PAGE 4
1 10
1
100
2.405 Ghz
100V AC 240V AC
10V DC 14V DC
1 A
170 mA
0.44 W 3.84 W
48V DC
0°C (32°F) 55°C (131°F)
2
3/4inch 7
3/4inch 4 inch
Specications
Carrier frequency
Environment
Dimensions
Min Max
Width Height Length
System Specication
DC supply voltage
Electrical
DC supply current
Waterproof
Min Max
Min Max
ACU's per Net2Air bridge - Recommended
No
Net2Air USB bridge per system
Operating temperature
Net2Air wireless range to ACU
Net2Air Ethernet bridge per system
Power over Ethernet (POE) power rating
Input supply voltage
IEEE 802.3 af
This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a trained technician.
Data Reset
To clear all settings back to their factory default, including clearing the current IP address and setting the bridge to
acquire new addresses using DHCP, power on the unit with the reset button held down for 3 seconds. This is located
at the rear of the unit through a small hole beneath the power connection.
The unit will beep to acknowledge once the reset is complete.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
FCC Compliance
30 yds
When connecting to a WAN or different subnet mask
If you are connecting this device to a remote subnet which is different from the Net2 software PC, the standard
detect mechanism cannot work across the network routers between them. The IP address, along with the correct
subnet mask and gateway for the remote subnet have to be set. Either do this on the local subnet with the existing
Net2 PC, or use a PC on the remote subnet once the device is installed.
The PC that has the Net2 server installed must be able to access the IP address range on the WAN/remote site.
This may require the routers and gateways to be congured between the networks. Again, this would be done by
the Network administrator of that site. Make sure the ports listed above are open on all intermediate routers.
Once installed, create a record with the;Add button (if none was created during initial set up) and you should then
be able to detect its MAC by entering the IP address in the Conguration screen Ping box.
Mains power adaptor
Net2 Ethernet bridge current
Power over Ethernet (POE) voltage
Product compliance and limitations
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
