Penguin Computing Relion 2804e Quick start guide

Relion 2804e
Technical Guide
Rev. 1.0
PENGUIN
COMPUTING
www.penguincomputing.com | 1-888-PENGUIN (736-4846) | twitter:@PenguinHPC

Intel®Server System R2000LH2/LT2
Family Service Guide
A Guide for Technically Qualified Assemblers of Intel® identified Subassemblies/Products
Order Number: G42282-004

Disclaimer
ii Intel®Server System R2000LH2/LT2 Service Guide
Disclaimer
Information in this document is provided in connection with Intel®products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel®’s
Terms and Conditions of Sale for such products, Intel®assumes no liability whatsoever, and Intel®disclaims any
express or implied warranty, relating to sale and/or use of Intel®products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual
property right. Intel®products are not designed, intended or authorized for use in any medical, life-saving, or life
sustaining applications or for any other application in which the failure of the Intel®product could create a situation
where personal injury or death may occur. Intel®may make changes to specifications and product descriptions at
any time, without notice.
Intel®server boards contain a number of high-density VLSI and power delivery components that need adequate
airflow for cooling. Intel®’s own chassis are designed and tested to meet the intended thermal requirements of these
components when the fully integrated system is used together. It is the responsibility of the system integrator that
chooses not to use Intel®developed server building blocks to consult vendor datasheets and operating parameters to
determine the amount of airflow required for their specific application and environmental conditions. Intel
Corporation cannot be held responsible if components fail or the server board does not operate correctly when used
outside any of their published operating or non-operating limits.
Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the United States and other countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2012 Intel Corporation. All Rights Reserved.

Safety Information
Intel®Server System R2000LH2/LT2 Service Guide iii
Safety Information
Important Safety Instructions
Read all caution and safety statements in this document before performing any of the instructions.
See also Intel®Server Boards and Server Chassis Safety Information on the Intel®Server
Deployment Toolkit 3.0 CD and/or at
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
Wichtige Sicherheitshinweise
Lesen Sie zunächst sämtliche Warnund Sicherheitshinweise in diesem Dokument, bevor Sie eine
der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel®-
Serverplatinen und Servergehäusen auf der Intel®Server Deployment Toolkit 3.0 CD oder unter
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
Consignes de sécurité
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document
avant de suivre toute instruction. Consultez Intel®Server Boards and Server Chassis Safety
Information sur le Intel®Server Deployment Toolkit 3.0 CD ou bien rendez-vous sur le site
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
Instrucciones de seguridad importantes
Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar
cualquiera de las instrucciones. Vea Intel®Server Boards and Server Chassis Safety Information en
el Intel®Server Deployment Toolkit 3.0 CD y/o en
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
重要安全指导
在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。和/或
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm 上的 Intel®Server Boards
and Server Chassis Safety InformationIntel®服务器主板与服务器机箱安全信息。

Warnings
iv Intel®Server System R2000LH2/LT2 Service Guide
Warnings
Heed safety instructions: Before working with your server product, whether
you are using this guide or any other resource as a reference, pay close
attention to the safety instructions. You must adhere to the assembly
instructions in this guide to ensure and maintain compliance with existing
product certifications and approvals. Use only the described, regulated
components specified in this guide. Use of other products/components will
void the UL listing and other regulatory approvals of the product and will
most likely result in noncompliance with product regulations in the region(s)
in which the product is sold.
System power on/off: The power button DOES NOT turn off the system AC
power. To remove power from the system, you must unplug the AC power
cord from the wall outlet. Make sure the AC power cord is unplugged before
you open the chassis, add, or remove any components.
Hazardous conditions, devices and cables: Hazardous electrical conditions
may be present on power, telephone, and communication cables. Turn off the
server and disconnect the power cord, telecommunications systems, networks,
and modems attached to the server before opening it. Otherwise, personal
injury or equipment damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage disk
drives, boards, and other parts. We recommend that you perform all
procedures in this chapter only at an ESD workstation. If one is not available,
provide some ESD protection by wearing an antistatic wrist strap attached to
chassis ground - any unpainted metal surface - on your server when handling
parts.
ESD and handling boards: Always handle boards carefully. They can be
extremely sensitive to ESD. Hold boards only by their edges. After removing
a board from its protective wrapper or from the server, place the board
component side up on a grounded, static free surface. Use a conductive foam
pad if available but not the board wrapper. Do not slide board over
any surface.
Installing or removing jumpers: A jumper is a small plastic encased
conductor that slips over two jumper pins. Some jumpers have a small tab on
top that you can grip with your fingertips or with a pair of fine needle nosed
pliers. If your jumpers do not have such a tab, take care when using needle
nosed pliers to remove or install a jumper; grip the narrow sides of the
jumper with the pliers, never the wide sides. Gripping the wide sides can
damage the contacts inside the jumper, causing intermittent problems with
the function controlled by that jumper. Take care to grip with, but not
squeeze, the pliers or other tool you use to remove a jumper, or you may
bend or break the pins on the board.

Preface
Intel®Server System R2000LH2/LT2 Service Guide v
Preface
About this Manual
This manual is written for system technicians who are responsible for troubleshooting, upgrading,
and repairing this server system. It provides a brief overview of the features of the server
board/chassis, a list of accessories or other components you may need, troubleshooting information,
and instructions on how to add and replace components on the Intel®Server System
R2000LH2/LT2 family products. For the latest revision of this manual, go to
http://www.intel.com/p/en_US/support.
Table 1. Intel®Server System R2000LH2/LT2 family product list
Product Code
Description
Intel®Server System R2208LT2HKC4
With Intel®Server Board S4600LT2 and 8"x 2.5"hot swap hard drive bay
Intel®Server System R2304LT2HVC
With Intel®Server Board S4600LT2 and 4"x 3.5"hot swap hard drive bay
Intel®Server System R2304LH2HKC
With Intel®Server Board S4600LH2 and 4"x 3.5"hot swap hard drive bay
Intel®Server System R2208LH2HKC2
With Intel®Server Board S4600LH2 and 8"x 2.5"hot swap hard drive bay
Manual Organization
Chapter 1 provides a brief overview of the Intel®Server System R2000LH2/LT2 family. In this
chapter, you will find a list of the server system features, and figures of the system and components
to help you identify your system components and their locations.
Chapter 2 provides instructions on adding and replacing components. Use this chapter for step-by-
step instructions and diagrams for installing or replacing components such as the fan, power supply,
and front panel board, among other components.
Chapter 3 provides instructions on using the utilities that are shipped with the board or that may be
required to update the system. This includes information for navigating through the BIOS Setup
screens, performing a BIOS update, and resetting the password or BIOS defaults.
At the back of this document, you will find appendices on safety, “getting help”, and
warranty information.
Additional Information and Software
For additional information about this family of products or any of their supported accessories, refer
to the following resources available at http://www.intel.com/p/en_US/support/.

Preface
vi Intel®Server System R2000LH2/LT2 Service Guide
Table 2. Server System References
For this information or software
Use this Document or Software
For in-depth technical information about
this product.
Intel®Server System R2000LH2/LT2 Family Technical Product Specification
See the section on the web page titled, “Architecture/Specifications”.
For supported Intel®spares and
accessories
Intel®Server System R2000LH2/LT2 Family Quick Installation User’s Guide
See the section on the web page titled, “System Integration/User
Guides/Compatibility”.
For supported Intel®spares and
accessories
Spares and Configuration Guide
See the section on the web page titled, “Documents & Guides”.
For server configuration guidance and
compatibility
Intel®Server Configurator tool
For system power budget guidance
Power Budget Analysis Tool
For software to manage your Intel®Server
System.
Intel®Server Management Software
See the section on the web page titled, “Software/Code”.
For system firmware updates and onboard
device drivers
Firmware and Drivers
See the section on the web page titled, “Software/Code”.
Product Safety and Regulatory document
Intel®Server Products - Product Safety and Regulatory Compliance Document
See the section on the web page titled, “Regulations/Certification/Compliance”.

Table of Contents
Intel®Server System R2000LH2/LT2 Service Guide vii
Table of Contents
Safety Information .......................................................................................................................................iii
Preface .......................................................................................................................................................... v
1 Server System Features .......................................................................................................................... 1
Server System Feature Overview ........................................................................................................... 1
Wattage Limitation of the PCI Loading ................................................................................................. 3
Power Rating .......................................................................................................................................... 3
Server System Components.................................................................................................................... 4
Hot Swap Hard Drive Bay and Front Panel Options.............................................................................. 4
Front Panel ............................................................................................................................................. 5
Back Panel.............................................................................................................................................. 5
Server Board Components...................................................................................................................... 6
System Recovery Jumpers...................................................................................................................... 8
Peripheral Devices.................................................................................................................................. 9
2 Hardware Installations and Upgrades................................................................................................... 13
Before You Begin................................................................................................................................. 13
Tools and Supplies Needed ........................................................................................................ 13
System Reference ....................................................................................................................... 13
Cable Routing....................................................................................................................................... 13
For system with 4 x 3.5" hot swap hard drive bay...................................................................... 13
For system with 8 x 2.5" hot swap hard drive bay...................................................................... 15
Fan Connections................................................................................................................................... 16
Removing and Installing the Front Bezel (Optional) ........................................................................... 17
Removing the Front Bezel.......................................................................................................... 17
Installing the Front Bezel............................................................................................................ 17
Removing and Installing the Front Fan Bezel...................................................................................... 18
Removing the Front Fan Bezel ................................................................................................... 18
Installing the Front Fan Bezel..................................................................................................... 18
Removing and Installing the Rack Handles ......................................................................................... 19
Removing the Rack Handles ...................................................................................................... 19
Installing the Rack Handles........................................................................................................ 19
Removing and Installing the Power Supply Module(s)........................................................................ 20
Removing the Power Supply Module(s)..................................................................................... 20
Installing a Power Supply Module(s) ......................................................................................... 20
Removing and Installing the System Cover ......................................................................................... 20
Removing the System Cover ...................................................................................................... 20
Installing the System Cover........................................................................................................ 21
Removing and Installing the Front End Module .................................................................................. 22
Removing the Front End Module ............................................................................................... 22
Installing the Front End Module................................................................................................. 22
Removing and Installing the PCI Riser Assembly ............................................................................... 23
Removing the PCI Riser Assembly ............................................................................................ 23
Installing the PCI Riser Assembly.............................................................................................. 23
Installing and Removing a PCI Add-in Card........................................................................................ 24
Installing a PCI Add-in Card ...................................................................................................... 24
Removing a PCI Add-in Card..................................................................................................... 25

Table of Contents
viii Intel®Server System R2000LH2/LT2 Service Guide
Removing and Installing the Air Duct.................................................................................................. 26
Removing the Air Duct............................................................................................................... 27
Installing the Air Duct ................................................................................................................ 27
Removing and Installing the Processor Heatsink(s)............................................................................. 28
Removing Processor Heatsink(s)................................................................................................ 28
Installing Processor Heatsink(s) ................................................................................................. 28
Installing or Replacing the Processor ................................................................................................... 29
Installing the Processor............................................................................................................... 30
Installing and Removing the Memory.................................................................................................. 31
Installing Memory ...................................................................................................................... 32
Removing Memory..................................................................................................................... 32
Installing and Removing Hard Drive ................................................................................................... 32
Installing a Hard Disk Drive into 3.5" Hot Swap Hard Drive Carrier........................................ 33
Installing a Hard Disk Drive into 2.5" Hot Swap Hard Drive Carrier........................................ 35
Installing and Removing a Slimline Optical Drive .............................................................................. 36
Installing a Slimline Optical Drive............................................................................................. 36
Removing a Slimline Optical Drive ........................................................................................... 37
Installing and Removing the Intel®I/O Expansion Module................................................................. 37
Before Installing Intel®I/O Expansion Module at the Left Edge of the Board (Optional) ........ 38
Installing Intel®I/O Expansion Module ..................................................................................... 39
Removing Intel®I/O Expansion Module.............................................................................................. 40
Installing and Removing the Intel®Remote Management Module 4................................................... 41
Installing the Intel®RMM4 Lite................................................................................................. 41
Install the Intel®RMM4 NIC ..................................................................................................... 42
Removing the Intel®RMM4 Lite ............................................................................................... 42
Removing the Intel®RMM4 NIC............................................................................................... 42
Installing and Removing an Internal Solid State Drive........................................................................ 43
Installing a Solid State Drive...................................................................................................... 43
Removing a Solid State Drive .................................................................................................... 44
Installing and Removing the Intel®RAID Smart Battery .................................................................... 45
Installing the Intel®RAID Smart Battery ................................................................................... 45
Removing the Intel®RAID Smart Battery ................................................................................. 46
Installing and Removing the Server Board .......................................................................................... 46
Removing the Server Board........................................................................................................ 47
Installing the Server Board ......................................................................................................... 47
Replacing the Backup Battery.............................................................................................................. 48
Replacing a Redundant Fan Module .................................................................................................... 49
Replacing the Backplane ...................................................................................................................... 50
Removing the Backplane............................................................................................................ 50
Installing the Backplane ............................................................................................................. 50
Replacing the Lower Fan Board........................................................................................................... 51
Removing the Lower Fan Board................................................................................................. 51
Installing the Lower Fan Board .................................................................................................. 52
Replacing the Front Video and USB Module....................................................................................... 52
Removing the Front Video and USB Module ............................................................................ 53
Installing the Front Video and USB Module.............................................................................. 54
Installing and Removing the LCP Module........................................................................................... 54
Installing the LCP Module.......................................................................................................... 55
Removing the LCP Module........................................................................................................ 56
Install the Bezel (Optional) .................................................................................................................. 57
Install the System into Rack (Optional) ............................................................................................... 57

Table of Contents
Intel®Server System R2000LH2/LT2 Service Guide ix
Installing the Chassis into Rack.................................................................................................. 58
Removing the Chassis from Rack............................................................................................... 59
3 Server Utilities...................................................................................................................................... 61
Using the BIOS Setup Utility............................................................................................................... 61
Starting Setup ............................................................................................................................. 61
Setup Navigation Keyboard Commands .................................................................................... 61
Setup Screen Menu Selection Bar .............................................................................................. 62
BIOS Setup Utility Screens ........................................................................................................ 62
Map of Screens and Functionality .............................................................................................. 63
Appendix A: Regulatory and Compliance Information.............................................................................. 65
Appendix B: Safety Information................................................................................................................. 66
Appendix C: Installation/Assembly Safety Instructions ............................................................................. 67
Appendix D: Getting Help .......................................................................................................................... 68
Warranty Information ................................................................................................................. 68
Appendix E: Intel®Server Issue Report Form............................................................................................ 69
Appendix F: Warranty ................................................................................................................................ 73
Limited Warranty for Intel®Chassis Subassembly Products ............................................................... 73
Extent of Limited Warranty.................................................................................................................. 73
Warranty Limitations and Exclusions .................................................................................................. 73
Limitations of Liability............................................................................................................... 74
How to Obtain Warranty Service ......................................................................................................... 74
Telephone Support...................................................................................................................... 74
Returning a Defective Product.................................................................................................... 74

List of Figures
x Intel®Server System R2000LH2/LT2 Service Guide
List of Figures
Figure 1. Intel®Server System R2000LH2/LT2........................................................................................... 1
Figure 2. Intel®Server System R2000LH2/LT2 Components...................................................................... 4
Figure 3. 3.5" Hot Swap Hard Drive Bay - 4 Drive Configuration .............................................................. 4
Figure 4. 2.5" Hot Swap Hard Drive Bay - 8 Drive Configuration .............................................................. 4
Figure 5. Front Panel Options....................................................................................................................... 5
Figure 6. Back Panel Feature Identification.................................................................................................. 5
Figure 7. Server Board Connector and Component Locations ..................................................................... 7
Figure 8. Configuration Jumpers .................................................................................................................. 8
Figure 9. Optional Peripherals (4x3.5-inch hard drive bays as shown) ........................................................ 9
Figure 10. Front Bezel (Front View) .......................................................................................................... 10
Figure 11. 4 x 3.5-inch Hard Drive Backplane Components (Front View)................................................ 10
Figure 12. 4 x 3.5-inch Hard Drive Backplane Components (Rear View) ................................................. 11
Figure 13. 8 x 2.5-inch Hard Drive Backplane Components (Front View)................................................ 11
Figure 14. 8 x 2.5-inch Hard Drive Backplane Components (Rear View)................................................. 11
Figure 15. Cable Routing –4 x 3.5" Hot Swap HDD................................................................................. 14
Figure 16. Cable Routing –8 x 2.5" Hot Swap HDD................................................................................. 15
Figure 17. System Fan Order...................................................................................................................... 16
Figure 18. Connecting the Fan Power Cables to the Fan Board and PDB.................................................. 16
Figure 19. Removing the Front Bezel......................................................................................................... 17
Figure 20. Installing the Front Bezel .......................................................................................................... 17
Figure 21. Removing the Front Fan Bezel.................................................................................................. 18
Figure 22. Installing the Front Fan Bezel ................................................................................................... 18
Figure 23. Removing the Rack Handle....................................................................................................... 19
Figure 24. Installing the Rack Handle ........................................................................................................ 19
Figure 25. Removing the Power Supply Module........................................................................................ 20
Figure 26. Installing the Power Supply Module ......................................................................................... 20
Figure 27. Removing the System Cover ..................................................................................................... 21
Figure 28. Installing the System Cover....................................................................................................... 21
Figure 29. Removing the Front End Module .............................................................................................. 22
Figure 30. Installing the Front End Module................................................................................................ 22
Figure 31. Removing the PCI Riser Assembly ........................................................................................... 23
Figure 32. Installing the PCI Riser Assembly............................................................................................. 23
Figure 33. Installing a Half-Length PCI Add-In Card ................................................................................ 24
Figure 34. Installing a Full-Length PCI Add-In Card................................................................................. 25
Figure 35. Removing a Half-Length PCI Add-In Card............................................................................... 25
Figure 36. Removing a Full-Length PCI Add-In Card ............................................................................... 26
Figure 37. Removing the Air Duct.............................................................................................................. 27
Figure 38. Installing the Air Duct ............................................................................................................... 27
Figure 39. Removing Processor Heatsink................................................................................................... 28
Figure 40. Installing Processor Heatsink .................................................................................................... 29
Figure 41. Installing Processor –Remove the Cover.................................................................................. 30
Figure 42. Installing Processor –Open the Socket Lever........................................................................... 30
Figure 43. Installing Processor –Open the Load Plate............................................................................... 30
Figure 44. Installing Processor –Install the Processor ............................................................................... 31
Figure 45. Installing Processor –Close the Load Plate .............................................................................. 31
Figure 46. Installing Processor –Latch the Locking Lever ........................................................................ 31
Figure 47. Installing Memory ..................................................................................................................... 32

List of Figures
Intel®Server System R2000LH2/LT2 Service Guide xi
Figure 48. Installing Hard Disk Drive –Removing 3.5" HDD carrier ....................................................... 33
Figure 49. Installing Hard Disk Drive –Removing 3.5" HDD interface bracket....................................... 33
Figure 50. Installing Hard Disk Drive –Installing 3.5" HDD .................................................................... 33
Figure 51. Installing Hard Disk Drive –Installing 2.5" HDD .................................................................... 34
Figure 52. Installing Hard Disk Drive –Inserting 3.5" HDD Assembly .................................................... 34
Figure 53. Installing Hard Disk Drive –Removing 2.5" HDD carrier ....................................................... 35
Figure 54. Installing Hard Disk Drive –Removing Plastic Drive Blank.................................................... 35
Figure 55. Installing Hard Disk Drive –Installing 2.5" HDD .................................................................... 35
Figure 56. Installing Hard Disk Drive –Inserting 2.5" HDD assembly ..................................................... 36
Figure 57. Installing the Plastic Guide to the Optical Drive....................................................................... 36
Figure 58. Installing an Optical Drive ........................................................................................................ 37
Figure 59. Removing the Slimline Optical Drive ....................................................................................... 37
Figure 60. Installing Intel®I/O Expansion Module .................................................................................... 38
Figure 61. Installing Intel®I/O Expansion Module .................................................................................... 39
Figure 62. Removing Intel®I/O Expansion Module................................................................................... 40
Figure 63. Installing the Intel®RMM4 Lite................................................................................................ 41
Figure 64. Installing the Intel®RMM4 NIC ............................................................................................... 42
Figure 65. Removing the Intel®RMM4 NIC.............................................................................................. 42
Figure 66. Installing a SSD......................................................................................................................... 43
Figure 67. Removing a SSD ....................................................................................................................... 44
Figure 68. Installing the Intel®RAID Smart Battery.................................................................................. 45
Figure 69. Removing the Intel®RAID Smart Battery ................................................................................ 46
Figure 70. Removing the Server Board ...................................................................................................... 47
Figure 71. Installing the Server Board........................................................................................................ 47
Figure 72. Replacing the Backup Battery ................................................................................................... 48
Figure 73. Replacing a system fan.............................................................................................................. 49
Figure 74. Removing the backplane ........................................................................................................... 50
Figure 75. Installing the backplane............................................................................................................. 50
Figure 76. Removing the Lower Fan Board ............................................................................................... 51
Figure 77. Installing the Lower Fan Board................................................................................................. 52
Figure 78. Removing the front video and USB Module ............................................................................. 53
Figure 79. Installing the front video and USB Module............................................................................... 54
Figure 80. Installing the LCP Module ........................................................................................................ 55
Figure 81. Removing the LCP Module....................................................................................................... 56
Figure 82. Slides Component...................................................................................................................... 57
Figure 83. Install Slides to Rack ................................................................................................................. 58
Figure 84. Install Inner Member to Chassis................................................................................................ 58
Figure 85. Install Chassis to Fixed Slides ................................................................................................... 59
Figure 86. Extend Slides ............................................................................................................................. 59
Figure 87. Remove Inner Member from Chassis........................................................................................ 60

List of Tables
xii Intel®Server System R2000LH2/LT2 Service Guide
List of Tables
Table 1. Intel®Server System R2000LH2/LT2 family product list.............................................................. v
Table 2. Server System References.............................................................................................................. vi
Table 3. Intel®Server System R2000LH2/LT2 Feature Summary............................................................... 1
Table 4. Wattage Limitation of the PCIe Loading........................................................................................ 3
Table 5. Power Rating of the Power Supply................................................................................................. 3
Table 6. Hard Disk Drive Options ................................................................................................................ 9
Table 7. BIOS Setup: Keyboard Command Bar ......................................................................................... 61
Table 8. Screen Map ................................................................................................................................... 63

Server System Features
Intel®Server System R2000LH2/LT2 Service Guide 1
1Server System Features
This chapter briefly describes the main features of the Intel®Server System R2000LH2/LT2
family. This includes illustrations of the products, a list of the server system features, and
diagrams showing the location of important components and connections on the server systems.
Figure 1. Intel®Server System R2000LH2/LT2
Server System Feature Overview
Table 3 summarizes the features of the server systems.
Table 3. Intel®Server System R2000LH2/LT2 Feature Summary
Server System
Integrated Server Board
Intel®Server System R2000LH2 product family
Intel®Server Board S4600LH2
Intel®Server System R2000LT2 product family
Intel®Server Board S4600LT2
Feature
Description
Dimensions
3.43 inches (87.3 mm) high
17.24 inches (438.0 mm) wide
28.0 inches (712.0 mm) deep
Processor Support
Support up to four Intel®Xeon®processors E5-4600 product family with a Thermal Design Power
(TDP) of up to 130 W.
Memory
48 DIMM slots –Three DIMMs/Channel –Four memory channels per processor
Unbuffered DDR3 and registered DDR3 DIMMs
Memory DDR3 data transfer rates of 800, 1066, 1333 MT/s and 1600 MT/s
DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Chipset
Intel®C600-A chipset with support for optional Storage Option Select keys
External I/O
connections
Video –Back Panel + Front Panel
RJ-45 Serial- A Port
S4600LH2 - 2 RJ-45 Network Interface Connectors supporting 10/100/1000Mb
S4600LT2 - 2 RJ-45 Network Interface Connectors supporting 100/1000/10000Mb

Server System Features
2 Intel®Server System R2000LH2/LT2 Service Guide
Feature
Description
USB 2.0 connectors - 4 on back panel + 2 on front panel
Internal I/O
connectors/headers
One Type-A USB 2.0 connector
One internal USB header
One DH-10 Serial-B port connector
Optional I/O Module
Support
The following I/O modules utilize a single proprietary on-board connector. An installed I/O module
can be supported in addition to standard on-board features and any add-in expansion cards.
Quad port 1 GbE based on Intel®Ethernet Controller I350
Dual port 10GBase-T Ethernet module based on Intel®Ethernet Controller I350 –
AXX10GBTWLIOM
Dual SFP+ port 10GbE module based on Intel®82500 10 GbE controller –AXX10GBNIAIOM
Single Port FDR speed InfiniBand* module with QSFP connector –AXX1FDRIBIOM
System Fans
Eleven managed system fans
One power supply fan for each installed power supply module
Riser Cards
Support for two riser card slots. Each riser card slot has support for three PCIe x16 slots
Video
Integrated 2D Video Controller
16 MB DDR3 Memory
On-board storage
controllers and
options
One low-profile eUSB 2x5 pin connector to support low-profile eUSB solid state devices
Two single port SATA connectors capable of supporting up to 6 GB/sec
Two 4-port mini-SAS connectors capable of supporting up to 3 GB/sec SAS/SATA
Intel®RAID C600 Upgrade Key support providing optional expanded SATA/SAS RAID capabilities
Security
Trusted Platform Module (Optional)
Server Management
Integrated Baseboard Management Controller, IPMI 2.0 compliant
Support for Intel®Server Management Software (version TBD)
Intel®Remote Management Module 4 support (optional)
Intel®Remote Management Module 4 Lite support (optional)
Power Supply Options
The system is shipped with two power supplies with support below options.
1600W (1+1) Redundant Hot-swap Capable
1600W (1+0 or 2+0) Non-Redundant
Storage Bay Options
4"x 3.5"SATA/SAS Hot Swap Hard Drive Bays + Optical Drive support
8" x 2.5"SATA/SAS Hot Swap Hard Drive Bays
Rack Mount Kit
Options
Extended Value rack mount rail kit (AXXELVRAIL)
Premium rack mount rail kit (AXXPRAIL), will be available at post launch
CAUTION: THE MAXIMUM RECOMMENDED SERVER WEIGHT FOR THE RACK RAILS CAN
BE FOUND at http://www.intel.com/support/motherboards/server/sb/CS-033655.htm.
EXCEEDING THE MAXIMUM RECOMMENDED WEIGHT OR MISALIGNMENT OF THE
SERVER MAY RESULT IN FAILURE OF THE RACK RAILS HOLDING THE SERVER. Use of a
mechanical assist to install and align server into the rack rails is recommended.

Server System Features
Intel®Server System R2000LH2/LT2 Service Guide 3
Wattage Limitation of the PCI Loading
Table 4 summarizes the wattage limitation of the PCI loading.
Table 4. Wattage Limitation of the PCIe Loading
VIN
Power Supply Configuration
Maximum PCI Loading
90 –140VAC
(AC low-Line)
1600W (1+1) Redundant Hot-swap Capable
1600W (1+0 or 2+0) Non-Redundant
260W
180 –264VAC
(AC high-line)
1600W (1+1) Redundant Hot-swap Capable
1600W (1+0 or 2+0) Non-Redundant
450W
Power Rating
Table 5 summarizes the power rating of the power supply.
Table 5. Power Rating of the Power Supply
VIN
Total Available Power
100~127VAC
(AC low-Line)
1120W
200~240VAC
(AC high-line)
1600W

Server System Features
4 Intel®Server System R2000LH2/LT2 Service Guide
Server System Components
This section helps you identify the components of your server system. If you are near the
system, you can also use the Quick Reference Label provided on the inside of the chassis cover
to assist in identifying components.
Figure 2. Intel®Server System R2000LH2/LT2 Components
Hot Swap Hard Drive Bay and Front Panel Options
Figure 3. 3.5" Hot Swap Hard Drive Bay - 4 Drive Configuration
Figure 4. 2.5" Hot Swap Hard Drive Bay - 8 Drive Configuration

Server System Features
Intel®Server System R2000LH2/LT2 Service Guide 5
Front Panel
Label
Description
Label
Description
A
System ID Button w/Integrated LED
F
System Status LED
B
NMI Button (recessed, tool required for use)
G
Power Button w/Integrated LED
C
NIC-1 Activity LED
H
Hard Drive Activity LED
D
Not Used
I
Not Used
E
System Cold Reset Button
J
NIC-2 Activity LED
Figure 5. Front Panel Options
Back Panel
Label
Description
Label
Description
A
USB Ports
H
I/O Module Ports/Connectors (Optional)
B
USB Ports
I
Add-in adapter slots from Riser Card
C
I/O Module Ports/Connectors (Optional)
J
RMM4 NIC Port (Optional)
D
Video Connector
K
Power Supply Module #2
E
NIC –1
L
Power Supply Module #1
F
NIC –2
M
Add-in adapter slots from Riser Card
G
RJ45 Serial-A Port
Figure 6. Back Panel Feature Identification

Server System Features
6 Intel®Server System R2000LH2/LT2 Service Guide
Server Board Components
This section helps you identify the components and connectors on the server board.
Description
Description
A
Manufacturing Mode jumper
AH
Riser Card slot #1
B
Serial ‘A’ Port (RJ45)
AI
CPU #4 DIMM slots –Memory Banks N and P
C
NIC 2
AJ
CPU #4 socket
D
NIC 1
AK
Front Panel Video connector
E
(Option) RMM4 Lite connector
AL
Front Panel header (SSI compatible)
F
Video connector
AM
CPU #1 Fan connector
G
CPU #2 DIMM slots –Memory Banks G and H
AN
CPU #4 Fan connector
H
CPU #1 DIMM slots –Memory Banks A and B
AO
CPU #4 DIMM slots –Memory Banks R and T
I
(Option) I/O Module connector
AP
Main Power Slot #2
J
(Option) eUSB Solid State Device (SSD) connector
AQ
Main Power Slot #1
K
Rear System Fan #2 connector
AR
CPU #3 DIMM slots –Memory Banks J and K

Server System Features
Intel®Server System R2000LH2/LT2 Service Guide 7
Description
Description
L
Rear System Fan #1 connector
AS
CPU #3 Fan connector
M
4 Port SATA/SAS connector (Drives 4-7)
AT
CPU #2 Fan connector
N
4 Port SATA/SAS connector (Drives 0-3)
AU
Fan board power connector
O
(Option) Intel®RAID C600 Upgrade Key connector
AV
PDB signal connector
P
Type-A USB 2.0 connector
AW
4-pin IPMB connector
Q
(Option) mSATA port
AX
LCP connector
R
2 Stacked USB 2.0 ports
AY
3-pin Hot Swap Backplane SMBus* connector
S
2 Stacked USB 2.0 ports
AZ
CPU #3 socket
T
System ID LED
BA
CPU #3 DIMM slots –Memory Banks L and M
U
System Status LED
BB
Riser Card slot #2
V
POST Code Diagnostic LEDs
BC
Backup Battery
W
SATA only port #0
BD
CPU #2 socket
X
Internal Serial Port
BE
CPU #2 DIMM slots –Memory Banks E and F
Y
SATA only port #1
BF
(Option) I/O Module connector
Z
Internal USB port
BG
(Option) RMM4 NIC connector
AA
Password Clear jumper
BH
(Option) TPM connector
AB
BIOS Recover jumper
BI
Serial A jumper
AC
BIOS Default jumper
BJ
BMC force update
AD
ME Force Update jumper
AE
CPU #1 DIMM slots –Memory Banks C and D
AF
CPU #1 socket
AG
CPLD programming header
Figure 7. Server Board Connector and Component Locations
