Patton electronics NetLink 2960 RAS User manual

V.92/V.90
K56Flex™
V.34+
ISDN SOHO Router
Dial-Up Users
Internet
& WWW
The 2960 RAS supports over
20 signaling methods and
PSTN/ISDN switch types and
16/24/30/48/60 analog or
digital modems
The Model 2960 integrates standard
CSU/DSUs and a 10/100 Ethernet port
with Frame Relay and PPP/HDLC pro-
tocol support
WWW
Model 2960 RAS
PSTN/ISDN
10/100 Ethernet Port
Two Frame Relay/PPP
Uplink Ports with
integrated T1 CSU/DSU
and E1 NTU
24/30 Calls
on each
T1/PRI and
E1/PRI
Access Port
Model 2960 RAS
The Patton 2960 RAS is an ideal
solution for the established Internet
Service Provider that is expanding
into a new calling area. By integrating
capabilities into our 2960 Remote Access
Server, the ISP lowers expansion costs
and produces revenue immediately.
The 2960 RAS integrates up to 60 analog
and digital modems, radius Accounting
and Authentication Client, a 10/100
Ethernet port, IP Routing, Frame Relay
forwarding, and four built-in E1/T1
CSU/DSUs. It connects 16 to 60 dial-in-
modems with V.92, V.44, V.90, K56Flex,
V.34+ or ISDN users to the Internet, IP
LANs, or Corporate Intranets. Load-shar-
ing dual-redundant
power supplies and
integrated Web-based
SNMP/HTTP manage-
ment system capabili-
ties make our 2960
RAS the most reliable
and easiest to use RAS in the business!
Need additional details?
Visit us at www.patton.com.
The Patton 2960 Remote Access Server provides 16 to 60 dial-up ports each supporting V.92, V.90,
V.44, K56Flex™, V.34+, and ISDN connections.
Remote Access Server
Patton 2960 Dual T1/E1/PRI RAS
Remote Access Products
SNMP/HTTP Network Management
Use a standard Web Browser, HP OpenView™ or
simple PCs to configure and manage the 2960
MultiLink and Multichassis Support
Combine multiple dial-in sessions, even across
boxes to deliver the highest performance
Dual-Redundant Power Supplies
Provide non-stop access with our high MTBF
2960. Convection-cooled and stackable
without fans
Frame Relay & PPP Network Uplinks
Dual Network uplinks to a FR switch or IP router
for high speed trunking
Dynamic Analog/Digital Modems
All modems (V.92, V.44, V.90, K56Flex™, V.34+
and ISDN) are dynamically supported on dedicat-
ed DSPs
16, 24, 30, 48, or 60 ports in a 1U-
High Platform
Model 2960 uses the latest technology
to achieve the highest densities
Special Rates
Available
Call for Details
Dial-out/Callback/Dial-on-demand
Use the Model 2960 as a dial-out modem pool
and support advanced dial-out applications

07MD2960-DS7
Why use our Model 2960 RAS?
NetLink RAS Product Family*
* Specifications subject to change without notice.
From HTTP management to dual-redundant power supplies to
FR/PPP uplink integration, the NetLink Model 2960 provides an
all-in-one package for the expanding ISP. Featuring:
Integrated T1/E1 uplink ports with Frame Relay and PPP.
Convection-cooled system. There are no fans or moving
parts to fail.
The lowest cost-of-ownership for an ISP or Telco building
a Remote POP for 48/60 ports.
The Model 2960 requires 1/2 the space of existing RAS solu-
tions. With greater reliability and a smaller package than any of
its competitors, the Model 2960 is the cost leader in the indus-
try.
Lucent
MAX 4000 Lucent
PM3
2960 Competitive Positioning
Number of V.90/V.92 calls
T1/E1/PRI ports
Backhaul/Uplink ports
Self Cooling
100Base-T Ethernet ports
Built-in HTTP/WEB Mgmt
Dual Redundant Power
Tech Support
Software Upgrades
Rack Height
Base Features
KKeeyySSeelllliinnggPPooiinnttss
48/60 (NO V.92)
2
2
NO
NO
NO
Add’l $$$
Add’l $$$
Add’l $$$
2U
48/60
(NO V.92)
2
Add’l $$$
NO
NO
NO
Add’l $$$
Add’l $$$
Add’l $$$
2U
Patton
2960
16/24/30/48/60
2
2
YES
YES
YES
YES
FREE
FREE
1U
V.92, V.44, V.90, K56Flex™, V.34 Annex 12, V.34, V.32bis, V.32, V.23, V.22, V.22bis, V.21, Bell 212A, Bell 202, Bell 103, EIA-PN-2330, V.8, V.8bis, Sync/Async receiver/transmitter for V.14,
V.42/V.42bis error correction & compression.
E1 Primary Rate interface (Q.931), E1 MFR2 (R2), T1 Primary Rate Interface, T1 Robbed bit with Loop/Ground Start or E&M Wink, E&M Immed, Taiwan R1 and Drop & Insert
HTTP, SNMP, TELNET Dial-in and Ethernet or RS-232 console port, SYSLOG client, Remote software upgrade via FTP, User configurable login prompts and banners
RADIUS, PAP/CHAP, Username/Password, and Static Users Database (111 Entries)
Achieved through Flash upgrades via FTP (upgrades available from wwwwww..ppaattttoonn..ccoomm)
TCP/IP suite with extensive protocol statistics • ICMP/TFTP/FTP/RLOGIN/TELNET • Ethernet ARP, Proxy ARP and RARP protocols • Point-to-Point Protocol (PPP) • SLIP protocol • Van
Jacobson TCP header compression PPP address and protocol compression • RADIUS authentication and accounting, with support for primary and secondary servers • RIP and RIPv2 • User
configurable static routes • MultiLink PPP • Multi-chassis MultiLink • Layer 3 and Layer 4 IP Filtering • NFAS • DNIS
Dial-out with support for multi-link PPP • Single-line call-back • Remote authentication using PAP and CHAP and session time
Model Number
Number of Connections
Power Supplies
Ethernet Ports
WAN Ports
Modem Modulations
PSTN Signaling
Management Services
Authentication
Software Upgrades
Protocol Services
Dial-out Services
MMooddeell22996600MMooddeell22999966MMooddeell33112200
Dual Redundant (Fixed) AC
One 10/100Base-T
Four
Dual-Redundant (Hot Swap) AC or DC
Two 10/100Base-T
Four
3120/48 3120/60 3120/96 3120/120
2960/16 2960/24 2960/30 2960/48 2960/60
Dual Redundant (Fixed) AC
One 10/100Base-T
Four
2996/96 2996/120
96/120 Calls—4 T1’s or 4 E1’s 48 60 96 120
16 24 30 48 60
