Jacuzzi SIGNATURE COLLECTION User manual

INSTALLATION AND OPERATION INSTRUCTIONS
NE60000B 2/2016
Jacuzzi Luxury Bath
14525 Monte Vista Avenue
Chino, CA 91710
1-800-288-4002
www.jacuzzi.com
SIGNATURE™
COLLECTION

Page 2 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ Collection
Contents
Save these instructions for future use. Use the form below to record your model and serial number for future reference.
Date Purchased
Purchased From
Installed By
Serial Number
Model
Installer: Leave the manual for the homeowner.
Homeowner: Read this manual and keep for future reference.
Product Information
NOTE
Contents. ......................................................................................................................................................................... 2
Product Information. ........................................................................................................................................................ 2
Important Safety Instructions........................................................................................................................................... 3
Inspection and Testing..................................................................................................................................................... 4
Visual Inspection. ............................................................................................................................................................ 4
Bathtub Water and Operational Test................................................................................................................................ 4
Framing and Support....................................................................................................................................................... 5
Electrical Connections..................................................................................................................................................... 6
Installation Procedures.................................................................................................................................................... 6
Cleanup. .......................................................................................................................................................................... 9
General Operation Information........................................................................................................................................ 9
Whirlpool Control........................................................................................................................................................... 10
RapidHeat™.................................................................................................................................................................. 10
Cleaning. ....................................................................................................................................................................... 10
Maintenance...................................................................................................................................................................11
Skirt Panel Installation....................................................................................................................................................11
Troubleshooting Procedures. ........................................................................................................................................ 12
Authorized Service. ....................................................................................................................................................... 13
Warranty ........................................................................................................................................................................ 14

Installation and Operation www.jacuzzi.com Page 3
English
Signature™ Collection
Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
Use this unit only for its intended use as described in this manual. Do not use attachments not recommended by the
manufacturer. Never drop or insert any object into any opening.
This is a professional grade product. A working knowledge of construction techniques, plumbing and electrical
installation according to codes are required for proper installation and user satisfaction. We recommend that a
licensed contractor perform the installation of all Jacuzzi Luxury Bath products. Our warranty does not cover improper
installation related problems.
DANGER RISK OF ACCIDENTAL INJURY OR DROWNING! Do not permit children to
use this unit unless they are closely supervised at all times. Do not use hydromassage bathtubs
unless all suction guards are installed to prevent body and hair entrapment. Never operate the
hydromassage bath if the suction cover is broken, damaged or missing. Do not operate this unit
without the guard over the intake for the circulation pump (suction cover/strainer).
DANGER RISK OF SEVERE INJURY FROM ELECTRIC SHOCK OR DEATH
FROM ELECTROCUTION! This unit must be connected only to a supply circuit that
is protected by a 15 amp ground fault circuit interrupter (GFCI). Such a GFCI should be provided
by the installer and should be tested on a routine basis. Follow the manufacturer’s instructions
when testing the GFCI. The GFCI should interrupt power. Push the reset button. Power should
be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI
   interruptspowertothebathtubwithoutthetestbuttonbeingpushed,agroundcurrentisowing,
indicating a possibility of an electric shock. Do not use this hydromassage bathtub. Disconnect
   thehydromassagebathtubandhavetheproblemcorrectedbyaqualiedservicerepresentative
before using.
DANGER RISK OF ELECTRIC SHOCK! Do not permit electrical appliances (such as a hair
dryer, lamp, telephone, radio or television) within 60” (1524mm) of this hydromassage bathtub.
Connect only to a circuit protected by a ground fault circuit interrupter (GFCI). (For permanently
connected units) A green colored terminal (or a wire connector) marked “G,” “GR,” “GROUND,”
or GROUNDING”) is provided within the terminal compartment. To reduce the risk of electric
shock, connect the terminal or connector to the grounding terminal of your electric service or
supply panel with a conductor equivalent in size to the circuit conductors supplying the
equipment.
DANGER PROLONGED IMMERSION IN HOT WATER MAY INDUCE
HYPERTHERMIA! Hyperthermia occurs when the internal temperature of the body
reaches a level several degrees above the normal body temperature of 98.6°F (37°C). The
symptoms of hyperthermia include an increase in the internal temperature of the body, dizziness,
lethargy, drowsiness and fainting. The effects of hyperthermia include:
A. Failure to perceive heat.
B. Failure to recognize the need to exit the bath.
C. Unawareness of impending hazard.
D. Fetal damage in pregnant women.
E. Physical inability to exit the bath.
F. Unconsciousness resulting in danger of drowning.
DANGER This equipment is intended for indoor use only. Install the equipment in accordance with these
instructions. Use supply wires that are suitable for 167°F (75°C), including the temperature
rating of the supply conductors to be used. This unit should be electrically grounded and installed
by a licensed contractor, electrician, and plumber. Building materials and wiring should be routed
away from the motor/pump or blower or other heat producing components of this unit. A pressure
wire connector is provided on the exterior of the motor/pump and heater to permit connection of
an No. 8 AWG solid copper bonding conductor between this unit and all other electric equipment
and exposed metal in the vicinity, as needed to comply with local requirements.
DANGER Risk of fetal injury. Pregnant or possibly pregnant women should consult a physician before
using a hydromassage bathtub equipped with a heater

Page 4 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ Collection
Important Safety Instructions (Cont)
Inspection and Testing
All bathtub units are factory tested for proper operation and watertight connections prior to shipping. However, the unit
must be retested by the installer prior to installation. Jacuzzi Luxury Bath is not responsible for any defect that could
have been discovered, repaired, or avoided by following this inspection and testing procedure:
1Place the bathtub on a level surface, near appropriate electrical supply, water supply, and water drainage. A
driveway is a suitable choice.
2 Coverthedrainandoverowholewithtapeorastopperandllthebathtubtothebottomoftheoverowhole.
3Allow bathtub to stand for 5 minutes.
4 Pluginmotor/pumpandturnuniton.ConrmthatallfeaturesfunctionasdescribedintheOperationsectionof
this manual. Do not install the bathtub if bathtub fails to operate as described.
5Visually inspect all joints for leaks. Do not install the bathtub if leaks are detected.
6Return bathtub to box or otherwise protect from damage until time of installation.
1Remove the bathtub from the shipping carton. Be careful not to scratch the surface of the bathtub on exposed
staples. Remove the staples or fold them into the carton. Retain the carton until satisfactory inspection of the
product has been made. Do not lift the bathtub by the plumbing at any time; handle by the shell only.
2 Inspecttheshellandbathtubcomponents.Shouldinspectionrevealanydamageordefectinthenishorvisible
damagetoanycomponents,donotinstallthebathtub.Damageordefecttothenishclaimedafterthebathtub
is installed is excluded from the warranty. Jacuzzi Luxury Bath’s responsibility for shipping damage ceases upon
delivery of the products in good order to the carrier.
3 Referanyclaimsfordamagetothecarrier.Fordenitionsofwarrantycoverageandlimitations,refertothe
published warranty information packed with the product or in the back of this manual.
Visual Inspection
Bathtub Water and Operational Test
CAUTION  Keepbodyandhairaminimumof6˝(152mm)awayfromthesuctionttingatalltimeswhen
the hydromassage system is in operation. Hair longer than shoulder length should be secured
close to the head.
CAUTION  Donotimmersethecontrolpanelbyoverllingthebath.
CAUTION To avoid injury, use care when entering and exiting the hydromassage bathtub.
CAUTION Do not use drugs or alcohol before or during the use of a hydromassage bathtub equipped
with a heater. Possible drowning may occur.
CAUTION Do not use a hydromassage bathtub equipped with a heater immediately following strenuous
exercise.
SAVE THESE INSTRUCTIONS.
The Company has obtained applicable code (standards) listings generally available on a national basis for products of
thistype.Itistheresponsibilityoftheinstaller/ownertodeterminespeciclocalcodecompliancepriortoinstallation
of the product. The Company makes no representation or warranty regarding, and will not be responsible for any code
compliance.Productspecicationsaresubjecttochangewithoutnotice.
CAUTION Use this unit only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturers. Do not tamper with user-operated controls or such
devices.
CAUTION Water temperature in excess of 104°F (40°C) may be injurious to your health. Check and
adjust water temperature before use.

Installation and Operation www.jacuzzi.com Page 5
English
Signature™ Collection
Framing and Support
Observe all governing codes and ordinances.
1 Properinstallationisyourresponsibility.Haveaqualiedtechnicianinstallthisbath.
2Installation using a ground-fault circuit-interrupter (GFCI) is required.
3It is the customer’s responsibility:
 •Tocontactaqualiedelectricalinstaller.
• To assure that electrical installation is adequate and in conformance with National Electrical Code (NEC).
ATechnicalSpecicationsManualhasbeenincludedwithyourbathtub.TheTechnicalSpecicationsManualwill
containpertinentinformationregardingyourJacuzziLuxuryBathproduct.LocatetheTechnicalSpecicationsManual
at this time.
NOTES
Finished alcove must have correct interior dimensions, as shown in the rough-in diagrams in the Technical
SpecicationsManual,toproperlyinstallunit.Forthreewallalcoveinstallations,useanintegralmoldedthree-sided
tilingangebathtubs.JacuzziLuxuryBathdoesnotrecommendutilizingbathtubswithoutanintegraltilingangeinan
alcove installation where a shower head would be installed above the unit and utilized as a shower.
•Inremodeling,ifnecessary,addstudsateachendtoprovideaverticalnailingsurfaceforthesidenailingangesof
bathxtureproduct.
•To avoid obstructions during installation make sure that supply lines, spout pipe and valve plumbing do not project
into alcove.
•Bathtubsrequirea6"x12"(150mmx305mm)ooropeningforthe1½"(38mm)drain,wasteandoverow(DWO)
kit.
•Besureooropeninglocationmatchesbathtubxturedrainlocation.
•Use of casting plaster/plaster of paris (foundation material) is recommended in all commercial structures (i.e. hotels,
motels, dormitories, health clubs, etc.).
•The unit must be supported from the bottom of the bathtub and not solely from the bathtub rim.
Fig. 1
READ ALL INSTALLATION INSTRUCTIONS COMPLETELY. IMPROPER INSTALLATION WILL VOID THE
WARRANTY.
IMPORTANT
Makesurethatwallsandoorsmeetresafetyrequirementsoflocalbuildingcodeand/orFHA/HUDMinimum
Property Standards.
•Per UPC code, access must be provided to the
pump/motorforyourspecicmodel(Figure1).Itisthe
responsibility of the installer, building contractor, or
owner to provide access for service. Jacuzzi is not
responsible for any costs relating to obtaining access for
repair. The owner shall bear such costs and, if
appropriate, must seek recovery from the installer.
Primary and secondary service access locations are
shown in the rough-in diagrams contained in the
TechnicalSpecicationsManual.
•Provide adequate ventilation for cooling and supply
sufcientairforthepump/motor.Donotinsulatearound
the equipment.
(Illustrations above shown with framing exposed for clarity.)
Access Locations
Access Location
Example
Access Location
Example

Page 6 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ Collection
Optional Heater
Suboor
DANGER
Risk of electric shock. Connect only to a circuit protected by a
GFCI (Figure 2).
CAUTION
Electricaloutletmustbemounted4˝(101mm)abovetheoor
line and 12" max (305mm) inside from the edge of the bathtub
(Figure 2), or in accordance with local building and electrical
codes.
Risk of component overheat. Do not use electric extension cord
to power this unit. Operating the pump without enough water in
the bathtub can cause permanent damage to the pump/motor.
If the GFCI unit indicates a malfunction, per manufacturer’s
instructions, turn OFF power and do not attempt to use the
bathtubuntilthesourceoftheproblemhasbeenidentiedand
corrected.
Electrical Connections
Installation Procedures
Framing and Support (Cont)
1 Preparethesuboorforthedrainandensurethattheareaislevel.Thedrain/overowofthebathtubextends
 belowthebottomofthebathtub.IdentifythedrawingintheTechnicalSpecicationsManualthatcorresponds
with your bathtub.
2 Jacuzzi’sTru-Level®baseisastandardfeatureonallbathtubs.Ifthesuboorislevelandacontinuoussurface,
no other preparation is necessary. Proceed to the “Installation Procedures” section.
3 Ifthesuboorisnotlevel,youmustleveltheentiresurfacepriortoinstallingthebathtub.
4 Ensurethattheoorislevelandcansupportaloadof50lbs.persquarefoot.
5The bathtub must remain level in order for it to drain properly and must make contact with the leveling material.
NOTES
When using electrical products, basic precautions should always be followed:
•Always follow local building and electrical codes. Grounding is required. The unit should be installed and grounded
byaqualiedelectrician.
•A dedicated, 120VAC, 15 Amp GFCI-protected circuit is required for the pump/motor. If the bathtub was purchased
with a heater installed, a separate 120VAC, 15 Amp GFCI-protected circuit is required. Bonding lugs are provided on
the motor and heater to satisfy local electrical codes.
1Make sure framed-in alcove is of proper size per
 Jacuzzidimensions,square,andplumb;checkoor
for levelness (Figure 3). Rough-in should be kept to
a minimum until the unit is on the job site.
 Measurementsmayvary+0or-⅜"fromoriginal
 specications.
2 Sufcientclearancemustbeprovidedforaccess
to service connections (pump/motor, controls,
heater plumbing and electrical hook ups).
NOTE
The following steps (A, B and C) will direct you in how
best to install the bathtub, depending on your installation
environment.
4˝
(101mm)
Fig. 2
Fig. 3
Level
12˝
(305mm)

Installation and Operation www.jacuzzi.com Page 7
English
Signature™ Collection
Installation Procedures (Cont)
Fig. 4
Fig. 5
Fig. 6
Fig. 7
A. Drop In Installation
1. Prepare the cutout hole for the bathtub using
the provided template (Figure 4).
NOTE
Please follow the instructions listed on the
template (included) to correctly mark the cutout
hole. The template may show guides for more
than one bathtub, be certain to select the
appropriate guide lines. If under mounting is an
option, be careful to select the guide lines that
apply to the installation that you are performing.
2. Place a piece of scrap lumber on each of the
ends of the cutout – this will be used as a
temporary support prior to lowering the bathtub
fully into the opening (Figure 5).
3. Install the unit, inserting the motor/pump end
 rst,loweringthebathtubintotheopeningas
shown in the illustration.
4. The bathtub must be set level. To check, use
a level on top of the ledges on both ends of tub
and on top of threshold (Figure 6).
B. 3-Wall Alcove Installation
1. Place the tub in the alcove with the front skirt
 rmlyontheoor.Thebathtubmustbeset
level. To check, use a level on top of the ledges
on both ends of tub and on top of dam
(Figure 7).
2. After leveling tub, mark each stud (concrete or
block wall) immediately above the back
 horizontalange.Removetubfromalcove.
Measure the distance between the top of the
 backhorizontalangeandthebottomofthe
 tubledgeapproximately1½"(40mm).
Carefully mark this dimension on the back
 studs(orwall),belowtherstmark(Figure7
inset).
3. Install a Ledger Strip: Jacuzzi mandates the
use of supports under the rear ledges of
bathtubs to prevent shifting. Use horizontal
ledger strip along the entire rear ledge or “I”,
“T” supports in at least two places in vertical
position. Nail a 1" x 3" x 60" (25mm x 75mm x
1525mm) ledger strip immediately below the
lower marks made on framing (Figure 7 -
inset).
Template
Scrap Lumber
Level
Top of
Ledger Strip
Ledger
Board
Level
1.50"

Page 8 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ Collection
Apply a continuous bead of silicone sealant around the entire seam
between the counter and the bathtub rim. Allow sealant to cure
according to manufacturer’s instructions.
3In a bucket, mix foundation material. Place a large mound
 ofplasteronthesuboor,intheapproximatelocationofthe
tub bottom center. The mounds should be placed high
enough so that when the tub is set, it will cause the plaster
to displace and spread. Replace unit into alcove with
 frontskirtrmlyonoor.Makecertainthatbackledgeof
 tubrestsrmlyonledgersupports.Levelunitandshim
ledger if necessary. The bathtub must be level.
NOTE
Bottom support materials: Casting plaster/plaster of paris (herein
referred as foundation materials) are not necessary but its use is
highlyrecommendedforarmerbottomsupport.
4 Fasteners:Towoodframing–predrillangeswitha
 ⅛"(5mm)carbidebitandfastenwith#8x1½"(38mm)
self tapping sheet metal screws, to concrete/block walls
use 1" (25mm) concrete nails with nailing tool or impact.
NOTE
Pre-drillingandnailingangesisrecommendedtoavoidcracking
of the acrylic unit. Silicone the top of each fastener to insure water
tightness.
Installation Procedures (Cont)
Rim of
Bathtub
Deck/Counter
Support
Frame
Plywood
Frame
Plywood
Rim of
Bathtub
Ledger Board
Frame
Plywood
Deck/Counter
Fig. 8
Fig. 9
CAUTION
Do not use an adhesive or adhesive sealant to secure the
counter to the bathtub. If maintenance or remodeling is
required, the counter may have to be removed. Adhesive will
permanently bond the counter to the bathtub. Carefully
position the deck/counter over the bathtub. Follow
manufacturer’s instructions to determine cure time.
C. Undermount Installation
1. Prepare the cutout hole for the deck/counter and
bathtub using the provided template.
NOTE
Please follow the instructions listed on the template (included)
to correctly mark the cutout hole. The template may show
guides for more than one bathtub, be certain to select the
appropriate guide lines. If under mounting is an option, be
careful to select the guide lines that apply to the installation
that you are performing.
Use the following steps for undermount as follows:
2. Position the bathtub template so that the desired
undermount guidelines are aligned with the rim edge
(Figure 4).
3. Attach the deck/support boards to the platform using
appropriate hardware (Figure 8 - inset). The
deck/counter support boards must be level with the rim
of the bathtub.
4. Attach deck/counter to the support boards using
suitable adhesive. Do not use adhesive to attach the
deck/counter to the rim of the bathtub.
5. Clean any dirt or debris from the top of the bathtub
rim. Secure the deck/counter to bathtub by applying a
bead of silicone sealant around the entire rim of
bathtub (Figure 9 - inset).

Installation and Operation www.jacuzzi.com Page 9
English
Signature™ Collection
5Spot-fasten the two bottom corners and the two top
 cornersoftheverticalsidenailingange.
 Nail/fastenateachstudthroughthetopsideangesat
6
each stud 16" (405mm) on center, working from both ends
toward back center. Complete the fastening through
 verticalsideange,approximately8"(205mm)oncenter.
7When other than cementitious backer board is to be used,
 furringstripsasthickasnailingangesarerecommended
for installation on studs above the installed unit to assure
 wallswillbeush.100%siliconesealantwithmildew
resistant properties should be applied between the backer
board and horizontal surface of unit (Figure 10). Then
 nishedwallmaterialscanbeapplied.
8Finishing of other trades should be done in conformance
with applicable codes and generally accepted building
practices.
9 Useaholesaw(netoothorabrasivegritcuttingedge)to
 drillholesfordeckmountedtubttings.
10  Connectexwatersupplylinestofaucet,connectbathtub
drains and plug power cords into GFCI outlets.
Installation Procedures (Cont)
Cleanup
To avoid dulling and scratching the surface of the bathtub, never use abrasive cleaners. For most soiled surfaces, a
mildliquiddetergentandwarmwaterissufcient.Thefollowingisalsorecommended:
• Remove spilled plaster with a wood or plastic edge. Spots left by plaster or grout can be removed if lightly rubbed
with detergent on a damp cloth or sponge. Do not use metal scrapers, wire brushes or other metal tools, as they
will damage the bathtub’s surface.
• Paint,tar,orotherdifcultstainscanberemovedwithFantastik®orsoapywater.
• Minorscratcheswhichdonotpenetratethecolornishcanberemovedbylightlysandingwith600-gritwet/dry
 sandpaper.Youcanrestoretheglossynishtotheacrylicsurfaceofthebathtubwithaspecialcompound,
 Meguiar’s#10MirrorGlaze.Ifthatisnotavailable,useautomotiverubbingcompoundfollowedbyanapplication
of automotive paste wax.
• Majorscratchesandgougeswhichpenetratetheacrylicsurfacewillrequirerenishing.CallJacuzziLuxuryBath
 tondaserviceagentinyourarea.
11 Turn on the power supply to the dedicated GFCI protected circuits and check system operation.
12  Caulkaroundtheperimeterofbathtubtosealthespacebetweentherimandthenisheddeck.
General Operation Information
All bathtubs manufactured by Jacuzzi Luxury Bath are designed
for“llanddrain,”whichmeansthebathtubshouldbedrained
aftereachuseandlledwithfreshwaterbythenextbather.This
is a health precaution, as these bathtubs are not designed to hold
water continuously like pools or spas.
Closethedrainandllthebathtubuntilwaterisatleast1˝to2˝
(25mm to 51mm) above the highest jet (see water line indicated in
the illustration - Figure 11). Do not turn on the whirlpool system at
any time if the jets are not completely immersed in water. Running
thewhirlpoolsystemwhenthereisinsufcientwaterinthebathtub
could result in water spraying outside the bath area. Running
the whirlpool system without water will damage the recirculating
pump.
NOTE When exiting the bathtub, the water level will drop below the jets which could result in water
being sprayed out of the unit. To prevent this, you must turn unit OFF before exiting bathtub.
Filltoatleast1˝to2˝
above highest jet
Fig. 11
Fig. 10
Finish Surface
Concrete Board
Silicone
Skirt

Page 10 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ Collection
ON/OFF Button
ON/OFF Button Fig. 12
Whirlpool Control
In the closed position, the jets massage with
only water.
In the open position, air mixes with water
to create a deep, wide plume of massaging
bubbles.
Fig. 13
OPEN Position CLOSED Position
Push down on the button to turn ON the whirlpool system.
Push down on the button to turn OFF the whirlpool system.
Direction (Figure 14A)
Tochangethedirectionofthewaterow,swivelthejetnozzleto
the desired angle.
Water Force (Figure 14B)
Increasetheforceoftheowbyrotatingthejetfacetotheleft
(counterclockwise).
Decreasetheforceoftheowbyrotatingthejetfacetotheright
(clockwise).
Never run the whirlpool system with all the jets closed.
Water ForceDirection
The heater turns ON automatically any time whirlpool
operation is active. Heater operation is not displayed on the
control panel. There is a visible indicator light on the heater
itselfthatsigniestheheaterisoperating.Theheaterwill
help maintain the temperature of the water in the bathtub
(Figure 15).
The heater is equipped with a preset vacuum switch which will
not allow the heater to turn ON if the pump is not running and
waterisnotowingthroughthewhirlpoolsystem.
The heater includes an exclusive High-Limit switch. This safety circuit will not false trip from hot tap water. It will
only turn OFF the heater if the thermostat fails. To reset, press the button. If the high-limit trips frequently, please
contact us at www.jacuzzi.com, or at 1-800-288-4002.
Vacuum Switch
High-Limit Switch
PUSH TO RESET
OVER HEAT
PROTECTION
HEATER ON
High Limit Reset
Heater On
Fig. 15
Fig. 14A Fig. 14B
Cleaning
If you want to use any kind of bathtub additive, use only a small amount of low-foaming powder or crystal substance;
thewhirlpoolactionintensiesthefoamingpropertiesofsoaps.
The use of certain bathtub oils, bubble baths, and bathtub additives may increase the level of accumulations of bathtub
residue in the whirlpool system and may cause false reading of the water level sensors. If excess accumulations
persist, you should discontinue use of these products.
To remove accumulations of bathtub residue from the whirlpool system, it is recommended that a bathtub be cleaned
regularly. For best results, however, we recommend that you clean your bathtub after each use using Systems Clean™,
ourexclusivetwo-partplumbingsystemcleanermadespecicallyforwhirlpoolbathtubs.SystemsClean™isavailable
through an authorized Jacuzzi Luxury Bath Distributor or by calling us direct at 1-800-288-4002 or may be purchased
online at www.jacuzzi.com.
CAUTION
CAUTION Do not use oil or oil-based bathtub additives. Never use abrasive, or caustic, household
cleaners on any Jacuzzi Luxury Bath product.
RapidHeat™

Installation and Operation www.jacuzzi.com Page 11
English
Signature™ Collection
Maintenance
Suction Cover/Strainer Maintenance
To clean your bathtub, simply use a mild, nonabrasive liquid detergent solution. You can protect and restore the gloss
toadulledacrylicsurfacebyapplyingMeguiar’s#10MirrorGlaze,aproductspecicallydesignedforuseonacrylic
nishes.IfMeguiar’sisnotavailable,useanegradeautomotiverubbingcompoundfollowedbyanapplicationofclear
automotive paste wax.
Minorscratcheswhichdonotpenetratethecolornishcanberemovedbylightlysandingwith600-gritwet/dry
sandpaper. Restore the gloss using Meguiar’s Mirror Glaze or automotive paste wax. Major scratches and gouges
whichpenetratetheacrylicsurfacewillrequirerenishing.CallJacuzziLuxuryBathtondaserviceagentinyourarea.
Clean the suction cover/strainer of hair and debris when
necessary (Figure 16).
1Remove the center screw and detach the suction cover.
2 Cleanthecoverbybackushingdebrisfromtheholes.
3Replace the suction cover immediately after cleaning.
Keep hair a minimum of 6 inches (152 mm) away from
thesuctionttingatalltimeswhenthewhirlpoolsystemis
operating. Hair longer than shoulder length should be secured
close to the head, or a bathing cap should be worn.
Do not operate the whirlpool system with the suction cover/
strainer removed! It is a safety device and must always be in
placeonthesuctionttingtominimizethepotentialhazardof
hair and body entrapment.
Fig. 16
Screw
Suction Fitting
Suction Cover
WARNING
Skirt Panel Installation
To remove the skirt panel -
Grasp an edge of the skirt panel and pull to separate.
To reinstall the skirt panel (Figure 17) -
Align the six (6) posts on the panel with the six (6)
receptor sockets on the tub and press into place.
Skirt Panel Adjustment (Figure 18) -
Insert a standard screwdriver into the receptor socket,
through the slot at the rear. Turn clockwise to tighten and
counter-clockwise to loosen.
Fig. 17
Receptor Socket
Post
If you are installing an optional skirt, please refer to the Skirt Installation Guide before proceeding any further.
Bathtubs with Optional Skirt
Fig. 18
Interior View
Exterior View
Receptor Socket
Slot

Page 12 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ Collection
If the unit is within the warranty period, contact Jacuzzi Luxury Bath Service Support at 1-800-288-4002 with your bath’s
serialnumberbeforeworkisstarted.TheserialnumberislocatedontheSpecication/SerialNumberPlate(theplateis
located behind the equipment area).
Troubleshooting Procedures
PROBLEM PROBABLE CAUSES REMEDY
Pump/motor does not start
Pump/motor shuts off by itself before time elapses
Pump/motor operates but no fully adjustable jets are
functioning
Water leakage from pump unions
No power to pump/motor
Pump/motor not plugged in
Pump/motor faulty
Motor thermal protection has deactivated pump/motor
due to overheating (supply voltage low)
GFCI tripped
Inadequate supply wiring
Reset GFCI
Insert plug securely into outlet
Ensure the control panel is connected to control box
Contact Jacuzzi Luxury Bath @ 800-288-4002
Let motor cool; thermal protection will reset. Check for
proper ventilation (check supply voltage)
Reset GFCI. If it continues to trip, do not use this unit.
Disconnect the unit and have the problem corrected by
a licensed electrician before using.
Consult a licensed electrician to correct the wiring unit.
Jets are closed
Suction cover/strainer may be clogged
Open jets by rotating counter-clockwise
With the motor turned OFF, remove the suction cover/
strainer and remove any debris. Replace the suction
cover before operating
Overtightened, O-ring may be pinched or improperly
seated, undertightened
Loosen unions , check and reseat O-ring. If O-ring has
been pinched out of shape, replace (refer to number
below). When tightening union nuts, handtighten only.
Pump/motor operates but air is not injected into the
water
Air valves are closed Open air control valves
Press Reset button on heaterWater not maintaining temperature High Limit switch on heater has been tripped
NOTES

Installation and Operation www.jacuzzi.com Page 13
English
Signature™ Collection
PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
USE TECHNICAL SPECIFICATIONS MANUAL SUPPLIED WITH PRODUCT.
Jacuzzi Luxury Bath has obtained applicable code (standards) listings generally available on a national basis for products of this
type.Itistheresponsibilityoftheinstaller/ownertodeterminespeciclocalcodecompliancepriortoinstallationoftheproduct.
Jacuzzi Luxury Bath makes no representation or warranty regarding, and will not be responsible for any code compliance.
Jacuzzi Luxury Bath
14525 Monte Vista Avenue
Chino, California, 91710
1-800-288-4002
www.jacuzzi.com
If you need a referral for a service company near you, or need assistance with operation or maintenance-related
questions, please call our Service Support Department at 1-800-288-4002. Visit our web site at http://www.jacuzzi.com/
for products, services, and an online copy of these Installation and Operation Instructions.
When requesting service or technical assistance please have available both the model and serial number of your
unit. This information can be obtained from the product registration card provided with your unit. If the card has been
misplaced,thisinformationcanbeobtainedfromthespecication/serialnumberlabelontheunititself.Thelabelis
located on the wall of the bathtub near the pump/motor.
SPECIFICATION/SERIAL NUMBER LABEL
MODEL: XXXXXXX
NAME: XXXXX
COLOR: XXXXX
MFG#: XXXXX
SER#: XXXXXX
Appropriate Safety Compliance Logos for your unit.
ApplicableElectricalSpecicationsforyourunit.
Electricalspecicationsprintedinthisarea.
Made in the USA
XXXX-XXXXX
Core Number,
Serial Number
Youwillndyourserial
number here
Authorized Service

Page 14 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ Collection
WARRANTY COVERAGE
Jacuzzi Luxury Bath (the “Company”) offers the following express limited warranty to the original purchaser of any Jacuzzi Luxury Bath product (“unit”) who purchases the product for personal or
single family use (“user”). The Company will repair or replace, at its option, the unit or its equipment in accordance with the following terms and conditions.
ONE YEAR LIMITED WARRANTY ON BATHS
Our limited warranty on bath products is for one (1) year. Our warranty covers the unit and factory-installed components (e.g., pump, motor) against defects in material or workman ship. Warranty
coverage begins on the date the unit was originally purchased by the user.
NINETY DAY (PARTS ONLY) LIMITED WARRANTY ON OPTIONS AND ACCESSORIES
Our limited warranty on options and accessories manufactured by the Company is for ninety (90) days for parts only. Our warranty covers options and accessories manufactured by the Company
(e.g.,llspoutkits,trimkits,skirts)againstdefectsinmaterialorworkmanship.Warrantycoveragebeginsonthedatetheoptionoraccessorywasoriginallypurchasedbytheuser.
WARRANTY LIMITATIONS
Our limited warranty does not cover defects, damage, or failure caused by the common carrier, installer, user, or other person, or resulting from, without limitation, any of the following: careless
handling(liftingunitbyplumbing,abradingnish,etc.);modicationofanytypeforanyreason(includingmodicationtomeetlocalcodes);improperinstallation(includinginstallationnotinaccor-
dancewithinstructionsandspecicationsprovidedwiththeunit);connectionssuppliedbytheinstalleroftheequipment;impropervoltagesupplyorunauthorizedelectricalmodication;misuse;
incorrectoperation,orlackofproperroutinemaintenance;operationoftheunitwithoutspeciedminimumamountofwateroratinappropriatewatertemperature;useofabrasiveorimproper
cleaners;oractsofGod,suchaslightning,oods,earthquakes,etc.
In addition, THE COMPANY WILL NOT BE RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES or losses arising from any cause (e.g., water damage to carpet, ceiling, loss of
use, etc.) including its own negligence; damages to, respecting, or resulting from: plated parts when pool and/or spa chemicals are used in the unit; optional bath equipment not manufactured by the
Company but supplied by Dealer, installer or the Company; the unit's prior usage as an operational display; or defects that should have been discovered before installation.
This limited warranty does not include: labor, transportation, or other costs incurred in the removal and/or reinstallation of the original unit and/or installation of a replacement unit; any costs relating
toobtainingaccessforrepair;orlossofusedamage,includinglossofsales,protorbusinessadvantageofanykindunderanycircumstances.Bathunitsareexcludedfromanywarrantycoverage
ifanyaddition,deletion,ormodicationofanykindwhatsoeverhasbeenmadetotheunit(ortoanycomponent).
Warranty coverage is provided in the United States of America only.
EXCLUSION OF IMPLIED WARRANTIES
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED ALTOGETHER OR TO THE FULL EXTENT ALLOWED BY LAW.
NOTICE:Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrightswhichvaryfromstatetostate.TherearenowarrantiesapplicabletoJacuzziLuxuryBathproductsexcept
as expressly stated herein or as implied by applicable state and federal laws. The Company will not be responsible for any statements or representations made in any form that go beyond, are
broaderthanorareinconsistentwithanyauthorizedliteratureorspecicationsfurnishedbytheCompany.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations and
exclusions may not apply to you.
WARRANTY REGISTRATION
Theattachedpre-addressedWarrantyRegistrationCardMUSTbelledoutbythepurchaserwithinthirty(30)daysfrompurchaseandmailedtoJacuzziLuxuryBathinorderforthiswarrantyto
become effective.
LIMITED WARRANTY ON THE JACUZZI LUXURY BATH
SIGNATURE™COLLECTION PRODUCT LINE
You may also register your product at our website, www.jacuzzi.com. You will be prompted to enter your product Serial Number followed by your warranty registration information. Or you may also
register by completing the registration below and mailing it to Jacuzzi at the address provided below.
TheattachedWarrantyRegistrationMUSTbelledoutbythepurchaserwithinthirty(30)daysfrompurchaseandreceivedbyJacuzziLuxuryBathinorderforthiswarrantytobecomeeffective.
RESPONSIBILITIES OF OTHERS
Inspecting the unit prior to installation is the responsibility of the installer or building contractor who acts on behalf of the User. They are responsible for ensuring the unit is free of defect or
damage. Notices are placed on and in the unit and on the shipping carton advising the installer of this responsibility. In the event of a problem, the unit must not be installed. The Company is not
responsible for failures or damage that could have been discovered, repaired, or avoided by proper inspection and testing (including proper water testing) prior to installation.
Damage occurring in transit is the responsibility of the carrier. The User or installer MUST open the crate and inspect the unit for damage when it is delivered. If damage is discovered, it must be
reported immediately to the seller and the carrier in writing, and an inspection requested. Failure of the carrier to respond should be reported to the seller and the carrier. Your freight claims should
beledpromptlythereafter.
Damage occurring to the unit during installation is the responsibility of the installer and/or building contractor and damage occurring thereafter is the responsibility of the user.
Failure of any optional equipment is the sole responsibility of the equipment manufacturer except as provided above and shall not extend to or apply to any replacement parts for the Options and
Accessories. Any replacement parts shall be covered by the original equipment manufacturer.
The Distributor or Dealer is responsible for knowing local code requirements and notifying the installing contractor and/or User of these requirements at the time of purchase. The Company is not
responsible for costs to modify any product to obtain any code approval, such as city, county, or state building codes in U.S.A. or municipal or provincial codes in Canada.
WARRANTY SERVICE
Forthecustomer'sbenet,theCompanymaintainsalistofindependentservicepersonneltoperformrequiredwarrantyservicerepairs.Suchrmsarenotagentsorrepresentativesofthe
Company and cannot bind the Company by words or conduct.
The Company will provide the warranty service described above when the following conditions have been met: the failure is of the nature or type covered by the warranty; the User has informed
an Authorized Jacuzzi Luxury Bath Service Agent or Warranty Service Department Representative of the nature of the problem during the warranty period; conclusive evidence (e.g., proof of
purchase or installation) is provided to the foregoing by the user proving that the failure occurred or was discovered within the warranty period; an authorized independent service person or
Company representative has been permitted to inspect the unit during regular business hours within a reasonable time after the problem was reported by the User. In order to obtain warranty
service, contact Jacuzzi Luxury Bath at:
jacuzzi.com
or
Warranty Service Department
14525 Monte Vista Avenue
Chino, California 91710
Call: 1-[phone]
To obtain warranty replacement for factory-installed components for Company supplied options and accessories manufactured and supplied by the Company, call or write the above. Provide a
description of the problem and proof of purchase. You will be instructed how to obtain replacements and where to return, at your expense, the failed component(s), option(s), or accessory(ies).
All replacement parts, equipment, and repairs shall assume the remaining warranty period of the part(s) replaced.
The Company's warranty obligation shall be discharged upon tender of replacement or repair. The customer's refusal to accept the tender terminates the Company's warranty obligation.

Installation and Operation www.jacuzzi.com Page 15
English
Signature™ Collection
Español
Jacuzzi Luxury Bath 14525 Monte Vista Avenue Chino, California 91710

Page 16 www.jacuzzi.com Installation and Operation
English
Signature™ CollectionSignature™ CollectionSignature™ Collection
Español
WARRANTY REGISTRATION CARD
Tocompleteyourregistration,visitourwebsiteatwww.jacuzzi.comorlloutandmailthiscardtotheaddressprinted
on the other side within thirty (30) days from date of purchase in order for this warranty to be come effective.
Purchaser's Name ______________________
Purchaser's Address ____________________
City __________________ State __ Zip ____
Home Phone:__________________ Cell Phone:
Email:________________________________
Date of Purchase________
Model Name __________________________
Serial Number _________________________
Dealer's Name_________________________
Dealer's Address _______________________
1.HowdidyoursthearaboutthisJacuzzi®product?
( ) Advertisement ( ) Article in Magazine/Newspaper
( ) Visited Dealer/Plumbing Supplier ( ) Yellow Pages
( ) Builder/Plumber/Remodeler ( ) Decorator/Architect
( ) Visited Retailer/Home Center Store
( ) Word of Mouth . . . Friend/Relative/Acquaintance
( ) Other (Please Describe) ______________
2.Whorstgaveyouspecicinformationaboutthisproduct(specications,prices,etc.)?
( ) Dealer/Plumbing Supplier ( ) Builder ( ) Remodeler
( ) Plumbing Contractor ( ) Retailer/Home Center Store
( ) Decorator/Architect ( ) Already Installed
3.Whatwasthemainreasonforpurchase?
( ) Styling ( ) Warranty Service ( ) Product Features
( ) Brand Name ( ) Price ( ) Hydrotherapy
( ) Home Resale_______________________
( ) Other _____________________________
4.Whonallydecidedwhichproductyouwouldbuy?
( ) Self ( ) Spouse ( ) Self and Spouse Together
( ) Other Family Member ( ) Designer/Architect
( ) Builder/Plumber/Remodeler ( ) Already Installed
5.Whoinstalled?()Alreadyinstalled/NewHome
( ) Contractor/Plumber when remodeling
( ) Self/Spouse when remodeling
( ) Other _____________________________
6.Whatisthecurrentmarketvalueofthisproperty?
Please estimate $ _____________________
7.Whatistheageoftheheadofthehousehold?Years
8.Whatothermanufacturersdidyouconsider?
 ()Eljer()Lasco()PricePster()AquaGlass
( ) Kohler ( ) American Standard ( ) Sterling
( ) Other (Specify) _____________________
9.Howlongdidyoushopbeforepurchasingunit?
( ) 1 day ( ) 2 months- 6 months
( ) 2-7 days ( ) 6 months- 1 year
( ) 1 week- 2 weeks ( ) 1 year- 2 years
( ) 2 weeks- 4 weeks ( ) +2 years
( ) 1 month- 2 months
10.Approximately how long have you lived in this home ?
11.Please indicate, approximately, the total annual income of your household.
( ) Up to $24,999 ( ) $50,000 to $74,999
( ) $25,000 to $29,999 ( ) $75,000 to $99,999
( ) $30,000 to $39,999 ( ) $100,000 to $149,999
( ) $40,000 to $49,999 ( ) $150,000 and Above
12.Wasyourpurchaseprocess?
 ()Veryeasy()Easy()Difcult()VeryDifcult
13.HowtechnicallyawarewereyouofthepatentedJacuzzi®jetsystempriortoyourpurchase?
( ) Not aware ( ) Somewhat aware ( ) Very aware
JACUZZI LUXURY BATH
NE60000B
Ninety-Day
Parts Only
Limited Warranty
On
Accessory(ies)

Installation et utilisation www.jacuzzi.com Page 17
Signature™ Collection
Français
Signature™ Collection
INSTRUCTIONS D'INSTALLATION ET FONCTIONNEMENT
NE60000B 2/2016
Jacuzzi Luxury Bath
14525 Monte Vista Avenue
Chino, CA 91710
1-800-288-4002
www.jacuzzi.com
SIGNATURE™
COLLECTION

Page 18 www.jacuzzi.com Installation et utilisation
Signature™ Collection
Français
Signature™ Collection
Française
Contentu
NOTE Conservez ces directives pour utilisation ultérieure. Utilisez le formulaire ci-dessous pour noter
votre modèle et numéro de série pour consultation future.
Date d’achat
Acheté chez
Installé par
Numéro de série
Modèle
Installateur : laissez le manuel au propriétaire.
Propriétaire : lisez ce manuel et gardez-le pour consultation future.
Renseignements sur le produit
Installation et utilisation
Contentu........................................................................................................................................................................ 18
Renseignements sur le produit...................................................................................................................................... 18
Avertissements.............................................................................................................................................................. 19
Inspection et essai......................................................................................................................................................... 20
Cadrage et soutien. ....................................................................................................................................................... 21
Connexions électriques. ................................................................................................................................................ 22
Procédures d'installation. .............................................................................................................................................. 22
Nettoyage. ..................................................................................................................................................................... 25
Renseignements généraux sur l’utilisation ................................................................................................................... 25
Commande du massage. .............................................................................................................................................. 26
RapidHeat™.................................................................................................................................................................. 26
Nettoyage et Additifs pour le bain.................................................................................................................................. 27
Entretien. ....................................................................................................................................................................... 27
Installation des Panneaux de Jupe................................................................................................................................ 27
Procédures de dépannage. ........................................................................................................................................... 28
Service autorisé............................................................................................................................................................. 29
Garantie......................................................................................................................................................................... 30

Installation et utilisation www.jacuzzi.com Page 19
Signature™ Collection
Français
Avertissements
LIRE ET SUIVRE TOUTES LES INSTRUCTIONS. CONSERVER CES
INSTRUCTIONS.
Utiliser cet appareil uniquement pour son usage prévu, comme décrit dans ce manuel. Ne pas utiliser d'accessoires
non recommandés par le fabricant. Ne jamais laisser tomber ou insérer des objets dans les ouvertures.
Il s'agit d'un produit de qualité professionnelle. Une connaissance pratique des techniques de construction, de
plomberie et installation électrique conformément aux codes sont nécessaires pour l'installation et la satisfaction des
utilisateurs. Nous recommandons qu'un entrepreneur agréé d'effectuer l'installation de tous les produits Jacuzzi Luxury
Bath. Notre garantie ne couvre pas les problèmes à une installation incorrecte.
DANGER RISQUE DE BLESSURES ACCIDENTELLES OU LA NOYADE! Ne
laissez pas les enfants utiliser cet appareil à moins qu'ils soient surveillés en tout temps. Ne pas
utiliser une baignoire hydromassage à moins que tous les gardes d'aspiration sont installés
pour empêcher le corps et le piégeage des cheveux. Ne jamais faire fonctionner le bain
hydromassant, si le couvercle d'aspiration est brisé, endommagé ou manquant. Ne pas faire
fonctionner cet appareil sans le garde sur la consommation pour la pompe de circulation (cover
   aspiration/ltre).
DANGER RISQUE DE BLESSURES GRAVES DE CHOC ÉLECTRIQUE OU
DE MORT! D'électrocution! Cet appareil doit être connecté uniquement à un circuit
d'alimentation que est protégé par un disjoncteur différentiel 15 ampères (GFCI). Une telle fuite à
la terre doit être prévu par l'installateur et doit être testé sur une base régulière. Suivez les
instructions du fabricant Lors du test de fuite à la terre. Le disjoncteur différentiel doit couper le
courant. Appuyez sur le bouton de réinitialisation. Power devrait être restauré. Si le GFCI ne
fonctionne pas de cette manière, le disjoncteur est défectueux. Si le disjoncteur interrompt le
pouvoir de la baignoire sans le bouton de test poussé, un court circuit, indiquant une possibilité
d'un choc électrique. Ne pas utiliser cette baignoire à hydromassage. Débranchez la baignoire à
   hydromassageetleproblèmecorrigéparuntechnicienqualiéavantd'utiliser.
DANGER IMMERSION PROLONGÉE EN EAU CHAUDE PEUT PROVOQUER
HYPERTHERMIE! L'hyperthermie survient lorsque la température interne du corps
atteint un niveau de plusieurs degrés au-dessus de la température normale de 98,6 ° F (37 ° C).
L' symptômes de l'hyperthermie comprennent une augmentation de la température interne du
corps, des vertiges, léthargie, la somnolence et des évanouissements. Les effets de
l'hyperthermie comprennent:
A. Non perception de la chaleur.
B. Le défaut de reconnaître la nécessité de sortir de la baignoire.
C. La méconnaissance du danger imminent.
D. dommages au fœtus chez les femmes enceintes.
E. physique incapacité à sortir de la baignoire.
Inconscience F. entraînant un risque de noyade.
DANGER Cet équipement est prévu pour une utilisation en intérieur. Installer l'équipement en conformité
avec ces instructions. Utilisez des câbles d'approvisionnement qui sont adaptés à 167 ° F (75 °
C), y compris la température Note des conducteurs d'alimentation à utiliser. Cet appareil doit être
relié à la terre et installé par un entrepreneur agréé, électricien, plombier et. Les matériaux de
construction et le câblage doivent être acheminés loin du moteur / pompe ou un ventilateur ou
des composants autres sources de chaleur de cet appareil. Une pression connecteur du câble
est fourni à l'extérieur du moteur / pompe et radiateur pour permettre le raccordement de
une n ° 8 AWG conducteur solide liaison cuivre entre cet appareil et tous les autres équipements
électriques et parties métalliques dans les environs, comme nécessaires pour se conformer aux
exigences locales.
DANGER Risque de blessure fœtale. Les femmes enceintes ou possiblement enceintes doivent consulter
un médecin avant l'aide d'une baignoire à hydromassage équipée d'un chauffe.
Française

Page 20 www.jacuzzi.com Installation et utilisation
Signature™ Collection
Français
Signature™ Collection
Avertissements (suite)
Française
Installation et utilisation
ATTENTION  Garderlecorpsetlescheveuxunminimumde6˝(152mm)dedistanceduraccordd'aspiration
à tous les moments où le système d'hydromassage est en marche. La longueur des cheveux
plus long que l'épaule doit être assurée près de la tête.
ATTENTION Ne pas immerger le panneau de contrôle par débordement du bain.
ATTENTION Pour éviter les blessures, l'utilisation des soins lors de l'entrée et la sortie de la baignoire
hydromassage.
ATTENTION Ne pas utiliser de médicaments ou d'alcool avant ou pendant l'utilisation d'une baignoire à
hydromassage équipée avec un appareil de chauffage. Noyade peut se produire.
ATTENTION Ne pas utiliser une baignoire à hydromassage équipée d'un chauffe immédiatement après
pénibles l'exercice.
CONSERVER CES INSTRUCTIONS.
La Société a obtenu le code applicable (normes) généralement disponibles sur une base nationale pour les produits
de ce type. Il est de la responsabilité de l'installateur / propriétaire de déterminer la conformité au code local avant
l'installation du produit. La Société ne fait aucune représentation ou garantie quant à, et ne sera pas responsable de
toutrespectducode.Lesspécicationsdesproduitssontsujetsàchangementsanspréavis.
ATTENTION Utiliser cet appareil uniquement pour son usage prévu, comme décrit dans ce manuel. Ne pas
utiliser d'accessoires non recommandées par les fabricants. Ne pas jouer avec les commandes
utilisateur exploités ou telle dispositifs.
ATTENTION  Températuredel'eauau-delàde104°F(40°C)peutêtrepréjudiciableàvotresanté.Vérieret
régler la température de l'eau avant utilisation.
Inspection et essai
Toutes les baignoires sont testées en usine avant d’être expédiées pour assurer leur fonctionnement adéquat et l’étanchéité des
connexions. Cependant, l’unité doit être testée à nouveau par l’installateur avant l’installation. Jacuzzi Luxury Bath n’est pas
responsable des défauts qui auraient pu être découverts, réparés ou évités en effectuant cette inspection et procédure d'essai :
1Placez la baignoire sur une surface de niveau près d’une l’alimentation électrique appropriée, d’une alimentation
en eau et d’une évacuation d'eau. Une voie d’accès pour autos est un bon endroit.
2Scellez le trou d’évacuation et de trop-plein avec du ruban ou un bouchon et remplissez la baignoire jusqu’à la
partie inférieure du trou de trop-plein.
3Laissez la baignoire reposer pendant cinq minutes.
4 Branchezleblocpompe/moteuretmettezl’unitéenmarche.Conrmezquetouteslescaractéristiques
fonctionnent selon leur description dans la section Utilisation de ce manuel. N’installez pas la baignoire si elle ne
fonctionne pas correctement.
5Examinez tous les joints pour vous assurer qu’ils ne fuient pas. N’installez pas la baignoire si vous découvrez
des fuites.
6Remettez la baignoire dans la boîte ou protégez-la des dommages jusqu’au moment de l’installation.
1Retirez la baignoire de la boîte d’expédition. Faites attention à ne pas égratigner la surface de la baignoire sur
les agrafes exposées. Retirez les agrafes ou pliez-les sur la boîte. Conservez la boîte jusqu’à ce que vous ayez
effectué une inspection satisfaisante du produit. Ne soulevez jamais la baignoire par la plomberie; manipulez-la
par la coquille seulement.
2Examinez la coquille et les composants de la baignoire. Si l’inspection révèle des dommages ou des défauts dans
lenioudesdommagesvisiblesàl’unoul’autredescomposants,n’installezpaslabaignoire.Lesdommages
oulesdéfautsauniréclamésaprèsl’installationdelabaignoiresontexclusdelagarantie.Laresponsabilité
deJacuzziLuxuryBathquantauxdommagescausésparl’expéditionprendnaumomentdelalivraisonau
transporteur de produits en bon état.
3Communiquez avec le transporteur pour toute réclamation pour des dommages. Pour obtenir des détails sur la
couverture et les limites de la garantie, reportez-vous aux renseignements sur la garantie publiés et emballés
avecleproduitouàceuxquisetrouventàlandecemanuel.
Inspection visuelle
Essai d’eau et de fonctionnement de la
baignoire
