Peavey TLS 2X User manual

FFrreeqquueennccyy rraannggee ((--1100 ddBB,, hhaallff ssppaaccee))::
51 Hz to 21 Hz
FFrreeqquueennccyy rreessppoonnssee ((±± 33 ddBB,, hhaallff
ssppaaccee))::
69 Hz to 17 Hz
SSeennssiittiivviittyy ((11ww//11mm))::
98 dB
PPoowweerr rraattiinngg ((pprrooggrraamm))::
500 Watts
PPeeaa ppoowweerr ccaappaacciittyy ((ppeeaa))::
1000 Watts
MMaaxxiimmuumm SSPPLL::
127 dB
TTrraannssdduucceerr ccoommpplleemmeenntt::
Sheffield®Pro 1200+™12" premium
woofer; 14XT™1.4" titanium
diaphragm dynamic compression
driver on a 90˚ x 40˚ coverage
constant directivity horn
DDrriivveerr pprrootteeccttiioonn::
Sound Guard™IV for the
compression driver provides long-
and medium-term overload and
overdrive protection
NNoommiinnaall ccoovveerraaggee ppaatttteerrnn::
90˚ x 40˚
EElleeccttrroo--aaccoouussttiicc ccrroossssoovveerr ffrreeqquueennccyy::
2.9 Hz
NNoommiinnaall iimmppeeddaannccee::
8 Ohms
IInnppuutt ccoonnnneeccttiioonnss::
Two 1/4" phone jac s in parallel
EEnncclloossuurree mmaatteerriiaallss && ffiinniisshh::
Trapezoidal blac carpet-covered
enclosure with dado joined 1/2"
MDF (Medium Density Fiberboard),
and a full-length blac powder-
coated steel grille
DDiimmeennssiioonnss ((HH xx WW xx DD))::
FFrroonntt::
25.25" x 17.5" x 13.375"
64.135 cm x 44.45 cm x 33.97 cm
RReeaarr::
25.25" x 13.25" x 13.375"
64.135 cm x 33.655 cm x 33.97 cm
WWeeiigghhtt::
45 lbs. (20.45 g)
MMoouunnttiinngg oorr ssuussppeennssiioonn::
Die-cast aluminum 1-3/8" pole-
mount cup for stand mounting
OOppttiioonnaall ssyysstteemm uuppggrraaddeess::
TLS™115X add-on subwoofer
BBuulllleettss::
• Two-way sound reinforcement
enclosure
• Peavey exclusive Sheffield Pro
1200+ woofer with 2.5" voice coil
• 14XT titanium diaphragm
compression driver with 1.4"
diaphragm
• Sound Guard IV tweeter
protection
• 500 Watts program/1000 Watts
pea power handling
• Heavy duty crossover networ for
driver protection and EQ
• Lightweight trapezoidal
enclosure
• 90˚ x 40˚ coverage constant
directivity horn for better off-axis
tonality
• High quality, heavy duty carpet
covering
• Steel handles
• Steel corners
• Rugged dado and rabbet
construction for light weight-yet-
strong joints
• T-Nut spea er mounting
• Heavy duty full-length steel grille
• SA-1 die-cast aluminum pole
mount
DDeessccrriippttiioonn
The TLS™2X is a two-way
spea er system based on a 12"
Sheffield Pro 1200+ woofer and a
14XT titanium diaphragm dynamic
compression driver, mounted on a 90
x 40˚ coverage constant directivity
horn. The lightweight-yet-rugged,
carpet-covered trapezoidal enclosure
with stand-mount cup facilitates
portable use for live music or speech
sound reinforcement, as well as
music playbac . A full-length, blac
powder-coated steel grille provides
driver protection and a professional
appearance.
The TLS 2X spea er system is
rated at 500 Watts program power,
and the full crossover networ
includes high voltage film capacitors
and Sound Guard IV tweeter
protection for clear, punchy sound
and long-term reliability. Two 1/4"
phone jac input connectors ma e
hoo -up a breeze.
Broaden your sound
reinforcement experience by utilizing
the TLS™115X subwoofer with the TLS
2X spea er system.
SSPPEECCIIFFIICCAATTIIOONNSS TTLLSS™™22XX

Features and specifications subject to change without notice.
Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 [phone] • FAX [phone] • www.peavey.com
©2003 Printed in the U.S.A. 2/03
80305048
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
60
70
80
90
100
110
dB SPL (re 20 Pa)
Amplitude Response (1W 1m On-Axis)
Figure 1
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
30
40
60
80
100
140
180
300
360
Beamwidth (Degrees)
Beamwidth
Vertical
Horizontal
Figure 2
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
1
10
100 Q & Directivity Index
Q
Figure 3
20
10
Di
0
SSPPEECCIIFFIICCAATTIIOONNSS TTLLSS™™22XX
33 ++ 22 YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY
NNOOTTEE:: For details, refer to the warranty statement. Copies of this statement may be obtained by
contacting Peavey Electronics Corporation, P.O. Box 2898, Meridian, Mississippi 39301-2898.
