Penclic KB3 User manual

HB186-A 105G : 105X148.5mm
The Keyboard will enter sleep mode after being idle for 30 minutes. To
activate it, press any key and wait for 3 seconds to reconnect.
POWER SAVING MODE (BLUETOOTH MODE)
When not in use for a prolonged period of time, it is recommended that
the keyboard is turned off to lengthen the battery life.
BATTERY LIFE TIP
Make sure that the keyboard is in wired mode. Press “FN+2” switch to
wired connection, State indicator light should be green.
TROUBLESHOOTING FOR WIRED MODE
If you are unable to connect the keyboard, please try the following:
1. Make sure the keyboard is in Bluetooth mode. State indicator light is
blue when keyboard is powered on. Press “FN+1” switch to wireless
connection.
2. Starting with a full charge on both devices ensures that process won´t
be interrupted by low battery.
3. Make sure your devices Bluetooth is on.
4. Make sure that the keyboard is within the effective operation distance
of 10 meters. (line of sight, walls etc. will reduce operational range)
TROUBLESHOOTING FOR WIRELESS MODE
1. Use the included Micro-USB cable for charging. Connect one end to a
USB charger or port, and the other to the keyboard. The keyboard can
be used while charging.
2. Whilst charging, the power indicator will turn red. Approximately 2 hours
until fully charged. (USB charger is not included, but cable to USB
port works)
HOW TO CHARGE
1. Keep the keyboard away from sharp objects that could damage it.
2. Do not put heavy objects on the keyboard.
3. Do not stretch, twist or apply force to the keyboard.
4. To clean the keyboard, gently wipe it by using a moist cotton cloth.
5. Make sure the keyboard is turned off before cleaning. Do not use
liquid cleanser.
6. Please do not spill liquids on the keyboard.
7. Avoid extreme hot and cold temperatures.
Supported platforms of Penclic Mini KeyboardKB3.
- Windows XP and newer.
- Android
-iOS
No driver needed.
Bluetooth version 3.0
USB HID 1.1 compatible.
Battery capacity: 250mA
Battery type: Lithium-polymer battery
Battery voltage:3.1V~4.2V
Sleep energy saving mode activates after 30 minutes, press any button to
reconnect.
Wireless reach: 10 meters.
Measurements:
Height: 10.25 mm
Surface: 280x 115.5 mm
Weight: 284 grams
Cable length: 150 cm
SAFETY INSTRUCTIONS
TECHNICAL SPECIFICATIONS
Penclic Mini Keyboard KB3
User Manual
PACKAGE CONTENTS
1. Aluminium Keyboard 2. Micro-USB Cable 3. User Manual
KEYS AND FUNCTIONS
Fn + Q Android
PC
iOS and OSX
Fn + W
Fn + E
Back N/A
Web Browser
N/A N/A
N/A
N/A
Home
Search for
Home
Reduce
Brightness
Increase
Brightness
Search for
Increase
Brightness
Search for
Increase
Brightness
Reduce
Brightness
Reduce
Brightness
Increase
Brightness
Reduce
Brightness
Android iOS Windows OSX
Battery power display indicator. Press “Fn + Backspace ” to show
battery status. Status indication: Flashing green. ( Each flash represents
25% battery. One Flash 25% charge. Two Flashes, 50% charge. Three
Flashes, 75% charge. Four Flashes, 100% charge)
Select your operating system after connecting to device.
Function list of escape and function key row.
Switch
Language
N/A Switch
Language N/A
Keyboard combination Operating system
Step 3. On your device, go to “settings”. Activate its Bluetooth function
and search for the keyboards device.
Step 4. The device will display “Penclic Mini Keyboard KB3” as an
available device.
Step 5. Select “Penclic Mini Keyboard KB3” on your device, click on it,
the keyboard will now be paired to your device and the Bluetooth
indicator will turn off.
Step 1. Get the keyboard to the desktop with the cable.
Optional step. If the State light is bluewhen power is switched on,
press “Fn + 2”key to change to Wired state. (note: State
will not change if cable is not connected)
Step 2. Wait for drivers to install.
Step 3. Press “Fn+ W” keys on the keyboard switch to the Windows
operating system.
PAIRING WITH DESKTOP (WIRED)
NOTE FOR WIRELESS MODE
Step 6.Choose your operating system.
Step 4.Choose your operating system.
Fn + Q
1. Keyboard can only be connected to one device at a time.
2. For other Bluetooth enabled devices, please verify the Bluetooth
capability before attempting to connect to the keyboard.
3. After pairing for the first time, your device will automatically connect
to the keyboard automatically when powering on or waking up the
keyboard. Unless the keyboard has been paired with something else.
4. In case of connection failure, Delete the pairing record from your
device and try the above procedures again.
Android
Windows
IOS / OSX
Fn + W
Fn + E
Fn + Q
Fn + W
Fn + E
Android
Windows
iOS / OSX
Step 1. Slide the Power switch to right side, to turn on the keyboard,
power light will turn green for 10 seconds. Note the State light
should be blue.
Optional step. If the State light is green when power is switched on,
press “Fn + 1” key to change to Bluetooth state.
Step 2. Press the “Fn + C” keys together to activate pairing mode. The
State light will start to blink blue.
Step 3. On the iPad, select: Settings- Bluetooth-On.
Step 4. The iPad will display “Penclic Mini Keyboard KB3” as an available
device.
Step 5. Select “Penclic Mini Keyboard KB3” on the iPad, click on it, the
keyboard will now be paired to iPad and the Bluetooth indicator
will turn off.
Step 6. Press “Fn +E” keys on the keyboard switch to the iOS operating
system setting.
Step 1. Slide the Power switch to right side, to turn on the keyboard,
power light will turn green for 10 seconds. Note the State light
should be blue.
Optional step. If the State light is green when power is switched on,
press “Fn + 1” key to change to Bluetooth state.
Step 2. Press the “FN+ C” Keys together to enter pairing mode. The
Bluetooth light will start to blink blue.
PAIRING WITH WIRELESS DEVICES
CHANGING KEYBOARD LAYOUT (CHOSEN IN THE
OPERATING SYSTEM)
HOW TO PAIR THE KEYBOARD WITH IPAD
Samsung Android: Shift +Space
Google Android: Ctrl +Space
Windows: Win+Space
iOS 8: Win+Space
iOS 9: Ctrl+Space
PAIRING WITH DESKTOP (BLUETOOTH)
3. Micro-USB cable. Wired mode:connect with desktops and notebooks,
sync and charging function. Wireless mode: charging for the keyboard.
INDICATOR LIGHTS DESCRIPTION
LIGHT FUNCTION DESCRIPTION
Caps Lock Indicator
Power switch, move right
(left in picture) to turn on.
⑤ Micro USB port, for wired
connection and charging
Power, Charging, and Battery Power Indicator
USB/Bluetooth Connection Indicator and Bluetooth Status Indicator
①
①
Caps Lock Indicator: The blue light will be on.
USB / Bluetooth state indicator:
(press “Fn + 1” switch to wireless connection. Light will turn blue.
Press “Fn + 2” switch to wired connection when cable is connected.
Light will turn green,)
Bluetooth connect status indicator: blue light will flash after pressing
the “Fn + C” keys together.
①
④
Power Indicator: Slide the power button to right side, the power
indicator will turn green. Charging Indicator: Red light whilst charging,
turns off once fully charged.
③
②
②
②
③
③
WIRELESS AND WIRED FUNCTION INTRODUCTION
PreviousTrack Previous Track PreviousTrack Previous Track
1. Bluetooth wireless connection: Fit for devices with Bluetooth function.
Like tablets, smartphones, etc.
2. USB wired connection: Fit for devices whitch can be connected with
USB cable, like notebooks, PC, etc.
Special Note:
Play/Pause
Next Track
Volume up
Screen Lock
Print screen
N/A
N/A N/A
Battery Power
Display
Battery
Power
Display
Battery
Power
Display
Battery Power
Display
Fn+
Fn+
N/A N/A
N/A
N/A
Keyboard
Display
Mute
Volume down
Play/Pause
Next Track
Volume up
ScreenLock
Mute
Volume
down
Play/Pause
Next Track
Volume up
Screen Lock
Mute
Volume down
Play/Pause
Next Track
Volume up
Mute
Volume down
For the Windows tablets, Hold Fn and press key simultaneously to
activate action.
1. This keyboard doesn’t support the Windows Mobile.
2. For Android users: The Caps Lock indicator may not light up, but will
still function normally.
3. While connected to an iOS or OSX device, the red printing is used. PC
standard layout and Apple standard layout are slightly different.
PrtSc
alt
