PASCO Form Number Description Date Revision
013-17359 PS-3219 Battery Replacement Instructions 05-05-22 Page 1 of 4 A

PS‐3219:WirelessMotionBatteryReplacementInstructions
Reference:Batterypartnumber540‐113;Li‐Poly1000mAH
RecommendedEquipment:(PS‐3299;BatteryReplacementToolSet)

Step1:PositiontheSensorasshown.Notethelocationofthe(4)T5Screws.
Unscrewthe4screws.






PASCO Form Number Description Date Revision
013-17359 PS-3219 Battery Replacement Instructions 05-05-22 Page 2 of 4 A

Step2:Flipoverwiththescrewsfacingthegroundandremovethetophalf.Thescrews
shouldfallout.Ifnot,shakeuntilthescrewsfallout.Notethekeepers/nutassemblymayalso
falloutoftheirslot.Takenotetoputbackduringre‐assembly.


Step3:RemovetheMotionModulefromtheassemblyandunscrewtheqty=4shortT5
screwsasshown.









PASCO Form Number Description Date Revision
013-17359 PS-3219 Battery Replacement Instructions 05-05-22 Page 3 of 4 A

Step4:Liftthetopoffandrotateasshown.Note:screwsmaystayinside
theirslotswhichisOK.




Step5:Unscrewtheqty=2T5Torxbatterydoorscrewsasshown.Unplugthebatteryfrom
itsconnector.Removethebatteryandaddthereplacementbatteryatthelocationshownand
plugthebatteryintoitsmatingconnectorandputbackandsecurethebatterydoor.








PASCO Form Number Description Date Revision
013-17359 PS-3219 Battery Replacement Instructions 05-05-22 Page 4 of 4 A

Step6:Reversethestepsnotedabovetocompletethereassembly.
Disposeofthebatteryproperlypertheinstructions.



Ifyouneedfurtherassistance,pleasecontactTechnicalSupportat[email protected]or
throughwww.pasco.comonchat.Toaccesschatthroughyourbrowser,pleaseenableall
cookiesonourwebsite.
