LEDs for monitoring Ethernet
link and activity
Serial connector:
• DB-9 male or female
• DB-25 male or female via cable
Locking style barrel
connector provides secure
power connection
10/100Base-TX LAN port
connects to Ethernet hub/switch
User-selectable serial RS-485/422/232
with async data rates up to 280 kbps
U
se Patton’s Model 2285 universal
single-port device server to control,
access, inter-connect, and manage
RS-485/422/232 devices from any remote
location as if you were there. Patton’s device
servers provide a new level of efficiency and
affordability to a variety of application envi-
ronments including industrial automation,
health care, security, transportation, retail,
and many others.
With built-in DHCP the Model 2285 automat-
ically obtains an IP address and a subnet
mask from the master server. With the IP
address identified and the serial port
attached, the Model 2285 can pass tranpar-
ently pass data end-to-end using Telnet over
TCP. Users can access management features
over telnet, serial console, or the web.
Security features include static key based
RC4 data encryption, SSL to provide a
secure connection between client and server,
HTTPS for secure data transfer over the net-
work, and IP filter, which limits and controls
access to the serial device. COM Port
Redirector is included with Patton’s 2285
enabling users to use their existing
COM/TTY-based software, preventing the
hassle and expense of investing in additional
software.
The Patton Model 2285 provides physical-
layer connectivity by a user selectable RS-
485/422/232 serial port and 10/100Base-TX
Ethernet port. Configure the serial port’s data
rate, ranging from 75 bps to 230 kbps, and
choose from a variety of connector types
including DB9 or DB25 male or female.
Easily and cost effectively bring serial
devices onto one global or local area net-
work!
Visit www.patton.com for more informa-
tion.
Control, monitor, and collect data from all your serial devices over the local network or Internet. Patton’s Model 2285 universal single-port
device server is cost-effective and feature-rich, linking virtually any serial RS-485/422/232 device to any IP network over a secure connection.
EtherBITS™ RS-485/422/232
Universal Device Server
Model 2285
Device Servers
User Selectable RS-485/422/232
Control, access, and monitor your asynchronous
serial terminals and devices over the LAN
COM Port Redirector Software Included
Windows®—Tactical COM Port Redirector
Linux-vtty drivers
Standard TCP/IP Protocols Supported
ARP, ICMP, TCP, Raw TCP, UDP, DHCP,
Telnet/SSH, HTTPS, DNS, Dynamic DNS, SNMP
v1, & v2, SSL
Secure Communication
Security features include static key based RC4
data encryption, SSL, HTTPS, and IP filtering
Special Rates Available
Call for Details
Connects Directly to the LAN
10/100Base-TX LAN connection
via RJ-45 connects to any hub/switch
EtherBITS… Connect with confidence.
Free Software Updates
Download new software via Patton’s FTP
site to internal FLASH memory

07M2285-DS3
Patton is a registered trademark, and TrinityAE and Visuality are trademarks of
Patton Electronics Company in the United States and other countries.
Specifications
Typical Applications
Physical Interface
Serial: DB-9M/F; DB-25M/F; Ethernet:
Shielded RJ-45
Serial Transmission
RS-485,422, and 232 rates from 75 bps
to 230 kbps (user selectable)
Ethernet Transmission
10/100Base-TX
Management
Monitoring, control, and diagnostics via
serial port,TELNET session, or HTTP
LED Indicators
Power, Ethernet Status, and Activity
Power
External AC: 9~30 VDC, 300 mA at 9
VDC
Compliance
EMC Directive 89/336/EEC, Low Voltage
Directive 73/23/EEC; CE Mark
Environment
Temperature: 40–122°F (5–50°C);
Humidity: Up to 90% non-condensing
Dimensions
4.5L x 3.2W x 1.0H in.
(9.0L x 5.3W x 1.9H cm)
Weight
Packaged: 1.05 lbs (0.46 kg);
Unit only: 0.15 lbs (0.06 kg)
✔✔The Patton Model 2285 connects various
RS-485/422/232 serial devices to a central loca-
tion over an Ethernet Local Area Network. The
device server enables monitoring, controlling,
management, and data collection.
✔✔The Model 2285 enhances COM Port
Redirection with the addition of encryption.
Secure connections between the 2285 and the
controller’s COM port are implemented with the
Serial/IP COM port redirector or OpenSSL
Toolkit with an SSL security option.
✔✔The Model 2285 performs Serial Data Tunneling
when used in pairs. The 2285’s will simulate a
direct serial link between two serial devices over
an Ethernet connection. Using IP allows the user
to extend serial connections across the building or
across the world.
Ethernet
Cash register or
Sales terminal
Model
2285
Model
2285
Model
2285
Model
2285
Card
reader
Monitor and Control
over the Network
Data collection
over the Network
Remote control
Port Operation
PBX
Time clock/Data
collection terminal
Ethernet Unix Server
RS-232 Console port
Model 2285
Model 2285
Ethernet
Serial
Serial
www
IP Network
