Swingline STACK-AND-SHRED200X&200XL 60X Instruction Manual

start here
démarrez ici
empieza aquí
comece aqui
SHREDDERS
STACK-AND-SHRED200X&200XL™

2min
1
2

**
4
3
7
6
5

SHREDDERS
STACK-AND-SHRED200X&200XL™
English instruction manual 6
Francais manuel d’utilisation 14
Español manual de instrucciones 22
Português manual de instruções 30

6register this product online at www.accobrands.com
autofeed technology
The Stack and Shred 200X/200XL has been designed to automatically shred up to 200 sheets
from the auto-feed chamber and up to 7 sheets through the manual feed slot.The auto-feed
mechanism has been designed to handle paper fastened with staples and paper clips and to only
pull a few sheets of paper into the cutting mechanism to minimise the risk of paper jams.
To guard against injury, the following basic safety precautions must be observed in the set-up of this
product.
• Ensure the machine is plugged into an easily accessible power outlet, and ensure the cable is not
likely to trip up a passer by.
• Any attempt to repair this unit by unqualied personnel will invalidate the warranty. Please return to
supplier.
• Unplug your shredder before moving it or when it is not in use for an extended period of time.
• Do not operate with a damaged power supply cord or plug, after it malfunctions, or after it has been
damaged in any manner.
• Do not overload electrical outlets beyond capacity as this can result in re or electrical shock.
• The socket-outlet should be installed near the equipment and shall be easily accessible.
• Do not alter the attachment plug. The plug is congured for the appropriate electrical supply.
• Do not use near water.
• Do not use aerosol dusters or cleaners.
• Do NOT spray anything into the shredder.
• Do NOT load the autofeed chamber with junk mail, magazines, bound documents etc.
Although this shredder has been designed to comply with UL 60950-1 EN 60950-1 safety standards
including the “probe accessibility tests”, do not operate the shredder near children or pets.
English

STACK-AND-SHRED 200X&200XL™SHREDDERS 7
warning symbols
This means no aerosols.
This means keep children away
from shredder.
This means you should be careful
because long hair can become
entangled in the cutting head.
This means don’t reach into the
feed opening of the cutting head.
This means be careful of loose
jewellery which could become
entangeld in the cutting head.
This means no oil lubrication,
use Swingline oil sheets only.
This means be careful of ties and
other loose clothing which could
become entangled in the cutting
head.
This means the shredder can
accept small paperclips.
This means the shredder can
accept small staples.
Safety First
Sheet capacity of manual feed
entry slot.
7
control panel and indicators
Continuous Jam BoostReverse Auto
Cool Down indicator – This means
the machine is cooling down.
This means the shredder can
accept credit cards.
Bin Full indicator – This means the
bin is full.
Paper Loading Door/Bin Door
Open indicator –
This means either:
• Loading door is open
• Bin is open
Lock indicator – This means the
paper loading door is locked (during
shredding).
Paper jam indicator – This means
there is a paper jam in the auto feed
chamber.
If this symbol is ashing the
shredder is attempting to clear a
paper jam automatically.
If this symbol is permanently
illuminated red please follow the
instructions under ‘Rare Occasion
of Jamming’.
Loading Door Locking
Mechanism – PIN Password
Buttons – Enter a four digit code
to lock the loading door during
shredding.
English

8register this product online at www.accobrands.com
Stack and Shred 200X/200XL shredding capability
Stack and Shred 200X/200XL CAN shred the following:
• 200 sheets
• Stapled paper, 25mm within the corner
• 26/6 and 24/6 or smaller staples
• Small sized paper loaded centrally
• 200 sheets
• Paper clip paper, 25mm within the corner (200XL through manual feed slot ONLY)
• Capable of shredding small/medium paper clips (max. wire thickness = 0.9 mm)
• >80/100gsm paper (through manual feed slot ONLY)
• A3 folded in half max. 2 sheets
• 200 sheets
• 80 gsm paper
- Letter and Legal
- A3 single sheet folded in half to make A4
Stack and Shred 200X/200XL CAN shred (through the manual feed slot):
Thick paper or
card.
Multiple folded
sheets (e.g. A3
sheets folded in
half).
Unopened mail
(e.g. junk mail).
Glossy paper or
a sheet covered
with print on both
sides.
Stack and Shred 200X/200XL CANNOT shred the following:
Large clips.
Check the length
of the paperclip
is not longer than
32mm.
Heavy duty
staples. Check
the staple leg
length is not
greater than
6mm.
Bound
documents
Bulldog clips
Magazines or
other documents
bound by multiple
staples or clips.
Adhesive labels.
Plastic sheets,
laminated
documents,
plastic folders.
English

STACK-AND-SHRED 200X&200XL™SHREDDERS 9
bin or loading door open safety function
As a safety precaution, if the bin or loading door is opened during shredding, the shredder
will stop and the bin full indicator will illuminate ( ).
intelligent help
1In the unlikely event of the shredder jamming, the Stack and Shred 200X & 200XL will stop
shredding, and the jam icon will blink in orange.
2The shredder will illuminate the FWD ( ) and REV ( ) buttons in the sequence
necessary to clear the jam.
3If the jam cannot be intelligentally cleared, the jam icon ( ) will illuminate in red. At this
point open the auto feed chamber to clear any jammed material.
automatic jam clearance
Intelligent Jam Clearance: In the unlikely event of the shredder jamming, the Stack and Shred
200X & 200XL will automatically reverse and forward the engine three times to clear a jam.
During this operation the Paper Jam indicator will ash ( ).
** 200XL only
locking the paper loading door
For additional security the paper loading door can be locked during the shredding of condential
material.
To lock shredder:
1
Place documents in tray. Close paper loading door.
2 Press any 4 digits. REMEMBER YOUR CODE!
Shredder unlocks automatically when:
• 4 digit code is re-entered.
• Shredding is complete.
• Shredder is inactive for 30 minutes (but documents remain in tray)
English

10 register this product online at www.accobrands.com
1. operation
1 Unpack the product.
2Connect the shredder to mains supply.
3 Ensure the ON/OFF button on the back of the machine is in the ON position, which will
illuminate the blue standby symbol ( ).
4To commence shredding, press the Auto button ( ), which sets the shredder into auto mode.
You are now ready to shred.
5To load the shredder, simply lift the loading door handle to open the loading door and insert
documents. You can open the door further to 90 degrees for easier access if required Load up
to 200 sheets at a time into the feed chamber. Do not ll above the 200 MAX level, this could
damage the shredder.
6 The shredder will start the shredding cycle automatically ONLY after closing the loading door.
If there is still paper in the Autofeed chamber after rst attempt open and reclose the paper
loading door a second time.
200XL only
Attention: If required you can now lock the loading door by entering a 4 digit code (see Locking
the Paper Loading Door section).
7If you only have up to 7 sheets to shred, you can use the manual feed slot, provided the auto
feed chamber is empty.
8Insert paper to be shredded into the feed area.The shredder will detect the paper and start
automatically.
9If the shredder is left in auto mode for more than 2 minutes without being used, the shredder will
automatically turn back to standby mode in order to save power.
10 The shredder will automatically ‘wake up’ from sleep mode when paper is inserted into the
shred mouth or you open the loading door.There is no need to press the Auto button ( ).
2. reverse function
1Should you wish to reverse paper out whilst shredding, a reverse button ( ) has been tted for
your convenience.
2 Reverse the paper out then turn the machine o using the ON/OFF switch at the rear of the
shredder. Remove the paper from the manual feed slot (if being used) or open the loading door,
remove the remaining stack of paper, then pull the jammed paper free of the cutting mechanism.
3 To resume shredding, turn the shredder on using the ON/OFF switch at the rear of the shredder.
Return the switch to the auto position ( ).
English
