How to use this Manual
This manual is intended for end users and has been written as a reference document
where you can skip to the relevant information.
Users can refer to the contents page to find the relevant information.
Please review each of the following sections carefully.
Thank you for selecting Peak Gas Generation to meet your gas generation needs, and
should you require any further assistance or support please do not hesitate to contact
Peak Gas Generation or the Peak Partner from which you purchased your generator.

Page 4
Introduction
The Peak Gas Generation i-Flow 6000 Generator is designed to cater for a wide variety
of industrial and scientific applications. Your generator will have been carefully selected
to meet your specific pressure, flow, and purity requirements, if you have any questions
regarding the sizing of your system please do not hesitate to contact Peak Gas
Generation or the Peak Partner from which you purchased your Generator.
Peak Gas Generation is a Trading Name of Peak Scientific Instruments Ltd. All Peak Gas
Generation products are manufactured by Peak Scientific Instruments Ltd.

Page 5
Technical Description
Basic Concept
The i-Flow is a modular range of Carbon Molecular Sieve (CMS) nitrogen gas
generators, that operate based on Pressure Swing Adsorption (PSA) technology.
Essentially this requires two separate columns or “beds” of granular carbon pellets.
The unit requires a compressed air supply to operate, ultimately works on very similar
principles to many standard air filtration / drying products. The inlet compressed air
is passed into the first “bed”, as the air passes across the carbon bed the oxygen is
adsorbed, allowing the nitrogen to carry on through the bed for collection and further
use. After a certain time the online carbon bed will become saturated with oxygen so
the control system will operate various valves to bring the second carbon bed online.
Whilst the second bed comes online, the first bed is vented to atmosphere to release
the adsorbed oxygen and regenerate the bed in preparation for the next cycle. This will
continue to alternate and repeat until the user stops consuming nitrogen.
Should the demand for nitrogen be less than the rated output flow, or indeed should
the demand stop, the generator will automatically go into ECO Mode and the front
panel LED will illuminate. In ECO mode the changeover of the columns is suspended
which will stop the consumption of inlet compressed air. The control system will
automatically detect when the demand resumes and the generator will start to produce
nitrogen again.
General Construction
The range consists of 10 dierent product sizesm, demonstrated below:
The front end cabinet, control system and valves are consistent across the range. To
increase the outlet capacity, as you go up the range of generators, additional banks of
CMS columns will be added. (Note: for 6 to 10 banks additional vent valves and silenc-
ers are required and are fitted to the rear of the CMS columns)
Base unit with
minimum single
bank of dual
CMS columns.
Base unit with
maximum 10
banks of dual
CMS columns.

Page 6
i-Flow 6000 Model Number Breakdown
01 1 Bank
02 2 Banks
03 3 Banks
04 4 Banks
05 5 Banks
06 6 Banks
07 7 Banks
08 8 Banks
09 9 Banks
10 10 Banks
0 None - Basic Unit
1 i-Flow - % Oxygen Analyser
2 i-Flow - PPM Oxygen Analyser
3 Inlet/Outlet Filter - No Oxygen Analyser
4 Inlet/Outlet Filter - % Oxygen Analyser
5 Inlet/Outlet Filter - PPM Oxygen Analyser
6 i-Flow Lab - % Oxygen Analyser
7 i-Flow Lab - PPM Oxygen Analyser
8 Currently unassigned
9 Currently unassigned
Model Numbering 6 01 2
No. of Banks Customer Option
Peak Range

Page 7
Warranties and Liabilities
Warranty & Liability Coverage
1. Peak warrants that, subject to the provisions in this statement, purchased Peak generators, whether
purchased directly from Peak or indirectly via an approved, certified and trained distributor or partner
(referred to hereafter as a “Peak Partner”) will comply in all material respects with any specifications
referred to in your customer order confirmation and, subject to installation and operational guidelines
being followed as described in applicable product manuals, shall be free from any defects in quality
of materials or workmanship for a period of one year from the date of installation, provided this takes
place within 3 months of factory dispatch.
2. Where the purchased generator is from the Precision Hydrogen series, Peak further warrants that,
subject to installation and operational guidelines being followed as described in applicable product
manuals, the hydrogen cell shall be free from any defects in quality of materials or workmanship for a
total period of three years (inclusive of warranty period specified in clause 1) from date of installation,
provided this takes place within 3 months of factory dispatch.
3. Where the purchased generator is from the i-Flow 6000 series, Peak further warrants that, subject
to installation and operational guidelines being followed as described in applicable product manuals,
the generator shall be free from any defects in quality of materials or workmanship for a total period
of two years (inclusive of warranty period specified in clause 1) from the date of installation, provided
this takes place within 3 months of factory dispatch and the following provisions have also been met:
a. you must purchase a service plan, ensuring the generator is serviced by Peak or a Peak Partner on
or before the end of the first 12 months of your ownership, and serviced at least once during each
subsequent 12 month period thereafter; b. the generator (and any associated equipment)
must have been commissioned by Peak or a Peak Partner;
c. the feed air or inlet air supply to the generator must comply with ISO 8573-1:2010 Class 1.2.1 at all
times;
d. your air compressor, dryer, filtration and oil removal systems must be deemed suitable for use
by Peak or a Peak Partner, and must be changed and serviced regularly, in line with the equipment
manufacturer’s recommended guidelines; and
e. any generator failure or fault that is deemed to have been caused by the failure of any upstream
equipment, component, part or system (such as air compressor, air treatment or filtration) will be
excluded from the warranty described herein.
4. Peak also warrants that any replacement parts whether purchased (directly from Peak, or via a Peak
Partner) or supplied as part of any remedial action undertaken in line with the provisions of clauses 12
and 13, shall be free from any defects in quality of materials or workmanship for a period of 180 days
from the date of factory dispatch, provided its installation is performed by Peak or a Peak Partner.
5. This warranty does not exclude Peak’s liability in respect of any claim for death or personal injury
to any person, in so far as such can be attributed to negligence or breach of duty of care directly
resulting from failure of Peak to comply with the provisions in clauses 1, 2, 3 & 4.
Exclusions & Limitations
6. This warranty does not cover:
a. damage, deterioration or malfunction resulting from an alteration or modification to a generator
which has not been carried out by Peak or a Peak Partner;
b. damage, deterioration or malfunction resulting from what Peak reasonably believes to be abuse, or
misuse of a generator by you or any third party;
c. liability for accident or neglect (other than pursuant to clause 5);
d. maintenance or repairs which have not been carried out by Peak or a Peak Partner;
e. operation of a generator or exposure of a generator to environmental conditions that fall out-with
operational guidelines as specified in the applicable product user manual; and
f. lightning, power surges or any other acts of God or nature.
7. This warranty is non-transferrable. Only the original owner of the generator may benefit from the
terms within this statement.

Page 8
8. Peak shall not be liable in respect of any claim made for costs, damages, losses or expenses (whether
consequential, direct, indirect or otherwise) or in any respect howsoever arising including, but not
limited to, liability from accident or negligence (other than pursuant to clause 5) that may be suered
by you or any third party.
9. No person or entity is authorised to change the terms and conditions outlined in this warranty
statement in any respect, or to create any additional obligations or liabilities for any party involved.
10. This warranty statement supersedes any and all prior warranty agreements between the parties and
constitutes the complete, final and exclusive understanding of the parties with respect to the subject
matter. All prior negotiations, representations, or promises, whether oral or written, of either party
shall be deemed to have been merged herein.
11. If any part of this warranty statement is invalidated, for whatever reason, such part will be deleted
and the rest shall remain unaected, continuing to be in full force and eect.
Delivery of Warranty Service
12. Subject to clause 13, and:
a. Peak being notified by you, within the duration of the applicable warranty period, of any defect
that you think is subject to any warranty valid under clauses 1, 2, 3 or 4; and
b. Peak being permitted to inspect the generators, parts and their installation (along with any relevant
packaging)
Peak shall at its option repair or replace defective generators or parts (including, if necessary, any
moving parts and irrespective of runtime). No additional charges will apply, for parts or delivery and,
where applicable, labour or travel. Peak will endeavour to deliver this service within 3 working days of
your notification.
13. Where, in Peak’s reasonable opinion, a defect is subject to an exclusion described in clause 6, Peak
reserves the right to charge for parts or delivery and, where applicable, you may also be charged by
Peak for call out, labour or travel in respect of any repair or replacement which you authorize Peak to
carry out.

WARNING
WARNING
WARNING
WARNING
CAUTION
Page 9
WARNING
Safety Notices
Peak Scientific Instruments cannot anticipate every possible circumstance which may
represent a potential hazard. The warnings detailed within this manual detail the most
known potential hazards, but by definition cannot be all inclusive. If the user employs
an operating procedure, item of equipment or a method of working which is not
specifically recommended by Peak Scientific, the user must ensure that the equipment
will not be damaged or become hazardous to persons or property.
Symbols
This manual uses the following symbols to highlight specific areas important to the safe
and proper use of the Generator
A WARNING notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause
personal injury or in the worst case death. Do not proceed beyond a WARNING
notice until the indicated conditions are fully understood or met.
A CAUTION notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause
damage to the Generator or the Application. Do not proceed beyond a CAUTION
notice until the indicated conditions are fully understood or met.
Caution, risk of electric shock. Ensure power to the Generator has been removed
before proceeding.
Safety Notice to Users
These instructions must be read thoroughly and understood before
installation and operation of your Peak i-Flow 6000 Generator. Use of
the Generator in a manner not specified by Peak Scientific MAY impair
the built in SAFETY features of the equipment.
When handling, operating or carrying out any maintenance, personnel
must employ safe engineering practices and observe all relevant local
health and safety requirements and regulations. The attention of UK
users is drawn to the Health and Safety at Work Act 1974, and the
Institute of Electrical Engineers regulations.
If the equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment may be impaired.
Nitrogen is not a poisonous gas, but if its concentration in breathed
air becomes too high, there will be a risk of asphyxiation. Ensure that
adequate ventilation is provided for the surrounding area, (depending
on the operating specification and model selected the generator can
produce up to a maximum nitrogen flow of 4,250 L/min)

No. 4 EU PED DOC
EU Declaration of Conformity
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Hereby declare that, this declaration of conformity is issued under the sole
responsibility of the manufacturer.
Equipment: Pressure Swing Adsorption Gas Generator
Models: i-Flow 6000 Series & i-Flow O2 8000 Series
PED Module B Certificate No : CE 608102
PED Module D Certificate No : CE 608103
Pressure assembly consisting of the following key parts :
Piping Spec or Description Fluid Phase PED Hazard Cat. Quality Module
Fluid Chart Cat
08-0700 CMS Assemblies
08-0700 CMS Assemblies
(1 to 10 Model Dependant)
(1 to 10 Model Dependant)
Air/N
Air/N
2
2
Gas
Gas
2G
2G
2
2
II
II
B+D
B+D
3303560 Sieve Assemblies
3303560 Sieve Assemblies
(1 to 6 model dependent)
(1 to 6 model dependent)
Air/0
Air/0
2
2
Gas
Gas
1G
1G
1
1
II
II
B+D
B+D
Output Pressure Relief Valve
Output Pressure Relief Valve
Air/N
Air/N
2
2
/O
/O
2
2
Gas
Gas
2G/1G
2G/1G
2/1
2/1
IV
IV
B+D
B+D
Front End Control Cabinet inc. associated valves & piping
Front End Control Cabinet inc. associated valves & piping
Air/N
Air/N
2
2
/O
/O
2
2
Gas
Gas
2G/1G
2G/1G
2/1
2/1
SEP
SEP
Not Applicable
Not Applicable
To which this declaration relates, is in conformity with the following applicable EU
Directives, harmonized standards, and other normative requirements.
• Low Voltage Directive 2014/35/EU
EN 61010-1: 2010 Safety Requirements for Electrical Equipment for Measurement,
Control and Laboratory Use.
• Electromagnetic Compatibility Directive 2014/30/EU
EN 61326-1: 2013 Electrical Equipment for Measurement, Control and Laboratory Use
– EMC Requirements. (Class A)
• Restriction on the use of certain hazardous substances in electronic equipment
(RoHS) Directive 2011/65/EU as amended by EU 2015/863.
• FCC 47 CFR Part 15 class A
Unintentional radiators; Conducted and Radiated emissions limits.
Name and address of Notified body conducting
the PED conformity assessment :
BSI Group The Netherlands B.V.
Say Building, John M Keynesplein 9,
1066 EP , Amsterdam,
Netherlands
EC Number - 2797
Signed for and on behalf of Peak Scientific by
Signed:
Name: Fraser Dunn
Position: Design Engineering Manager
Peak Scientific Instruments ltd,
Inchinnan, Renfrew, Scotland,
PA4 9RE, UK.
Date: 10th August 2021

No. 5 UK PED DOC
UK Declaration of Conformity
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Hereby declare that, this declaration of conformity is issued under the sole
responsibility of the manufacturer.
Equipment: Pressure Swing Adsorption Gas Generator
Models: i-Flow 6000 Series & i-Flow O2 8000 Series
PED Module B Certificate No : UKCA 753392
PED Module D Certificate No : UKCA 753395
Pressure assembly consisting of the following key parts :
Piping Spec or Description Fluid Phase PED Hazard Cat. Quality Module
Fluid Chart Cat
08-0700 CMS Assemblies08-0700 CMS Assemblies
(1 to 10 Model Dependant)(1 to 10 Model Dependant) Air/NAir/N22GasGas 2G2G 22IIII B+DB+D
3303560 Sieve Assemblies3303560 Sieve Assemblies
(1 to 6 model dependent)(1 to 6 model dependent) Air/0Air/022GasGas 1G1G 11IIII B+DB+D
Output Pressure Relief ValveOutput Pressure Relief Valve Air/NAir/N22/O/O22GasGas 2G/1G2G/1G 2/12/1 IVIV B+DB+D
Front End Control Cabinet inc. associated valves & pipingFront End Control Cabinet inc. associated valves & piping Air/NAir/N22/O/O22GasGas 2G/1G2G/1G 2/12/1 SEPSEP Not ApplicableNot Applicable
To which this declaration relates, is in conformity with the following applicable EU
Directives, harmonized standards, and other normative requirements.
• Low Voltage Directive 2014/35/EU
EN 61010-1: 2010 Safety Requirements for Electrical Equipment for Measurement,
Control and Laboratory Use.
• Electromagnetic Compatibility Directive 2014/30/EU
EN 61326-1: 2013 Electrical Equipment for Measurement, Control and Laboratory Use
– EMC Requirements. (Class A)
• Restriction on the use of certain hazardous substances in electronic equipment
(RoHS) Directive 2011/65/EU as amended by EU 2015/863.
• FCC 47 CFR Part 15 class A
Unintentional radiators; Conducted and Radiated emissions limits.
Name and address of Notified body conducting
the PED conformity assessment :
BSI Group The Netherlands B.V.
Say Building, John M Keynesplein 9,
1066 EP , Amsterdam,
Netherlands
EC Number - 2797
Signed for and on behalf of Peak Scientific by
Signed:
Name: Fraser Dunn
Position: Design Engineering Manager
Peak Scientific Instruments ltd,
Inchinnan, Renfrew, Scotland,
PA4 9RE, UK.
Date: 10th August 2021
Unit is currently under accreditation.

No. 6 EU PED DOC
WEEE Compliance Statement
The Waste Electrical and Electronic Equipment (WEEE) Regulations SI 2013 No 3113
and or the Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU
apply to all electrical and electronic equipment placed on the market in the UK and EU
covered by the scope of regulations which can be found in the Government Guidance
Notes (PDF) produced by the Department for Business Innovation and skills for the UK
and here for Europe.
All PEAK products that are subject to the WEEE directive are compliant with the
WEEE marking requirement. Such products are marked with the “crossed-out wheelie
bin” symbol (shown below) in accordance with European standard EN50419. All
old electrical equipment can be recycled. Please do not dispose of any electrical
equipment (including those marked with this symbol) in general rubbish bins. Please
contact your dealer or distributor for clarity.

Page 13
Technical Specification
Environment
Minimum Operating Ambient Temperature +5°C (41°F)
Maximum Operating Ambient Temperature +50°C (122°F)
Maximum Altitude 2000m
Maximum Relative Humidity 80% non-condensing
When taken out of storage, the Generator should be allowed to acclimatize at room
temperature for a minimum of 3 hours before operation.
Compressed Air Supply
Depending on your specific application, the pressure and flow required from the
compressed air supply to the generator will vary. For your specific requirements
please refer to your quotation documents, or contact Peak Gas Generation for further
information. However all installations must meet the following conditions:
Minimum Air Quality IS0 8573-1:2010 class 1.4.1 or 1.2.1†
Minimum Inlet Air Pressure 87 psig (6barg)
Maximum Inlet Air Pressure 145 psig (10barg)
Minimum Inlet Air Temperature +5°C (41°F)
Maximum Inlet Air Temperature +35°C (95°F)
If you are in any doubt over the quality of your inlet compressed air DO
NOT CONNECT to the generator, and contact Peak Gas Generation or
the Peak Partner from which you purchased your Generator. Peak Gas
Generation can oer a full range of compressors and air preparation
equipment if required, which can be backed up by our global service
support network.
It is the User / Installer’s responsibility to ensure the generator is connected to a
suitably rated air supply, the air supply must also provide suitable protection to prevent
over pressurization of the Nitrogen Gas Generator.
Electrical Requirements
Voltage 100 - 240 VAC ±10%
Frequency 50/60 Hz
Current 2.0 – 1.0 A
Input connection C20 Plug
Power cord (Supplied) C19 socket to local connection
Pollution degree 2
Installation category Class I Protection
Transient Overvoltage Category II
WARNING

Page 14
General
Model 601* 602* 603* 604* 605*
Width mm(in) 500 (19.68)
Height mm(in) 1738 (68.42)
Depth mm(in) 760(29.92) 920(36.22) 1080(42.52) 1240(48.82) 1400(55.12)
Weight kg(lbs) 197(433) 282(620) 367(807) 452(994) 537(1181)
Shipping weight kg(lbs) 277(609) 364(801) 451(992) 538(1184) 625(1375)
Noise level 59 dBA @ 1m
Model 606* 607* 608* 609* 610*
Width mm(in) 500 (19.68)
Height mm(in) 1738 (68.42)
Depth mm(in) 1560(61.42) 1720(67.72) 1880(74.02) 2040(80.31) 2200(86.61)
Weight kg(lbs) 622(1368) 707(1555) 792(1742) 877(1929) 962(2116)
Shipping weight kg(lbs) 712(1566) 799(1758) 886(1949) 973(2141) 1060(2332)
Noise level 59 dBA @ 1m
† (NOTE: Selection is application dependent – please confirm suitability via your local technical specialist).

Page 15
Unpacking
Although Peak Gas Generation takes every precaution with safe transit and packaging,
it is advisable to fully inspect the unit for any sign of transit damage.
Check ‘SHOCKWATCH’ and ‘TIP-N-TELL’ labels for signs of rough handling prior to
unpacking.
Any damage should be reported immediately to the carrier and Peak Gas Generation
or the Peak Partner from where the unit was purchased.
Page 15

Page 16
Installation
It is the user/installer’s responsibility to ensure that the generator
is located and protected against any external influences such as
vibration, shock, wind, snow loading, earthquake or fire. The installation
should conform to all local regulations and should be leak tight and
completed by technically competent personnel.
Final Location of the generator should be carefully considered, the largest model in the
range will weigh 1060 kg / 2332 lbs. Equipment is only to be installed on floor with a
weight rating of min 1000kg/m2 or 200 lbs per Sq.ft.
Once in position the foot plate of the generator should be secured to the floor with
fixings suitable to the materials of construction of the floor. 13mm diameter holes
are provided adjacent to the levelling bolts to allow the unit to be fixed to the floor.
Depending on the generator model you will have 4 or 8 fixing positions. Typically 10mm
or 3/8” floor fixings approx. 75mm or 3” in length will be suitable on most concrete
floors.
Generator Environment
The Generator is designed for indoor use only. It should be installed
adjacent to the application it is supplying. If this is not convenient
then the unit can be sited elsewhere, however, consideration should
be made of the lengths of pipe runs as pressure drops can result from
extended runs of pipe.
Consideration should be given to the location of the generator
to ensure it is protected from extreme fluctuations in ambient
temperature. Ensure that adequate ventilation is provided for the
surrounding area, (depending on the operating specification and
model selected the generator can produce up to a maximum flow
of 4,250 L/min). Installation in a confined space or poorly ventilated
space is not recommended, however if you choose to do so ambient
oxygen monitoring equipment is recommended.
WARNING
WARNING
CAUTION

Page 17
Generator
General Dimensions
Note: Each additional bank assembly = 160mm / 6.3”
The Generator must always be placed on a level surface. Failure to do so
will aect the stability of the Generator.
2200 mm / 86.6”
1738mm / 68.4”
WARNING
760 mm / 29.9”500 mm / 19.7”

Page 18
Inlet / Outlet Connections
All of the Generator output ports are located on the output panel on the Left hand side
of the Generator. See below for recommended piping layout.
Unit Controls
Power Inlet
Nitrogen Output
¾” BSP
Air Inlet 1” BSP
Tank Supply
¾” BSP
Tank Return
¾” BSP
Pressure Gauge
Pressure Gauge
Control Screen
Pressure Gauge
Pressure Gauge
Power Switch
Eco mode LED
Service LED

Page 19
Compressed Air Quality
The i-Flow 6000 Generator is an air purification system, it does not generate any
gas pressure. Gas pressure is created and supplied to the generator by the user’s
compressed air system. It is the user / installer’s responsibility to ensure that all
components connected to the gas generator comply with local health and safety
regulations and that the compressed air system is suitably protected from over
pressure, including appropriately sized safety relief devices for both the compressed air
and nitrogen process tanks.
No pressure greater than 10 barg should be applied to the inlet of the
iFlow product.
The i-Flow 6000 Generator will typically be the last stage in a complete air
compression and filtration system, the inlet air quality must meet a minimum of IS0
8573-1:2010 class 1.2.1. Class 1.2.1. is further defined as:
Class 1 – Particulate
Per cubic meter of air the particulate count should not exceed 20,000 particles in the
0.1 to 0.5 micron range, 400 particles in the 0.5 to 1 micron range and 10 particles in the
1 to 5 micron range.
Class 2 – Water
A minimum pressure dewpoint (PDP) of -40°degC (-40°degF) is required, no liquid
water is permitted.
Class 1 – Oil
Per cubic meter of air the maximum permissible oil content is 0.01mg, total level for
liquid, aerosol and vapor.
A typical installation will consist of the following items:
• Oil Lubricated Screw – Air Compressor
• Compressed Air Storage Tank (with automatic condensate drain)
• Water Separator
• Pre-filter
• Active Carbon Filter
• Line Air Regulator
• Desiccant Air Dryer
• Dust Filter
• Active Carbon Tower
• Dust Filter
• i-Flow 6000 Series Nitrogen Generator
• Nitrogen Process Gas Tank
WARNING

Page 20
Sizing of all components in this line will have a critical eect on the performance of
the Nitrogen Gas Generator, in particular the Nitrogen process Gas Tank. Please refer
to your quotation documents for details of the items we have recommended to meet
your specific requirements. Should you require any further assistance or support
please do not hesitate to contact Peak Gas Generation or the Peak Partner from which
you purchased your Generator. A full installation and commissioning service can be
provided through the Peak Global Service network.
