Patton electronics 3028 Turbo Setup guide

Doc #: 154001UA
Part #: 07M3028-A
STATISTICAL MULTIPLEXER
3028 Turbo
(CTS 2031 TURBO )
INSTALLATION AND OPERATIONS MANUAL
B
An ISO-9001
Certified Company
Copyright© 2000 Patton Electronics Co., All Rights Reserved
May 31, 2000

Doc #: 154001UA
Part #: 07M3028-A
STATISTICAL MULTIPLEXER
3028 Turbo
(CTS 2031 TURBO )
INSTALLATION AND OPERATIONS MANUAL
B
An ISO-9001
Certified Company
Copyright© 2000 Patton Electronics Co., All Rights Reserved

154001UA i
This manual contains information about the installation and operation of the
3028Turbo (CTS 2031 Turbo) Statistical Multiplexer. The manual is intended for
use by the technician installing the equipment and the operator using the equip-
ment. This manual assumes that its user is familiar with basic telecommunica-
tions and computer terminology.
AUDIENCE ANDAUDIENCE AND
AUDIENCE ANDAUDIENCE AND
AUDIENCE AND
OBJECTIVESOBJECTIVES
OBJECTIVESOBJECTIVES
OBJECTIVES
2980-A2-GN30 DCX 840 Installation, Operation and Maintenance Manual
2985-A2-GN30 DCX 840 Installation, Operation and Maintenance Manual
RELATED DOCUMENTSRELATED DOCUMENTS
RELATED DOCUMENTSRELATED DOCUMENTS
RELATED DOCUMENTS
The information contained herein is proprietary and confidential to Patton
Electronics Co. Any reproduction or redistribution of this publication, in whole or
in part, is expressly prohibited unless written authorization is given by Patton
ElectronicsCo.
PROPRIETARY NOTICEPROPRIETARY NOTICE
PROPRIETARY NOTICEPROPRIETARY NOTICE
PROPRIETARY NOTICE
Patton Electronics Co. (hereafter referred to as Patton) warrants that its equipment
is free from any defects in materials and workmanship. The warranty period shall
be two years from the date of shipment of equipment. Pattons sole obligation
under its warranty is limited to the repair or replacement of the defective equip-
ment. This warranty will not extend to equipment subjected to accident, misuse,
alterations or repair not made by Patton or authorized by Patton in writing.
All warranty and non-warranty repairs must be returned freight prepaid and
insured to Patton Electronics. All returns must have a Return Materials Authoriza-
tion number on the outside of the shipping container. This number may be ob-
tained from Patton Electronics Technical Services at:
Tel: [phone];
email: [email protected];
or, Web: http://www.patton.com.
NOTE: Packages received without an RMA number will not be accepted.
Patton Electronics technical staff is also available to answer any questions that
might arise concerning the installation or use of your Patton devices. Technical
Service hours: 8AM to 5PM EST, Monday through Friday.rations or repair not
made by Patton or authorized by Patton in writing.
PUBLICATION NOTICEPUBLICATION NOTICE
PUBLICATION NOTICEPUBLICATION NOTICE
PUBLICATION NOTICE This manual has been compiled and checked for accuracy. The information in this
manual does not constitute a warranty of performance. Patton reserves the right to
revise this publication and make changes from time to time in the content thereof.
Patton assumes no liability for losses incurred as a result of out-of-date or incorrect
information contained in this manual.
DCX is a trademark of AT&T Paradyne.
ENQ/ACK is a registered trademark of Hewlett-Packard Corporation.
Paradyne in a registered trademark of AT&T Paradyne.
Tandem is a registered trademark of Tandem Corporation.
T-Pause is a registered trademark of Tandem Corporation.
Wang is a registered trademark of Wang Laboritories, Inc.
2030 Statistical Multiplexer is a registered trademark of AT&T Paradyne.
PrefacePreface
PrefacePreface
Preface
SERVICESERVICE
SERVICESERVICE
SERVICE

154001UAii
B
7622 Rickenbacker Drive
Gaithersburg, Maryland 20879
Phone [phone] FAX [phone]
CE NOTICECE NOTICE
CE NOTICECE NOTICE
CE NOTICE
The CE symbol on your Patton Electronics equipment indicates that it is in compliance
with the electromagnetic Compatibility (EMC) directive and the Low Voltage Directive
(LVD) of the European Union (EU). A Certificate of Compliance is available by contacting
Technical Support.
RADIO AND TVRADIO AND TV
RADIO AND TVRADIO AND TV
RADIO AND TV
INTERFERENCEINTERFERENCE
INTERFERENCEINTERFERENCE
INTERFERENCE
The Patton MSDs generate and use radio frequency energy, and if not installed and used
properlythat is, in strict accordance with the manufacturers instructionsmay cause
interference to radio and television reception. The Patton MSDs have been tested and
found to comply with the limits for Class A computing devices in accordance with the
specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reason-
able protection from such interference in a commercial installation. However, there is no
guarantee that interference will not occur in a particular installation. If the Patton MSDs
do cause interference to radio or television reception, which can be determined by
disconnecting the cables, the user is encouraged to try to correct the interference by one
or more of the following measures: moving the computing equipment away from the
receiver, re-orienting the receiving antenna, and/or plugging the receiving equipment
into a different AC outlet (such that the computing equipment and receiver are on
different branches).
WARRANTY NOTICEWARRANTY NOTICE
WARRANTY NOTICEWARRANTY NOTICE
WARRANTY NOTICE
WARRANTIES: Patton Electronics Co. (hereafter referred to as Patton) warrants that its
equipment is free from any defects in materials and workmanship. The warranty period
shall be two years from the date of shipment of equipment. Pattons sole obligation
under its warranty is limited to the repair or replacement of the defective equipment,
provided it is returned to Patton, transportation prepaid, within a reasonable period. This
warranty will not extend to equipment subjected to accident, misuse, alterations or repair
not made by Patton or authorized by Patton in writing.

154001UA iii
TT
TT
Table of Contentsable of Contents
able of Contentsable of Contents
able of Contents
1. Introduction and Setup
Overview ......................................................................................................... 1-1
Equipment supplied ..................................................................................... 1-3
Equipment Required But Not Supplied ..................................................... 1-3
ProductTerminology .................................................................................... 1-3
Unpacking and Setup ................................................................................... 1-4
Multiplexer Factory Defaults ....................................................................... 1-5
EIA Signals ..................................................................................................... 1-6
2. Operation of the 3028 Turbo Multiplexer
Overview ......................................................................................................... 2-2
Supervisory Function Overview ................................................................. 2-2
Front Panel Operation .................................................................................. 2-3
Terminal Operation ....................................................................................... 2-5
Modes of Operation ....................................................................................... 2-5
StandbyMode/Logoff .................................................................................. 2-6
MonitorMode ................................................................................................ 2-6
MemoryCapability........................................................................................ 2-10
CommandMode ............................................................................................ 2-10
Resetting The Multiplexer ............................................................................ 2-75
Appendices
A. Multiplexer Command Mode Summary ........................................... A-1
B. Technical Specifications ..................................................................... B-1
C. ASCII Character Codes ....................................................................... C-1
D. Multiplexer Parity Options ................................................................. D-1
E. Hewlett-Packard Protocol ................................................................... E-1
F. Tandem T-Pause and Wang Flow Control Methods ...................... F-1
G. Flow Control Translation .................................................................... G-1
H. Factory Hardware Option Settings .................................................... H-1
I. SDLC/HDLC Protocol ......................................................................... I-1
J. EIA Signal Exceptions ......................................................................... J-1
K. Rack-Mount Installation ..................................................................... K-1
L. Vorbereitungen zur Inbetriebnahme der Gerate .............................. L-1
Index

1. Introduction and Setup
154001UA 1-1
Overview .................................................................................................................................................. 1-1
Product Terminology .............................................................................................................................. 1-3
Equipment Supplied ............................................................................................................................... 1-3
Equipment Required But Not Supplied ..............................................................................................1-3
Unpacking and Setup ............................................................................................................................. 1-4
Multiplexer Factory Defaults ................................................................................................................ 1-5
EIA Signals ............................................................................................................................................... 1-6
The 3028 Turbo (CTS 3028 Turbo (CTS 2031 Turbo)) Statistical Multiplexer has two
primary applications: Point-to-Point and DCX networking (Figure 1-1). Point-to-
Point operations in a single link environment supports up to eight terminals. All
of the DCX networking applications, including direct connections to a DCX 840 or
DCX 850 are supported. The 3028 Turbo (CTS 3028 Turbo (CTS 2031 Turbo)) also
supports the onward linking facilities through a DCX 825/871.
The SDLC/HDLC protocol is a standard feature that supports the bit-oriented
synchronous protocols.
1.1.
1.1.
1. Introduction and SetupIntroduction and Setup
Introduction and SetupIntroduction and Setup
Introduction and Setup
OVERVIEWOVERVIEW
OVERVIEWOVERVIEW
OVERVIEW
Figure 1-1. Multiplexer Product Application ExamplesFigure 1-1. Multiplexer Product Application Examples
Figure 1-1. Multiplexer Product Application ExamplesFigure 1-1. Multiplexer Product Application Examples
Figure 1-1. Multiplexer Product Application Examples
20311-1
Supervisor
DCX Network Application
3028Turbo
STATISTICAL
MU L TI PLEX E R
3028Turbo
STATISTICAL
MU L TI PLEX E R
3028Turbo
STATISTICAL
MU L TI PLEX E R
Point to Point Application
Supervisor
3028Turbo
STATISTICAL
MU L TI PLEX E R
3028Turbo
STATISTICAL
MU L TI PLEX E R

2031 Turbo Statistical Multiplexer
154001UA1-2
The multiplexer combines data traffic from up to eight sources into a high-speed
composite link. Channel speeds supported are from 75bps to 19,200bps with an
automatic channel speed detection (AUTOBAUD) option up to 9,600bps. The
buffer management allows storage of 16K bytes to be shared on demand by the
channels. Each channel is assigned a minimum of 372 bytes of buffer space to
prevent lockout. Because of the buffering action of the 2031, the data rates on the
channel side of the multiplexer may total several times the actual link rate without
data loss. The multiplexer will handle an aggregate of 76,800 bps in constant full-
duplex traffic (with flow control) and a 64,000K bps link without loss of data.
The multiplexer can transmit control messages end-to-end to handle such things
as break propagation, EIA signal propagation, and autobaud speeds. The control
messages are transparent to the user. In addition, any of the EIA interface outputs
can be forced high or low through the user interface.
Multiplexer configuration and operation monitoring is accomplished in a variety
of ways. An ASCII asynchronous terminal can be attached to the supervisory port
on the back panel or to a data channel that has the supervisory access enabled, or
the front panel push-buttons and LCD display can be used. Another method of
access is from a remote multiplexer in a point-to-point or a DCX network applica-
tion. Access to the supervisory function can be password protected for security.
All parameters are contained in nonvolatile storage.
The 3028 Turbo (CTS 3028 Turbo (CTS 2031 Turbo)) multiplexer is designed to be a
cost-effective point-to-point multiplexer. At the same time, it is fully compatible
with the CTS 2031 and the AT&T Paradyne DCX family of multiplexers and can
serve as an 8-channel node in a DCX network.

1. Introduction and Setup
154001UA 1-3
PRODUCTPRODUCT
PRODUCTPRODUCT
PRODUCT
TERMINOLOGYTERMINOLOGY
TERMINOLOGYTERMINOLOGY
TERMINOLOGY The following terms are used when referring to the multiplexer:
CHANNEL
EQUIPMENTEQUIPMENT
EQUIPMENTEQUIPMENT
EQUIPMENT
REQUIRED BUTREQUIRED BUT
REQUIRED BUTREQUIRED BUT
REQUIRED BUT
NOT SUPPLIEDNOT SUPPLIED
NOT SUPPLIEDNOT SUPPLIED
NOT SUPPLIED
Customer-supplied RS-232-C I/O cables from each DTE to standard EIA 25-pin
female connectors are required. A special cable is needed when using the
Tandem T-Pause® Flow Control application (refer to Appendix F).
Modem tail circuit applications require crossover cables (Figure 1-3).
One of the eight possible low-speed port interfaces.
LINK The high-speed composite multiplexed interface.
CHANNEL
PORT
The physical interface for a channel.
LINK PORT The physical interface for a link.
SUPERVISORY
PORT
The connector reserved for supervisor functions, such
as configuring channel parameters or monitoring status
and statistics.
A shielded, Male to Female, straight through cable is supplied to connect the
multiplexer Composite Port to an external modem.
This term refers to the use of the 3028 Turbo (CTS 2031
Turbo) multiplexer in direct communications with
another 3028 Turbo (CTS 2031 Turbo) multiplexer. This
application involves only two devices.
POINT-TO-POINT
APPLICATION
EQUIPMENTEQUIPMENT
EQUIPMENTEQUIPMENT
EQUIPMENT
SUPPLIEDSUPPLIED
SUPPLIEDSUPPLIED
SUPPLIED
Note
Shielded RS-232-C I/O cables
are required.
DCE Data Communication Equipment -- This can be any
Modem attached to the multiplexer on the Composite
port.
This term refers to the use of the 3028 Turbo (CTS 3028
Turbo (CTS 2031 Turbo)) multiplexer in a network of one
or more DCX devices.
NETWORK
APPLICATION
LCD Liquid Crystal Display -- This is located on the front
panel of the 3028 Turbo (CTS 3028 Turbo (CTS 2031
Turbo)). It displays two lines of 16 characters each.
DTE Data Terminal Equipment -- This can be any terminal or
host attached to the multiplexer on a channel port.

2031 Turbo Statistical Multiplexer
154001UA1-4
UNPUNP
UNPUNP
UNPACKING ANDACKING AND
ACKING ANDACKING AND
ACKING AND
SETUPSETUP
SETUPSETUP
SETUP
The following lists the procedure for unpacking and setting up the 3028 Turbo
(CTS 2031 Turbo).
Figure 1-2. Front & Rear Panel, Model 3028TurboFigure 1-2. Front & Rear Panel, Model 3028Turbo
Figure 1-2. Front & Rear Panel, Model 3028TurboFigure 1-2. Front & Rear Panel, Model 3028Turbo
Figure 1-2. Front & Rear Panel, Model 3028Turbo
1. Remove the 3028 Turbo (CTS 2031 Turbo) from the box and place it on a
flat surface.
2. MODEM CONNECTION. Connect the supplied composite link cable to
the port labeled COMPOSITE on the rear panel (Figures 1-2) and then to
the modem. The Composite port is configured as a DTE to allow use of a
shielded, Male to Female, straight through cable to connect the Modem.
3. Connect the customer-supplied shielded, Male to Male, RS-232-C cables to
the selected ports and the DTEs, respectively.
4. The voltage selector is set to the proper line voltage for the area of the
world where the unit will be used at the factory. For the United States the
switch is set to 115V. Plug the female end of the power cable into the
receptacle on the rear panel and connect the other end to the power source.
The unit is operational when the POWER LED lights.
5. After the 3028 Turbo (CTS 2031 Turbo) has been attached to the proper
power source, it performs a series of tests to insure the integrity of the
system components. If the tests are passed, the multiplexer LCD displays:
20312-51
SYSTEM READY
00:00:00
and the system configuration can be performed. If any of the tests fail, the
LCD displays a message (refer to System Error Messages section). When
this message is displayed, cycle the power. If the error occurs again
contact your CTS service representative.
6. Connect a standard ASCII terminal, if used, to the 3028 Turbo (CTS 2031
Turbo) using a customer-supplied, straight-through, RS-232-C I/O cable at
the port labeled SUPERVISORY.
Note
Shielded RS-232-C I/O cables
are required.
20311-2
POWER LOSS DOWN CONTROL
DATA LINK FLOW
STATISTICAL
MULTIPLEXER NE X T LA ST SE L M ON/ CL
3028
TURBO
COMPOSITE
SUPERVISORY
PORT 7
PORT 8
PORT 5
PORT 6
PORT 3
PORT 4
PORT 1
PORT 2
CAUTION:
FOR CONTINUED
PROTECT ION A GAINST
RISK OF FIRE
R E PLAC E O N LY
WITHSAMETYPE
OFFUSE

1. Introduction and Setup
154001UA 1-5
Connect the terminal to the power source and turn on the terminal.
PRESS: <supervisor logon character>
(default = CTRL + V)
The System Menu is Displayed
Check the following items if the System Menu does not appear.
 Terminal cabling
 Terminal power switch ON
 Terminal speed 9600 (refer to terminal manual)
 Multiplexer <supervisory logon character> is decimal 022
(default = CTRL + V) (refer to Appendix D)
 Multiplexer stop bits (refer to Chapter 2)
 Multiplexer parity (refer to Appendix D)
For additional information on these items refer to the indicated chap-
ters.
Table 1-1. Supervisory Port DefaultsTable 1-1. Supervisory Port Defaults
Table 1-1. Supervisory Port DefaultsTable 1-1. Supervisory Port Defaults
Table 1-1. Supervisory Port Defaults
COMMAND PARAMETER DEFAULT
SETTING
SUPERVISORY
PARAMETERS SPEED 9600
DATA BITS 8
STOP BITS 1
PARITY NONE/SPACE
RV FL CTL NONE
(Reverse Flow Control)
MULMUL
MULMUL
MULTIPLEXERTIPLEXER
TIPLEXERTIPLEXER
TIPLEXER
FACTORFACTOR
FACTORFACTOR
FACTORYY
YY
Y
DEFDEF
DEFDEF
DEFAULAUL
AULAUL
AULTSTS
TSTS
TS
The multiplexer is configured at the factory with a set of default parameters.
Refer to Tables 1-1 and 1-2 for the default settings.
If you want to change any of the multiplexer parameters, refer to the appropri-
ate paragraph in Chapter 2.
