PATHFINDER 6057 User manual

www.scanitparts.com
6057 Scanner Manual

www.scanitparts.com
How to use the Monarch Scanner
Note: On the ScanIt Parts PC, the Interact window
must always be open.
To boot the system:
1) Push the RED power button under the scanner screen.
2) When prompted, touch the screen to connect.
3) Load Labels: Select then select ,
this will print one label.
4) Choose a desired option from the Main Menu.
Main Menu

www.scanitparts.com
Main Menu 1:
Receive
Print Labels: Select the , select ,
then select which type of label to print:
Part # Barcode ●Point of Sale
SPO Label ●Reserved
Note: Customize the labels: Main Menu > Equipment > Label
Designer.
Print all labels: Select then turn print mode on by selecting
.
Quantity enter while scanning: Select then turn single
mode off by selecting .
Shipper # enter: Select , select , enter
or scan a new shipper #. The shipper # will remain as a default in
the scanner until changed or removed.

www.scanitparts.com
Main Menu 2:
Bin Changes
1) Scan the part number.
2) Enter the new bin location.
3) A label will automatically print.
Note: If a label does not automatically print,
select the button, then select .
Print Label: Select the , select , then
select which type of label to print:
Bin Barcode
Bin Change
Note: Add up to 2 additional labels using the label designer
through Main Menu > Equipment > Label Designer

www.scanitparts.com
Main Menu 3:
Misc Menu
1. Other Items Call for information
Note: Available for CDK and Reynolds only
2. Create Part List
Step 1. Enter batch number
Step 2. Scan part number
Step 3. Enter a quantity
Step 4. Scan all parts to be added to the list
Step 5. Export the List: All scanned items can be
exported as a list to Excel for viewing, saving,
and printing.
Step 6. Run Reports: Run Print Part List report for totals

www.scanitparts.com
3. Part Inquiry
Step 1. Scan Part: Displays part #, description,
bin location, and quantity
Step 2. Print Label: Select then
Step 3. Choose label type
Note: Add up to 2 additional labels using the label
designer through Main Menu > Equipment >
Label Designer
4. Add Lookup
Converts a UPC barcode to the part number used in your
inventory.
Step 1. Enter Make/Manufacturer Code
Step 2. Scan UPC barcode
Step 3. Enter the part number for that item that is used in
your inventory
Note: The part number only needs to be entered
one time per UPC. Once completed, you now have
the capability to scan that UPC and it will
automatically convert to the part number in your
inventory.

www.scanitparts.com
Main Menu 4:
Perpetual Inventory
Step 1. Pull Inventory in Interact
Step 2. Enter the bin location on the scanner
Step 3. Begin scanning parts:
The default quantity will be 1.
Example: If you have 20 pieces in a bin, you can (A) scan one piece at a
time or (B) scan a part then select then .
Note: No quantity changes are uploaded to your inventory while doing
a perpetual inventory/cycle count. You must manually adjust
your inventory counts in the DMS.
Step 4. Perpetual Inventory Report: Available under the reports section of
the Main Menu, run by date or an exact bin location.
Change bin locations: Select then . Enter the new bin
location.
Wrong bin: To move a part number to another bin location select
then . Select . This changes the part's bin
location within your inventory.

www.scanitparts.com
Charging the Battery
***** Wait 15 seconds after removing the charged battery from
the charger, before inserting the dead battery in the charger.
To recharge the battery, insert the battery into the charger,
with the ribbed end sticking out. Charging time can take up
to three hours.
Make sure that the battery is pushed in all the way, and the
lights are blinking.

www.scanitparts.com
Load Labels in 10 Steps

1. Turnonthescanner
2. Pressthelatchbuttonsandopenthesupply
cover.
3. Peelanddiscardthefirstfourlabelsfromthe
backingpaper.
4. Placethelabelrollinthesupplyholdersothe
labelsfeedfromthebottom.


5.FeedtheblankbackingpaperOVERthepeel
bar.

PeelBar

6.FeedthepaperTHROUGHtheslotatthe
baseofthelabeldeflector.



Label
Deflector

7.Leave1/2inchoffirstlabelexposed.

8.Closethesupplycover.

9.Holdthebackingpaperandpushupthe
labeldeflectoruntilitsnapsintoplace.

10.ThenselecttheHotKeybuttonandpress 
PaperFeed.Thescannershouldprinta 
labelthatreads"PaperFeed".

Su
pp
l
y
Holder

www.scanitparts.com
Nightlyordersdidnotpull
If the computer that Scanit Parts is on shuts down or reboots overnight, ensure you complete the
following steps to ensure order and inventory is up to date before scanning.
Open Scanit Parts Main Menu.
*If your Main Menu looks like this: * If your Main Menu looks like this:
.
Step 1. Select Interact. Step 1. Select Settings.
Step 2. Pull Open Orders and Inventory. Step 2. Select Interact Data Pulls Tab.
Step 3. Select Pull Open Orders
and Pull Inventory.


www.scanitparts.com
Thank you for purchasing a Monarch 6057 Scanner. THIS WARRANTY IS A LIMITED
WARRANTY AND IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES, EITHER
EXPRESSED OR IMPLIED.
Warranty Period – Warranty begins on the day you purchase the product up to one year.
The warranty from the manufacturer will be voided if the scanner is dropped, misused or
abused. Scanner units received with broken cases are generally not covered under
warranty.
Parts and Labor – IPS will provide new or remanufactured parts and labor to correct
defects in material and workmanship for the product covered during the 1-year
manufacturer warranty period.
Shipping – The customer is responsible for inbound transportation charges and IPS will
pay for return transportation charges unless prior arrangements are made.
Packaging – In the event the product is not packaged properly or if shipping damage is
evident, Innovative Programming Systems, Inc. will not accept the scanner for service
under warranty.
Operating Instructions/Exclusions – Warranty does not cover service that is required as
a result of operator error and or failure. Warranty does not cover damages caused by
accident, abuse, violence, acts of God or use of supplies other than supplies purchased
through IPS.
To Initiate a Warranty Claim:
1) Call [phone] in order to report your problem to our technical support center.
2) An IPS technical support specialist will work with you to attempt to resolve the
problem by telephone. If telephone resolution of your problem is unsuccessful, the
technical support specialist will get the proper information to send you a loaner
according to the maintenance agreement.

www.scanitparts.com
For Support:
1) http://www.scanitparts.com/contact.aspx
2) Call [phone], Option 1, Technical Support
To Order Labels or Batteries:
1) http://www.scanitparts.com/order.aspx
2) Call [phone], Option 3, Supplies
