of the following:
—Exit to close the window
and return to the main menu.
—Help to access screen help.
6. From the HotWire main menu,
select File, then select Exit to quit
the utility.
NOTE:
Typically, the utility will detect the card’s base address once it is installed.
Subsequently, when you select Recommend Base Address, the Available
Base Address window displays only that address.

Installation and Setup
2-4 5100-A2-GB21-00
November 1996
Setting the I/O Base Address
I/O base addresses are areas of memory that your CPU uses to distinguish
between the various peripheral devices connected to your system when
transferring or receiving data. This card uses a single DIP switch bank (SW1), as
shown in the card illustration below, to assign the card’s base address. The
illustration shows the switch settings for an I/O base address of 380.
NOTE:
Each hardware device included in the system must have a different I/O base
address.
496-14998
1234567812345678
1234
I/O Base Address
J2
6-Pin
Modular Jack
(Network Access
Connector)
LEDs
678
ON
12345
SW1
Procedure
To set the I/O base address switches:
1. Determine the appropriate I/O base address for the card. You may use the
utility feature for obtaining a list of unused addresses. See
Selecting an I/O
Base Address
on page 2-3.
2. Identify the switch settings for the address selected. Appendix D provides a
list of switch settings for possible addresses.
3. Set the switches to the desired address. A switch in the up or On position
represents a binary 1. A switch in the down or Off position represents a
binary 0.

Installation and Setup
2-5
5100-A2-GB21-00 November 1996
NOTE:
Switches 7 and 8 on SW1 are not used so they may be On or Off. The
example shows them On.
Make a note of the base address used so you can verify/set that address in the
HotWire Hardware Setup window after the HotWire software is installed.
Setting the IRQ Switches
IRQ (hardware interrupt request) is a signal used by your device to inform your
CPU when it wants to transfer or receive data. Use Switch Banks 2 and 3 (SW2
and SW3) to select an IRQ. You can use the following illustration to locate these
switches. The callouts show the switch settings when IRQ is set to 5.
NOTE:
The IRQ setting must not conflict with any other device in the PC.
496-14970
1234567812345678
1234
678
ON 12345
IRQ 14 15 12 11 10 3 4 5
ON 1234
IRQ 9 7 6 not used
SW2
SW3
J2
6-Pin
Modular Jack
(Network Access
Connector)
LEDs

Installation and Setup
2-6 5100-A2-GB21-00
November 1996
The following table shows how the switch setting was determined for the previous
illustration where the IRQ was set to 5.
SW2 SW3
IRQ '14 15 12 11 10 3 4 5 9 7 6 *
Switch 1 2 3 4 5 6 7 8 1 2 3 4
Setting Off Off Off Off Off Off Off ON Off Off Off Off
*= Not Used
"Procedure
To set the IRQ switches:
1. Determine the appropriate IRQ for the card. Using the previous table, you
may already know of an available IRQ. It not, refer to your PC documentation
for instructions on how to determine available IRQs. Typically, the available
IRQ settings are 5, 7, 10 and 11. It is common in systems to use the other
IRQs for system devices.
2. Identify the switch to be set on SW2 or SW3 for the selected IRQ using the
previous table (note that the table shows the setting if the IRQ is set to 5). A
switch in the On position selects the IRQ associated with that switch. All other
switches should be Off.
3. Set the switch.
Make a note of the IRQ setting used so you can verify/set the Interrupt No. in the
HotWire Hardware Setup window after the HotWire software is installed.

Installation and Setup
2-7
5100-A2-GB21-00 November 1996
Inserting the Card
Procedure
To install your HotWire DSL card into your PC:
CAUTION:
This modem card is intended to be installed in UL Listed CSA Certified
equipment in the field by the user in the manufacturer’s defined
operator access area. Check the equipment operating/installation
instructions and/or equipment manufacturer to verify/confirm if your
equipment is suitable for user-installed application cards.
1. Turn Off the PC. Disconnect cables for the monitor and any powered
equipment to the PC. Then, lay the PC chassis on a flat surface.
2. After waiting at least one minute, remove the PC cover and touch the metal
PC frame to discharge any static electricity on your clothes or body.
CAUTION:
Plugging in and turning on the system at the wrong time could result in
an electrical shock to you or cause damage to your computer system’s
components.
3. Choose an unused 16-bit expansion slot
for the card.
4. Unscrew and remove the slot cover
panel, if present.
16-Bit
ISA Expansion
Card Slot
8-Bit
ISA Expansion
Card Slot
496-14966
495-14661

Installation and Setup
2-8 5100-A2-GB21-00
November 1996
5. Verify that the DIP switches on the HotWire
card are set to the proper settings.
6. Insert the card into the expansion slot:
— Pick up the card by the edges or the
top corners. Be careful not to touch
the pins on the bottom of the card.
— Align the connector on the bottom of
the card, directly over the slot. Place
one hand along the top edge of the
card, directly over the connector
area, and push down firmly but
gently until the connector is fully
seated.
— To ensure that the card is properly
seated, gently try to lift the card.
7. Secure the card to the chassis using a bracket screw.
8. Insert the 6-pin plug on the provided
cable into the network access jack
on the card. Connect the other end of
the cable to the network access point.
9. Plug in the power cable and
power on the PC, being careful not to
touch any internal boards or components,
and verify that the LEDs function as
follows (refer to Appendix A to locate
the LEDs):
— The SYS LED turns solid green.
Refer to the
Power-Up Self-Test
section following this procedure if
the SYS LED does not turn green.
— The CD LED blinks and then both the CD and LNK LEDs turn solid
green. This indicates that the card is communicating with the central
office unit, meaning your DSL link is operational. If the CD and LNK
LEDs do not function as stated, stop the installation process and
contact your customer service representative for assistance.
10. Turn the power Off again.
11. Replace and secure the cover to the PC.
12. Plug in the monitor and other peripheral devices you disconnected and power
on the PC.
16-Bit
ISA Expansion
Card Slot
8-Bit
ISA Expansion
Card Slot
496-1496
8
Push Down Firmly
496-14971
Network
Access
Jack
Hotwire
Card
Cable

Installation and Setup
2-9
5100-A2-GB21-00 November 1996
Power-Up Self-Test
Whenever you turn on your system or after the card reset operation is selected in
the Diagnostics Utility, a power-up self-test is automatically performed on the
HotWire DSL card to ensure that the card is installed and functioning properly.
The self-test includes a basic hardware test and verification of card components.
The SYS (system) LED state identifies the following conditions by:
Turning solid green if the test is successful.
Turning Off if the test fails.
The LEDs are only visible when the PC cover is removed. To locate the SYS LED
on the card, refer to Appendix A for an illustration of the LEDs. If the test fails:
Recheck or change the IRQ setting.
Check the seating of the card.
Installing the Network Driver
After installing the card, you must install the network driver.
If you are using . . . Refer to . . .
Windows for Workgroups 3.11 Installing the Network Driver Using
Windows for Workgroups 3.11 to install the
HotWire DSL NDIS driver contained on the
installation disk.
Windows 95 Installing the Network Driver Using
Windows 95
to install the HotWire DSL
NDIS driver contained on the installation
disk.
Windows 3.1 or Non-Windows for
Workgroups 3.11 TCP/IP stack Your TCP/IP stack documentation for information on how to install the HotWire
DSL NDIS driver.
When you reboot your PC after driver installation, the driver will obtain your
Media Access Control (MAC) address from the central office and cache it locally.
