PC LINE P13GWCB09 User manual

1.3 Mega Pixel
Manual Focus Webcam
Quick Start Guide
P13GWCB09
Congratulations on the purchase of your new PC Line Webcam.
Before commencing the installation and set up, please check that you have all the items
and familarise yourself with this Quick Start Guide.
Package Contents
System Requirements
Hardware:
 Pentium PIII 700 MHz CPU
 1 Available USB port
 1 Available CD-ROM drive
 Windows compatible sound
card and speakers
 128MB RAM Minimum Internal
Memory
 500MB Free Hard Disk space
Software:
 Windows XP SP2
 Windows Vista / Windows 7
Product Overview
Installation
CD Disc
(Part Number: 2D1-MP1V3T-D0161)
Quick Start Guide
(Part Number: 2P7-MP1V3T-D0161)
Webcam
Driver Installation:
1. Turn on your computer and insert the CD
Driver.
2. Select and click on Driver.
3. Click OK to continue the installation.
4. Click Finish to complete the installation.
Note: If the operating system is Windows
Vista, the Found New Hardware
message will pop-up once the webcam
is connected to your computer. Choose
Locate and install driver software
(recommended) from the list to start
the installation.
GB-1 GB-2 GB-3
NOTE: Please ensure you have Windows
Media Player Version 9 or above
prior to using the bundled
software ArcSoft WebCam
Companion 3.0.
Snap Shot button
Adjustable Focus Lens
Power LED Indicators
Webcam stand
USB cable
Software Installation:
ArcSoft WebCam Companion 3.0
1. In the main menu of the CD driver, select and
click on ArcSoft WebCompanion 3.
2. Select the language for this installation and click
OK to conrm.
3. Click Next and follow the instructions to
continue the installation.
4. Click Finish to complete the installation.
ArcSoft Magic-i
1. In the main menu of the CD driver, select and
click on ArcSoft Magic-i.
2. Select the language for this installation and click
OK to conrm.
3. Click Next and follow the instructions to
continue the installation.
4. Click Finish to complete the installation.
PC Line P13GWCB09_QSG_GB_090918vPage 1 18/09/09 4:15:37 PM

Set Up and Mounting the Webcam Specication
Model P13GWCB09
Image Sensor 1280x 1024 pixels, 1/4”Colour Progressive CMOS
Lens Specication F2.4, f=6.1mm
White Balance Auto
Exposure Auto
Frame Rate 1280 x 1024 pixels @ 5-9fps / 640 x 480 pixels @ 25-30fps
320 x 240 pixels @ 25-30fps
Focus Range Manual focus, 5cm to innity
Depth of Field 5cm to innity
PC Interface USB2.0
Video Format WMV
Audio Built-in
Video Capture Res. 1280 x 1024 pixels/ 640 x 480 pixels/ 320 x 240 pixels
Still Capture Res. Up to 1280 x 1024 pixels
Flicker Control 50Hz, 60Hz
Bundled Software Arcsoft WebCam Companion 3.0
Arcsoft Magic-i
GB-4 GB-5
