PCS Digital PCS digital System 24 User manual

C-1Appendix C - Database Quick Reference
PCS digital
System 24
and
System 48
Database
Quick Reference
Rev 1.2

C-2 Appendix C - Database Quick Reference

C-3Appendix C - Database Quick Reference
Database Admin Programming
Operation
1. Press f#*.
2. Enter the Database Administrator password
Default Password: 000000.
3. Press [show].
3. Use the hbutton to go back one step.
DB PSWD:000000
bksp show chg
SYSTEM TYPE:PBX
back next chg Press [chg] to toggle value from PBX and
KEY. PBX setting will allow for dial 9
access. KEY setting, system will have
to have direct appearing CO lines on all
stations. Default: PBX
1.STATION
back next chg
2.CO LINE
back next chg
3.CALL HANDLING
back next chg
4.RESOURCE
back next chg
5.RESTRICTION
back next chg
6.SYS APPLICAT
back next chg
Page 2-3
Page 2-11
Page 2-15
Page 2-34
Page 2-51
Page 2-54

C-4 Appendix C - Database Quick Reference
1.STATION
back next show
SHOW STA:__
bksp show chg
DAY CLASS:0
back next chg
NITE CLASS:0
back next chg
CO LINE ASSIGNM
back next show
CO LINE 1:Y
back next chg
CO LINE 18:Y
back next chg
RECEIVE ASSIGNM
back next show
CO LINE 1:Y
back next chg
CO LINE 18:Y
back next chg
RING ASSIGNMENT
back next show
CO LINE 1:Y
back next chg
CO LINE 18:Y
back next chg
AC_CODE FORCE:N
back next chg
STA GROUP:1
back next chg
WARNING TONE:N
back next chg
DROP TIMEOUT:N
back next chg
Class Of Service: 2-4,2-51,3-27
Class Of Service: 2-4,2-51,3-27
CO Line Assignment: 2-5,3-29
Receive Assignment: 2-6,3-56
Ring Assignment: 2-7,3-56
Account Code: 2-8,3-11
Station Groups: 2-8,3-59
Warning Tone: 2-8,3-71
Drop Caller Time-Out: 2-9,3-38

C-5Appendix C - Database Quick Reference
STA POSITION:10
back next chg
STA POSITION:__
bksp save chg
VM PORT:N
back next chg
DSS OWNER:NONE
back next chg
DSS OWNER:__
bksp save chg
Station Position: 2-9
Voice Mail Port: 2-9
DSS Console: 2-10,3-38

C-6 Appendix C - Database Quick Reference
2.CO LINE
back next show
SHOW CO LINE:__
bksp show chg
DIALING:TONE
back next chg
CALL ABANDON:Y
back next chg
CO LINE TYPE:CO
back next chg
LOUD BELL: N
back next chg
CO LINE GROUP:1
back next chg
PRIVATE TO:EMPTY
back next chg
PRIVATE TO:_
bksp save chg
TOLL OVERRIDE:N
back next chg
DISTINCT TONE:1
back next chg
ICLID PORT:0
back next chg
Tone/Pulse Mode: 2-11,3-65
Hold - Hold Abandon: 2-12,3-45
CO Line Type Assignment: 2-12,3-31
Loud Bell Control: 2-12,3-50
CO Line Group Assignment: 2-13,3-30
Private Line: 2-13,3-55
Toll Override: 2-13
Distinctive Ring: 2-14
Incoming Call Line ID: 2-14

C-7Appendix C - Database Quick Reference
PRIV RLS TONE:Y
back next chg
3.CALL HANDLING
back next show
PRIVACY RLS:N
back next chg
EX_HOLD TIME:4
back next chg
FLASH TIME:0.7
back next chg
REMIND TIME:30
back next chg
PARK REMIND:30
back next chg
PAUSE TIME:2
back next chg
PBX CODE:9
back next chg
PBX AUTO PAUSE:1
back next chg
DIALING RATIO
back next show
TONE TIME:70
back next chg
INT_DGT TIME:70
back next chg
VM DIALING RATIO
back next show
TONE TIME:120
back next chg
INT_DGT TIME:120
back next chg
WARNING TIME:3
back next chg
RECALL TIME:30
back next chg
Tone / Inter-Digit Duration: 2-19,3-65
Privacy Release: 2-15,3-55
Hold - Exclusive Hold: 2-16,3-45
Flash: 2-16,3-40
Hold - Reminder Time: 2-16,3-45
Park Remind: 2-17
Pause: 2-17,3-54
VM Dialing Ratio: 2-19
Warning Tone: 2-20,3-71
Transfer Recall: 2-20,3-67
PBX Auto Pause: 2-18
PBX Code: 2-17

C-8 Appendix C - Database Quick Reference
SLT HOOK_FLASH
back next show
START:300
back next chg
END:800
back next chg
DISA
back next show
ACCESS CODE
back next show
01:EMPTY
back next chg
01:_
bksp save chg
24:EMPTY
back next chg
CO LN ATTRIBUTE
back next show
SHOW CO LINE:_
bksp show chg
DISA LINE:N
back next chg
DISA DAY COS:0
back next chg
DISA NITE COS:0
back next chg
SERVICE:NEVER
back next chg
TALK TIME:1
back next chg
EXTERNAL FORWARD
back next show
INCOMING:0
back next chg
OUTGOING:0
back next chg
External Call Forward: 2-25,3-39
SLT Hook Flash Time: 2-21
Direct Inward System Access: 2-22,3-34

C-9Appendix C - Database Quick Reference
SERVICE:NEVER
back next chg
TALK TIME:1
back next chg
UNS CONF TIME:1
back next chg
OPERATOR CODE:0
back next chg
UNS CONFERENCE:Y
back next chg
AUTO BUSY REDIAL
back next show
ABR ATTEMPTS:10
back next chg
ABR INTERVAL:60
back next chg
TONE DET TIME:0
back next chg
ACTIVE CALL:600
back next chg
HELD CALL:600
back next chg
CALL ABANDON TIM
back next show
ACTIVE CALL:600
back next chg
HELD CALL:600
back next chg
RING ALT POS:30
back next chg
CO LN PRESET FWD
back next show
CO P-FWD TIME:16
back next chg
CO LN ATTRIBUTES
back next show
Unsupervised Conference: 2-26,3-33
External Call Forward: 2-25,3-39
Unsupervised Conference: 2-27,3-33
Operator Code: 2-27
Auto Busy Redial:
Currently, this feature is not available.
Call Abandon Time: 2-29,3-45
Alternate Attendant Position: 2-30,3-14
CO Line Preset Forward: 2-31

C-10 Appendix C - Database Quick Reference
CO 1 DEST:EMPTY
back next chg
CO 1 DEST:_
bksp save chg
CO1 VMID: EMPTY
back next chg
WAIT_ICLID:6
back next chg
VM MON TIME:10
back next chg
SHOW CO LINE:_
bksp show chg
CO Line Preset Forward: 2-31
Wait ICLID: 2-33
VM Monitor Time: 2-33

C-11Appendix C - Database Quick Reference
4.RESOURCE
back next show
RING SCHEME:1
back next chg
LETTER TYPE:0
back next chg
ALARM:1
back next show
SYSTEM ALARM
back next show
ATTENDANT: 10
back next chg
ALARM TIME:_
bksp save chg
ALARM:8
back next show
NITE START:17:00
back next chg
NITE END:08:00
back next chg
DB PSWD:000000
back next chg
USER PASSWORD
back next show
SHOW STA #:_
bksp show chg
STA PSWD:0000
back next
USER NAMES
back next show
SHOW STA #:_
bksp show chg
STA 10:EMPTY
back next chg
ALTERNATE:EMPTY
back next chg
Ring Scheme: 2-34
Letter Scheme: 2-35,3-49
Attendant Position: 2-35,3-16
Alternate Attendant Position: 2-35,3-14
Alarm - System: 2-36,3-13
Night Service: 2-36,3-52
Database Password: 2-37
User Passwords: 2-37
User Names: 2-38,3-68

C-12 Appendix C - Database Quick Reference
OUTGOING MESSAGE
back next show
PREPROG MESSAGE
back next show
Call Operator
back next chg
_
bksp save chg
Call Home
back next chg
Call School
back next chg
Visitors Waiting
back next chg
Urgent
back next chg
Come See Me
back next chg
EXECUTIVE NOTIFY
back next show
Out For Lunch
back next chg
_
bksp save chg
Be Back Soon
back next chg
Left For The Day
back next chg
In A Meeting
back next chg
On Vacation
back next chg
STA 10:_
bksp save chg
Out Of Office
back next chg
User Names: 2-38,3-68
Text Messaging: 2-39,3-62

C-13Appendix C - Database Quick Reference
EMPTY
back next chg
_
bksp save chg
BGM:N
back next chg
CO LINE COPY
back next show
COPY FROM:_
bksp save chg
COPY TO:_
bksp save chg
STATION COPY
back next show
COPY FROM:_
bksp save chg
COPY TO:_
bksp save chg
FEATURE BTN COPY
back next show
COPY FROM:_
bksp save chg
COPY TO:_
bksp save chg
SYSTEM TIME
back next show
YEAR:03
back next chg
YEAR:_
bksp save chg
MONTH:JAN
back next chg
SYSTEM SPEED NO
back next show
SPEED NO:_
bksp show chg
System Speed Dial: 2-40,3-61
Background Music: 2-41,3-18
CO Line Copy: 2-42
Station Copy: 2-43
Feature Button Copy: 2-44
System Time: 2-45,3-62

C-14 Appendix C - Database Quick Reference
WEEKDAY:WED
back next chg
HOUR:01
back next chg
HOUR:_
bksp save chg
MINUTE:00
back next chg
MINUTE:_
bksp save chg
AC_CODE TABLE
back next show
LENGTH:4
back next chg
001:EMPTY
back next chg
001:_
bksp save chg
100:EMPTY
back next chg
NAME DIRECTORY
back next show
SHOW ENTRY:_
bksp show chg
NAME
back next show
EMPTY
bksp save chg
DESTINATION
back next show
TYPE:ICM
back next chg
DAY:01
back next chg
DAY:_
bksp save chg
System Time: 2-45,3-62
Account Codes: 2-46,3-11
Directory Dial: 2-47,3-35

C-15Appendix C - Database Quick Reference
DATA LINK:MANUAL
back next chg
RMT X_RATE:9600
back next chg
SMDR X_RATE:9600
back next chg
HOUR MODE:12
back next chg
DIAL TONE DET:N
back next chg
DIAL WAIT TIME:0
back next chg
KSU REVISION
back next show
KSU:KxxUVFx.xxx
back next
MODEM PORT #:
back next chg
DEST:NONE
back next chg
DEST:_
bksp save chg
RELAY CTRL:EMPTY
back next chg
Directory Dial: 2-47,3-35
Data Link: 2-48
Remote Transmit Rate: 2-48
SMDR Transmit Rate: 2-48
Hour Mode Selection: 2-48, 3-47
Dial Tone Detection: 2-48
Dial Wait Time: 2-49
Relay Control: 2-49
KSU Revision: 2-50

C-16 Appendix C - Database Quick Reference
5.RESTRICTION
back next show
CO LN CALL DISCR
back next show
DGT INTERVAL:001
back next show
0 ->
back next chg
_ ->
bksp save chg
->#
back next chg
->_
bksp save chg
DAY ALLOWED
back next show
CLASS 0:Y
back next chg
CLASS 7:N
back next chg
NITE ALLOWED
back next show
CLASS 0:Y
back next chg
CLASS 7:N
back next chg
DGT INTERVAL:100
back next show
Toll Restriction: 2-51,3-64

C-17Appendix C - Database Quick Reference
6.SYS APPLICAT
back next show
STA HUNT GROUP
back next show
HUNT GROUP:_
bksp save chg
GROUP TYPE:HUNT
back next chg
GROUP MEMBER
back next show
MEMBER 01:EMPTY
back next chg
MEMBER 01:_
bksp save chg
MEMBER 24:EMPTY
back next chg
RING ASSIGNMENT
back next show
CO LINE 1:NONE
back next chg
CO LINE 18:NONE
back next chg
VOICE MAIL
back next show
ICM PREFIX:EMPTY
back next chg
ICM PREFIX:_
bksp save chg
XFR PREFIX:EMPTY
back next chg
XFER PREFIX:_
bksp save chg
RECORD DGT:EMPTY
back next chg
RECORD DGT:_
bksp save chg
Hunt Groups: 2-54, 3-47
Voice Mail: 2-56

C-18 Appendix C - Database Quick Reference
ICM SUFFIX:EMPTY
back next chg
ICM SUFFIX:_
bksp save chg
XFR SUFFIX:EMPTY
back next chg
XFR SUFFIX:EMPTY
bksp save chg
DIS DGT:EMPTY
back next chg
DIS DGT:EMPTY
bksp save chg
Voice Mail: 2-56
