PDC spas Owner's Manual User manual

Hot Tub Spa
Owner’s Manual
R 2022/03

Record of Ownership 1
Safety Warning 2
Safety Instrucons 3-6
Parts Descripon 7-8
Luxury Model Specificaons 9-13
Premium Model Specificaons 14-19
Lifestyle Model Specificaons 20-24
Installaon and Site Preparaon 25-27
Start-Up Instrucons 28-29
Wiring Guidelines 30
Electrical Guidelines
North America 31-32
Export 33
Operaon Systems
SmartTouch™, Luxury Series 34-45
ProView™, Premium Series 46-52
Accent™, Lifestyle Series 53-61
Water Chemistry
Basics 62
Maintenance 63-64
Roune Maintenance 65-67
Troubleshoong 68
Maintenance Records 69-71
Plasc Development Company, Inc.
3743 West Fourth Street
Williamsport, PA 17701 USA
570-323-3060 tel [phone] fax
www.pdcspas.com
Hot Tub Owner’s Manual

Congratulaons on Choosing a Quality PDC Hot Tub! America’s Best Spas
You now own a high quality PDC Spa hot tub built for years of enjoyment and relaxaon. It is of prime importance that you
understand the operaon of your hot tub and enjoy it with safety in mind. You must read this manual thoroughly and
understand all of the safety precauons. Using your hot tub within these guidelines assures years of fun and relaxaon
gained from adding a PDC Spa Hot Tub to your lifestyle.
Please read the Owner’s Manual completely before installing and using your new hot tub. The purpose of this manual is
to provide you with safety, operaonal and installaon informaon which will allow you the fullest enjoyment of this fine
product. For addional copies of this manual, log onto www.pdcspas.com/Customer Care.
At the me of prinng, this manual was deemed as accurate as possible. PDC Spas reserves the right to change product in
an effort to enhance and improve, without prior noce. To be aware of any of these possible changes, log on to
www.pdcspas.com, referring to the Customer Care secon, or contact your retailer directly.
Ownership Informaon
Name ___________________________________________________
Address ___________________________________________________
___________________________________________________
Installaon Date ____ / ____ / ____
Model Name _____________________________ Serial # __________________________________
Retailer Name _____________________________ Retailer Phone Number _____________________
Service Technician Contact Info _________________________________
Register Your Hot Tub
Please be sure to register your new spa hot tub upon delivery. Log onto hps://www.pdcspas.com/register and enter the
required informaon. We have no record of ownership unl this is completed. This will ensure warranty coverage and
informaon regarding possible product updates.
Locang Your Serial Number
Luxury & Premium Series: The silver serial number plate can be found on the inside of filter housing at spa lip. Simply
remove the plasc filter cover revealing the silver serial number plate.
Lifestyle Series: The silver serial number plate is found on the backside of the shell behind the cabinet wall near the filter
housing.
SAVE THIS MANUAL FOR FUTURE REFERENCE !
Hot Tub Spa Owner’s Manual 1
Plasc Development Company, Inc.
3743 West Fourth Street, PO Box 4007, Williamsport, PA 17701 USA
570-323-3060 tel [phone] fax www.pdcspas.com

Important: It is extremely important that this sign be posted permanently placed in
clear view of persons using the hot tub. Occasional users may not be aware of some
of the dangers hot water poses to pregnant women, small children, seniors, and
people under the influence of alcohol. If you did not receive a warning sign or your
sign has become damaged, please call your local retailer or the factory for a
replacement.
Hot Tub Owner’s Manual 2
! WARNING
REPLACE ALL SAFETY SUCTION COVERS EVERY 7 YEARS.
Replace with similar VGB approved fings at same or higher flow rangs.
Replacement applies to all hot tub spa models.
! WARNING SIGNS
Cabinet Installed: For your referral, safety and convenience, a weather resistant sign has been
mounted on the end cabinet side of your hot tub spa. Become familiar with the precauons,
exercise safety and care while enjoying your hot tub. Nofy the factory or your retailer should
you require addional signs or replacements.
Warning Sign Must Be Posted: An addional copy of this sign can be found packaged with your
new hot tub. This sign must be posted permanently in a prominent area near the spa where it is
clearly visible to all occupants. Post this sign immediately upon installaon. Nofy the factory or
your retailer should you require addional signs or replacements.
WARNING: Read all instrucons before using the hot tub. PDC Spas assumes no responsibility
for personal injury or property damage sustained by or through the use of this product.
SAVE THIS MANUAL, SIGNS AND INSTRUCTIONS FOR FUTURE REFERENCE.
! WARNING
This unit is a professional-grade product. A knowledge of construcon techniques, plumbing and
electrical installaon according to codes are required for proper installaon and user sasfacon.
It is recommended that a licensed contractor perform the installaon. Warranty is voided for
improper installaon related issues.

READ AND FOLLOW ALL INSTRUCTIONS!!
This unit is a professional-grade product. A knowledge of construcon techniques, plumbing and electrical installaon
according to codes are required for proper installaon and user sasfacon. It is recommended that a licensed contractor
perform the installaon. Warranty is voided for improper Installaon related issues.
It is the responsibility of the home owner to ensure all users of the hot tub are adequately informed of all precauons.
Use the hot tub spa only as described in this manual. The spa is intended for home use only. Do not use the spa in a
commercial or rental seng; all warranes will be voided.
GROUND ALL METAL ELECTRICAL EQUIPMENT
• A green colored terminal or a terminal marked G, GR, Ground, or Grounding, is located inside the supply terminal box or
compartment. This terminal must be connected to the grounding means provided in the electric supply service panel, using a
connuous copper wire equivalent in size to the circuit conductors supplying this equipment. *according to, but not limited to: NEC,
NFPA 70, Secon 680.40, UL 1563.
• At least two lugs marked “Bonding Lugs” are provided on the external surface or on the inside of the supply terminal box or
compartment. Connect the local common bonding grid (household ground) in the area of the spa to these terminals, using an
insulated or bare copper conductor not smaller than No. 6 AWG.
• All field-installed metal components such as rails, ladders, drains or similar hardware located within 5 feet of the spa must be
bonded to the equipment grounding bus with copper conductors not smaller than No. 6 AWG.
• All metal surfaces within 5 feet of the spa must be bonded to the home bonding grid.
GROUND FAULT CIRCUIT INTERRUPTER PROTECTION (or equivalent; RCD, for export installs)
• All PDC Spas hot tubs are permanently installed units. GROUND FAULT CIRCUIT INTERRUPTER PROTECTION IS REQUIRED.
All spa equipment systems must be protected by a class A ground fault circuit interrupter (GFCI) or equivalent; RCD, for export
installs. A ground fault circuit interrupter type circuit breaker (NOT SUPPLIED) must be installed in the home panel box by a
licensed electrician when making wire connecon to the spa support pack equipment.
DANGER: RISK OF ELECTRICAL SHOCK:
• Install the spa at least five feet (1.52 m) from all ungrounded (unbounded) metal surfaces.
• Ground fault circuit interrupter protecon of the home power supply to the hot tub spa is necessary. Your electrician should
explain how it operates. (See maintenance for funcon and tesng)
• Do not permit any electric appliance, such as a light, telephone, radio or television, within five feet (1.52 m) of a hot tub spa.
Keep electrical appliances and extension cords away from the spa; water is a conductor of electricity.
DANGER: RISK OF ACCIDENTAL DROWNING.
• Extreme cauon must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot
use a hot tub spa unless they are supervised at all mes.
DANGER: TO REDUCE THE RISK OF DROWNING:
1. Never use the spa alone.
2. Children should not use the spa unless they are supervised by an adult.
3. Keep pets away from the spa at all mes.
4. ALWAYS REPLACE AND LOCK THE SPA COVER WHEN THE SPA IS NOT IN USE.
READ AND FOLLOW ALL IMPORTANT SAFETY INSTRUCTIONS
When installing and using this equipment, basic safety precauons should always be taken to reduce the risk of electrical shock,
to ensure safe usage, and to safeguard the user’s health.
Safety Instrucons 3

DANGER: TO REDUCE THE RISK OF DROWNING
• Prolonged immersion in the spa may cause hyperthermia. The causes, symptoms and effects of hyperthermia may be described
as follows: Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above the normal
body temperature of 98.6 °F (37°C). The symptoms of hyperthermia include an increase in the internal temperature of the body,
dizziness, lethargy, drowsiness, and fainng. The effects of hyperthermia include:
1. Failure to perceive heat
2. Failure to recognize the need to exit the spa
3. Unawareness of impending hazard
4. Fetal damage in pregnant women
5. Physical inability to exit the spa
6. Unconsciousness resulng in the danger of drowning
DANGER: RISK OF INJURY
• Do not remove the sucon fings. The sucon fing in this hot tub spa is sized to match the specific water flow created by the
pump. Should the need arise to replace the sucon fing or the pump, be sure that the flow rates are compable. Never operate
the spa if the sucon fing is broken or missing. Never replace a sucon fing with one rated less than the flow rate marked on
the original sucon fing.
DANGER: RISK OF ACCIDENTAL DROWNING
• Keep hair and body parts away from the sucon guard. Do not allow long hair to float freely in the water; long hair should be
restrained with a bathing cap. To reduce the risk of drowning from hair or body entrapment, install a sucon fing(s) with a
marked flow rate in gallons per minute that equals or exceeds the flow rate marked on the equipment assembly, if replacement
of sucon fings becomes necessary.
WARNING
• Ground fault circuit interrupter protecon (GFCI) or equivalent; RCD, for the spa should be tested prior to each use by the
homeowner. With the spa in operaon, push the “test” buon on the GFCI circuit breaker at the panel box. The spa should shut
down immediately. Now reset the GFCI. The hot tub spa should return to normal operaon. If the GFCI fails to operate in this
manner, there exists a possibility of electrical shock. Approved tesng applies for export protecon devices, i.e. RCD.
• Disconnue spa operaon by disconnecng the power source and nofy a qualified electrician for idenficaon and correcon
of the problem.
WARNING
• To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all mes.
WARNING: TO REDUCE THE RISK OF INJURY
• The water in a hot tub spa should never exceed 104ºF (40° C). Water temperatures between 100° F (38º C ) and 104º F (40° C) are
considered safe for a healthy adult. Lower water temperatures are recommended for extended use (exceeding 10 to 15 minutes)
and for young children.
• Excessive water temperatures have a high potenal for causing fetal damage during the early months of pregnancy. Pregnant or
possibly pregnant women should limit spa temperatures to 100º F (38° C).
• Before entering a hot tub spa, the user should measure the water temperature with an accurate thermometer since the tolerance
of water temperature regulang devices may vary as much as 5º F (3°C).
• THE USE OF ALCOHOL, DRUGS, OR MEDICATION BEFORE OR DURING SPA USE MAY LEAD TO UNCONSCIOUSNESS
WITH THE POSSIBILITY OF DROWNING.
• Persons suffering from obesity or with a medical history of heart disease, low or high blood pressure, circulaory system
problems, or diabetes should consult a physician before using a spa.
Safety Instrucons 4

• Persons using medicaon should consult a physician before using a spa since some medicaon may induce drowsiness while other
medicaon may affect heart rate, blood pressure, and circulaon.
• Enter and leave spa slowly and with cauon. Surfaces around spa will be wet and slippery.
WARNING
1. Never use the hot tub spa alone.
2. Do not bring any object into the spa that could damage the spa shell.
3. Do not sit on hot tub spa cover or place objects on it; it is not designed to support weight.
4. Remove any water or debris that may collect on the spa cover.
5. Keep all chemicals away from children and pets.
6. The PH and chemical balance of the water must be maintained as explained in this manual. Failure to do so may cause
injury to users or damage to the spa, and will void your warranty.
WARNING: HEALTH CONSIDERATIONS
• The use of alcohol, drugs, medicaon can greatly increase risk of fatal hyperthermia.
• Individuals with infecons and open sores or wounds should not use the spa. Bacteria thrive in warm and hot water.
Always keep your hot tub spa disinfected and maintain the proper chemical balance.
• Shower before and aer using the spa. This will remove any deodorant, perspiraon, or body oils that could contaminate the
water. Showering aer will remove any residual chemicals and/or possible bacteria.
• Do not use the hot tub spa immediately aer strenuous exercise.
• If you feel pain or dizziness at any me while using the spa, disconnue use and contact a physician.
WARNING: TO REDUCE THE RISK OF INJURY
• It is especially important for persons over the age of 35 or persons with pre-exisng health problems, such as obesity, heart
disease, high blood pressure, circulatory problems, or diabetes to consult their physician before using the spa.
• The hot tub spa jets produce a stream of water with relavely high pressure. Prolonged exposure of a localized area of the body
may cause bruises to the skin.
• Never insert any object into any opening.
• Do not use breakable containers in or near the hot tub spa.
WARNING: ELECTRICAL CONSIDERATIONS
• For controls other than underwater lighng circuits: A Ground Fault Circuit Interrupter (or equivalent for export installs) must be
provided if this device is used to control an underwater lighng fixture. The conductors on the load side on the Ground Fault
Circuit Interrupter shall not occupy conduit, boxes, or enclosures containing other conductors unless the addional conductors
are also protected by a Ground Fault Circuit Interrupter (or equivalent for export installs).
• The electrical supply for this product must include a suitably rated switch or circuit breaker to open all underground supply
conductors to comply with Secon 422-20 of the U.S. Naonal Electric Code. The disconnecng means must be readily accessible
to the spa occupant but installed at least 5 FT (1.5 M) away from the spa water.
WARNING: For hot tub spas with audio / video components
1. CAUTION - Risk of Electric Shock. Do not leave compartment door open.
2. CAUTION - Risk of Electric Shock. Replace components only with idencal components.
3. Do not operate the audio/video controls while inside the spa.
Safety Instrucons 5

4.
WARNING - Prevent Electrocuon. Do not connect any auxiliary components (for example cable, addional speakers,
headphones, addional audio/video components, etc.) to the system.
5. These units are not provided with an outdoor antennae; when provided, it should be installed in accordance with Arcle 810
of the U.S. Naonal Electrical Code, ANSI/NFPA 70.
6. Do not service this product yourself as opening or removing covers may expose you to dangerous voltage or other risk of
injury. Refer all servicing to qualified service personnel.
7. When the power supply connecon or power supply cord(s) are damaged; if water is entering the audio/video compartment
or any electrical equipment compartment area; if the protecve shields or barriers are showing signs of deterioraon; or if there
are signs of other potenal damage to the unit, turn off the unit and refer servicing to qualified service personnel.
8. This unit should be subjected to periodic roune maintenance (for example, once every 3 months) to make sure the unit is
operang properly.
ADDITIONAL SAFETY CONSIDERATIONS
• Install the hot tub spa to provide drainage for compartments of electrical components.
• For floor recessed spas: Install to permit access for servicing from above or below the floor. Hot tub spa equipment must be
installed below water level.
• When planning your spa installaon site, prepare for the unlikely event of rapid spa drainage.
• Do not place spa in direct sunlight while unit is empty or when sealed in shipping materials. Excessive heat build may
cause damage to spa and void warranty.
• When installing hot tub spa, allow ample space for future servicing, nong locaon of all support equipment per the model
specificaons.
SAVE THESE INSTRUCTIONS
Safety Instrucons 6

Parts Descripon and Funcon 7
Hydrotherapy Jets:
Various sized fings mix water with air to produce localized therapy, in a straight stream, circular
moon, or in random paerns for massage. Posioned in massage seats from neck to feet, upper
and lower back in contoured and straight seang arrangements. Jet nozzles are easily
interchangeable with a simple turn allowing user to enjoy the type and power of massage best
suited to them.
Ultra Massage™ Selector: (Diverter Valve) Located on hot tub lip, this fing is much larger than
the air control described below. Turn to adjust pump power to selected jets which enhances water
acon through those jets by decreasing water acon through others. Be sure no sand or parcles
are brought into the hot tub spa as they will cause the diverter to seize up. It is best to turn the
diverter valve only when the pump is turned off.
Air Controls: Fings mounted on the lip of spa controlling amount of outside air mixed with in-
coming water of the hydrotherapy jet. Your spa has mulple air controls on the hot tub spa lip that
control air/ water mix for a segment of the jets. You choose the strength that best suits you. When
not in use, the air controls should be kept in the off posion.
Sucon: Circular fing mounted on the vercal wall of the foot well and serves as an addional
pump water inlet. These fings must be replaced every 7 years with similar VGB approved fings
at same or higher flow rangs.
PowerFlo™ Filter: This pressure-side filtraon is a powerful design built into Luxury and Premium
Series models. The filter cartridge is easily accessible for maintenance and hidden from occupant’s
view.
Prisne™ Filter: This sucon-side filtraon is a proven effecve filtraon system posioned on the
sucon side of the jet pump in the Lifestyle Series models. The filter cartridge is easily accessible for
maintenance and hidden from occupant’s view.
Ozone Jets: All spas are equipped with ozone jets for sanitaon. The filter cycle should circulate
8-10 hours daily for proper ozonaon. Use the programmable electronic control center to
automacally operate this funcon.
Ozonator: Your EverPure™ ozonator will operate in conjuncon with your filtraon system.
Ozone is a gas, O3, that has been used for years as a sanitaon treatment for drinking water, and
now as a proven purifier for hot tubs.

Parts Descripon and Funcon 8
Slide Valves: Valves are used to shut off the water flow to the heater, circulaon pump,
And jet pump(s) for specific service problems.
Support Pack: The control system operates all funcons of the hot tub. Make sure your
electrician connects the power supply accordingly to all Naonal Electric Code, and shows you
how to test the GFCI circuit breaker (not supplied). This pack is connected to a 50 amp GFCI
breaker. Make note of this locaon along with other major components prior to installaon for
possible servicing access.
Heater: Your hot tub is equipped with a thermostat control at the spa side (topside control).
Set the water at the temperature you enjoy. Leave the thermostat at that seng, and the hot tub
will automacally maintain the correct temperature; ready for your enjoyment anyme. Avoid
constant reseng of the thermostat; it is more economical to maintain temperature than to let
the temperature fall and raise. Never raise the temperature above 104 degrees.
Moon Glow: Low voltage underwater spa light, with varying shades of a color wash,
controlled at the spa side control panel. Choose rotaon of color or constant color of your choice.
EverLite™: Exclusive to all PDC hot tub spa models is the cabinet mounted indicator light which
confirms the EverPure™ ozone purificaon system is properly operang.
EverLite2™: Oponal on Luxury Series units, EverPure ozone in conjuncon with UV-C acvely
treats spa water for a highly effecve sanitaon method. A sight glass provides indicaon of
proper performance
Water Spout Control Valve: Most all hot tub models feature the cascading water spout feature.
A control valve is mounted on the spa adjusng the pressure and height of the spout.
Air’assage Air Channel: All Luxury Series models have the benefit of an air massage delivering a
so Swedish massage through a series of stainless grommets in the seat areas. This massage is
separate from the jets, driven by an air blower under separate control.

Specificaons, Luxury Series | Bali Model 9
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
GENERAL rev. 2020/04
Seating Capacity 7
Shell Material Acrylic
Dimensions (Domestic) 94” (7’10”) sq. x 39” (3’3”)
Dimensions (Export) 240 cm. sq. x 99 cm.
Water Capacity 650 Gallons ( 2,460 liters)
Dry Weight 908 lbs (412 kg.)
Skirt Material Permawood™
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 6.0 (3.0) HP 6.0 (3.0) HP
Pump #2 peak (continuous) HP 2 6.0 (3.0) HP 6.0 (3.0) HP
Air Bubbler 4 1.5 HP 1.5 HP
Electronics
Electrical Can 6 Balboa 501X1 in.kYE 5 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 SmartTouch™ in.k1000 Series
SPECIAL FEATURES
Spa Pillows 4
Stainless Steel Jetting Standard
Cascading Spouts/Control Valve WS, C Standard
Allure2™ LED Lighting Optional
Halo LED lighting™ Standard
SoundStream™ Audio Optional*
V
L
WS
G
C
I
LE
7
A
E
I
E
V
OZ 6, H
5 1
2
LE
LE
I I
I
E
E
E
A
A
G
G
G
G
O O
G
LE
LE
LE
I
U
E
K G
U U
U
4
WATER SYSTEM** (photo ref.)
Ozonator
25 sq. ft.
4
5
31
15
2
19
2
4
1
6
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
7”
10” wire
feed

Specificaons, Luxury Series | Biscayne Model 10
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
C
A
G
I
K
G
G
O
LE
L
7
WS
E
V
LE
C
E
E
GENERAL rev. 2020/04
Seating Capacity 5
Shell Material Acrylic
Dimensions (Domestic) 90” (7’6”) x 79” (6’7”) x 37” (3’1”)
Dimensions (Export) 229 cm. x 201 cm. x 94 cm.
Water Capacity 325 Gallons (1,230 liters)
Dry Weight 800 lbs. (363 kg.)
Skirt Material Permawood™
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 6.0 (3.0) HP 6.0 (3.0) HP
Pump #2 peak (continuous) HP 2 6.0 (3.0) HP 6.0 (3.0) HP
Air Bubbler 4 1.5 HP 1.5 HP
Electronics
Electrical Can 6 Balboa 501X1 in.kYE 5 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 SmartTouch™ in.k1000 Series
SPECIAL FEATURES
Spa Pillows 4
Stainless Steel Jetting Standard
Cascading Spouts/Control Valve WS, C Standard
Allure2™ LED Lighting Optional
Halo LED lighting™ Standard
SoundStream™ Audio Optional*
A
G
G
U
V
I
I
E
E
E
E
E
E
LE
LE
LE
OZ 6, H
WATER SYSTEM** (photo ref.)
U
U
U
E
E
5
1
4
2
Ozonator
25 sq. ft.
4
4
36
11
2
15
2
4
1
5
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
12”
36” wire
feed

Specificaons, Luxury Series | Fiji Model 11
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
GENERAL rev. 2020/04
Seating Capacity 6
Shell Material Acrylic
Dimensions (Domestic) 94” (7’10”) sq. x 39” (3’3”)
Dimensions (Export) 240 cm. sq. x 99 cm.
Water Capacity 525 Gallons (1,987 liters)
Dry Weight 865 lbs. (392 kg.)
Skirt Material Permawood™
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 6.0 (3.0) HP 6.0 (3.0) HP
Pump #2 peak (continuous) HP 2 6.0 (3.0) HP 6.0 (3.0) HP
Air Bubbler 4 1.5 HP 1.5 HP
Electronics
Electrical Can 6 Balboa 501X1 in.kYE 5 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 SmartTouch™ in.k1000 Series
SPECIAL FEATURES
Spa Pillows 4
Stainless Steel Jetting Standard
Cascading Spouts/Control Valve WS, C Standard
Allure2™ LED Lighting Optional
Halo LED lighting™ Standard
SoundStream™ Audio Optional*
WATER SYSTEM** (photo ref.)
Ozonator
25 sq. ft.
4
5
29
15
2
22
2
4
1
5
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
V
U
C
L
I
K
7
V
I
I
WS
A
A
A
E
LE
LE
G
G
G
LE
E
E
O
G
G
G
E
LE
G
E
E
LE
I
I
U
U
U
LE
LE
LE
E
G
LE
1
2
4
5
6,H
OZ
24”
16” wire
feed

Specificaons, Luxury Series | Malibu Model 12
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
Seating Capacity 5
Shell Material Acrylic
Dimensions (Domestic) 82” (6’10”) sq. x 37” (3’1”)
Dimensions (Export) 209 cm. sq. x 94 cm.
Water Capacity 400 Gallons (1,514 liters)
Dry Weight 635 lbs (288 kg)
Skirt Material Permawood™
GENERAL rev. 2020/01
SPECIAL FEATURES
Spa Pillows 3
Stainless Steel Jetting Standard
Cascading Spouts/Control Valve WS, C Standard
Allure2™ LED Lighting Optional
Halo LED lighting™ Standard
SoundStream™ Audio Optional*
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 6.0 (3.0) HP 6.0 (3.0) HP
Pump #2 peak (continuous) HP 2 6.0 (3.0) HP 6.0 (3.0) HP
Air Bubbler 4 1.5 HP 1.5 HP
Electronics
Electrical Can 6 Balboa 501X1 in.kYE 5 Series
Voltage 120/240 230/400
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 SmartTouch™ in.k1000 Series
WATER SYSTEM** (photo ref.)
Ozonator
25 sq. ft.
4
4
24
11
2
18
2
4
1
4
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
E
WS
L
7
K
I
E
E
G
E
OZ 6, H
E
E
G E
E
E
LE
LE
E
LE
LE
LE
LE
I
V
E
V
U
U
I
A
A
U
U
I
C
O
G
G
G
5
4
G
A
A
E
E
1
2
10”
15”
wire feed

Specificaons, Luxury Series | Reno Model 13
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
Seating Capacity 6
Shell Material Acrylic
Dimensions (Domestic) 86” (7’2”) sq. x 37” (3’1”)
Dimensions (Export) 218 cm. sq. x 94 cm.
Water Capacity 375 Gallons (1,420 liters)
Dry Weight 705 lbs (320 kg)
Skirt Material Permawood™
GENERAL rev. 2020/04
SPECIAL FEATURES
Spa Pillows 4
Stainless Steel Jetting Standard
Cascading Spouts/Control Valve WS, C Standard
Allure2™ LED Lighting Optional
Halo LED lighting™ Standard
SoundStream™ Audio Optional*
1
4
E
E
V
A
G
O, L
A
2
G
E
G
K
A
I
G
G
5
7
WS
E
I
E
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 6.0 (3.0) HP 6.0 (3.0) HP
Pump #2 peak (continuous) HP 2 6.0 (3.0) HP 6.0 (3.0) HP
Air Bubbler 4 1.5 HP 1.5 HP
Electronics
Electrical Can 6 Balboa 501X1 in.kYE 5 Series
Voltage 120/240 230/400
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 SmartTouch™ in.k1000 Series
V
I
U
C
E
WATER SYSTEM** (photo ref.)
U
U
U
G
G
G
I OZ
H
6
Ozonator
25 sq. ft.
4
7
47
12
2
0
2
4
1
6
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
8”
8”
wire
feed

Specificaons, Premium Series | Barbados Model 14
** Not every jet is referenced. Each type of jet is noted for ease of identification. *Note location of audio components prior to install.
All specifications are accurate at time of print. Manufacturer reserves the option to change product without prior notice. Dimensions are approximate.
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 4.0 (2.0) HP 4.0 (2.0) HP
Pump #2 peak (continuous) HP 2 4.0 (2.0) HP 4.0 (2.0) HP
Electronics
Electrical Can 6 Balboa 100X1 in.kYE 3 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 4.0 KW 3.6 KW
Operation System
Main Spa Side Control 7 ProView™ in.k500 Series
Seating Capacity 7
Shell Material Acrylic
Dimensions (Domestic) 94” (7’10”) sq. x 39” (3’3”)
Dimensions (Export) 240 cm. sq. x 99 cm.
Water Capacity 650 Gallons (2,460 liters)
Dry Weight 775 lbs (352 kg)
Skirt Material PermaWood™
GENERAL rev. 2020/04
SPECIAL FEATURES
Spa Pillows
Spout Control Valve C
Cascading Spouts WS
Stainless Steel Jetting
Prism LED™ Light
SoundStream™ Audio
4
Standard
Standard
Standard
Optional*
Standard
Ozone Water Purification Standard
A
E LE
O
U
OZ 7, 6, H
I
A
G
C
LE
LE
LE
E
U
U
L
I
LE
LE
WS
LE
I
E
E
G
A
G
E
G
V
LE
LE
LE
E
O
U
G
I
LE
LE
LE
I
V
K
G
G
G
G
WATER SYSTEM** (photo ref.)
5 1
2
Ozonator
25 sq. ft.
4
4
20
11
2
27
2
4
1
5
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
11”
18”
wire feed

Specificaons, Premium Series | Carmel Model 15
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
Seating Capacity 3
Shell Material Acrylic
Dimensions (Domestic) 60”(5’) x 84”(7’) x 33”(2’9”)
Dimensions (Export) 152 cm. x 213 cm. x 84 cm.
Water Capacity 220 Gallons (832 liters)
Dry Weight 575 lbs. (261 kg.)
Skirt Material PermaWood™
GENERAL rev. 2020/04
SPECIAL FEATURES
Spa Pillows
Water Spout Control Valve C
Cascading Spouts WS
Stainless Steel Jetting
Prism LED™ Light
SoundStream™ Audio
4
Standard
Standard
Standard
Optional*
Standard
Ozone Water Purification Standard
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 4.0 (2.0) HP 4.0 (2.0) HP
Electronics
Electrical Can 6 Balboa 100X1 in.kYE 3 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 ProView™ in.k500 Series
ELECTRICAL SYSTEM
U
G
A
WS
A
O
C
I I
K
1
L
U
E
E
I
G
6, H OZ
I
7
WATER SYSTEM** (photo ref.)
5
Ozonator
25 sq. ft.
2
6
12
2
2
8
0
2
1
4
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
24”
14”
wire
feed

Specificaons, Premium Series | Catalina Model 16
5
2
OZ 6 , H
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
Seating Capacity 5
Shell Material Acrylic
Dimensions (Domestic) 90”(7’6”) x 79”(6’7”) x
37”(3’1”)
Dimensions (Export) 229 cm. x 201 cm. x 94cm.
Water Capacity 325 Gallons (1,230 liters)
Dry Weight 695 lbs. (315 kg.)
Skirt Material PermaWood™
GENERAL rev. 2020/04
SPECIAL FEATURES
Spa Pillows
Water Spout Control Valve C
Cascading Spouts WS
Stainless Steel Jetting
Prism LED™ Light
SoundStream™ Audio
4
Standard
Standard
Standard
Optional*
Standard
Ozone Water Purification Standard
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 4.0 (2.0) HP 4.0 (2.0) HP
Pump #2 peak (continuous) HP 2 4.0 (2.0) HP 4.0 (2.0) HP
Electronics
Electrical Can 6 Balboa 100X1 in.kYE 3 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 ProView™ in.k500 Series
G
LE
LE
G
U I
LE
G
A
G
7
K
V
V
E
A
G
E
E
U
G
E
LE
LE
E
O
U
U
G
I
I
LE, E
WS
LE
I
G
E
A
E
E
E
L
I
LE
WATER SYSTEM** (photo ref.)
1
Ozonator
25 sq. ft.
4
4
20
9
2
21
2
4
1
5
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5
34”
10”
wire feed

Specificaons, Premium Series | Denali Model 17
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
GENERAL rev. 2020/04
Seating Capacity 7
Shell Material Acrylic
Dimensions (Domestic) 82” (6’10”) sq. x 39” (3’3”)
Dimensions (Export) 209cm. sq. x 100 cm.
Water Capacity 425 Gallons (1,609 liters)
Dry Weight 645 lbs. (293 kg)
Skirt Material PermaWood™
Water Flow 428 Gallons per Minute
SPECIAL FEATURES
Spa Pillows
Water Spout Control Valve C
Cascading Spouts WS
Stainless Steel Jetting
Prism LED™ Light
SoundStream™ Audio
Ozone Water Purification
2
Standard
Standard
Standard
Optional*
Standard
Standard
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 4.0 (2.0) HP 4.0 (2.0) HP
Pump #2 peak (continuous) HP 2 4.0 (2.0) HP 4.0 (2.0) HP
Electronics
Electrical Can 6 Balboa 100X1 in.kYE 3 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 ProView™ in.k500 Series
WATER SYSTEM** (photo ref.)
7
G
A
I
G
A
E
E
U
V
LE
LE
LE
E
O
U
U
L
G
A
WS
G
I V
E
I
C
LE
1
2
U
I
G
A
G
O
5
OZ 6, H
Ozonator
25 sq. ft.
4
3
41
14
2
3
2
4
1
4
1
1
Water Treatment System
Filter, PowerFlo™ System
Slide Valves
MegaSwirl™ Jet
Euro Jet w/eyeball
Mega’assage™ Jet
Ozone Jet
Large Euro Jet
Diverter Valves
Safety Suction
Mini Skimmer
Air Control
Spa Light
Drain Valve
OZ
A
E
G
O
LE
V
U
K
I
L
5 12”
14”
wire feed
