Parallax Gyroscope Module KickStart (#27911)
What It Can Do
•Modular angular rate sensor tracks motion in three axes
•Three selectable measurement scales, with rates up to 2000° per second
•Built-in temperature sensor; can be used separately, or for temperature drift compensation
The 3-Axis Gyroscope module provides separate data values for yaw, pitch, and roll. Motion is
indicated as a positive or negative value, depending on the direction of rotation. The sensor is
useful in 3D simulation, virtual gaming input devices, robotics, and for remotely controlled or
unpiloted aircraft and submersibles.
Gyroscopes are commonly used with multi-axis accelerometers, where the data from both
sensors can provide useful information detailing speed and direction of travel. The Memsic 2125
Dual-axis Accelerometer and MMA7455 3-Axis Accelerometer Module are good companion
accelerometers for the 3-Axis Gyroscope module
It may also be used with an accelerometer and 3-axis compass to construct a 9-axis IMU (inertial
measurement unit), common in unmanned aerial vehicles, such as drones and quadcopters.

Copyright © Parallax Inc. Page 2 of 12
Parts List
•3-Axis Gyroscope module
•BASIC Stamp HomeWork Board, Propeller BOE, Propeller QuickStart, or Arduino Uno
microcontroller (with breadboard, as needed)
•22 gauge solid conductor hookup wire
Basic Wiring
•Power Requirements: 2.7 to 6.5 VDC
•Communication Interface: I2C (up to 400 kHz) or SPI (10 MHz; 4 & 3 wire)
•Dimensions: 0.85 X 0.80 in (2.16 X 2.03 cm)
Program KickStarts
The KickStart examples display raw data output for each of the three axes. Values are retrieved
from the module using the I2C interface.

Copyright © Parallax Inc. Page 3 of 12
BASIC Stamp HomeWork Board
' {$STAMP BS2}
' {$PBASIC 2.5}
SDA PIN 0 ' SDA of gyro connected to P0
SCL PIN 1 ' SCL of gyro connected to P1
WRITE_Data CON $D2 ' Request Write operation
READ_Data CON $D3 ' Request Read operation
' Control registers
CTRL_REG1 CON $20
CTRL_REG2 CON $21
CTRL_REG3 CON $22
CTRL_REG4 CON $23
STATUS_REG CON $27
OUT_X_INC CON $A8
X VAR Word
Y VAR Word
Z VAR Word
rawl VAR Word
rawh VAR Word
' Variables for I2C communications
I2C_DATA VAR Byte
I2C_LSB VAR Bit
I2C_REG VAR Byte
I2C_VAL VAR Byte
PAUSE 100 ' Power up delay
' Set up data ready signal
I2C_REG = CTRL_REG3
I2C_VAL = $08

Copyright © Parallax Inc. Page 4 of 12
GOSUB I2C_Write_Reg
' Set up "block data update" mode
I2C_REG = CTRL_REG4
I2C_VAL = $80
GOSUB I2C_Write_Reg
' Send the get continuous output command
I2C_REG = CTRL_REG1
I2C_VAL = $1F
GOSUB I2C_Write_Reg
DO
GOSUB Gyro_Get_Raw ' Get XYZ data
' Divide X Y Z, by 114 to reduce noise
IF (X.BIT15) THEN
X = (ABS X) / 114
X = -X
ELSE
X = X / 114
ENDIF
IF (Y.BIT15) THEN
Y = (ABS Y) / 114
Y = -Y
ELSE
Y = Y / 114
ENDIF
IF (Z.BIT15) THEN
Z = (ABS Z) / 114
Z = -Z
ELSE
Z = Z / 114
ENDIF
DEBUG HOME, "RAW X = ",11, SDEC X, CR ' Display data
DEBUG "RAW Y = ",11, SDEC Y, CR
DEBUG "RAW Z = ",11, SDEC Z, CR
PAUSE 250
LOOP
Gyro_Get_Raw:
GOSUB Wait_For_Data_Ready
GOSUB I2C_Start
I2C_DATA = WRITE_DATA
GOSUB I2C_Write ' Read the data starting
I2C_DATA = OUT_X_INC ' at pointer register
GOSUB I2C_Write
GOSUB I2C_Stop
GOSUB I2C_Start
I2C_DATA = READ_DATA

Copyright © Parallax Inc. Page 5 of 12
GOSUB I2C_Write
GOSUB I2C_Read
rawL = I2C_DATA ' Read high byte
GOSUB I2C_ACK
GOSUB I2C_Read
rawH = I2C_DATA ' Read low byte
GOSUB I2C_ACK
X = (rawH <&lt 8) | rawL ' OR high and low into X
' Do the same for Y and Z:
GOSUB I2C_Read
rawL = I2C_DATA
GOSUB I2C_ACK
GOSUB I2C_Read
rawH = I2C_DATA
GOSUB I2C_ACK
Y = (rawH <&lt 8) | rawL
GOSUB I2C_Read
rawL = I2C_DATA
GOSUB I2C_ACK
GOSUB I2C_Read
rawH = I2C_DATA
GOSUB I2C_NACK
Z = (rawH << 8) | rawL
GOSUB I2C_Stop
RETURN
'---------I2C functions------------
' Read the status register until the ZYXDA bit is high
Wait_For_Data_Ready:
DO
I2C_REG = STATUS_REG
GOSUB I2C_Read_Reg
LOOP UNTIL ((I2C_DATA & $08) <> 0)
RETURN
' Set I2C_REG & I2C_VAL before calling this
I2C_Write_Reg:
GOSUB I2C_Start
I2C_DATA = WRITE_DATA
GOSUB I2C_Write
I2C_DATA = I2C_REG
GOSUB I2C_Write
I2C_DATA = I2C_VAL
GOSUB I2C_Write
GOSUB I2C_Stop
RETURN
' Set I2C_REG before calling this, I2C_DATA will have result
I2C_Read_Reg:

Copyright © Parallax Inc. Page 6 of 12
GOSUB I2C_Start
I2C_DATA = WRITE_DATA
GOSUB I2C_Write
I2C_DATA = I2C_REG
GOSUB I2C_Write
GOSUB I2C_Stop
GOSUB I2C_Start
I2C_DATA = READ_DATA
GOSUB I2C_Write
GOSUB I2C_Read
GOSUB I2C_NACK
GOSUB I2C_Stop
RETURN
I2C_Start:
LOW SDA
LOW SCL
RETURN
I2C_Stop:
LOW SDA
INPUT SCL
INPUT SDA
RETURN
I2C_ACK:
LOW SDA
INPUT SCL
LOW SCL
INPUT SDA
RETURN
I2C_NACK:
INPUT SDA
INPUT SCL
LOW SCL
RETURN
I2C_Read:
SHIFTIN SDA, SCL, MSBPRE, [I2C_DATA]
RETURN
I2C_Write:
I2C_LSB = I2C_DATA.BIT0
I2C_DATA = I2C_DATA / 2
SHIFTOUT SDA, SCL, MSBFIRST, [I2C_DATA\7]
IF I2C_LSB THEN INPUT SDA ELSE LOW SDA
INPUT SCL
LOW SCL
INPUT SDA
INPUT SCL
LOW SCL
RETURN
Note: When this program is run the BASIC Stamp Debug Terminal will automatically open.

Copyright © Parallax Inc. Page 7 of 12
Propeller BOE and Propeller QuickStart
Propeller BOE Wiring Diagram
Propeller QuickStart Wiring Diagram
OBJ
pst : "FullDuplexSerial"
CON
_clkmode = xtal1 + pll16x
_clkfreq = 80_000_000
SDApin = 0 ' SDA of gyro connected to P0
SCLpin = 1 ' SCL of gyro connected to P1
WRITE = $D2 ' Request Write operation
READ = $D3 ' Request Read operation
' Control registers
CTRL_REG1 = $20
CTRL_REG2 = $21
CTRL_REG3 = $22
CTRL_REG4 = $23
STATUS_REG = $27
OUT_X_INC = $A8
x_idx = 0
y_idx = 1
z_idx = 2
VAR
long x
long y
long z
long cx

Copyright © Parallax Inc. Page 8 of 12
long cy
long cz
long ff_x
long ff_y
long ff_z
long multiBYTE[3]
PUB Go | last_ticks
pst.start(31, 30, 0, 115200)
' Set modes
Wrt_1B(CTRL_REG3, $08) ' Data ready signal
Wrt_1B(CTRL_REG4, $80) ' Block data update
Wrt_1B(CTRL_REG1, $1F) ' Enable all axes
last_ticks := cnt
repeat
pst.tx(1) ' Set Terminal data
WaitForDataReady ' at top of screen
Read_MultiB(OUT_X_INC) ' Read XYZ bytes
' Divide by 114 to reduce noise
x := (x - cx) / 114
y := (y - cy) / 114
z := (z - cz) / 114
RawXYZ
WaitCnt(ClkFreq / 4 + Cnt) ' Delay before next loop
PUB RawXYZ
'Display Raw X,Y,Z data
pst.str(string("RAW X ",11))
pst.dec(x)
pst.str(string(13, "RAW Y ",11))
pst.dec(y)
pst.str(string(13, "RAW Z ",11))
pst.dec(z)
'' Below here routines to support I2C interfacing
PUB WaitForDataReady | status
repeat
status := Read_1B(STATUS_REG)
if (status & $08) == $08
quit
PUB Wrt_1B(SUB1, data)
''Write single byte to Gyroscope.

Copyright © Parallax Inc. Page 9 of 12
start
send(WRITE)
send(SUB1)
send(data)
stop
PUB Read_1B(SUB3) | rxd
''Read single byte from Gyroscope
start
send(WRITE)
send(SUB3)
stop
start
send(READ)
rxd := receive(false)
stop
result := rxd
PUB Read_MultiB(SUB3)
''Read multiple bytes from Gyroscope
start
send(WRITE)
send(SUB3)
stop
start
send(READ)
multiBYTE[x_idx] := (receive(true)) | (receive(true)) << 8
multiBYTE[y_idx] := (receive(true)) | (receive(true)) << 8
multiBYTE[z_idx] := (receive(true)) | (receive(false)) << 8
stop
x := ~~multiBYTE[x_idx]
y := ~~multiBYTE[y_idx]
z := ~~multiBYTE[z_idx]
PRI send(value)
value := ((!value) >< 8)
repeat 8
dira[SDApin] := value
dira[SCLpin] := false
dira[SCLpin] := true
value >>= 1
dira[SDApin] := false
dira[SCLpin] := false
result := not(ina[SDApin])
dira[SCLpin] := true
dira[SDApin] := true
PRI receive(aknowledge)

Copyright © Parallax Inc. Page 10 of 12
dira[SDApin] := false
repeat 8
result <<= 1
dira[SCLpin] := false
result |= ina[SDApin]
dira[SCLpin] := true
dira[SDApin] := (aknowledge)
dira[SCLpin] := false
dira[SCLpin] := true
dira[SDApin] := true
PRI start
outa[SDApin] := false
outa[SCLpin] := false
dira[SDApin] := true
dira[SCLpin] := true
PRI stop
dira[SCLpin] := false
dira[SDApin] := false
Note: To view the results of the demonstration, after uploading is complete run the Parallax
Serial Terminal from the Run menu, or press F12. Click the Enable button in the Terminal
window, then momentarily depress the Reset button on the Propeller QuickStart board to restart
the program.

Copyright © Parallax Inc. Page 11 of 12
Arduino Uno
#include <Wire.h>
#define CTRL_REG1 0x20
#define CTRL_REG2 0x21
#define CTRL_REG3 0x22
#define CTRL_REG4 0x23
int Addr = 105; // I2C address of gyro
int x, y, z;
void setup(){
Wire.begin();
Serial.begin(9600);
writeI2C(CTRL_REG1, 0x1F); // Turn on all axes, disable power down
writeI2C(CTRL_REG3, 0x08); // Enable control ready signal
writeI2C(CTRL_REG4, 0x80); // Set scale (500 deg/sec)
delay(100); // Wait to synchronize
}
void loop(){
getGyroValues(); // Get new values
// In following Dividing by 114 reduces noise
Serial.print("Raw X:"); Serial.print(x / 114);
Serial.print(" Raw Y:"); Serial.print(y / 114);
Serial.print(" Raw Z:"); Serial.println(z / 114);
delay(500); // Short delay between reads
}
void getGyroValues () {
byte MSB, LSB;
MSB = readI2C(0x29);
LSB = readI2C(0x28);

Copyright © Parallax Inc. Page 12 of 12
x = ((MSB << 8) | LSB);
MSB = readI2C(0x2B);
LSB = readI2C(0x2A);
y = ((MSB << 8) | LSB);
MSB = readI2C(0x2D);
LSB = readI2C(0x2C);
z = ((MSB << 8) | LSB);
}
int readI2C (byte regAddr) {
Wire.beginTransmission(Addr);
Wire.write(regAddr); // Register address to read
Wire.endTransmission(); // Terminate request
Wire.requestFrom(Addr, 1); // Read a byte
while(!Wire.available()) { }; // Wait for receipt
return(Wire.read()); // Get result
}
void writeI2C (byte regAddr, byte val) {
Wire.beginTransmission(Addr);
Wire.write(regAddr);
Wire.write(val);
Wire.endTransmission();
}
Note: To view the results of the demonstration, after uploading is complete click the Serial
Monitor icon in the Arduino IDE. This displays the Serial Monitor window. Momentarily
depress the Reset button on the Arduino board to restart the sketch.
For More Information
•See the 3-Axis Gyroscope (#27911) data sheet.
•More information on gyroscopes and inertial navigation may be found by searching Wikipedia:
Gyroscope.
•Combine the 3-axis gyroscope with the Parallax MMA7455 3-Axis Accelerometer Module
and Compass Module 3-Axis HMC5883L to create a 9-axis inertial momentum unit (IMU)
