Penpower TOOYA Master Assembly instructions

1
Driver Installation
◎ Windows Version
1.
Insert the Driver CD into your CD drive and wait until the
auto start window appears. On Windows Vista and Windows 7
you may conrm the action by pressing [Continue] if the User
Access Control window appear.
2. Simply follow the steps on the screen and nish the installation
with rebooting your system.
◎ Mac Version
1. Insert the Driver CD into your CD drive and wait until the Drive
is loaded.
2. Click on the Tablet con and simply follow the steps on the
screen and nish the installation with restarting your system.
Note: You have to remove the exiting pen tablet driver before installing
the driver (including the tablet driver with other brands.)
Before starting with the driver installation, please make sure
that the tablet is not connected to your PC.

2
3
Knowing Your Tablet
1. USB connector: Please connect the USB cable here.
2. LED indicator: The LED light on the tablet is the main indicator
for hardware operation. This LED normally stays off, and will
only turn it on or off in response to various conditions.
If the LED of tablet is blinking continuously, it means that the
USB port of your PC has a bad connection or power is not stable.
Please re-plug in your USB/dongle again. If still not working,
please change to another USB port.
1
2
3
4

2
3
Knowing Your Pen
The pen of TOOYA Master Tablet is
the connection between your hand and the
graphic tablet. Just use and hold the pen like
a normal pen. If you move over the tablet in
max 10mm distance without touching it you
can see the movement of the pointer. The pen
tip is like left mouse buttons which also offer
double click function. Further, the pen offers
two buttons witch can be programmed in
Control Panel.
Button 2
Button 1
Pen Tip
3. Express keys & Ring switch: For Express Keys & Scroll Ring
settings, you can modify from the Express Keys conguration
page.
◎ Re-dene Express keys
Select “Common”, “Mouse”, “Multimedia”, “Other”, “Run”,
“Internet” and “Hot Key” tabs to re-define the settings, you can
resume the Express Keys to the default settings by clicking “Default”
button.
4. Working area: The area for you to draw.

4
5
◎ How to change the pen tip
If the tip is not soft any more or leaves scratches (scratch
noise) on the graphic tablet it’s recommend to exchange the tip to
avoid any damage on your tablet.
1. Use the pen tip remover tool like a classical tool you know from
home. Grap the tip with the open end of the remover tool and
pull out the tip with care.
2. Place the new tip in the pen and gently push it in until the end is
reached. Don’t use to much pressure to avoid damage of the pen.

4
5
Control Panel
This paragraph describes the Windows control panel but can
be adopt to Mac control panel as well.
After driver installation, restart and successful connection of
your Graphic tablet you will find a small Tablet Icon in the
quick start bar close to your clock. Click on the Icon to open the
Control Panel. The Control Panel is divided into 2 main parts
1. Info: The Info tab displays the version number of the driver and
Tablet PC function. You can select the tablet PC function of the
Pressure Sensitive by tick the box of Support Tablet PC Feature.
Note: No Tablet PC feature under the Mac System.

6
7
2. Button: You may re-program
the functions of the pen tip
and the two-barrel buttons by
selecting the button’s name.
A c c o r d i n g t o t h e m o u s e
function, you can select no
action, left click, left double
click, middle click, middle
double click, right click, or
right double click.
Note: Mac system has no middle
click and middle double click.
3. Express Keys: For the models
with express keys or scroll
r i n g , y o u c an ch a n g e t h e
express key settings from the
Express Keys Congure Page.

6
7
4. Scope:
I. Full Area: Select the largest
possibly working area.
II. Screen Ratio: Set the tablet
area as same as the screen size
by reducing either the current
width or height of the Pen area.
III. Reserve Edges: Allocate the
space for the tablet’s hot cells.
5. Pressure Test: There are four
different colors for selecting
and the pressure sensitivity
of the pen can be adjusted in
this tab. There is a test area to
see the thickness of a line at a
certain pressure of the pen tip
of the pad.
Note: The similar function are
also working on different
Windows and Mac OS.
TOOYAMASTER01EN
