Parrot Uncle F3513 Manual

INSTALLING THE FAN
BEFORE INSTALLATION
TECHNICAL INFORMATION
Installation & Operating Instructions for the
WARNING:SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F3513
Owner’s Installation ,Manual
All rights reserved. Made in China
Unpack your fan and check the contents.You should have followings:
THANK YOU FOR YOUR PURCHASE
SAFETY RULES
Thank you for purchasing this quality product.To ensure correct function and safety, please read and save
all instructions before using the product
SKU Rated Voltage Rated power(motor).
110-120V AC 32W LED 5500K-3000K-4000KF3513 34W
Tools Required: Phillips screwdriver , Pair of pliers, straight slot screwdriver , adjustable wrench, step ladder , and wire cutters.
INSTALLING THE MOUNTING BRACKET
The ceiling fan must be installed in a location so that the blades are 300mm spacing from the tip of the blade to the nearest objects or walls. When hanging the Fan REMEMBER
to turn off the power. Follow the instruction below to hang your fan properly:
1. For the concrete ceiling, drill two holes in the ceiling
and secure the mounting bracket to the ceiling with two
Φ8(distance between the two holes should be
appropriate)expansion screws, flat washers,nuts
provided and tighten with a spanner.
2. For the wood ceiling, Secure the mounting bracket to the
ceiling is capable of carrying a load of at least 45KGS with
two long mounting screws and washers provided. Be sure
at least 30mm of the screw is threaded into the support.
3. Refer to the Fig. in right for mounting when the ceiling is
angled max. 15 degree angle.
NOTE:Hanger after the installation must be able to withstand the weight of 45kg or more.
1. To reduce the risk of electric shock, insure electricity has been turned off at the circuit breaker or fuse box
before beginning.
2. All wiring must be in accordance with the National Electrical Code and local electrical codes. Electrical
installation should be performed by a qualified licensed electrician.
3. `WARNING: To reduce the risk of electrical shock and fire, do not use this fan with any solid-state fan speed
control device.
4. WARNING: To reduce the risk of fire, electric shock, or personal injury,mount to outlet box marked
"Acceptable for Fan Support of 45kg (99.12 lbs.) Or Less" and use mounting screws provided with the outlet
box. Most outlet boxes commonly used for the support of light fixtures are not acceptable for fan support and
may need to be replaced. Due to the complexity of the installation of this fan, a qualified licensed electrician
is strongly recommended.
5. The outlet box and support structure must be securely mounted and capable of reliably supporting a
minimum of 45KGS. Use only UL Listed outlet boxes marked FOR FAN SUPPORT.
6. The fan must be mounted with a minimum of 7 feet clearance from the trailing edge of the blades to the floor.
7. Avoid placing objects in the path of the blades.
8. To avoid personal injury or damage to the fan and other items, be cautious when working around or cleaning
the fan.
9. Do not use water or detergents when cleaning the fan or fan blades. A dry dust cloth or lightly dampened
cloth will be suitable for most cleaning.
10. After making electrical connections, spliced conductors should be turned upward and pushed carefully up
into the outlet box. The wires should be spread apart with the grounded conductor and the equipment-
grounding conductor on one side of the outlet box.
11. Electrical diagrams are for reference only.
12. The fan is suitable for indoor use only.
Light CCT.
13. Please do not use the tan in a specific environment like high temperature environment. high
radiation environment.lampblack or other abnormal use environments.
BEFORE INSTALLATION
Installation & Operating Instructions for the
WARNING:SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F3513
Owner’s Installation ,Manual
All rights reserved. Made in China
Unpack your fan and check the contents.You should have followings:
1. Mounting Bracket
2. Canopy screws
3. Canopy
4. Downrod&hanger ball
7. Bolt
6. Coupling cover
8. Lock pin
9. Top housing
10. Blades
11. Fan motor assembly
12. Base plate
13. LED
15. Wood screws
16. Expansion screws
17. Screw washers
18. Balance tapes
19. Remote control set
5. Canopy cover
15 16 17 18 19
15 16 17 18
19
1. Mounting Bracket
2. Canopy screws
3. Canopy
4. Downrod&hanger ball
7. Bolt
6. Coupling cover
8. Lock pin
5. Canopy cover
9. Top housing
10. Blades
11. Fan motor assembly
12. Base plate
13. Light kit
14. Lampshade
17. Screw washers
18. Balance tapes
19. Remote control set
14. Lampshade
16. Expansion screws
15. Wood screws
1
10
11
7
9
2
3
4
6
5
8
12
13
14
1
10
11
7
9
2
3
4
6
5
8
12
13
14

Installation & Operating Instructions for the
F3513
Owner’s Installation ,Manual
All rights reserved. Made in China
AFTER INSTRUCRION
MAKE THE ELECTRIC CONNECTIONS
INSTALLING THE LIGHT KIT
WARNING:To avoid possible electrical shock, be sure electricity is turned off at the main fuse
box before wiring.
1. Insert the receiver into the mounting bracket with the flat side of the receiver facing the ceiling.
2. Motor to Receiver Electrical Connections: Connect the Black wire from the fan to Black wire from
the receiver. Connect the white wire from the fan to the white wire from the receiver. Connect the blue
wire from the fan to the Blue wire from the receive. Secure wire connections with the wire nuts provided.
3. Receiver to House supply wires Electrical Connections: Connect the black(hot) wire from the ceiling
to the black wire from the receiver.Connect the white(neutral) wire from the ceiling to the white wire from
the Receiver. Secure the wire connections with the wire nuts provided.
4. Light kit to motor wires Electrical Connections: Connect the two white wires from light pan to the black
and blue wires from fan. Secure the wire connections with the wire nuts provided.
1.Remove the 7 Light and Lampshade screws preassembled from the screws on the base
plate. Connect white and blue wires from light kit and
Lampshade to the white and blue wires
from fan, using wire nuts provided. Attach the light fixture onto the base plate. Aligning the
3 holes on the light fixture with and the 4 holes on the the
Lampshade fixture with
There are 7 screw holes in the bottom plate. Reinstall the 7
Light and Lampshade
screws that were just removed. And tighten all nuts and screws securely.
2. Install 3 X Max.25 watt bulbs (bulb not included)
WARNING: Over lamping the fan will result in the fan lights shutting down until
the proper wattage of bulbs are installed. Replace bulbs with the correct wattage
bulbs, turn the power on.
WARNING: Do not replace bulb until it cools down.
WOBBLE
The fan blades have been adjusted in the factory to minimize any wobble
NOTE:CEILING FANS TEND TO MOVE DURING OPERATION DUE TO THE FACT THAT THEY ARE MOUNTED ON A RUBBER CROMMET. IF THE FAN WAS MOUNTED RIGIDLY TO THE CEILING,
IT WOULD CAUSE EXCESS VIBRATION. MOVEMENT OF A FEW CENTIMENTERS IS QUITE ACCEPTABLE AND DOES NOT SUGGEST ANY PROBLEM
TO REDUCE THE FAN WOBBLE: PLEASE CHECK THAT ALL SCREWS WHICH SECURED THE MOUNTING BRACKET AND DOWNROD ARE SECURE.
BALANCING A WOBBLING CEILING FAN:
For your convenience, a Balancing Kit is included; please follow this procedure when balancing the fan:
1) Install fan without light dome before balancing the fan.
2) Define the base plate into four areas(point A,B,C&D). Use one weight from the balance kit to lightly stick on the edge of the base plate(Point A), if the wobble worsens, then take off the
balance kit to lightly stick on the opposite side(Point B); if the wobble is worse,then go to the adjacent point C or D, if the wobble gets better, then securely stick on the weight at this
location on the base plate.
3) After balancing the fan, assemble the light dome to the light base.
NOISE
When it is quiet(especially at night) you may hear occasional small noises. Slight power fluctuations and frequency signals superimposed in the electricity for off-peak hot water control,
may cause a change in fan motor noise. This is normal. Please allow a 24-hour “breaking-in” period, most noises associated with a new fan disappear during the time. The
manufacturer’s warranty covers actual faults that may develop and NOT minor complaints such as hearing the motor run – All electric
motors are audible to some extent.
CARE AND CLEANING
1. Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint ree cloth to avoid scratching the paint finish. Please make sure to turn off electricity
power before you clean your fan
2. Do not use water when cleaning your ceiling fan. It could damage the motor or the blades and create the possibility of an electrical shock.
3. Motor has permanently lubricated ball bearing. No need to oil
NOTE: MAKE SURE THE POWER IS OFF AT THE ELECTRICAL PANEL BOX BEFORE YOU ATTEMPT ANY CLEANING OR REPAIRS.
WARNING:SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
INSTALLING THE DOWNROD
CHANGING THE DOWNROD (OPTIONAL)
When hanging the Fan REMEMBER to turn off the power. Follow the steps below to hang your fan properly:
1)Remove the bolt, lock pin and set screws from the top of the housing
2)Route wires exiting from the top of the fan motor through the bolt&pin , canopy and then through the ball / downrod.
3)Align the holes at the bottom of the downrod with the holes in the coupling on top of the top housing .
4)Carefully insert the Bolt through the holes in the Coupling and downrod. Be careful not to jam the Bolt against the wiring inside the downrod. Insert the locking pin through the hole near the end
of the Bolt until it snaps into its locked position.
5)Tighten two set screws on top of the fan housing firmly
NOTE: Your fan comes with a 25cm downrod attached to the hanger ball.
In addition, a 10cm downrod has been provided to be used in case the
ceiling is lower.In this case, perform the following steps for correct
installation:
1. Remove the hanger ball from downrod by loosening the setscrew at the
top of the downrod which holds the hanger ball to the downrod.
2. Slide the hanger ball down the downrod and remove the support pin.
3. Insert the support pin in the holes at the top of the 10cm downrod and
slide the hanger ball up the 10cm downrod. Make sure the support pin is
properly seated in the grooves in the top of the hanger ball.
4.Tighten the set crews firmly .
For Canadian installation and for USA fan and light kit combinations over 35 lbs, the safety cable must be installed into the house structure beams. Make sure that when the safety cable is fully
extended the lead wires are longer than the cable and no stress is placed on the lead wires. Note: If Installing The Secondary Support Safety Cable in the U.S., Do Not Remove Knockouts In The Outlet
Box.
SAFETY CABLE INSTALLATION
Installation & Operating Instructions for the
F3513
Owner’s Installation ,Manual
All rights reserved. Made in China
INSTALLING THE FAN TO MOUNTING BRACKET ON CEILING
REMOTE CONTROL
Turn on the power and check the operation of the fan
1– Fan Shutdown
2– Speed Controlle
3– Lamp Switch
1.Install ball end of downrod into mounting bracket opening. Align (engage) slot on ball with tab on mounting bracket.
Warning: Failure to align slot on ball with tab may result in serious injury.
2.Slide the canopy up to ceiling and align the keyhole slots on the canopy with the preassembled screws on the hanger
bracket. Twist clockwise untill locks.Tighten two screws securely.
WARNING:SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
WARNING:To avoid possible electrical dhock . be sure electricity is turned off at the main fuse box before wiring.
3.Attach the decorative canopy cover to the bottom of the canopy by pressing it until it locks.
USING YOUR CEILING FAN
4– Timer(2H,4H,8H)
Bolt
Coupling
Canopy
Downrod&
hanger ball
Coupling cover
Decorative
Canopy cover
Lock pin
Set screw
Base plate
Lampshade
1
23
4
