Peachtree decco 125 User manual

125
USB
OPT
PHONO
AUX
The Spotify software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses

IMPORTANT SAFETY INSTRUCTIONS
BRead these instructions – All the safety and operating instructions should be read before this
product is operated.
CKeep these instructions – The safety and operating instructions should be retained for future
reference.
DHeed all warnings – All warnings on the appliance and in the operating instructions should be
adhered to.
EFollow all instructions.
FDo not use this apparatus near water – The appliance should not be used near water or
moisture – for example, in a wet basement or near a swimming pool, and the like.
GClean only with dry cloth.
H Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
IDo not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
JDo not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two
blades with one wider than the other. A grounding plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does
not t into your outlet, consult an electrician for replacement of the obsolete outlet.
KProtect the power cord from being walked on or pinched particularly at the plugs, convenience
receptacles, and at the point where they exit from the apparatus.
L Only use attachments/accessories specied by the manufacturer.
M Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
NUnplug this apparatus during lightning storms or when unused for long periods of time.
O Refer all servicing to qualied personnel. Servicing is required when the apparatus has been
damaged in any way such as the power cord or plug is damaged. Other damage may occur
if liquid or objects have been dropped or spilled into the apparatus. Dropping the apparatus,
exposure to rain, and excessive moisture may cause additional damage.
PPlease keep the unit in a good ventilation environment.
Q CAUTION: These servicing instructions are for use by qualied service personnel only. To
reduce the risk of electric shock, do not perform any servicing other than that contained in the
operating instructions unless you are qualied to do so.
R WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and objects lled with
liquids, such as vases, shall not be placed on apparatus.
SWARNING: The mains plug/appliance coupler is used as disconnect device, the disconnect
device shall remain readily operable.
T The lightning ash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the presence of non-insulated “dangerous
voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of
electric shock.

WARNING: To reduce the risk of electric shock, do not remove cover (or back), as there are no
user-serviceable parts inside. Refer servicing to qualied personnel.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions in the literature accompanying the appliance.
U No naked ame sources, such as lighted candles, should be placed on the apparatus.
VBatteries are included for the remote control. Do not expose these batteries to direct sunlight
or excessive heat such as a re. Care should be taken in the act of battery disposal as they
include toxic materials that may harm the environment. Please refer to your local recycling
and hazardous waste center for advise with battery disposal.
WWARNING: The terminals marked with symbol of “+/-” may be of sufcient magnitude
to constitute a risk of electric shock. The external wiring connected to the terminals
requires installation by an instructed person or the use of ready-made insulated
leads or cords.
XCorrect disposal of this product. This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmentally safe recycling.
Unpacking and Warranty
BPlease keep all packing materials for any potential shipping needs.
CPlease keep a copy of the sales receipt and note the serial number on it for warranty and
insurance purposes.
DPlease register your product online at www.peachtreeaudio.com.
Marking by the “CE” symbol (shown left) indicates compliance of this device with the
EMC (Electromagnetic Compatibility) and LVD (Low Voltage Directive) standards of
the European Community.
Note: This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
The equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help

Introduction
Back Panel
Front Panel
Remote Control
Wireless Network
Spotify connect
Useful Tips
Troubleshooting
Warranty and Repair
Specications
(Rev. 6/2017)
125

INTRODUCTION
Thank you for choosing the decco125! The original decco that Peachtree Audio launched
over a decade ago was a ground-breaking product that featured a USB input and built-in
DAC to facilitate audio streaming from a computer. The whole concept of “computer audio”
was cutting-edge at the time and other brands eventually followed Peachtree Audio’s lead
and DACs built into integrated ampliers became an industry standard over time.
The new decco takes the integrated amplier concept another step further and addresses
the most critical component in a Hi-Fi system; the speaker. The amplier inside the decco
is designed to drive virtually any pair of traditional speakers, but when it is paired with
the optional duet speakers, it becomes a 3-way, fully-active, Hi-Fi system that easily
outperforms much larger and more expensive systems.
A portion of the decco rear panel is modular. As shipped from Peachtree, the rear panel
is congured to drive a pair of traditional loudspeakers. When the optional duet speakers
are added, the rear panel is replaced with a new one that congures the decco to drive
the speakers in a fully active conguration including individually amplied drivers, active
crossovers and equalization.
The new decco carries on the Peachtree tradition of form following function. The front
panel is machined out of a single piece of aluminum and designed to emulate an old car
radio with a single row of buttons and a volume knob. Simply select the desired input and
adjust the volume to easily enjoy all of your music! The chassis is wrapped in a beautiful
real-wood cabinet that has been a calling card of Peachtree Audio since the original decco
was launched over a decade ago.
The new decco is designed to handle a wide range of inputs. There is a USB input for a
computer along with an optical input for another digital audio source like a streamer or
a disc player. There are two analog inputs as well. One for a turntable (with a moving
magnet cartridge) and a second for a cassette deck or other “line-level” analog source
device. The decco also includes an optional wireless input to facilitate audio streaming
from the Internet. On the front panel, there is a headphone output capable of driving a
wide range of headphones to enjoy music without disturbing others.
Please take the time to read this manual to get familiar with the decco125 and
visit www.peachtreeaudio.com to register your purchase. We will extend the standard
warranty if you do and your information will not be shared with anyone. We will only
contact you with news that is relevant to your decco purchase! If you have additional
questions or feedback, please contact your Peachtree dealer or us directly.
Thank you again for choosing Peachtree Audio. We sincerely hope that you love your
decco and that it brings you many years of enjoyment. It represents a new standard for
value, exibility and innovation in the market. Happy listening!
- Your friends at Peachtree Audio

BACK PANEL
B C DEFGHI
AC~IN
RoHS
CAUTION
RIS K OF ELEC TRIC SHOCK
TO REDUCETHE RISK OF ELECTRIC SHOCK,
DO NOTEXPOSETHIS EQUIPMENT
TO RAIN OR MOISTURE !
DO NO T OPEN
WARNING
ANT-1 ANT-2
Gnd.
SERVICE SERVICE
ONLY
OPTICAL
INPUT
USB-B
INPUT
SPEAKER
OUTPUT
RIGHT
SPEAKER
OUTPUT
LEFT
L
L
L
R
R
R
PHONO
PREOUT
AUX
Serial NumberMADE INCHINA
DESIGNEDIN CANADA Type: IntegratedAmplifier
Model: Decco125
Maximum power consumption is 400W
125
J K L
BAC INPUT: For connection to a 100-240VAC 50/60Hz AC outlet using the included
power cord.
CANT-1 & 2: RF antenna inputs for use with wireless input equipped units. Connect both
antennas if the decco is or will be located in a spot where the wireless network signal
strength is weaker. Check this by placing a mobile device in the spot the decco is or
will be located and reading the wireless network signal strength. If all “bars” are lit, you
shouldn’t need to utilize the antennas. If fewer “bars” are lit, utilized the antennas to
ensure optimal wireless performance.
DSERVICE ONLY: This is NOT a USB audio input! Reserved for service use.
EUSB-B INPUT: Accepts digital audio input up to 24-bit/96kHz PCM from a computer.
FGROUND: Accepts the ground connection from a phonograph/turntable.
GOPTICAL INPUT: Accepts S/PDIF digital audio input from an optical (Toslink style)
output up to 96kHz. Optical digital audio outputs are common on digital audio sources
including; streaming audio devices, disc players, cable boxes and HDTVs.
HAUX ANALOG INPUT (L) (R): Accepts line level input from devices with analog outputs.
If the device also has a digital audio output, it may provide better sound quality.
IPHONO INPUT (L) (R): Accepts input from a phonograph/turntable with a moving
magnet (MM) cartridge.
JPRE-OUT: Provides analog audio output to connect to a powered subwoofer or an
external power amplier. Note: the RIGHT and LEFT speaker outputs remain active
when the PRE OUT is used and both sets of outputs are automatically muted when the
mute function is engaged or when headphones are connected to the front panel. Note:
The PRE-OUT is not available when the decco is used with the optional Peachtree
Audio duet speaker system.
KRIGHT & LEFT SPEAKER OUTPUTS: Speaker binding post outputs that accept
banana style, spade or bare wire speaker cable terminations. The binding posts are
clearly marked RIGHT and LEFT with red (+) and black (-) for proper connections with
the speakers. Please check that all of the ends of the speaker cables are connected
with the correct polarity; positive-to-positive and negative-to-negative. Wiring positive-
to-negative or negative-to-positive should not cause any damage but it does alter
the phase and therefore the sound the speakers create. Note: the RIGHT and LEFT
speaker outputs are automatically muted when the mute function is engaged or when
headphones are connected to the front panel.
L Rear Panel Hand Screws (4): Hand screws provided for the installation of the rear
panel included with the optional Peachtree Audio duet speaker system. Please do not
remove these screws unless you are installing this option.

FRONT PANEL
USB
OPT
PHONO
AUX
B C DEFGHIJ
BOn/Standby Button: With the AC power cord connected, this button toggles the unit
between On mode (which selects the last input used) and Standby mode which lights
the LED red.
CUSB Button: This button selects the USB input and lights the LED blue.
DOPT Button: This button selects the OPT input and lights the LED blue.
EPHONO Button: This button selects the PHONO input and lights the LED blue.
FAUX Button: This button selects the AUX input and lights the LED blue.
GWireless Button: This button selects the optional Wireless network input and lights the
blue LED. This button does not function if the wireless network feature is not enabled.
For more information on the wireless network input, please refer to that section.
Note: The inputs buttons will also toggle the unit into On mode when in Standby mode
for faster access.
HIR Receiver: Window for receiving Infra-Red (IR) commands from the included remote
control or third-party remote control systems.
IVolume Knob: Rotate clockwise to increase and counter-clockwise to decrease output
level. Note: the volume level will be indicated for ~2 seconds utilizing the 5 blue input
LEDS on the front panel. Each one represents ~20% of the volume range.
JHeadphone Output: 1/4” headphone output connection. Inserting a headphone
connection automatically mutes the RIGHT & LEFT Speaker outputs. Removing a
headphone connection automatically un-mutes the RIGHT & LEFT Speaker outputs.
Caution: Please lower the output level when inserting or removing headphone
connections as headphone sensitivity varies widely and a comfortable speaker listening
level may be extremely loud when switching to headphones.
Note: The front panel input LEDs are also used to display; volume level, bass level,
treble level and whenever the unit is going into the On or Standby modes. These are
temporary indicators that end after a few seconds.

REMOTE
BOn/Standby Button: With the AC power cord
connected, this button toggles the unit between
On mode (which selects the last input used) and
Standby mode which lights the LED red. Note:
the input LEDs will ash white in a sequence
when the unit goes into on or standby mode.
CBASS +/-: Increases or decreases the BASS
(low frequencies). The front panel input LEDs
will display the bass level with FLAT indicated
by the middle LED being lit Blue.
DVOL /:Increases and decreases the output
level. Note: the volume level will be indicated for
~2 seconds using the 5 blue input LEDS on the
front panel. Each LED represents ~20% of the
entire volume range.
EWireless Network: This button selects the
optional Wireless network input and lights the
LED blue. This button does not function if the
wireless network feature is not enabled. For
more information on the wireless network input,
please refer to that section.
FTransport Control Buttons: Controls playback
of compatible sources connected. selects
the previous track or the beginning of the
current track if playback is in progress. 
toggles between play mode and pause mode.
 selects the next track in the current queue
or list. Please note that some USB capable
devices and wireless streaming applications
may not support these controls. This is not a
malfunction of the remote control. If the source does not respond to these commands, it
does not support them.
GUSB Button: This button selects the USB-B input and lights the LED blue.
HOPT Button: This button selects the OPT input and lights the LED blue.
Note: The inputs buttons will also toggle the unit into On mode when in Standby mode
for faster access.
I1 2 3 4: Reserved for wireless network input use. For more information on the wireless
network input, please refer to that section.
JMUTE Button: Mutes and un-mutes the RIGHT & LEFT Speaker and headphone
outputs. Note: the currently selected input LED will ash white while the output is muted.
KTREB Button +/-: Increases or decreases the TREBle (high frequencies).
LFLAT Button: Sets the bass and treble control to “FLAT” (no increase or decrease
applied).
MPHONO Button: This button selects the PHONO input and lights the LED blue.
NAUX Button: This button selects the AUX input and lights the LED blue.
B
C
D
E
F
G
H
I
M
N
J
K
L

WIRELESS NETWORK
The decco125 offers an optional IEEE 802.11b/g/n wireless network input optimized
for audio. If equipped, this input can be selected by pressing the button on the front
panel or remote control. It can also be selected by starting an audio stream using the
MUZO Player application on a compatible phone or tablet.
To setup the mobile device, please download the MUZO Player application on your
compatible phone or tablet from the App Store (iOS devices) or Google Play (Android
devices).
To setup the decco for wireless streaming, please use one of the following methods:
Setup method 1 - Web Browser
1. Open the Wi-Fi settings on the mobile device and connect to the
decco125_xxxx network
2. Open a web browser and enter 10.10.10.254 in the address bar
3. A settings page will load. Select the desired wireless network and enter the
password (if necessary)
4. Once the decco125 is connected to the wireless network, “forget” or delete
the decco125_xxxx network from the mobile device used to set it up
5. Make sure the mobile device is put on to the same network as the decco125
Setup method 2 - WPS button on router
1. Press and hold the WPS button on the router until it enters pairing mode
2. Press and hold the wireless network input button on the decco125 for more
than 3 seconds
3. The router and the decco125 should nd each other and complete the
setup automatically
Once the decco125 is connected to the wireless network, utilize the MUZO Player
application to select and control playback. The MUZO Player application can also
control the decco125 volume and the following input selections: USB, OPT and AUX.
To setup the 1-4 direct access buttons on the decco remote control, navigate to the
station or playlist you want to add and press the small icon in the lower right hand
corner shown as a circle surrounding three dots. This will bring up a sub-menu to
select this as a “Favorite” or a “Preset”. Select “Preset” then select 1, 2, 3 or 4. This will
provide direct access for up to 4 of your favorite stations and/or playlists.
Please visit www.peachtreeaudio.com for any other tips and updates on setting up and
using the wireless input feature.
If the wireless network input stops working; Press the wireless network input button and
the On/Standby button simultaneously to reset the wireless network receiver without
unplugging the unit from AC power.

SPOTIFY CONNECT
You’ll need Spotify Premium to use Connect, see details overleaf provided separately.
1. Add your new device to the same wi network as your phone, tablet or
PC (see product user instructions for details).
2. Open the Spotify app on your phone, tablet or PC, and play any song.
3. If you’re using the app on a phone - tap the song image in the bottom
left of the screen. For tablet and PC move to step 4.
4. Tap the Connect icon
5. Pick your device from the list. If you can’t see it, just check it’s
connected to the same wi network as your phone, tablet or PC.
All done! Happy listening.
Licenses
The Spotify Software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses.
