CHAPTER 1 - Operation
ThePatton2021P(CTSTCB-V.24/X.21)isanEIARS-232toCCITTX.21
interface converter with a built in tail circuit buffer, allowing modem to
modeminterconnection.Theinterfaceconverteroperatesbi-directionally.
DCE / DTE selection of each port permits interfacing an RS-232 terminal or
modem to an X.21 terminal or modem. This interface converter can satisfy
allinterfaceconversion requirements. This adapterisidealfor High Speed
Modems since it can operate at up to 128Kbps. Connection of two terminal
devices is not supported because internal clocking is not provided by this
device.
Devices can be separated up to 4000 feet away from the interface con-
verteronthe balanced interface sideandRS-232devices can be separated
up to 50 feet away from the interface converter. The unit is supplied with a
femaleDB-25fortheRS-232portandafemaleDB-15fortheCCITTX.21
port.
The interface converter is housed in a sturdy aluminum enclosure and has
an internal 110/220VAC switch selectable power supply. Sixteen of the
interface converters will also fit into the MCS-16 card rack for convenient
data center applications.
The unit can operate on standard power found in most countries.
IC-V.24/X.21
X.21 Modem
1-1
Typical Application

172001UA
CHAPTER 2 - SETUP AND INSTALLATION
Installation
Set the switches to match the required configurations based on the
diagramsbelow.Thecabling betweeneachdeviceandtheinterface
converter must be terminated with male connectors. J1 is the RS-232 /
V.24 interface and J2 is the X.21 interface. The IEC connector is provided
to interface to the power plug required in the country of use. Insure the
110/220VAC switch is set correctly for the line voltage in use prior to
applyingpowertotheinterfaceconverter.
Selection of DTE/DCE
To connect an RS-232 terminal type device (DTE) to an X.21 Modem type
device (DCE), connect the terminal to J1 and the Modem to J2. Move
SW1 and SW2 to the DCE position, and SW3, SW4 and SW5 to the DTE
position, as shown in Fig. 1.
X.21 DCE V.24 DTE
RXD - 3
TX D - 2
RX C - 1 7
TXC - 15
S - 6, 13
T - 2, 9
R - 4, 11
X.21 DTE V.24 DCE
Buff er
RTS - 4 / DTR - 20C - 3, 10
CTS - 5 / DC D - 8
I - 5, 1 2
JP3JP2JP1 JP4
I
Power
T
S
R
J3
SW1
C
X.21 INTERFACE
DCE DTE
Factory Test Straps
Must be Installed for Unit To
Operate Correctly
J1 (RS-232) Is a DCE, and
MUST Connect to a
Terminal (DTE)
J2 (X.21) Is a DTE, and
MUST Connect
to a Modem (DCE)
Signal
to
Chassis
Ground
SW2
SW3
J2
X.21
J1
RS-232
JP5
JP6
DTR /RTS
DCD / CTS
SW4
SW5
DCEDTE
V.24 INTERFACE
Figure 1.
*NOTE: All clocks in the communication system must be frequency locked. One and
only one clock must be selected as master for the system. All other clocks must be
2-1
Note: Hazardous voltages are present when the equipment cover is removed.
Installation and setup shall be performed by qualified service personnel only.

172001UA
2-2
slaved to this clock.
To connect a X.21 terminal type device (DTE) to an RS-232 Modem type
device (DCE), connect the terminal to J2 and the Modem to J1. Move
SW1 and SW2 to the DTE position, and SW3, SW4 and SW5 to the DCE
position, as shown in Fig.2.
X.21 DTE
X.21 DCE V.24 DTE
TX D - 2
TXC - 15
RX C - 1 7
S - 6, 13
T - 2, 9 V.24 DCE
RXD - 3R - 4, 11
Buff er
RT S - 4 / DTR - 20
C - 3, 10
CTS - 5 / DC D - 8I - 5, 1 2
I
Power
T
S
R
J3
C
Factory Test Straps
Must be Installed for Unit To
Operate Correctly
J1 (RS-232) Is a DTE, and
MUST Connect to a
Modem (DCE)
J2 (X.21) Is a DCE, and
MUST Connect
to a Terminal (DTE)
J2
X.21
J1
RS-232
JP3JP2
JP1 JP4
SW1
X.21 INTERFACE
DCE D TE
Signal
to
Chassis
Ground
SW2
SW3
JP5
JP6
DTR /RTS
DCD / CTS
SW4
SW5
DCEDTE
V.24 INTERFACE
Figure 2.
To connect a X.21 Modem type device (DCE) to an RS-232 Modem type
device (DCE), connect the X.21 Modem to J2 and the V.24 Modem to J1.
Move SW1, SW2, SW3, SW4 and SW5 to the DTE position, as shown in
Fig.3.
X.21 DCE
X.21 DTE V.24 DTE
TX D - 2
RXD - 3
RX C - 1 7
XT X C - 2 4
S - 6, 13
T - 2, 9
R - 4, 11
V.24 DCE
Buff er
RT S - 4 / DTR - 20
C - 3, 10 CTS - 5 / DC D - 8
I - 5, 1 2

172001UA
2-3
I
Power
T
S
R
J3
C
Factory Test Straps
Must be Installed for Unit To
Operate Correctly
J1 (RS-232) Is a DTE, and
MUST Connect to a
Modem (DCE)
J2 (X.21) Is a DTE, and
MUST Connect
to a Modem (DCE)
J2
X.21
J1
RS-232
JP3JP2
JP1 JP4
SW1
X.21 INTERFACE
DCE D TE
Signal
to
Chassis
Ground
SW2
SW3
JP5
JP6
DTR /RTS
DCD / CTS
SW4
SW5
DCEDTE
V.24 INTERFACE
Figure 3 (Factory Default Setting)
Equipment Grounding
JP4 provides grounding interconnection in those systems requiring a
connectionbetweenFrameGroundand SignalGround.Ifsignalground
and chassis ground interconnection is desired, install the jumper on JP4.
LED Indicators
TheFollowing LEDindicatorsareprovidedfor diagnostics:Power,Transmit
Data(T),Receive Data (R), Control (C), Indicate(I)andSignalTiming (S).
Factory Test Straps
The Factory Test Straps JP1, JP2 and JP3 must be installed for proper
operationoftheinterfaceconverter.
Signal Crossover
JP5 controls selection of DTR or RTS as the active V.24 control signal.
JP6 controls selection of the DCD or CTS as the active V.24 control signal.
The selection of DTE or DCE on the two interfaces will determine which
X.21 signal is connected to which V.24 control signal.

172001UA
A-1
