Owner’s Manual
®

®
INTRODUCTION
The small boat business is changing and Patriot is at the
leading edge of this change. Our boats are produced in a
zero waste/zero landfill factory. We are committed to
protecting the environment.
We encourage you to read this Owner’s Manual carefully
and consider the recommended safety tips. Important
navigation techniques, maintenance procedures, care,
and storage are explained in this manual to better assist
you.
As a valued consumer, your comments or questions
are always appreciated.
CONTACT
Service : [email protected]
Sales : [email protected]
Website : www.patriotkayaks.com
Congratulations!
You have just purchased
a Patriot kayak.

p.4
p.5
p.6
p.7
p.8
p.9
p.10
p.11
p.12
p.13
INDEX
Registration & Declaration
Model 10.4 SI
Model 12.0 Angler
Ready to paddle & Navigation
Equipment
Safety measures & Warning
Maintenance & Storage
Warranty
Manufacturer’s Declaration of Origin
Reminder

REGISTRATION & DECLARATION
WARRANTY REGISTRATION
A section of our website www.patriotkayaks.com is
dedicated to the warranty registration. Please fill out and
complete the warranty registration within 30 days following
the product’s purchase date. This information will be very
important should you require assistance from our customer
service department.
DECLARATION OF ORIGIN
Certain states and/or provinces in North America require
that we provide a declaration of origin. This declaration of
origin is provided on page 12.
We strongly recommend
that you consider all the
information provided.
Keep this owner’s
manual in a safe place.
4
4

812 3
44
4
5 67
10.4 SI
®
Familiarizing yourself
with your kayak
Length
Width
Height
Weight
Capacity
124 in / 315 cm
29.5 in / 75 cm
12 in / 30,5 cm
53 lbs / 24 kg
250 lbs / 114 kg
1 - Multi channel hull for ultimate tracking and stability
2 - Adjustable backrest and seat cushion
3 - Adjustable Step Lock footrest system
4 - Front and rear bungees
5 - 10 in X 18 in elliptical stern hatch
6 - Front 10 in round hatch
7 - Molded-in cup holder
8 - Bow and stern carry handles
Features
Read carefully, discover and learn the
major kayak components.
45

9
9
1
2
3
4 6
5
5
78
8
8
12.0
angler
®
Familiarizing yourself
with your kayak
Length
Width
Height
Weight
Capacity
144,5 in / 367 cm
29.9 in / 76 cm
12.3 in / 31.5 cm
69 lbs / 31.15 kg
420 lbs / 191 kg
1 - Dihedral hull for the ultimate stability and tracking
2 - Adjustable backrest and seat cushion
3 - Graduated foot wells
4 - Large stern well with bungees
5 - 2 flush mount rod holders
6 - 10 in x 18 in elliptical bow hatch
7 - 6 in round storage hatch stern and center
8 - Bow, stern and side carry handles
9 - Paddle tie downs
Features
Read carefully, discover and learn the
major kayak components.
6

READY TO PADDLE & NAVIGATION
· It is strongly recommended that you take a
certified kayak initiation course to learn the
basic techniques and security measures.
· When boarding, place one foot in the center of
the kayak while holding on both sides of the
cockpit.
· Sit comfortably into the seat back and adjust
your feet on the gratuated foot wells or
adjustable foot rests.
· It is important to wear an approved life-jacket
or a personal floatation device.
· Your kayak should have a basic emergency
equipment on board (sparepaddle, first aid kit,
whistle)
· Before heading to the water, make sure that
all drain plugs are closed.
7

EQUIPMENT
It is important to wear an approved life-jacket
or a personnal floatation device. The following
list of equipment will make your experience
safer and more enjoyable.
· Spare Paddle
· Sunglasses
· Suntan lotion
· First-Aid kit
· Sound-Signaling device (whistle)
· Non-skid foot wear
WEATHER AND WATER CONDITIONS
Always verify the weather and water conditions
in the area you will be boating. Your kayak is
only designed for use in sheltered waters, lakes
and slow moving streams. Your kayak is not
recommended for white water use. NEVER go
kayaking in severe winds, rain, thunderstorms,
choppy waters, strong currents, flood waters or
where tides will seriously affect your ability to
steer your kayak back to shore.
8

All paddle sports can be dangerous and physically challenging.
Paddle sports can cause serious injuries or death if appropriate
safety measures are not followed. The user assumes all risks
and accepts all & any responsibility for any damage or injury
that may occur. Patriot shall have no liability whatsoever for
any personal injury, accident or consequential damages.
We recommend that you receive instruction in proper paddling
techniques, safety and security on the water and first aid
techniques before using your kayak.
Our Owner’s Manual gives you a summary of the important
points to follow for a pleasant and safe experience.
Warning: Not a lifesaving device.
Hypothermia
Hypothermia is a dangerous drop in the body’s core
temperature below the normal level (37˚C or 98.6˚F). Marine
accidents are very dangerous and can be more so if you are
poorly prepared for the cold water.
Location
Before setting out, make sure you are familiar with your
surroundings. Be aware of permitted navigation hours,
emergency services and locate the danger zones.
Physical Capacity
Realistically evaluate your physical capacities and
resistance should you have to swim to the shore.
Slippery Hull
Your kayak becomes extremely slippery when wet.
Therefore, it is recommended that you wear slip-resistant
shoes and that you remain in the middle of your kayak at
all times.
Do not stand in your kayak
Your kayak may capsize if you stand in it.
Children
Never allow children to kayak without adult supervision.
Coast guard regulations
Always abide by Coast Guard regulations, State and local
laws, ordinances and rules concerning boating and
boating safety.
SAFETY MEASURES & WARNING
9

MAINTENANCE & STORAGE
MAINTENANCE
The best way to clean your kayak is with water.
However, with tougher stains, you can use
some soft soap and a non-abrasive plastic
brush.
STORAGE
The easiest way to store your kayak is to sit it
on a flat surface. If your kayak remains
outdoor, you should keep it covered and out of
direct sunlight. Do not leave any straps tightly
clinched around your kayak for long periods,
especially in warm weather. This can distort the
shape of the kayak.
WARNING
You may find an accumulation of water
between the hull and the deck due to paddle
handling, rain or condensation. Patriot Kayaks
are equiped with drain plugs to remove this
accumulation of water.
Make sure the drain plug is closed before
putting the kayak on the water.
TO EMPTY THE WATER FROM YOUR
KAYAK, REMOVE THE DRAIN PLUG
AND PROP UP THE KAYAK VERTICALLY
ON ITS STERN.
10

Limited Consumer Warranty
Patriot® Kayaks warrants your new kayak to be free from defect in
materials and workmanship, subject to the following terms and
conditions:
• Patriot® Kayaks warrants the hull of your new kayak to be free from
defects in materials and workmanship for a period of 2 (two) years from
the date of retail sale.
• The kayak components are covered for a period of 1 (one) year from
the date of purchase.
• The warranty is applicable to Patriot® Kayaks products registered and
normally operated in North America. Under this warranty, Patriot®
Kayaks is limited to the repair, replacement or refund of the
components at the option of Patriot® Kayaks.
• This warranty is non-transferable to a subsequent owner.
The following is not covered by this warranty:
• Damage due to misuse, accident, collision, etc.
• Patriot® Kayaks shall have no liability whatsoever for any personal
injury, accident or consequential damages.
• Wear-and-tear deterioration, discoloration, or fading, etc.
• Commercial use or rental.
• Damage or surface corrosion caused by the environment.
• Damage caused by the use of aggressive chemical cleaning solvents.
• All incidental or consequential damages.
• Any damage incurred in transport from Patriot® Kayaks to the
customer.
• Any transportation charges to and from an Authorized repair facility.
• Labor to install new or replacement components
Customers are responsible for inspecting their kayak upon arrival for any shipping
damage and must notify Patriot® Kayaks in writing within 5 (five) days of the date
of delivery. ([email protected])
Transportation charges for hulls and/or replacement components are the
responsibility of the purchaser. This warranty is limited to the purchase price of
the product, and is nontransferable to a subsequent owner.
Repair or return of boats
All requests for a return authorization number must be sent by email to
[email protected]. The return of any boats will not be accepted by
Patriot® Kayaks without an authorization number.
This warranty is the sole and exclusive warranty by Patriot® Kayaks in connection
with its boats and Patriot® Kayaks makes no warranties or representations,
expressed or implied (including warranties of merchantability and or fitness for a
particular purpose) in such connection except as specifically described in this
warranty.
All incidental and/or consequential damages are excluded from this warranty.
Implied warranties are limited to the life of this warranty. Some states do not
allow limitations on how long an implied warranty lasts or the exclusion or
limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you. This warranty gives you special legal rights, and
you may also have other legal rights which may vary from state to state.
During the warranty period, Patriot® Kayaks is obliged only to repair, replace or
refund at its discretion, the above mentioned parts, at either its manufacturing
plant, or at an authorized dealer store or service center, as decided by Patriot®
Kayaks. Transportation costs back to the appointed place of repair or
replacement are at the expense of the consumer. Patriot® Kayaks is not
responsible for any damages incurred in transport, charges for storage or
transportation fees, nor for inconvenience or loss of time or money while repairs
are being made.
LIMITED 2 YEAR WARRANTY
11

MANUFACTURER’S DECLARATION OF ORIGIN
The undersigned corporation hereby certifies
that the new boat described below, has been
transferred this day of , Year
,on invoice #
to
whose address is
Type of board : Kayak
Model:
Serial Number:
The corporation further certifies that this was
the first transfer of such new boat in ordinary
trade or commerce.
750 RT 9, Champlain, NY 2919
www.patriotkayaks.com
Marc Tremblay
IMPORTANT
Please download the complete user manual and make sure to read and
fully understand all product and safety information
patriotkayaks.com/documentation
12

YOUR KAYAK INFORMATION
Serial #
Date of purchase
Store name and address
(Please keep following
information along with this
user manual in a safe place
for further reference.)
WARRANTY REGISTRATION
It is important to proceed with this registration
within 30 days following the product’s
purchase date.
Registration can be done electronically at
www.patriotkayaks.com
REMINDER
13

®
PAKA000301_1016
PAKA000301_1016
USA : 750 route 9, Champlain, New York 12919
Canada : 160 Vanier, St-Jean, Quebec, Canada J3B 3R4
www.patriotkayaks.com
Copyright© 2017 Patriot Kayaks® is a Registered Trademark of GSC Technologies Corporation.
