Paton VDI 150 MINI User manual

1 | Page PATON®VDI SERIES MINI DC MMA
TABLE OF CONTENTS
1.
GENERAL INFORMATION ...............................................................................
3
1.1.
TECHNICAL CHARACTERISTICS ...................................................................
4
1.2.
CONTROLS AND CONNECTORS .....................................................................
5
2.
SETTING THE WELDING UNIT INTO OPERATION .....................................
6
2.1.
PROPER USE........................................................................................................
6
2.2.
REQUIREMENTS FOR INSTALLATION .........................................................
6
2.3.
CONNECTION TO A POWER SUPPLY SYSTEM ...........................................
7
2.4.
REQUIREMENTS FOR AN ELECTRICAL OUTLET .......................................
7
3.
MANUAL COVERED-ELECTRODE ARC WELDING PROCESS (MMA) ....
7
3.1
PREPARING THE WELDING UNIT FOR OPERATION .................................
7
3.2.
INCREASED –CURRENT ARC STARTING "HOT-START" .........................
8
3.3.
REDUCED –WELDING VOLTAGE FUNCTION "ARC-FORCE" ..................
9
3.4.
PROTECTION AGAINST ELECTRODE STICKING ANTI-STICK ................
9
4.
MAINTENANCE ..................................................................................................
9
5.
OPERATION WITH AN ELECTRIC GENERATOR .........................................
10
6.
STORAGE .............................................................................................................
10
7.
TRANSPORTATION ...........................................................................................
10
8.
SPECIFICATION DATA .....................................................................................
10
9.
DELIVERY SET ...................................................................................................
11
10.
TROUBLESHOOTING ........................................................................................
11
11.
SAFETY INSTRUCTIONS ..................................................................................
12
12.
ELECTRICAL SCHEMATIC DIAGRAM ..........................................................
15
13.
WARRANTY ........................................................................................................
16
14.
WASTE ELECTRICAL & ELECTRONIC EQUIPMENT ..................................
17
15.
ACCEPTANCE CERTIFICATE ..........................................................................
18
16.
WARRANTY CARD ............................................................................................
19

2 | Pa g e PATON®VDI SERIES MINI DC MMA
EC Declaration of Conformity
The following products have been tested by us with the listed
standards and found in compliance with the European Community
Low Voltage Directive 2014/35/EU and Electromagnetic
Compatibility Directive 2014/30/EU.
AUTHORISED
REPRESENTATIVE:
MASTERWELD Sp. z o.o., Poland
ul. Przemysłowa 14,
35 -105 Rzeszów Poland
Ust.ID. PL8133751525
MANUFACTURER
ADDRESS:
Limited Liability Company “Pilot Plant of Welding
Equipment of Electric Welding Institute named after
E.O. Paton”
Ukraine, 03045, Kyiv, 66 Novopyrohivska St.
PRODUCT:
INVERTER RECTIFIER
PATON VDI –150 MINI DC MMA
The statement is based on a single evaluation of one sample of above mentioned products. It
does not imply an assessment of the whole production. The manufacturer should ensure that all
product in series production are in conformity with the product sample detailed in this report.
The applicant should hold the whole technical report at disposal of the competent all the right.
Applied EC Directives:
2014/35/EU (Low Voltage)
2014/30/EU (Electromagnetic Compatibility)
Applied Standards:
EN 60204-1:2006. Safety of machinery - Electrical equipment of
machines –Part 1: General requirements; EN 60974-1:2012 Are
welding equipment –Part 1: Welding power sources; EN 60974-
10:2014 Are welding equipment –Part 10: Electromagnetic
compatibility (EMC) –requirements.
Issued Date: 12 September 2017
Expiry Date: 11 September 2022
General Manager
We, MASTERWELD Sp. z o. o., hereby declare that specified above conforms covering
European Parliament and Council Directives, 2014/35/EC Low Voltage Directive of 26
February 2014 and 2014/30/EU Electromagnetic Compatibility of 26 February 2014.
The CE mark above can be used under the responsibility of manufacturer. After completion of an EC
declaration of conformity and compliance with all relevant EU Directives.

3 | Pa g e PATON®VDI SERIES MINI DC MMA
ATTENTION!!! When connecting the welding unit to an electrical outlet (at
a temperature of 25 ºC) of a power supply system, it is necessary to consider
wall-buried wiring and the lengths of extension cables.
Electrode diameter
Set current
Cross-section area of
the power cable
conductor (mm2)
Maximum power
cable length (m)
Ф2 mm
Not more than 80
A
1.0
120
1.5
180
2.0
240
2.5
300
4.0
480
6.0
720
Ф3 mm
Not more than 120
A
1.5
120
2.0
160
2.5
200
4.0
320
6.0
480
Ф4 mm
Up to 150 A
2.0
120
2.5
150
4.0
240
6.0
360
1. GENERAL INFORMATION
The invertor-rectifier welding unit PATON®VDI MINI is designed for direct-current manual arc
welding (MMA). This welding unit’s series "MINI" is intended for exacting users who need a
portable fully functional welding unit with a rated current of up to 150 A. Such a current is sufficient
for welding by using any welding electrodes from Ф1.6 mm through Ф4.0 mm in diameter, at a load
factor not less than 40 percent, allowing welding works to be performed in household conditions, such
as at country sites, in small workshops, or in garages.
Due to the increased frequency of voltage at the input of the rectifier transformer of the welding unit,
the weight and overall dimensions of the transformer are significantly reduced as compared with other
welding units with similar output characteristics.
The basic advantages of the PATON®welding unit are the following:
1. The welding unit is protected against long-time fluctuations of power supply voltage and
ensures welding arc stabilization when the input voltage of the unit changes in the range of 170
V through 260 V. It should be noted that welding at a minimum voltage of 170 V is allowed only
by using an electrode not more than Ф3 mm in diameter;
2. The welding unit is rated for operation with a standard power supply system. Due to the higher
efficiency coefficient of the welding unit, the power consumed by the unit is reduced by 50
percent as compared with other similar welding units;
3. The welding unit is easily operated due to the optimal operating load factor in operation of the
unit at the rated current. Due to this, it is possible to perform welding works comfortably
using 3 mm welding electrodes at the rated current;
4. The enhanced reliability of the welding unit in operation in dusty environment;
5. All the printed-circuit boards with electronic elements of the welding unit are impregnated with
two layers of high-quality varnish in order to provide the high reliability of the welding unit
within its service life;
6. The possibility to adjust welding current smoothly;
7. The Improved welding arc stability.

4 | Pa g e PATON®VDI SERIES MINI DC MMA
1.1. TECHNICAL CHARACTERISTICS
PARAMETERS
VDI MINI
Rated power supply voltage 50/60 Hz, V
230
Rated power supply current, A
18.5
Rated welding current, A
150
Maximum operating current, A
180
Operating load factor, %
40% at 150 A
100% at 94 A
Power supply voltage range, V
170 … 260
Welding current control range, A
20 … 150
Increased-current arc starting function of the manual arc welding
process
Available
Reduced-voltage welding function of the manual arc welding process
Available
Protection against electrode sticking
Available
Open-circuit voltage, V
to 80
Welding arc starting voltage, V
110
Rated consumed power, kVA
4.0
Maximum consumed power, kVA
5.0
Efficiency coefficient, %
90
Cooling
Forced
Operating temperature range
-25 … +45 ºC
Overall dimensions (length width height), mm
200 100 200
Weight, kg
3.3
Protection class*
IP 21
*these Mini-series welding units are protected against ingress of foreign particles more than 12.5 mm in size
and against vertically falling raindrops.
THE RECOMMENDED LENGTHS OF THE WELDING CABLES ARE INDICATED
BELOW:
Unit model
One-direction
cable length (m)
Cross-section area of the
cable conductor (mm2)
Cable designation
VDI MINI
1 –4
8
KG 1 8
2 –5
10
KG 1 10
3 –8
16
KG 1 16

5 | Pa g e PATON®VDI SERIES MINI DC MMA
1.2. CONTROLS AND CONNECTORS

6 | Pa g e PATON®VDI SERIES MINI DC MMA
1–The control for smoothly adjusting welding current;
2–The indicator of operating condition of the welding unit:
a) Continuously lights green when the welding unit is in the operating mode;
b) Alternately flashes green and yellow when the power supply voltage is insufficient for arc
starting;
c) Continuously lights yellow when the welding unit is overheated;
d) Does not light when the power supply voltage is not available;
А(+) –The bayonet connector socket:
a) For connecting the electrode cable (or the grounding cable in some cases when special
electrodes are used for welding) for the manual arc welding (MMA);
B (-) –The bayonet connector socket:
b) for connecting the grounding cable (or the electrode cable in some cases when special
electrodes are used for welding) for the manual arc welding (MMA).
3–The push-button switch for switching on and off the welding unit (the push-button is without a
light indicator; the colour of the push-button is decorative).
2. SETTING THE WELDING UNIT INTO OPERATION
ATTENTION!!! Read Section 11, "Safety instructions", before setting the
welding unit into operation.
2.1 PROPER USE
The welding unit is designed exclusively for manual covered-electrode arc welding.
Any other use of the welding unit is considered as improper. The manufacturer of the welding unit is
not responsible for damages caused by any improper use of the unit.
The use of the welding unit is proper if all the requirements of this Operation Manual are satisfied.
ATTENTION!!! Do not use the welding unit to unfreeze pipes.
2.2 REQUIREMENTS FOR INSTALLATION
The welding unit is protected against ingress of foreign particles more than 12.5 mm in size.
The welding unit is allowed for outdoor operation. The internal electrical and electronic elements of
the welding unit are protected against moisture but are not protected against atmospheric condensate
drops.
ATTENTION!When operating the welding unit in cold season, after the unit
was switched off and cooled, condensate may appear inside the unit, so switch
on the welding unit only 3 –4 hours after the switching off!!!

7 | Pa g e PATON®VDI SERIES MINI DC MMA
For this reason, do not switch off the welding unit if it is anticipated that the unit is to be switched on
not later than 4 hours after switching off.
Install the welding unit so as not to block or cover the ventilation slots on the front and rear panels of
the unit. Prevent ingress of metallic particles (for example, when grinding the weld) sucked into the
welding unit by the unit ventilator.
ATTENTION!!!After fall from a height, the welding unit might be a source
of electrical shock. Install the unit on a firm stable surface.
2.3 CONNECTION TO A POWER SUPPLY SYSTEM
The commercial welding unit is rated for an input power supply voltage of 230 V (- 26% / +13%).
ATTENTION!!! If the welding unit has been damaged in the result of
increase of the input power supply voltage of the welding unit to more than 270
V, possible in the case of large unbalance of phase voltages in the standard
power supply system, the warranty of the manufacturer of the welding unit will
be invalid.
The power supply connector, cross-section areas of the power cable conductors, and power supply line
fuses should be selected with consideration for the technical characteristics of the welding unit.
2.4 REQUIREMENTS FOR AN ELECTRICAL OUTLET
ATTENTION!!! The parameters of an electrical outlet for the power supply
of the welding unit must correspond to the power supply voltage and
consumption current of the unit (see "Technical characteristics"). Connect the
welding unit to an electrical outlet that is rated for a three-wire plug with a
grounding conductor!!!
3. MANUAL COVERED-ELECTRODE ARC WELDING PROCESS (MMA)
3.1 PREPARING THE WELDING UNIT FOR OPERATION
Preparation the welding unit for MMA operation:
1. Insert the plug of the electrode cable into socket A (+) of the welding unit;
2. Insert the plug of the grounding cable into socket B (-) of the welding unit;
3. Connect the grounding cable to the workpiece;
4. Connect the power cable of the welding unit to the outlet of the power supply
system;
5. Set switch 3 to position 1 (switching on).
6. The device is ready for use. Enjoy Your work.

8 | Pa g e PATON®VDI SERIES MINI DC MMA
ATTENTION!!! In the manual arc welding process, after switching on the
welding unit by switch 3, the welding electrode is under voltage. Do not allow
the electrode to contact current-conducting or grounded parts, such as the
casing of the welding unit etc.
3.2 INCREASED-CURRENT ARC STARTING HOT-START
The advantages ensured by the increased-current arc starting function are the following:
1. Improved arc starting even when low-quality electrodes are used;
2. Better base metal penetration during the arc starting period and, as a result, the lesser number
of defects associated with incomplete penetration;
3. Prevention of slag inclusions.
What is achieved by:
During the short time interval of arc starting, the welding current increases by 33 percent of the
welding current set by default (see Figure 1).
Example: The electrode diameter is 3 mm.
The set welding current is 90 A.
The current at the increased-current arc starting stage is 90A + 33% = 120 A.
Figure 1. Increased-current arc starting HOT-START
ELECTRODE HOLDER
GROUNDING CLAMP
t (s)
WORKPIECE

9 | Pa g e PATON®VDI SERIES MINI DC MMA
3.3 REDUCED WELDING VOLTAGE FUNCTION ARC-FORCE
The advantages ensured by the forced arcing at reduced welding voltage function are the
following:
1. Improved arc stability in the short arc welding mode;
2. Improved transfer of molten metal drops into the welding pool;
3. Improved arc starting;
4. Reduced probability of electrode sticking.
What is achieved by:
When the arc voltage is lower than the minimum voltage required for stable arcing, the welding
current increases by 30 percent relative to the set current (see Fig. 2)
Figure 2. Forced arcing at reduced welding voltage ARC-FORCE
3.4 PROTECTION AGAINST ELECTRODE STICKING “ANTI-STICK”
At the stage of arc starting, the electrode can stick to the workpiece and, as a result, the electrode can
be damaged due to overheating.
If the electrode has stuck to the workpiece, the welding current decreases within 0.6 … 0.8 s after the
sticking. The temporary reduction in the welding current makes it easier for the welder to peel off the
stuck electrode. After separating the electrode from the product, the welding process can be resumed
without any problems.
4. MAINTENANCE
ATTENTION!!! Before maintenance, switch off the welding unit and
disconnect the power cable from the outlet of the power supply system. Wait
for about 5 minutes until static charges in the electrical circuits of the unit
disappear, and then perform the maintenance operations. After the completion
of works with the welding unit, apply to the unit a plate with a warning text
prohibiting switching on the unit.
130
Uoc
U (V)
Uw
Umin

10 | Pa g e PATON®VDI SERIES MINI DC MMA
For ensuring the operability of the welding unit for a long-term service life, it is necessary to perform
the following procedures:
1. Periodically, at specified time intervals, check that the safety requirements in operation of the
welding unit are met (see Section 11, "Safety instructions").
2. At half-yearly intervals, if the unit is intensely operated, purge the welding unit with dry
compressed air. Warning! Purging the welding unit with compressed air at a short distance may
result in damage of the electronic elements of the unit.
3. When operating the welding unit in environment with excessive dust content, manually clean
the unit passages for cooling air.
ATTENTION!Purging of the unit from a short distance can result in damage
of the electronic elements of the unit.
5. OPERATION WITH AN ELECTRIC GENERATOR
The welding unit can operate with power supply from an electric generator if the following conditions
are satisfied:
Electrode diameter (mm)
Set welding current (A)
Minimum power
of the generator (kVA)
Ф2
not more than 80А
2.6
Ф3
not more than 120А
4.1
Ф4
Up to 150А
5.0
ATTENTION!!!The output voltage of the electric generator must be in the
range of 170 –260 V. The manufacturer suggests the use of a generator set
with the AVR system responsible for voltage stabilization.
6. STORAGE
The preserved and packed welding unit can be stored according to GOST 15150-69 for 5 years.
The welding unit should be stored in a dry closed room at an ambient temperature not lower than 5 ºC.
In the room, vapors of acids and other chemically active substances must not be present.
7. TRANSPORTATION
The packed welding unit can be transported by any means of transport which ensure the integrity of
the unit and compliance of the unit with the shipping rules established for the specified transport
means.
8. SPECIFICATION DATA
ATTENTION!!! If the welding unit is rated for a special power supply
voltage, the specification data of the unit are indicated on the nameplate on the
upper or rear panel of the unit. In this case, the electrical outlet of the power
supply system and the power cable of the welding unit should be selected with
consideration for the actual power supply voltage.

11 | Pa g e PATON®VDI SERIES MINI DC MMA
PARAMETERS
VDI MINI
Rated power supply voltage 50/60 Hz, V
~230
Power supply voltage range, V
170 –260
Efficiency coefficient, (at 150A)%
90
Welding current control range, A
20 –150
Welding current at a load factor of
40%, for 5 minutes
100%, for 5 minutes
150 А
94 А
Maximum consumed power, kVA
5.0
Normal operating voltage for the manual
- arc welding process MMA, V
20.4 –25.5
9. DELIVERY SET
1. Welding unit with a power cable –1 pcs;
2. The welding cable 3 m in length with electrode holder –1 pcs;
3. The welding cable 2 m in length with grounding clamp –1 pcs;
4. Shoulder-carry belt –1 pcs;
5. Plastic case „PATON®”–1 pcs;
6. Operation manual –1 pcs.
10. TROUBLESHOOTING
FAULT
FAULT CAUSE
FAULT RECOVERY
No welding currents.
The power is switched on;
the unit state indicator does
not light
Power cable breakdown
Check the state of the power cable
Power supply voltage is
below 165 V
Connect the welding unit to the
power supply system with proper
voltage.
Power supply voltage exceeds
260 V
Connect the welding unit to the
power supply system with proper
voltage
Fault of the internal power
supply module of the welding
unit
Apply to the service center
No welding currents
The power is switched on;
the state indicator lights
green
Welding cables are not
connected
Check the state of electric
connectors
The grounding clamp is not
properly connected or is not
connected to the workpiece
Properly connect the grounding
clamp terminal to the workpiece
No welding currents
The power is switched on;
the state indicator lights
yellow
The temperature sensor has
actuated
Wait until the welding unit is
cooled. After cooling, the welding
unit switches on automatically
Insufficient supply of cooling
air
Provide sufficient supply of cooling
air
Fault or the temperature
sensor
Apply to the service center

12 | Pa g e PATON®VDI SERIES MINI DC MMA
FAULT
FAULT CAUSE
FAULT RECOVERY
Improper arc starting in the
manual consumable-
electrode arc welding the
state indicator flashes green
The power supply voltage is
close to the minimum
allowable voltage of 165 V
If it is not possible to increase the
cross-section of the conductors of
the power cable, decrease the set
welding current to the value which
is sufficient for arc staring. Select
the welding electrode with
consideration for the welding
current
Random arc extinction
during welding
The arc voltage is too high
for the electrode used
Use another electrode or a welding
unit rated at higher power
The electrode sticks to the
workpiece
The welding current is too
low
Set the proper welding current
Low quality of the weld
(metal scattering)
The polarity of voltage across
the electrode is improper
Change the polarity across the
electrode according to the
instructions of the electrode
manufacturer
The contact of the grounding
clamp with the workpiece is
unreliable
Fasten the grounding clamp to the
workpiece as close to the welding
area as possible
11. SAFETY INSTRUCTIONS
GENERAL INFORMATION
This device may only be used for the purposes for which it was created. This appliance is intended for
use by persons with the requisite qualifications. It is the responsibility of the qualified personnel to
install, service and repair. Please read this manual carefully before installing and using this product.
Failure to follow the instructions in this manual may result in serious personal injury, death and
damage to the unit itself. Incorrect installation, maintenance and operation resulting in damage to the
device - the manufacturer is not liable.
INSTRUCTION
Before using this product, please read this manual and use the instructions in
this manual. This instruction manual is a basic piece of equipment.
USER RESPONSIBILITIES: The user agrees to allow only persons who:
have been acquainted with the basic safety rules, have been trained in the use
of welding equipment and have appropriate qualifications. They are familiar
with the chapter "Safety Regulations" and the precautionary guidelines in this
manual.
THREATS
ELECTRIC SHOCK CAN KILL: Welding devices produce high voltage.
While the machine is connected to the power supply, it is not allowed to
touch the welding handle and the workpiece. All of these elements form a
welding current circuit and may cause electric shock, so avoid touching them
with bare hands and wet or damaged protective clothing. Protective clothing
should not restrain movements. If possible, it should not be made of synthetic
materials. Electrocution can be fatal !!!

13 | Pa g e PATON®VDI SERIES MINI DC MMA
ARC RAYS CAN BURN: It is not allowed to directly observe the welding
arc with uncovered eyes.
Arc and splinters may cause skin burns or flames, so always wear a
protective mask fitted with a darkened filter (glasses should be equipped with
glass filter grade DIN 9 10)
Any unauthorized persons near your site should protect your eyes with
special protective goggles or with non-flammable, radiation-absorbing
screens.
VAPOUR AND GASES MAY BE DANGEROUS: The resulting smoke and
harmful gases should be removed from the work area by means of specialized
equipment, do not cover the ventilation openings. Welding should be carried
out in well ventilated areas and welding vapors are harmful to health -
especially when welding materials such as lead, mercury, cadmium, zinc,
beryllium, galvanized or stainless steel. Ensure sufficient fresh air flow in the
room. Do not allow solvent vapors to enter the welding arc area.
ELECTROMAGNETIC POLE MAY BE DANGEROUS:
By inducing a high voltage current, the electromagnetic field flowing through
the welding wires may have a negative effect on the performance of electrical
devices such as the cardio-stimulator. Persons wearing such equipment
should consult a physician before entering the area where welding work is
performed. Welding hoses should be arranged in parallel, as close as possible
to each other.
ELECTRICAL SPARK MAY CAUSE FIRE OR EXPLOSIVES:
Flammable items should be removed from the workplace. Do not perform
welding work on containers that contain gases, fuels, oil products or other
flammable materials. There is a risk of explosion of residue of these products.
When performing welding work in potentially explosive or fire hazards,
special rules must be observed that comply with national and international
standards. Firefighting equipment such as: (powder or snow fire
extinguishers, fire blankets) should be located near the workstation in a
visible, readily accessible place.
BOTTLE CAN EXPLODE: Use only approved bottles and properly
functioning regulators. The cylinder should be transported and positioned
vertically. Protect the cylinder from heat, overturning and mechanical
damage.
WELDED MATERIALS MAY BURN: In no case should you touch the
welded parts with bare hands. Always wear protective gloves when operating
the machine. The arc and splinters that develop during the burn can cause
skin burns. Wear protective gloves and pliers when touching or moving the
welded item.
ELECTRIC POWER SOURCES: It is forbidden to work with damaged
welding wires or on wet substrates. Welding cables should be strong,
undamaged and insulated. Weakened connections and damaged cable must
be replaced immediately. Do not carry the device by pulling it by the power
cord or wires. Do not perform any maintenance work on the unit.
Removing the outside cover of the device while it is connected to the
network and using the device with the lid removed is forbidden.

14 | Pa g e PATON®VDI SERIES MINI DC MMA
NOISE ASSOCIATED WITH WELDING CAN BE HARMFUL: The
welding arc formed during welding can emit sounds higher than 85dB for - 8
hours of working time. Welders operating the equipment are obliged to wear
equivalent hearing protectors during work in accordance with the Regulation
of the Minister of Labor and Social Policy of 6 June 2014r. - Dz. U. 2014
pos. 817. Pursuant to the Ordinance of the Minister of Health on Social
Welfare dated 09.07.1996 OJ No. 68 pos. 194 - The employer is required to
carry out research and measurement of factors harmful to health.
CONFORMITY DECISION: This device accomplish the recommendation
of the European CE Committee.
SAFETY MARK: This device is suitable for mains power, for welding work
in an environment of higher standard of electric shock. It is recommended
that the power line be provided with a separate protection against the shock
absorber.

15 | Pa g e PATON®VDI SERIES MINI DC MMA
12. ELECTRICAL SCHEMATIC DIAGRAM
Electrical schematic diagram
of the welding unit PATON®VDI MINI
BIS-0400
BVR-0331
BPK-0400
Arc/Argon
Welding
CURRENT
~ 230 V

16 | Pa g e PATON®VDI SERIES MINI DC MMA
13. WARRANTY
The Pilot Plant of Welding Equipment of the E.O Paton Electric Welding Institute guarantees the
correct operation of the power supply if the costumers provided service conditions, storage and
transportation.
ATTENTION!!! Warranty commitments are canceled in case of mechanical
damage!
Basic warranty for MINI welding rectifiers is granted for a period of 3 years.
The basic warranty period starts on the date of the purchase of the equipment to the final
purchaser.
During the basic warranty period, the seller is obliged, free of chargé, to perform the fallowing actions
for the owner of the PATON®brand:
1. Perform diagnostics and detect the cause of the failure;
2. Provide the necessary components for the repair of the welding device;
3. Perform work on replacement of defective elements and component parts;
4. Test the repaired device.
The basic warranty obligations do not include devices:
1. Mechanical damage affected the availability of the device (deformation body parts and in
consequence of a fall or drop heavy objects on the equipment, loss of pins and connectors)
2. Traces of corrosion that caused the fault condition,
3. The failed because of the impact on its power and electronic elements abundant moisture,
4. The failed due to the accumulation of conductive dust inside (coal dust, metal chips, etc.),
5. In case of attempting to repair its nodes and / or replacement of electronic components,
Depending on operating conditions, it is recommended to clean the internal components and
compressed air units one a year to avoid defects. Remove to cover from the device. Clean the unit
carefully with the compressor hose at a sufficient distance to avoid damage to the electrical
components and mechanical assemblies.
Also, the basic warranty does not apply to defective external elements of equipment that exposed to
physical contact and the attendant supplies. Claims on the fallowing items are accepted no later than
two weeks from the date of sale:
1. On and off buton;
2. Control knobs for welding parameters;
3. Connection of cables and connectors;
4. Control socket;
5. Power cord and power plug;
6. Carrying handle, shoulder strap, case, box;
7. Electrode holder, mass clamp, wires and welding hoses;
The Seller reserves the right to refuse warranty repair or to specify the warranty start date as the date
of manufacture of the appliance month and year (in accordance with the serial number) in the
following cases:
1. The manual has been lost;
2. The instruction manual was not filled in or was incorrectly filled in by the seller.

17 | Pa g e PATON®VDI SERIES MINI DC MMA
ATTENTION!!! The warranty period is extended by the date of repair of the
equipment at an authorized service center.
14. WASTE ELECTRICAL & ELECTRONIC EQUIPMENT
Do not dispose of electrical equipment together with normal waste!
In observance of European Directive 2012/19/EC on Waste
Electrical and Electronic Equipment (WEEE) and its
implementation in accordance with national law, electrical
equipment that has reached the end of its life must be collected
separately and returned to an environmentally compatible recycling
facility. As the owner of the equipment, you should get information
on approved collection systems from our local representative. By
applying this European Directive you will protect the environment
and human health!
IMPORTER / AUTHORIZED DISTRIBUTOR IN EUROPE
MasterWeld Sp. z o.o.
14 Przemysłowa Street,
Rzeszów City, Poland zip-code 35105
Tel. [phone]
e-mail: s[email protected]
[email protected]
All rights reserved. This document is protected by copyright. Copying or distributing the User Manual in whole
or in excerpts without MasterWeld permission is prohibited.

18 | Pa g e PATON®VDI SERIES MINI DC MMA
15. ACCEPTANCE CERTIFICATE
The Inverter rectifiers „PATON®VDI MINI”
The Serial number ____________________MINI complies with the harmonized standards and is fit
for use.
Date of sale:” _______” _____________ 20____
Stamp here ________________________
(Signature of the Seller)
================================================================================
CENTRAL PATON SERVICE CENTER
14 Przemysłowa Street,
Rzeszów City, Poland zip-code 35105
Head of Service Center
Piotr Błaszkowski
Phone: [phone]
e-mail: s[email protected]
ATTENTION!!! DO NOT SEND the welding cables for repair, as these
equipment items are not required for repair!
ATTENTION!!! The delivery of the device to the Paton Service Center is
carried out at the expense of the manufacturer for the entire warranty period
from the date of purchase exclusively in Poland!

19 | Pa g e PATON®VDI SERIES MINI DC MMA
16. WARRANTY CARD
DATE OF REPORT TO REPAIR
DATE OF SERVICE REPAIR:
________________ _______________
(Signature) (Signature)
FAULTS DETECTED AND FAULTY-CONDITION CAUSE:
=======================================================================
Tel. Technical support: [phone]
Address of the service center: 35105, Poland, Rzeszów, 14 Przemysłowa Street,
DATE OF REPORT TO REPAIR
DATE OF SERVICE REPAIR:
________________ _______________
(Signature) (Signature)
FAULTS DETECTED AND FAULTY-CONDITION CAUSE:
=======================================================================
Tel. Technical support: [phone]
Address of the service center: 35105, Poland, Rzeszów, 14 Przemysłowa Street,
