User-friendly
Manual
User Manual
Manual
del usuario
English........06
Español ...... 23
CROSS CUT PAPER
SHREDDER
DESTRUCTORA DE DOCUMENTOS
DE CORTE CRUZADO

Dok./Rev.-Nr. 195389_20170830_US
Contents
Overview .............................................................................3
Use........................................................................................4
Package contents/device parts..........................................6
General information............................................................7
Reading and storing the user manual ..................................7
Explanation of symbols ...........................................................7
Safety...................................................................................8
Proper use................................................................................. 8
Safety instructions................................................................... 9
Checking the paper shredder and package contents..... 14
Assembly ........................................................................... 14
Set-up ................................................................................ 15
Shredding.......................................................................... 15
Paper......................................................................................... 17
CDs............................................................................................. 17
Credit cards.............................................................................. 17
Emptying the waste bins ...................................................17
Paper, CD or credit card jam.............................................. 18
When not in use................................................................. 18
Cleaning and maintenance............................................... 19
Storage ..............................................................................20
Troubleshooting................................................................20
Technical data ....................................................................21
Disposal.............................................................................. 22
Disposing of the packaging ..................................................22
Disposing of old appliances ..................................................22

3
A
1 2 3 5 6
7
4
8
9
10
11
12 13

4
B C 6
10
9
13
D E
12
11
12

5
G
I
F
H
12

6
Package contents⁄device parts
1Power cord
2CD feed slot
3CD detection sensor (built-in)
4Paper / credit card feed slot
5Paper / credit card detection sensor (built-in)
6Main unit
7Safety switch (built-in)
8Slide switch (AUTO/OFF / REV)
9Castor, 2×
10 Castor with locking lever, 2×
11 CD waste bin
12 Paper / credit card waste bin
13 Base unit

General information
7
General information
Reading and storing the user manual
This user manual accompanies this cross cut paper shredder
(hereafter referred to as “paper shredder”), and contains
important information on setup and handling.
Before using the paper shredder, read the user manual carefully.
This particularly applies to the safety notes. Failure to do so may result in
personal injury or damage to the paper shredder.
Store the user manual for further use. Make sure to include this user manual
when passing the paper shredder on to third parties.
Explanation of symbols
The following symbols and signal words are used in this user manual, on the
paper shredder or on the packaging.
WARNING! This signal symbol/word designates a hazard
with moderate risk, which may result in
death or severe injury if not avoided.
CAUTION! This signal symbol/word designates a hazard
with low risk, which may result in minor or
moderate injury if not avoided.
NOTICE! This signal word warns of possible damage
to property.
This symbol provides you with useful additional information on
handling and use.
Important safety information.
Read the instruction manual carefully before using the paper
shredder for the first time and keep it for later reference.
Keep children away from the paper shredder. Do not allow
children to use the paper shredder.
Never insert your fingers into the feed slot.

Safety
8
Keep long hair, loose clothing, jewellery, etc. away
from the feed slot.
Do not spray oil or other lubricants into the feed slot. Do not use
any spray cans / aerosols in the vicinity of the device!
Do not insert any paper clips or staples in the feed slot!
Do not feed more than 10 sheets of paper simultaneously into
the feed slot.
Feed slot for CDs / DVDs / Blu-rays. Only insert one CD/ DVD /
Blu-ray into the feed slot at a time.
Feed slot for paper
Feed slot for credit cards. Only insert one credit card into the
feed slot at a time.
The symbol indicates that the product is of CLASS II (double
insulated) construction. It does not require a safety connection
to electrical earth (ground).
Only use the paper shredder in indoor areas.
If a product carries this mark, it means UL found that
representative product samples met UL’s safety requirements.
Safety
Proper use
The paper shredder is exclusively designed for shredding paper, CDs and
credit cards. It is only intended for private use and not suitable for commercial
purposes.
Only use the paper shredder as described in this user manual. Any other use is
considered improper and may result in damage to property.
The manufacturer or vendor cannot be held liable for damages incurred
through improper or incorrect use.

Safety
9
Safety instructions
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed including the following. Read all
instructions.
WARNING!
Risk of electric shock!
A faulty electrical installation, excessive line voltage or incorrect
operation may result in an electric shock.
− Connect the paper shredder only to an alternating current
(AC) power supply (120 V~). Make sure that the voltage
corresponds with the voltage details on the device.
− Only connect the paper shredder to an easily accessible
outlet near the equipment so that you can quickly
disconnect it from the grid in case of a failure.
− Do not operate the paper shredder if it exhibits visible
damages or if the power cord or plug is defective.
− If the power cord of the paper shredder is damaged, the
manufacturer, its customer service team or a person with
similar qualifications must replace it.
− Do not open the housing; instead, have a qualified
professional perform repairs. Contact a qualified workshop
for this. Liability and warranty claims are waived in
the event of repairs performed by the user, improper
connection or incorrect operation.
− Only parts that comply with the original device data
may be used for repairs. This device contains electrical
and mechanical parts which are essential for providing
protection against sources of danger.
− The paper shredder must not be operated with an
external timer or separate remote control system.

Safety
10
− Do not immerse the paper shredder or power cord in
water or other liquids.
− Never touch the power plug with wet or damp hands.
− Do not use the paper shredder if you are standing on a
wet floor, or if your hands or the paper shredder are/ is
wet.
− Do not pull the power plug out of the outlet by the cord;
instead, always pull it out by the plug itself.
− Never move, pull, or carry the paper shredder by its power
cord.
− Keep the paper shredder and power cord away from open
flames and hot surfaces.
− Lay the power cord so that it does not pose a tripping
hazard.
− Do not kink the power cord and do not lay it over sharp
edges.
− Do not bend the power cable and do not wrap it around
the paper shredder, as this may lead to a broken cable.
− Only use the paper shredder indoors. Do not use the
paper shredder in damp rooms or in the rain.
− Never store the paper shredder such that there is a risk of
it falling into a tub or sink.
− Never reach to retrieve an electrical device if it has fallen
into water. In such a case, immediately disconnect the
power plug.
− Never insert any objects into the housing.
− Always switch the paper shredder off and pull the power
plug out of the outlet
• when you are not using the paper shredder,
• before you clean the paper shredder,
• if a fault occurs,
• in the event of a storm.

Safety
11
− Do not modify the plug in any way. The paper shredder
has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug will fit in a
polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician.
WARNING!
The paper shredder and its power cord must be kept
away from children. Danger for persons with impaired
physical, sensory or mental capacities (e.g. partially
disabled persons, older persons with reduced physical
and mental capacities) or lack of experience and
knowledge.
− If they are supervised or have been instructed in how to
safely use the paper shredder and have understood the
risks associated with operating it, this paper shredder
may be used by persons with impaired physical, sensory
or mental capacities or those lacking experience and
knowledge.
− Make sure children do not play with the paper shredder. It
is not a children’s toy.
− Do not allow children to use the paper shredder. Keep
children away from the paper shredder and power cord.
− Do not leave the paper shredder unattended while in
operation.
− Make sure that children do not play with the plastic
wrapping. They may get caught in it when playing and
suffocate.

Safety
12
WARNING!
Risk of injury!
Handling the paper shredder improperly may result in injury.
− Do not reach into the feed slots with your hands.
− Keep long hair away from the feed slots.
− Keep ties, scarves, loose clothing, and long necklaces or
bracelets well away from the feed slots.
− Keep the feed slots away from aerosols.
− Only hold the CD by the outer edge when inserting into
the feed slot. Make sure that your finger is not in the CD
hole; this can cause injury when the CD is drawn in.
− Set up the paper shredder in the vicinity of a properly
installed outlet. The outlet must be freely accessible.
− Remove regularly any shredded paper, credit card and
CD residue from the underside of the cutting unit using a
suitable tool (e.g. a brush).
− Always switch the paper shredder off and unplug the
power plug before emptying the waste bins.
− After pulling out the waste bins, sharp and pointed parts
of the cutting unit become touchable. Operate carefully.
− Lay the power cord so that it does not pose a tripping
hazard.
− Only use the paper shredder when it is fully and correctly
assembled.
− Never disassemble the paper shredder for cleaning or
storage.

Safety
13
NOTICE!
Risk of damage!
Improper handling of the paper shredder may result in damage
to the paper shredder.
− Do not operate the paper shredder for longer than
3minutes without interruption. Allow it to cool down to
room temperature first before restarting operation.
− Do not drop paper clips or staples into the feed slots.
− Both cutting units will rotate when one is activated by the
respective detection sensor. Make sure that there are no
objects close to the feed slot which is not in use.
− Do not compress the shredded paper in the waste bin with
your hands or feet. The pressure could damage the waste
bin.
− Only insert paper or credit cards, but not other items into
the paper/credit card feed slot.
− Only insert CDs, but not other items into the CD feed slot.
− Do not insert more than one CD or more than one credit
card into the feed slot at the same time. The cutting unit
could be irreparably damaged.
− Empty the waste bins at regular intervals. If it overfills
there is danger that shredded paper, credit card and
CD residue will be drawn up from underneath into the
respective shredding system.
SAVE THESE INSTRUCTIONS
Keep the user manual for future reference.

Checking the paper shredder and package contents
14
Checking the paper shredder and package
contents
NOTICE!
Risk of damage!
If you are not cautious when opening the packaging with a sharp
knife or other pointed objects, you may easily damage the paper
shredder.
− For this reason, be very careful when opening the
packaging.
1. Take the paper shredder out of the packaging.
2. Check to make sure that all contents have been received (see fig. A).
3. Check whether the paper shredder or individual parts exhibit damages. If
this is the case, do not use the paper shredder. Contact the manufacturer
using the service address specified on the warranty card.
Assembly
CAUTION!
Risk of injury!
Improper handling of the paper shredder may cause injury.
− Do not connect the paper shredder to an outlet during
assembly.
− The main unit of the paper shredder contains sharp
edges. Be very careful when assembling the paper
shredder.
1. Place the base unit 13 upside down so that the bottom side is facing
upwards.
2. Install the castors 9at the right side and the castors with locking levers 10
at the left side of the base unit. Push the castors downwards into the holes
on the base unit until they lock into place (see fig. B).
3. Turn the base unit over after the installation of the castors.

Set-up
15
4. Install the main unit 6on top of the base unit. Firmly push the main unit
downwards until it locks into place (see fig. C).
A loud click sound can be heard on each side when the main unit has been
securely installed.
Please note that you may need to exert more effort to install the
main unit.
5. Install the CD waste bin 11 in the paper/credit card waste bin 12
(see fig. D).
6. Slide the paper/ credit card waste bin into the base unit (see fig. E).
You must fully slide the paper/credit card waste bin into the base unit until
a click sound is heard. This indicates that the safety switch 7has been
deactivated for normal operation.
The paper shredder is now assembled. Please note that the base unit
should not be disassembled.
Set-up
1. Make sure that the paper shredder is switched off (slide switch 8at the
OFFposition) before plugging it into an outlet.
2. Connect the power cord 1to an outlet.
3. Set the slide switch to the AUTO position.
The paper shredder is now ready for use.
Shredding
WARNING!
Risk of injury!
Handling the paper shredder improperly may result in injury.
− Hold the paper by both sides when inserting into the feed
slot. Make sure that your fingers do not get too close to the
feed slot.
− Only hold the CD by the outer edge when inserting into
the feed slot. Make sure that your finger is not in the CD
hole, this can cause injury when the CD is drawn in.
− Hold the credit card by its narrow side when inserting into
the feed slot. Make sure that your fingers do not get too
close to the feed slot.

Shredding
16
NOTICE!
Risk of damage!
Improper handling of the paper shredder may result in damage
to the paper shredder.
− Do not operate the paper shredder for longer than
3minutes without interruption. Allow it to cool down to
room temperature first before restarting operation.
− Do not feed damp paper into the feed slot. It could wrap
around the cutting unit and cause a blockage.
− Do not feed paper with paper clips. This could damage the
cutting unit.
− Do not feed more than 10 sheets of paper simultaneously
into the feed slot. This could damage the cutting unit.
• The paper shredder is equipped with a safety switch 7
which stops the operation of the paper shredder when
it is activated. The safety switch is activated when the
paper/ credit card waste bin 12 is not fully inserted into the
base unit 13 . You will hear a click sound when the safety
switch is activated or deactivated.
• The paper shredder is equipped with a paper / credit card
detection sensor 5and a CD detection sensor 3. The
paper shredder switches on automatically only when you
insert paper or credit cards at the centre of the paper/ credit
card feed slot 4. The same applies when you insert the CD
at the centre of the CD feed slot 2.
The paper, credit card or CD is drawn in automatically after
activating the respective detection sensor.
If you feed in paper that is too thin (e.g. airmail, carbon copy
or tracing paper), the paper / credit card detection sensor
may not be activated. This is normal and not a defect. In this
case, do not feed in single sheets, but multiple sheets. Also
note that excessively thin paper is difficult to feed and can
thus more easily jam in the cutting unit.

Emptying the waste bins
17
• The paper shredder will automatically switch off in case of
overload to prevent damage to the motor. Disconnect the
paper shredder from the power supply and let it cool down to
room temperature before putting it back to use.
• Engage the levers on the castors with locking levers 10 to
prevent the paper shredder from rolling during use.
Paper
− Feed the paper to be shredded centrally into the paper/ credit card feed
slot 4(see fig. F).
The paper shredder automatically switches on and draws in the paper.
Approx. 1–2 seconds after processing the paper, the paper shredder will
automatically stop.
CDs
− Push the CD to be shredded centrally into the CD feed slot 2(see fig. G).
The paper shredder switches on automatically and draws in the CD.
Approx. 1–2 seconds after processing the CD, the paper shredder will
automatically stop.
Credit cards
1. Hold the credit card upright.
2. Slide the credit card centrally into the paper / credit card feed slot 4
(see fig. H).
The paper shredder switches on automatically and draws in the credit card.
Approx. 1–2 seconds after processing the credit card, the paper shredder
will automatically stop.
Emptying the waste bins
WARNING!
Risk of injury!
Handling the paper shredder improperly may result in injury.
− Do not touch the cutting unit with your fingers.
For proper waste disposal, shred credit cards only when there
is no processed paper, and shred paper only when there are no
processed credit cards in the paper / credit card waste bin.

Paper, CD or credit card jam
18
Empty the waste bins regularly to avoid paper, credit card, or CD residues being
drawn into the cutting unit from underneath.
1. Switch off the paper shredder (slide switch 8at the OFFposition) and
disconnect the power cord 1.
2. Pull the paper/ credit card waste bin 12 out from the base unit 13
(see fig. I).
3. Remove the CD waste bin 11 from the paper/credit card waste bin.
4. Empty the paper / credit card and CD waste bins separately.
5. Replace the CD waste bin in the paper / credit card waste bin and then slide
the paper/credit card waste bin back into the base unit.
You must fully slide the paper/credit card waste bin into the base unit until
a click sound is heard. This indicates that the safety switch 7has been
deactivated for normal operation.
Paper, CD or credit card jam
WARNING!
Risk of injury!
Handling the paper shredder improperly may result in injury.
− Never use objects of any kind to clear jammed CDs, credit
cards or paper. Do not insert objects such as knives,
scissors etc. into the feed slots.
To clear a jam:
1. Set the slide switch 8to the REV position. The paper shredder runs in
reverse direction.
2. The paper, credit card, or CD is discharged through the respective feed slot.
3. Allow the paper shredder to cool down to room temperature before you
restart.
When not in use
If you will not be using the paper shredder for an extended period of time,
proceed as follows:
1. Set the slide switch 8to the OFF position.
2. Unplug the power cord 1from the outlet.

Cleaning and maintenance
19
Cleaning and maintenance
WARNING!
Risk of electric shock!
An incorrect operation may result in an electric shock.
− Always switch off the paper shredder and unplug the
power cord before cleaning.
CAUTION!
Risk of injury!
Cleaning the paper shredder improperly may result in injury.
− The paper shredder will get hot during operation. Allow
the paper shredder to cool down completely before
cleaning.
− Do not touch the cutting unit with your fingers.
− Never disassemble the paper shredder for cleaning or
storage.
NOTICE!
Risk of short circuit!
Water or other liquids that have penetrated the housing may
cause a short circuit.
− Make sure that no water or other fluids penetrate the
housing.
− Never immerse the paper shredder and power cord in
water or other fluids.

Storage
20
NOTICE!
Risk of damage!
Improper handling of the paper shredder may result in damage.
− Do not use any aggressive cleaners, brushes with metal or
nylon bristles, sharp or metallic cleaning utensils such as
knives, hard scrapers and the like. They could damage the
surfaces of the paper shredder.
1. Set the slide switch 8to the OFF position and unplug the power cord 1
from the outlet.
2. To clean the exterior of the paper shredder, use a dry, or slightly moist, well-
wrung cloth and then thoroughly dry all parts.
3. For trouble-free operation, regularly and carefully remove any remaining
scraps of paper, credit card, or CD residues from the bottom of the
main unit 6. Use a suitable tool (e.g. brush) for this purpose. Do not touch
the cutting unit with your fingers. Never disassemble the paper shredder for
cleaning.
Storage
1. Clean the paper shredder (see chapter “Cleaning and maintenance”).
2. Store the paper shredder in a clean and dry location. Never disassemble the
paper shredder for storage.
3. Keep the paper shredder away from children.
Troubleshooting
WARNING!
Risk of electric shock!
Repairing the paper shredder yourself or using unsuitable
parts for repair may increase the risk of electric shock.
− Do not open the housing of the paper shredder; instead,
have qualified professionals perform any repairs. Contact
a qualified workshop for this. Liability and warranty claims
are waived in the event of repairs performed by the user
or incorrect operation.
