Parallax RX-101 User manual

Instruction
Booklet
RX-101
Please read all instructions
carefully before opening box

PULL YOUR PARALLAX
FABRIC OUT OF THE BOX
& UNWRAP YOUR
EXTRUSION
CAREFUL NOT TO CUT
INTO THE BAGS OR THE BOX
AS YOU COULD DAMAGE
THE FABRIC
LINE UP THE X2 TOP CORNER
LENGTHS
NOTE: IF THERE IS NO SCREW
HOLE SIMPLY DRILL A HOLE
AS SHOWN BELOW
1
2

DEPENDING ON THE SURFACE, PRE-DRILL
ANY HOLES TO LINE UP WITH THE HOLES IN
THE EXTRUSION.
LINE UP THE SCREWS
SCREW INTO PLACE AND REPEAT FOR
THE OTHER LENGTHS UNTIL THE ENTIRE FRAME
IS FIXED INTO PLACE.
NOTE: THE RX-101 IS SPECIALLY DESIGNED TO
CATER FOR UNEVEN&UNSQUARE WALLS,
IT IS NOT IMPERATIVE THAT THE MITRE LINES UP
PERFECTLY ONLY THE TOP FABRIC CHANNEL
ITSELF
3
5

INSERT THE FABRIC INTO THE EXTRUSION STARTING WITH
THE CORNERS ENSURE THE SILICON GASKET IS CONCEALED
FOLLOW THE DIAGRAM BELOW FOR THE REMAINING
SILICON GASKET EDGE.
STARTING WITH ALL CORNERS
ENSURE SILICON GASKET EDGE ON FABRIC IS PUSHED AS FAR
INTO THE CHANNEL AS POSSIBLE, THIS SHOULD SUBSIDE
ANY WRINKLES THAT MAY HAVE APPEARED.
6
7
Inserting Fabric

CONTINUE WITH THE MIDDLE OF EACH LENGTH,
AND THEN THEREMAINDER OF THE FABRIC
CONTINUE UNTIL ALL THE FABRIC HAS BEEN FULLY INSERTED
8
9
