nova™ 536 whirlpool bath and soaking bath
nova—a brightly burning star. the nova™ whirlpool bath—a rejuvenating point of light in your day, your night, your routine.
Clean lined and classic, the Nova™
whirlpool is versatility defined.
features:
• 4 Fully adjustable TheraPro™ jets
• 2 Directionally adjustable AccuPro™ lumbar jets
• Sculpted armrest
• Contoured backrest
• Handrails
• Exclusive Tru-Level™ base system
• Slip-resistant bottom
• Patented Silent Air™ Induction system
• Electronic controls
• Drain included on whirlpool baths
nova™ 536
whirlpool bath
model number: H532 – RH, H531 – LH
exterior dimensions:
60" long x 36" wide x 19¼" high
interior dimensions (at bottom):
34½" long x 22" wide(mid) x 14" wide (end)
# of Jets/type of Jets:
4 TheraPro™ Jets
2 AccuPro™ Jets
operating gallons:
42 gallons
nova™ 536
soaking bath
model number: H533
exterior dimensions:
60" long x 36" wide x 19¼" high
interior dimensions:
34½" long x 22" wide

Nova® 536 Whirlpool Bath
Model: H531, H532
Nova® 536 Bath
Model: H533
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Electrical Components and Electrical Specifications do not apply to non-jetted baths.
Ordering Information
Product Code:
H532 Nova® 536 Whirlpool Bath
Right Hand
H531 Nova® 536 Whirlpool Bath
Left Hand
H533 Nova® 536 Bath
• Right and Left Hand Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
HTC Jet Trim Kit: #D095
BMH Jet Trim Kit: #J869
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Technical Specifications
Dimensions
60” L x 36” W x 19-1/4” H
(1524 mm) L x (914 mm) W x (489 mm) H
Drain/Overflow
A: 15-1/8” (384 mm) B: 9” (229 mm)
Cutout
58” x 34”
Total Weight
H531, H532: 683 lb (310 kg) / 46 lb/ft2(222 kg/m2)
H533: 660 lb (299 kg) / 44 lb/ft2(215 kg/m2)
Operating Gallonage
42 U.S. Gal. (159 Liters)
Product Weight
H531, H532: 83 lb (38 kg)
H533: 60 lb (27 kg)
Skirt Mounting
Not Available
Electrical Specifications Models H531, H532 only
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
Heater (Optional Models H531, H532 only)
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
NOVA™ 536, Left Hand
10" x 4"*
Motor
12" H x 18" L Service Access
Opt. Service Access
36"
60"
18"
2"
9"
4-5/8"
© Jacuzzi Whirlpool Bath • 14801 Quorum Drive • Dallas • Texas • 75254 • www.jacuzzi.com
END VIEW
H
W
SIDE VIEW
L
2"
#FR88 12/06
DRAIN/OVERFLOW
A
B
Product Shown: Nova® 536 Whirlpool Bath Left Hand Model: H531
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
