PedalPCB Arkaim Fuzz User manual
Copyright © 2019 - PedalPCB.com 1
Revision 04.14.19
Arkaim Fuzz
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in
this web site are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.
Controls
• Output
• More
• Input
• Slope
• Notch
• Shift(toggleswitch)
• Bypass(footswitch)
• Heavy(footswitch)
Copyright © 2019 - PedalPCB.com 2
RESISTORS(1/4W)
R1 4K7
R2 100K
R3 10K
R4 47K
R5 47K
R6 51K
R7 33K
R8 330K
R9 51K
R10 4M7
R11 51K
R12 1M
R100 4K7
R101 4K7
Arkaim Fuzz
Parts List
Common ooard components (enclosure, footswitch, jacks, etc) are not listed
CAPACITORS
C1 10u
C2 22n
C3 47u
C4 47u
C5 47u
C6 4n7
C7 12n
C8 10n
C9 22n
C10 1n
C11 470n
C12 47u
C13 47u
C100 100u
SWITCHES
SHIFT On/OFF/On DPDT Toggle
BYPASS Latching 3PDT Footswitch
HEAVY Latching 3PDT Footswitch
TRANSISTORS
Q1 BC338
Q2 2N5088
Q3 BC338
DIODES
D1 Orange 3mm LED
D100 1N5817
LED1 Indicator LED
LED2 Indicator LED
POTENTIOMETERS
INPUT C1M
MORE B5K
NOTCH A50K
OUTPUT B100K
SLOPE B100K
Copyright © 2019 - PedalPCB.com 3
Arkaim Fuzz
Copyright © 2019 - PedalPCB.com 4
Arkaim Fuzz
Wiring Diagram
Copyright © 2019 - PedalPCB.com 5
Arkaim Fuzz
Drill Template
1590BB enclosure with top mounted jacks
D
C
J
A
C
K
O
U
T
P
U
T
J
A
C
K
I
N
P
U
T
J
A
C
K
F
O
O
T
S
W
I
T
C
H
L
E
D
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
L
E
D
F
O
O
T
S
W
I
T
C
H
