Parkside Performance PASSP 20-Li A3 User manual

CORDLESS IMPACT WRENCH 20V / AKKU-DREH-
SCHLAGSCHRAUBER 20 V / VISSEUSE À CHOCS
SANS FIL 20 V PASSP 20-Li A3
VISSEUSE À CHOCS SANS FIL 20 V
Traduction des instructions d’origine
AKKU-DREHSCHLAGSCHRAUBER
20V
Originalbetriebsanleitung
CORDLESS IMPACT WRENCH 20V
Translation of the original instructions
AKU RÁZOVÝ UTAHOVÁK 20 V
Překlad originálního provozního návodu
ACCU-DRAAISLAGSCHROEF-
MACHINE 20 V
Vertaling van de originele gebruiksaanwijzing
AKU RÁZOVÝ UŤAHOVÁK 20 V
Preklad originálneho návodu na obsluhu
AKUMULATOROWA WKRĘTARKA
UDAROWA 20 V
Tłumaczenie oryginalnej instrukcji obsługi
ATORNILLADORA DE IMPACTO
RECARGABLE 20 V
Traducción del manual de instrucciones original
BATTERIDREVEN SLAGNØGLE 20 V
Oversættelse af den originale driftsvejledning
AVVITATORE A PERCUSSIONE
RICARICABILE 20 V
Traduzione delle istruzioni d’uso originali
AKKU-CSAVAROZÓ 20 V
Az originál használati utasítás fordítása AKUMULATORSKI VRTALNI
UDARNI VIJAČNIK 20 V
Prevod originalnega navodila za uporabo
IAN 391002_2201

GB/ IE Translation of the original instructions Page 1
DE/AT/CH Originalbetriebsanleitung Seite 15
FR/BE Traduction des instructions d’origine Page 29
NL/BE Vertaling van de originele gebruiksaanwijzing Pagina 45
CZ Překlad originálního provozního návodu Strana 59
PL Tłumaczenie oryginalnej instrukcji obsługi Strona 73
SK Preklad originálneho návodu na obsluhu Strana 87
ES Traducción del manual de instrucciones original Página 101
DK Oversættelse af den originale driftsvejledning Side 115
IT Traduzione delle istruzioni d’uso originali Pagina 129
HU Az originál használati utasítás fordítása Oldal 143
SI Prevod originalnega navodila za uporabo Stran 157
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
Avant de lire le mode d‘emploi, ouvrez la page contenant les illustrations et familiarisez-vous ensuite avec
toutes les fonctions de l‘appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u vertrouwd met alle functies van het
apparaat.
Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi funkcemi přístroje.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z wszystkimi
funkcjami urządzenia.
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
Antes de empezar a leer abra la página que contiene las imágenes y, en seguida, familiarícese con todas
las funciones del dispositivo.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Prima di leggere aprire la pagina con le immagini e prendere confidenza con le diverse funzioni
dell‘apparecchio.
Olvasás előtt kattintson az ábrát tartalmazó oldalra és végezetül ismerje meg a készülék mindegyik funkcióját.
Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.

A
3a

All Parkside tools and the chargers PLG20A1/A4/C1/A2/C2/A3/C3/PDSLG20A1/
PLGS2012A1 of the X20V Team series are compatible with the PAP 20 A1/A2/A3/B1/B3/
PAPS 204 A1/PAPS 208 A1 battery pack.
Alle Parkside Geräte und die Ladegeräte PLG20A1/A4/C1/A2/C2/A3/C3/PDSLG20A1/
PLGS2012A1 der X20V Team Serie sind mit dem Akku-Pack PAP 20 A1/A2/A3/B1/B3/
PAPS204 A1/PAPS 208 A1 kompatibel.
Tous les outils Parkside et les chargeurs PLG20A1/A4/C1/A2/C2/A3/C3/PDSLG20A1/
PLGS2012A1 de la série X20V Team sont compatibles avec la batterie PAP 20 A1/A2/A3/
B1/B3/PAPS 204 A1/PAPS 208 A1.
Charging times
Ladezeiten
Temps de charge
Charging currents
Ladeströme
Courants de charge
max. 2,4 A
Charger
Ladegerät
Chargeur
PLG 20 A1/A4/C1
max. 3,5 A
Charger
Ladegerät
Chargeur
PLG 20 A2/C2
max. 4,5 A
Charger
Ladegerät
Chargeur
PLG 20 A3/C3
max. 4,5 A
Charger
Ladegerät
Chargeur
PDSLG 20 A1
max. 12,0 A
Charger
Ladegerät
Chargeur
PLGS 2012 A1
2 Ah PAP 20 A1/B1
Battery pack · Akku ·
Batterie
60 min
2,4 A
45 min
3,5 A
35 min
3,8 A
35 min
3,8 A
35 min
3,8 A
3 Ah PAP 20 A2
Battery pack · Akku ·
Batterie
90 min
2,4 A
60 min
3,5 A
45 min
4,5 A
45 min
4,5 A
32 min
5,3 A
4 Ah PAP 20 A3/B3
Battery pack · Akku ·
Batterie
120 min
2,4 A
80 min
3,5 A
60 min
4,5 A
60 min
4,5 A
35 min
7,8 A
4 Ah PAPS 204 A1
Battery pack · Akku ·
Batterie
120 min
2,4 A
80 min
3,5 A
50 min
4,5 A
50 min
4,5 A
35 min
6,0 A
8 Ah PAPS 208 A1
Battery pack · Akku ·
Batterie
210 min
2,4 A
165 min
3,5 A
120 min
4,5 A
120 min
4,5 A
45 min
12,0 A

Smart battery supportu
This appliance supports advanced functions when using special smart batteries. For more infor-
mation, please refer to the accompanying material provided by the respective manufacturer.
If smart battery functions are supported, the Ready2Connect LEDulights up in the following
manner:
Ready2Connect LED
Connect the battery pack
LED flashes 3 times
Connect to the app
LED stays on
Not connected to the app
LED stays off
Tool in update mode
LED flashes continuously
Tool update successful
The LED flashes for 5 seconds
Tool update failed
LED flashes rapidly alternately
Smart-Akku Unterstützungu
Dieses Gerät unterstützt erweiterte Funktionen bei Verwendung spezieller Smart-Akkus. Weitere
Informationen entnehmen Sie bitte den Begleitmaterialien der jeweiligen Hersteller. Wenn die
Smart-Akku-Funktionen unterstützt werden, leuchtet die Ready2Connect LEDuin nachfolgender
Weise:
Ready2Connect LED
Akkupack verbinden
LED blinkt 3 mal
Mit der App verbinden
LED bleibt an
Nicht mit der App verbunden
LED bleibt aus
Werkzeug im Update Modus
LED blinkt kontinuierlich
Werkzeug Update erfolgreich
Die LED blinkt 5 Sekunden lang
Werkzeug Update fehlgeschlagen
LED blinkt abwechselnd schnell

Compatibilité avec batterie intelligenteu
En utilisant des batteries intelligentes spéciales, cet appareil prend en charge des fonctions
élargies. Vous trouverez de plus amples informations dans les documents d‘accompagnement
des fabricants respectifs. Lorsque les fonctions de batterie intelligente sont prises en charge,
laLEDReady2Connectus‘allume de la façon suivante:
LED Ready2Connect
Connecter le bloc-batterie
La LED clignote 3fois
Connecter à l'application
La LED reste allumée
Non connecté à l'application
La LED reste éteinte
Outil en mode Mise à jour
La LED clignote en continu
Mise à jour de l'outil réussie
La LED clignote pendant 5secondes
Échec de la mise à jour de l'outil
La LED clignote en alternance rapidement
Smart-accu ondersteuningu
Dit apparaat ondersteunt geavanceerde functies bij gebruik van speciale smart-accu‘s.
Voor nadere informatie wordt verwezen naar het begeleidend materiaal van de respectieve
fabrikanten. Als de smart-accu-functies worden ondersteund, licht de Ready2Connect ledu
alsvolgt op:
Ready2Connect-led
Accupak aansluiten
Led knippert 3 keer
Met de app verbinden
Led blijft branden
Niet met de app verbonden
Led blijft uit
Gereedschap in update-modus
Led knippert continu
Update gereedschap gelukt
Led knippert 5 seconden lang
Update gereedschap mislukt
Led knippert afwisselend snel

Podpora smart akumulátoruu
Toto zařízení podporuje rozšířené funkce při použití speciálních smart akumulátorů. Další
informace naleznete v doprovodných materiálech příslušných výrobců. Když jsou podporovány
funkce smart akumulátoru, tak svítí Ready2Connect LEDunásledujícím způsobem:
Ready2Connect LED
Navázání spojení se sadou akumulátorů
LED bliká 3krát
Navázání spojení s aplikací
LED stále svítí
Nespojeno s aplikací
LED nesvítí
Nástroj v režimu aktualizace
LED trvale bliká
Aktualizace nástroje úspěšná
LED bliká 5 sekund
Aktualizace nástroje selhala
LED bliká střídavě rychle
Obsługa funkcji Smart bateriiu
To urządzenie obsługuje zaawansowane funkcje podczas korzystania ze specjalnych Smart
baterii. Więcej informacji można znaleźć w dołączonych materiałach odpowiednich produ-
centów. Gdy obsługiwane są funkcje Smart baterii, dioda LED Ready2Connectuświeci się
wnastępujący sposób:
Ready2Connect LED
Podłączanie akumulatora
Dioda LED mignie 3 razy
Łączenie z aplikacją
Dioda LED pozostaje włączona
Brak połączenia z aplikacją
Dioda LED pozostaje wyłączona
Narzędzie w trybie aktualizacji
Dioda LED miga w sposób ciągły
Aktualizacja narzędzia powiodła się
Dioda LED miga przez 5 sekund
Aktualizacja narzędzia nie powiodła się
Dioda LED miga szybko naprzemiennie

Podpora akumulátora smartu
Tento prístroj podporuje rozšírené funkcie pri použití špeciálnych akumulátorov smart.
Ďalšie informácie nájdete v sprievodných materiáloch príslušných výrobcov. Keď sa podporujú
funkcie akumulátora smart, svieti LED Ready2Connectunasledujúcim spôsobom:
Ready2Connect LED
Pripojiť box s akumulátorom
LED 3-krát zabliká
Nadviazať spojenie s aplikáciou
LED zostane zapnutá
Nie je spojené s aplikáciou
LED zostane vypnutá
Náradie v režime aktualizácie
LED bliká nepretržite
Aktualizácia náradia úspešná
LED bliká 5 sekúnd
Aktualizácia náradia zlyhala
LED bliká striedavo rýchlo
Compatibilidad con funciones de batería inteligenteu
Este aparato admite funciones avanzadas si se emplea una batería inteligente especial.
Encontrará más información en la documentación y material adjunto del fabricante que
corresponda. Si se admiten las funciones de batería inteligente, el led Ready2Connectu
seilumina de la manera siguiente:
Led Ready2Connect
Conexión a la batería
El led parpadea 3veces
Conectado a la aplicación
El led permanece encendido
Desconectado de la aplicación
El led permanece apagado
Herramienta en el modo de actualización
El led parpadea de forma continua
Actualización correcta de la herramienta
El led parpadea durante 5segundos
Error en la actualización de la herramienta
El led parpadea rápidamente de forma alterna

Smart-batteri-understøttelseu
Dette produkt understøtter udvidede funktioner ved anvendelse af specielle smart-batterier.
Yderligere informationer kan findes ide vedlagte materialer fra producenten.
Hvis smart-batteri-funktionerne understøttes, lyser Ready2Connect LEDupå følgende måde:
Ready2Connect LED
Forbindelse af batteripakken
LED’en blinker 3 gange
Forbindelse med appen
LED’en er tændt
Ikke forbundet med appen
LED’en er slukket
Værktøj i opdateringsmodus
LED’en blinker permanent
Værktøjsopdatering udført
LED’en blinker i 5 sekunder
Værktøjsopdatering mislykkedes
LED’en blinker hurtigt
Supporto batteria intelligenteu
Questo apparecchio supporta funzioni avanzate quando si utilizzano speciali batterie intelligenti.
Per ulteriori informazioni, consultare il materiale messo a disposizione dai rispettivi produttori.
Quando le funzioni per batterie intelligenti sono supportate, il Ready2Connect LEDulampeggia
come segue:
Ready2Connect LED
Collegare il pacco batteria
Il LED lampeggia 3 volte
Collegare all'app
Il LED resta acceso
Non collegato all'app
Il LED resta spento
Utensile in modalità di aggiornamento
Il LED lampeggia in modo continuo
Aggiornamento utensile riuscito
Il LED lampeggia per 5 secondi
Aggiornamento utensile non riuscito
Il LED lampeggia a velocità alterne

Okos akkumulátor támogatásu
Ez a készülék bővített funkciókat támogat speciális okos akkumulátorok használata esetén.
További információkért tekintse meg az adott gyártók mellékelt anyagait. Ha támogatva
vannak az okos akkumulátor funkciók, a Ready2Connect LEDuaz alábbi módon világít:
Ready2Connect LED
Akkumulátor-telep csatlakoztatása
A LED 3-szor villog
Csatlakoztatás az alkalmazáshoz
A LED világít
Nincs csatlakoztatva az alkalmazáshoz
A LED nem világít
Szerszám frissítés módban van
A LED folyamatosan villog
Szerszám frissítése sikeres
A LED 5 másodpercig villog
Szerszám frissítése nem sikerült
A LED felváltva gyorsan villog
Podpora za pametne akumulatorjeu
Ta naprava podpira razširjene funkcije pri uporabi posebnih pametnih akumulatorjev.
Dodatne informacije najdete v spremni dokumentaciji ustreznih proizvajalcev. Če naprava
podpira funkcije pametnega akumulatorja, lučka LED Ready2Connectusveti, kot sledi:
Lučka LED Ready2Connect
Povezava akumulatorja
Lučka LED 3-krat utripne
Povezava z aplikacijo
Lučka LED sveti
Ni povezave z aplikacijo
Lučka LED ne sveti
Orodje v načinu posodabljanja
Lučka LED trajno utripa
Posodobitev orodja je uspešna
Lučka LED utripa 5 sekund
Posodobitev orodja ni uspešna
Lučka LED utripa izmenično hitro

PASSP 20-Li A3 GB│IE │ 1■
Contents
Introduction............................................................ 2
Intended use........................................................................2
Features ...........................................................................2
Package contents ....................................................................2
Technical data ......................................................................3
General power tool safety warnings .......................................4
1. Work area safety..................................................................4
2.Electricalsafety...................................................................4
3. Personal safety....................................................................4
4. Power tool use and care ............................................................5
5. Use and handling of the cordless electrical power tool.....................................5
6.Service..........................................................................6
Appliance-specific safety instructions for impact wrenches ....................................6
Original accessories/auxiliary equipment .................................................6
Safety guidelines for battery chargers ....................................................7
Before use ............................................................. 7
Charging the battery pack (seefig.A)....................................................7
Inserting/removing the battery pack .....................................................8
Checking the battery charge level .......................................................8
Fitting the belt clip ...................................................................8
Switching on/off.....................................................................8
Setting/preselecting the rotation speed/tightening torque.....................................8
Changing the direction of rotation .......................................................8
Fitting a socket ......................................................................8
Maintenance and cleaning................................................8
Kompernass Handels GmbH warranty .....................................9
Service...............................................................10
Importer .............................................................10
Disposal..............................................................11
Translation of the original Conformity Declaration ...........................12
Ordering a replacement battery..........................................13
Telephone ordering .................................................................13

PASSP 20-Li A3
■ 2 │ GB│IE
CORDLESS IMPACT
WRENCH 20V PASSP 20-Li A3
Introduction
Congratulations on the purchase of your new tool.
You have chosen a high-quality product. The oper-
ating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Intended use
This appliance is intended for screwing in and
unscrewing screws as well as for tightening and
loosening nuts. The appliance has a clockwise/
anticlockwise rotation, a 1/2" external square
drive bit holder and an LED working light. The light
on this appliance is intended to illuminate the
immediate working area of the appliance. The
rotary impact function of the appliance enables the
power of the motor to be converted into uniform
rotary impacts. The impact mechanism comes into
effect during tightening and loosening.
The appliance is designed for use by adults. Young
people under 16 years of age may only use the
appliance under supervision. The manufacturer
accepts no liability for damages caused by
improper use or incorrect operation of the appli-
ance.
Use this appliance only as described and for the
areas of applications specified. The tool is not
intended for commercial use. Any other usage or
modification of the tool is deemed to be improper
and carries a significant risk of accidents.
The manufacturer accepts no responsibility for
damage attributable to misuse.
Features
Tool holder
Rotational direction switch/lock
Belt clip
3a Fixing screw
LED work light
Torque display
Torque selector
ON/OFF switch/speed control
Battery pack*
Release button for the battery pack
High-speed charger*
Battery display LED
Battery charge level button
Red charge control LED
Green charge control LED
Sockets
1/2” to 3/4” adapter
Ready2Connect LED
Package contents
1 cordless impact wrench 20V
1 1/2” to 3/4” adapter
3 sockets (17/19/21 mm)
1 belt clip
1 carrying case
1 set of operating instructions

PASSP 20-Li A3 GB│IE │ 3■
Technical data
Cordless impact wrench 20V PASSP 20-Li A3
Rated voltage 20 V (DC)
Rated idle speed 1st gear n00–660 rpm
2nd gear n00–1250 rpm
3rd gear n00–1550 rpm
Impact frequency 1st gear n00–500 rpm
2nd gear n00–1500 rpm
3rd gear n00–1900 rpm
Torque levels 1st level 130 Nm
2nd level 400 Nm
3rd level 1356 Nm
Max. screw capacity M33
Max. release torque 1898 Nm
Tool holder 1/2"
Battery PAP 20 B3*
Type LITHIUM ION
Rated voltage 20 V (DC)
Capacity 4 Ah
Cells 10 (80 Wh)
NOTE
► Please note that the maximum performance
of the device can only be achieved when
using the PAP 20 A3/PAP 20 B3 battery.
High-speed battery charger PLG 20 C3*
INPUT
Rated voltage 230–240 V ∼, 50 Hz
(AC)
Rated power
consumption 120 W
Fuse (internal) 3.15 A T3.15A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 4.5 A
Charging time approx. 60 min
Protection class II/ (double insulation)
* BATTERY AND CHARGER ARE NOT SUPPLIED
Noise emission value
Noise measurement value determined in
accordance with EN62841. The A-rated
noise level of the power tool is typically:
Sound pressure level LPA = 105.6dB (A)
Uncertainty KPA = 3 dB
Sound power level LWA = 116.6 dB (A)
Uncertainty KWA = 3 dB
Vibration emission value
Total vibration values (vector total of three direc-
tions) determined in accordance with EN 62841:
Tightening screws and nuts of maximum
permissible size ah= 7.159 m/s2
Uncertainty K = 1.5 m/s2
Wear ear muffs!
NOTE
► The vibration emission values and the noise
emission values given in these instructions
have been measured in accordance with a
standardised test procedure and can be used
for comparison of the power tool with
another tool.
► The specified total vibration values and the
noise emission values can also be used to
make a provisional load estimate.

PASSP 20-Li A3
■ 4 │ GB│IE
WARNING!
► Depending on the manner in which the
power tool is being used and, in particular,
the kind of workpiece being worked, the
vibration and noise emission values can
deviate from the values given in these instruc-
tions during actual use of the power tool.
► Try to keep the vibration load as low as
possible. Measures to reduce the vibration
load are, e.g. wearing gloves and limiting the
working time. Wherein all states of operation
must be included (e.g. times when the power
tool is switched off and times where the power
tool is switched on but running without load).
General power tool
safety warnings
WARNING!
►Read all safety warnings, instructions,
illustrations and specifications provided
with this power tool. Failure to follow all
instructions listed below may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat
or hearing protection used for appropriate condi-
tions will reduce personal injuries.

PASSP 20-Li A3 GB│IE │ 5■
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising
power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
h) Do not allow yourself to get lulled into a false
sense of security and do not ignore the safety
rules for power tools, even if you are familiar
with the power tool after repeated use.
A careless action can cause severe injury within
a fraction of a second.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any adjust-
ments, changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and accessory
tools etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power
tool for operations different from those intended
could result in a hazardous situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow
for safe handling and control of the tool in unex-
pected situations.
5. Use and handling of the cordless
electrical power tool
a) Charge a rechargeable battery using only the
charger recommended by the manufacturer.
Chargers are often designed for a particular
type of rechargeable battery unit. There is the
danger of fire if other types of rechargeable
battery units are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store
rechargeable battery units away from paper-
clips, coins, keys, nails, screws or other small
metal objects that could cause the contacts to
be bridged. Short-circuiting the contacts of a
rechargeable battery unit may result in heat
damage or fire.

PASSP 20-Li A3
■ 6 │ GB│IE
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens,
avoid contact with the fluid. If contact occurs,
flush the affected area with water. Seek addi-
tional medical help if any of the fluid gets into
your eyes. Escaping battery fluid may cause
skin irritation or burns.
e) Do not use a damaged or modified battery.
Damaged or modified batteries may behave
unexpectedly and cause fires, explosions or
pose a risk of injury.
f) Do not expose a battery to fire or excessively
high temperatures. Fire or temperatures in excess
of 130°C (265°F) can cause an explosion.
g) Follow all instructions regarding charging
and never charge the battery or the cordless
tool outside of the temperature range given in
the operating instructions. Incorrect charging
or charging outside of the permissible tempera-
ture range can destroy the battery and increase
the risk of fire.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries!
Protect the recharge-
able battery from heat, for example from
continuous exposure to sunlight, fire, water
and moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replace-
ment parts. This will ensure that the safety of
the power tool is maintained.
b) Never try to repair damaged batteries. Main-
tenance of batteries should only be carried out
by the manufacturer or an approved customer
service centre.
Appliance-specific safety instructions
for impact wrenches
■Wear ear muffs when impact screwing. Expo-
sure to loud noise can lead to hearing loss.
■Secure the workpiece. A workpiece securely
held by a clamping device or vice is much safer
than one held in your hand.
■Hold the power tool firmly. High torques can
occur for brief periods while tightening and
loosening screws.
■Wait until the power tool has come to a stand-
still before putting it down. The tool could
catch in something and thus lead to loss of
control of the power tool.
■Hold the power tool by the insulated gripping
surfaces when performing an operation
where a screw may hit hidden power lines. If
a screw comes into contact with a live wire, this
may make exposed metal parts of the power
tool live and could give the operator an electric
shock.
Original accessories/auxiliary
equipment
■ Use only the accessories and additional equip-
ment that are specified in the operating instruc-
tions and are compatible with the appliance.
WARNING!
■ Do not use any accessories that are not
recommended by PARKSIDE. Doing so could
lead to an electric shock and/or fire.
ATTENTION! Hot surface.
There is a risk of burns.

PASSP 20-Li A3 GB│IE │ 7■
Safety guidelines for battery
chargers
■ This tool may be used by children
aged 8 years and above and
by persons with limited physical,
sensory or mental capabilities or
lack of experience and knowl-
edge, provided that they are
under supervision or have been
told how to use the tool safely
and are aware of the potential
risks. Do not allow children to use
the tool as a toy. Cleaning and
user maintenance tasks may not
be carried out by children unless
they are supervised.
■ To avoid potential risks, if the
appliance power cable is dam-
aged, it must be replaced by the
manufacturer, its customer service
or by a qualified technician.
The charger is suitable for indoor use only.
WARNING!
■ To avoid potential risks, if the appliance
power cable is damaged, it must be replaced
by the manufacturer, its customer service or
by a qualified technician.
ATTENTION!
♦ This charger can only charge the following
batteries: PAP20A1/PAP20A2/
PAP20A3/PAP20B1/PAP20B3/
PAPS204A1/PAPS208A1.
♦ A current list of battery compatibility can be
found at www.Lidl.de/Akku.
Before use
Charging the battery pack
(seefig.A)
CAUTION!
► Always unplug the appliance before you
remove the battery pack from or connect the
battery pack to the charger.
NOTE
► Never charge the battery pack at an ambient
temperature of below 10°C or above 40°C.
If a lithium-ion battery is going to be stored
for an extended period, the charge level
should be checked regularly. The optimum
charge level is between 50% and 80%. The
storage climate should be cool and dry and
the ambient temperature should be between
0°C and 50°C.
♦ Connect the battery pack to the high-speed
battery charger (see fig. A).
♦ Insert the mains plug into the mains power
socket. The green charge control LED lights
up briefly, then the red charge control LED
lights up.
♦ The green control LED indicates that the
charging process is complete and the battery
pack is ready for use.
ATTENTION!
♦ If the red control LED flashes, this means
that the battery pack has overheated and
cannot be charged.
♦ If the red and green control LEDs both
flash, this means that the battery pack is
defective.
♦ Push the battery pack into the appliance.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains
power socket.

PASSP 20-Li A3
■ 8 │ GB│IE
Inserting/removing the battery pack
Attaching the battery pack
♦ Push the rotation direction switch into the
middle position (lock). Push the battery pack
into the handle until it clicks into place.
Removing the battery pack
♦ Press the release button and remove the
battery pack .
Checking the battery charge level
♦ Press the battery charge level button to
check the status of the battery (see also main
diagram).
The status/remaining charge will be shown on
the battery display LED as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Fitting the belt clip
♦ Loosen the fixing screw 3a using a standard
Phillips screwdriver (not supplied).
♦ Hold the corresponding hole of the belt clip
over that of the screw thread.
♦ Tighten the fixing screw 3a .
Switching on/off
Turn on
♦ Press and hold the ON/OFF switch to
start up the tool.
The LED work light lights up when the
ON/OFF switch is pressed lightly or fully.
This provides illumination of the work area in
poor lighting conditions.
Switching off
♦ Release the ON/OFF switch to switch off
the appliance.
Setting/preselecting the rotation
speed/tightening torque
♦ Press the torque selector to select the
required torque in stages. The selected torque is
shown on the torque display .
♦ Press the ON/OFF switch lightly for a low
speed and a low tightening torque. Increasing
the pressure increases the speed and the tight-
ening torque.
■ The tightening torque depends on the selected
speed/torque selection and impact duration.
NOTE
► When tightening wheel nuts, however, the
smallest torque setting must be selected to
avoid over-tightening.
► The integrated motor brake ensures that the
tool stops quickly.
ATTENTION!
♦ The tightening torque actually attained must
always be checked with a torque wrench!
Changing the direction of rotation
♦ Change the direction of rotation by pressing the
rotation direction switch towards the left or
right.
Fitting a socket
♦ Push one of the supplied sockets or the
adapter onto the tool holder .
Maintenance and cleaning
WARNING! RISK OF INJURY!
Always switch the appliance off and
remove the battery before carrying
out any work on the appliance.
The tool is maintenance-free.
■ The appliance must always be kept clean, dry
and free from oil or grease.
■ Never allow liquids to get into the tool.

PASSP 20-Li A3 GB│IE │ 9■
■ Use a dry cloth to clean the housing. Never use
petrol, solvents or cleansers which can damage
plastic.
■ If a lithium-ion battery is going to be stored for
an extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
NOTE
► Unlisted replacement parts (such as switches)
can be ordered via our service hotline.
Kompernass Handels GmbH
warranty
Dear customer,
This appliance comes with a 5-year warranty
valid from the date of purchase. In the event that
this product has any defects, you, the buyer, have
certain statutory rights. Your statutory rights are
not limited in any way by the warranty described
below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will
be required as proof of purchase.
If any material or manufacturing fault occurs within
5 years of the product’s date of purchase, we
will either repair or replace the product for you
or refund the purchase price (at our discretion).
This warranty service requires that you present the
defective appliance and the proof of purchase
(receipt) within the 5-year warranty period,
together with a brief written description of the fault
and of when it occurred.
If the defect is covered by the warranty, your
product will either be repaired or replaced by us.
The repair or replacement of a product does not
signify the beginning of a new warranty period.
The X 20 V Team Series battery pack comes with
a 3-year warranty valid from the date of purchase.
Warranty period and statutory claims
for defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accord-
ance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product
parts subject to normal wear and tear or to fragile
parts which could be considered as consumable
parts such as switches or parts made of glass.
The warranty does not apply if the product has
been damaged, improperly used or improp-
erly maintained. The directions in the operating
instructions for the product regarding proper use
of the product are to be strictly followed. Uses
and actions that are discouraged in the operating
instructions or which are warned against must be
avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications/repairs
which have not been carried out by one of our
authorised Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity
over time
■ Commercial use of the product
■ Damage to or alteration of the product by the
customer
■ Non-compliance with safety and maintenance
instructions, operating errors
■ Damage caused by natural hazards

PASSP 20-Li A3
■ 10 │ GB│IE
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(IAN) 391002_2201 available as proof of
purchase.
■ You will find the item number on the type plate
on the product, an engraving on the product,
on the front page of the operating instructions
(below left) or on the sticker on the rear or
bottom of the product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free
of charge to the service address that will be
provided to you. Ensure that you enclose the
proof of purchase (till receipt) and information
about what the defect is and when it occurred.
You can download these instructions
along with many other manuals,
product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to the Lidl
service page (www.lidl-service.com) where you
can open your operating instructions by entering
the item number (IAN) 391002_2201.
WARNING!
►Have your tools repaired by the Service
Centre or a qualified electrician and only
using genuine replacement parts. This will
ensure that the safety of the appliance is
maintained.
►Ensure that the power plug or the mains
cable is replaced only by the manufacturer
of the tool or by an approved customer
service provider. This will ensure that the
safety of the appliance is maintained.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
Service Ireland
Tel.: [phone]
E-Mail: [email protected]
IAN 391002_2201
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
