Pentax Optio W80 - Optio W80 - Digital Camera User manual

Thank you for purchasing this PENTAX digital camera.
The Optio W80 is waterproof, dustproof, and shockproof,
as shown below, so you can use it in a wide range of
outdoor activities.
Waterproof/dustproof: JIS grade 8 waterproof and grade 6
dustproof (IP68).
Shockproof: Satisfies Pentax drop test (1 m height onto a
5 cm thick plywood surface) complying with MIL-Standard
810F Method 516.5-Shock testing.
* Waterproof performance is not guaranteed if the camera
is exposed to impact such as being dropped or hit.
* The camera is not guaranteed to be free of trouble
or damage under every condition.
OptioW80_QSG.fm Page -1 Wednesday, July 1, 2009 3:49 PM

To users of this camera
• Do not use or store this device in the vicinity of equipment that generates
strong electromagnetic radiation or magnetic fields.
Strong static charges or the magnetic fields produced by equipment such as
radio transmitters could interfere with the monitor, damage the stored data,
or affect the product’s internal circuitry and cause camera misoperation.
• The liquid crystal panel used in the display is manufactured using extremely
high precision technology. Although the level of functioning pixels is 99.99%
or better, you should be aware that 0.01% or fewer of the pixels may not
illuminate or may illuminate when they should not. However, this has no
effect on the recorded image.
• A band of light may appear on the display if the camera is aimed at a bright
subject. This is known as a smear, but it is not a malfunction.
• There is a possibility that the illustrations and the display screen in this
manual are different from the actual product.
• In this manual, both an SD Memory Card and an SDHC Memory Card are
referred to as SD Memory Cards hereafter.
• In this manual, the generic term “computer(s)” refers to either a Windows PC
or a Macintosh hereafter.
OptioW80_QSG.fm Page 0 Wednesday, July 1, 2009 3:49 PM

1
We have paid close attention to the safety of this product. When using this
product, we request your special attention regarding items marked with the
following symbols.
Warning
• Do not attempt to take the camera apart or modify the camera. High voltages
are present within the camera, and there is a danger of electric shock if the
camera is taken apart.
• If the inside of the camera should become exposed as a result of,
for example, the camera being dropped, please do not under any
circumstances touch such exposed portions, as there is a danger
of receiving an electric shock.
• Wrapping the strap of the camera around your neck is also dangerous.
Please take care that small children do not hang the strap around their necks.
• If any irregularities occur during use, such as smoke or a strange odor,
stop use immediately, remove the battery or the AC adapter, and contact
your nearest PENTAX Service Center. Continuing to use the product can
cause a fire or electric shock.
Caution
• Do not place your finger on the flash when it is discharging as there is a risk
of burns.
• Do not discharge the flash while it is touching your clothing as there is a risk
of discoloring.
• Some portions of the camera heat up during use, so please take care, as
there is a risk of low temperature burns if such portions are held for long
periods of time.
• Should the LCD be damaged, be careful of glass fragments. Also, be careful
not to allow the liquid crystal to get on your skin, in your eyes, or in your mouth.
Warning This symbol indicates that violating this item could cause
serious personal injuries.
Caution This symbol indicates that violating this item could cause
minor or medium personal injuries, or loss of property.
About the Camera
USING YOUR CAMERA SAFELY
OptioW80_QSG.fm Page 1 Wednesday, July 1, 2009 3:49 PM

2
• Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any abnormality,
stop using the camera and get medical attention immediately.
Warning
• Always use the battery charger and AC adapter exclusively developed for
this product, with the specified power and voltage. Using a battery charger
or AC adapter not exclusive to this product, or using the exclusive battery
charger or AC adapter with an unspecified power or voltage can cause
a fire, electric shock, or camera breakdown. The specified voltage is
100-240V AC.
• Do not disassemble or modify the product. This can cause a fire or electric
shock.
• If the generation of smoke or strange odor from the product or other
abnormality occurs, immediately discontinue its use and consult a PENTAX
Service Center. Continuing to use the product can cause a fire or electric
shock.
• If water should happen to get inside the product, consult a PENTAX Service
Center. Continuing to use the product can cause a fire or electric shock.
• If a thunder storm should occur while using the battery charger or AC
adapter, unplug the AC plug cord and discontinue use. Continuing to use
the product can cause damage to the equipment, fire, or electric shock.
• Wipe off the plug of the AC plug cord if it becomes covered with dust.
Dust on the plug may cause a fire.
Caution
• Do not place heavy objects on the AC plug cord, allow heavy objects to drop
onto it or allow the AC plug cord to become damaged due to excessive
bending. If the AC plug cord becomes damaged, consult a PENTAX
Service Center.
• Do not short or touch the output terminals of the product while it is still
plugged in.
• Do not plug in the AC plug cord with wet hands. This can cause an electric
shock.
About the Battery Charger and the AC Adapter
OptioW80_QSG.fm Page 2 Wednesday, July 1, 2009 3:49 PM

3
• Do not subject the product to strong impacts or allow it to drop onto a hard
surface. This can cause a malfunction.
• Do not use the battery charger to charge a battery other than a
rechargeable lithium-ion battery D-LI78. This can cause overheating,
explosion, or battery charger failure.
• To reduce the risk of hazards, use only a CSA/UL certified power supply
cord set, cord is Type SPT-2 or heavier, minimum NO.18 AWG copper,
one end with a molded-on male attachment plug cap (with a specified
NEMA configuration), and the other is provided with a molded-on female
connector body (with a specified IEC nonindustrial type configuration)
or the equivalent.
Warning
• Be sure to store the battery out of the reach of small children. Placing it
in their mouths may cause an electric shock.
• If any leakage from the battery should come in contact with your eyes,
it may cause a loss of sight. Flush your eyes with clean water and get
medical attention immediately. Do not rub them.
Caution
• Only use the specified battery with this camera. Use of other batteries
may cause an explosion or fire.
• Do not disassemble the battery. Disassembling the battery may cause
an explosion or leakage.
• The battery should be inserted correctly, observing (+) and (-) marks on
the battery and the camera. Inserting the battery incorrectly may cause
an explosion or fire.
• Remove the battery from the camera immediately if it becomes hot or
begins to smoke. Be careful not to burn yourself during removal.
• Keep wires, hairpins, and other metal objects away from the + and -
contacts of the battery.
• Do not short the battery or dispose of the battery in fire. This can cause
an explosion or fire.
About the Battery
OptioW80_QSG.fm Page 3 Wednesday, July 1, 2009 3:49 PM

4
• If any leakage from the battery should come in contact with skin or clothes,
it may cause irritation to the skin. Wash the affected areas thoroughly with
water.
• Precautions for D-LI78 Battery Usage:
- USE SPECIFIED CHARGER ONLY.
- DO NOT INCINERATE.
- DO NOT DISASSEMBLE.
- DO NOT SHORT CIRCUIT.
- DO NOT EXPOSE TO HIGH TEMP. (140°F/60°C)
Warning
• To avoid the risk of SD Memory Cards from being swallowed by mistake,
keep them out of the reach of small children. Seek medical attention
immediately if an SD Memory Card is accidentally swallowed.
About SD Memory Cards
OptioW80_QSG.fm Page 4 Wednesday, July 1, 2009 3:49 PM

5
• When traveling, take the Worldwide Service Network listing that is included
in the package. This will be useful if you experience problems abroad.
• When the camera has not been used for a long time, confirm that it is still
working properly, particularly prior to taking important pictures (such as
at a wedding or during traveling). Contents of the recording cannot be
guaranteed if recording, playback or transferring your data to a computer,
etc. is not possible due to a malfunction of your camera or recording media
(SD Memory Card), etc.
• The lens on this camera is not interchangeable. The lens is not removable.
• Storing the battery fully charged may decrease the battery performance.
Avoid storing it especially in high temperatures.
If the battery is left inserted and the camera is not used for a long time,
the battery will over-discharge and shorten the battery’s service life.
• Charging the battery a day before use or on the day of use is
recommended.
• The AC plug cord supplied with the camera is for exclusive use with the
battery charger D-BC78. Do not use it with any other equipment.
• Hot and humid places should be avoided. Particular care should be taken
regarding vehicles, which can become very hot inside.
• Ensure that the camera is not subjected to substantial vibrations, shocks,
or pressure as this may cause damage, malfunction, or a loss in waterproof
performance. Place the camera on a cushion for protection when the camera
is subjected to the vibrations of a motorbike, car, ship, etc. If the camera is
subjected to substantial vibrations, shocks, or pressure, take your camera
to your nearest PENTAX Service Center and have it checked.
• The temperature range in which the camera can be used is -10°C to 40°C
(14°F to 104°F).
• The liquid crystal display will become black at high temperatures but will
return to normal at normal temperatures.
Before Starting Use
About the Battery and Battery Charger
Cautions when Carrying and Using the Camera
Care to be Taken During Handling
OptioW80_QSG.fm Page 5 Wednesday, July 1, 2009 3:49 PM

6
• The response speed of the liquid crystal display becomes slow at low
temperatures. This is due to the properties of the liquid crystal and is
not a malfunction.
• If the camera is subjected to rapid temperature changes, condensation may
form on the inside and outside of the camera. Therefore put the camera
in a bag or plastic bag and take the camera out when the difference
in temperature has subsided.
• Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salts.
These could cause the camera to breakdown. Wipe dry any rain or water
drops on the camera.
• Please do not press forcefully on the display. This could cause it to break
or malfunction.
• Be careful not to sit down with the camera in your back pocket as this may
damage the exterior of the camera or the display.
• When using a tripod with the camera, be careful not to overtighten the
screw in the tripod socket on the camera.
• Do not clean the product with organic solvents such as thinner, alcohol
or benzene.
• Use a lens brush to remove dust accumulated on the lens. Never use
a spray blower for cleaning as it may damage the lens.
• Avoid storing the camera where pesticides and chemicals are handled.
Remove the camera from its case and store it in a well-ventilated place
to prevent the camera from becoming moldy during storage.
About Repairs
About Storage
OptioW80_QSG.fm Page 6 Wednesday, July 1, 2009 3:49 PM

7
• This camera is provided with a waterproof/dustproof design complying with
JIS waterproof grade 8 and JIS dustproof grade 6 (equivalent to IP68).
• The camera satisfies the PENTAX drop test (1 m height onto a 5 cm thick
plywood surface) complying with MIL-Standard 810F Method 516.5-Shock
testing.
• Waterproof performance is not guaranteed if the camera is exposed to
impact such as being dropped or hit.
• The camera is not guaranteed to be free of trouble or damages under every
condition.
• To enhance the waterproof performance of the camera, the front of the lens
is protected by glass. As any dirt or water on the glass will affect the quality
of pictures taken, the glass should be kept clean at all times.
• Leaving the camera on the sand at the beach may cause the camera to
exceed its operating temperature or cause the speaker or microphone
to become blocked with sand.
• The camera will sink if dropped in water, so be sure to attach the strap and
slip the strap over your wrist when using the camera in or near water.
• Be sure to check that the battery/card/terminal cover is securely locked
before using the camera in an environment where it is likely to get wet or
dirty, such as underwater or at the beach. Water, sand or dirt inside the
camera may cause failure of the camera. Wipe off any water or dirt with
a dry cloth as soon as possible after using the camera.
• Avoid opening the battery/card/terminal cover at the beach or by the sea.
Wait until the camera is completely dry before changing the battery or the
SD Memory Card. Avoid changing the battery or card where the camera
is likely to get wet or dirty, and make sure that your hands are dry.
• If the camera is very dirty or after it has been used in the sea, make sure
that it is turned off and the battery/card/terminal cover is firmly closed before
rinsing it under running tap water or leaving it in a bowl of clean water for
a short time (2 or 3 minutes).
• Avoid cleaning with agents such as soapy water, mild detergents, or alcohol
as this may compromise the waterproof performance of the camera.
Regarding Waterproof, Dustproof, and Shockproof Design
OptioW80_QSG.fm Page 7 Wednesday, July 1, 2009 3:49 PM

8
• Wipe off any dirt or sand on the waterproof packing or the packing contact
surface. The camera’s waterproof performance may be compromised by
loose packing or cracks or dents in the packing or packing contact surface.
If there is any such damage, contact your nearest PENTAX Service Center.
• To maintain the waterproof performance of the camera, you are
recommended to change the waterproof packing once a year. Contact your
nearest PENTAX Service Center regarding changing the packing.
(A charge will be made.)
• Avoid subjecting the camera to substantial vibrations, shocks, or pressure
as this may cause a loss in waterproof performance. If the camera is
subjected to substantial vibrations, shocks or pressure, take your camera
to your nearest PENTAX Service Center and have it checked.
• Avoid getting sunscreen or sun oil on the camera as it may cause
discoloration of the surface. If any oil gets on the camera, wash it off
immediately with warm water.
• The camera’s accessories are not waterproof.
• Periodic checks are recommended every 1 to 2 years in order to maintain
high performance.
• Please note that formatting an SD Memory Card or the built-in memory will
delete all data; however it may still be possible to recover that data using
off-the-shelf data recovery software. Please manage your camera memory
at your own risk.
Others
OptioW80_QSG.fm Page 8 Wednesday, July 1, 2009 3:49 PM

9
MENU
LandscapeLandscape
For capturing landscape
views. Enhances colors
of sky and foliage
1 / 2
1/2
OK
OK
OK
Cancel
Cancel
OK
Cancel
Checking the Contents of the Package
Check that your camera comes complete with the items
listed below.
PCamera (Optio W80) PStrap (O-ST20)
PSoftware (CD-ROM) S-SW87 PUSB cable (I-USB7)
PAV cable (I-AVC7) PRechargeable lithium-ion battery
(D-LI78)
PBattery charger (D-BC78) PAC plug cord
POperating Manual OQuick Guide (this guide)
OptioW80_QSG.fm Page 9 Wednesday, July 1, 2009 3:49 PM

10
Front
Back
Speaker
Shutter release button
Microphone
Power switch/Power lamp (green)
Flash
Self timer lamp/Focus
assist
Lens
Lens
Display
Battery lock lever
Battery/card/terminal cover
lock lever
Tripod socket
Battery/card/terminal cover
PC/AV terminal
Names of Parts and Monitor Indicators
In this Quick Guide, the arrow keys
to be pressed are indicated as
shown on the right.
OptioW80_QSG.fm Page 10 Wednesday, July 1, 2009 3:49 PM

11
zMonitor Indicators
The following indicators are displayed in the Still Picture Capture Mode.
Battery Level Indicator
You can check the battery level by the indicator on the display.
Screen Display Battery Status
(green) Adequate power remains.
(green) Battery is running low.
(yellow) Battery is running very low.
(red) Battery is exhausted.
[Battery depleted] The camera turns off after this message appears.
Normal display in the Still Picture Capture Mode
World Time setting
Battery level
indicator
Focus Frame
EV Compensation
F5.6
1/250
F5.6
1/250
14:25
14:25+1.0+1.0
3838
07/07/200907/07/2009
F3.5F3.5
1/250
1/250
Digital Zoom/Intelligent Zoom icon Memory status
Focus mode
Drive mode
Flash mode
Shooting mode
Face Priority
icon
Aperture
Shutter
speed
D-Range
icon
Date
and
time
Pixel Track
SR icon
Date Imprint setting
Remaining image
storage capacity
+Built-in memory (without
card)
?SD Memory Card
rCard is write-protected
No icon : Hometown
: Destination
OptioW80_QSG.fm Page 11 Wednesday, July 1, 2009 3:49 PM

12
Prepare your camera for use before you begin using it.
zAttaching the Strap
Attach the strap supplied with
the camera as shown in the
illustration.
zInstalling the Battery and SD Memory Card
Install the battery and SD
Memory Card as shown
in the illustration.
* The SD Memory Card is sold separately.
Battery/card/
terminal cover
Battery
lock
lever
The inside of the battery/card/terminal cover is not waterproof
• In locations where the camera is exposed to water or dirt such as
underwater, at the beach, in a kitchen, etc., make sure that the battery/
card/terminal cover lock lever is firmly locked so that it won't open
unexpectedly. Do not open the cover in such locations.
• When removing the battery or card, avoid surroundings where the
camera may be exposed to water or dirt, and make sure the camera,
battery, card, and your hands are completely dry.
Preparing the Camera for Use
1
1
Battery/card/terminal cover
lock lever
SD Memory Card
Battery
SD Memory Card socket
OptioW80_QSG.fm Page 12 Wednesday, July 1, 2009 3:49 PM

13
zPress the Power Switch
The camera turns on and is
ready to take still pictures.
Press the power switch
again to turn the camera off.
zSetting the Language, Date and Time
The language selection screen appears when the camera is turned
on for the first time. Select the desired language and then set the
date and time.
Use the four-way controller
(2345) to select the desired
language.
Press the OK button.
If you accidentally select the wrong
language, press the four-way
controller (5), use the four-way
controller (2345) to select the
correct language, and then press the
OK button. The Initial Setting screen
appears in the selected language.
MENU
Cancel
English
Nederlands
Svenska
Italiano
Dansk
OK
Deutsch
Polski
Magyar
Suomi
OK
1
2
2
Memo
Initial Setting
MENU
Cancel
English
DST
OFF
OFF
OFF
Hometown
New York
Settings complete
Turning the Camera On
2
2
OptioW80_QSG.fm Page 13 Wednesday, July 1, 2009 3:49 PM

14
Press the four-way controller (3)
to move the frame to [Hometown].
Press the four-way controller (5) to display the Hometown
screen.
Use the four-way controller (45) to choose the city.
Press the four-way controller (3) to move the frame to [DST]
(Daylight Saving Time).
Use the four-way controller (45) to select O(On) or P(Off).
Press the OK button to display the Initial Setting screen.
Use the four-way controller (3) to select [Settings complete]
and press the OK button.
Use the four-way controller (23) to select [Date Format].
Press the four-way controller (5)
to select [mm/dd/yy], then use
the four-way controller (23) to
choose the date display style.
Press the four-way controller (5)
to select [24h], then use the four-
way controller (23) to select [24h]
(24-hour display) or [12h] (12-hour
display).
Initial Setting
Cancel
English
Hometown
New York
Settings complete
MENU
DST
OFF
OFF
OFF
3
4
5
6
7
8
9
10
Date Adjustment
Cancel
Date Format
Date
Time
00:00
01/01/2009
MENU
mm dd yy// 24h
Settings complete
11
12
OptioW80_QSG.fm Page 14 Wednesday, July 1, 2009 3:49 PM

15
Press the four-way controller (5), then press the four-way
controller (3) to move the frame to [Date].
Press the four-way controller (5) to select [01] (month),
[01] (day) or [2009] (year), then use the four-way controller (23)
to set the date to the current day.
Press the four-way controller (5), then press the four-way
controller (3) to move the frame to [Time].
Set the time in the same manner as in .
Use the four-way controller (3) to select [Settings complete].
Press the OK button.
zFormatting an SD Memory Card
Use this camera to format (initialize) an SD Memory Card that is
unused or has been used on another camera or digital device.
Be aware that formatting deletes all the data stored in the SD
Memory Card.
13
14
15
15
16 14
17
17
17
18
OptioW80_QSG.fm Page 15 Wednesday, July 1, 2009 3:49 PM

16
Aim the camera at the subject, then press the shutter release
button. The flash discharges automatically depending on
the brightness.
Frame the subject using the focus frame on the display.
Press the w/xbutton to change the captured area.
Press the shutter release button halfway.
The focus frame on the display turns green if the subject
is in focus.
Press the shutter release button
fully.
The picture is taken.
2
1
2
2
Widens the area
that is captured
by the camera
Enlarges the
subject
2
3
F 3 . 5
1 / 2 5 0
F3.5
1/250
14:25
1 4 : 2 5
14:25
38
3 8
38
0 7 / 0 7 / 2 0 0 907/07/2009
2
4
Taking Pictures
3
3
OptioW80_QSG.fm Page 16 Wednesday, July 1, 2009 3:49 PM

17
zSelecting the Flash Mode
Each time you press the four-way controller (4), the flash mode
switches between the following modes.
The functions available in Capture mode may be different.
zSelecting the Drive Mode
Each time you press the four-way controller (2), the drive mode
switches between the following modes.
Auto
Flash Off
Flash On
Auto + Red-eye
Flash On + Red-eye
Soft Flash
Memo
Standard (single-frame)
10 sec. Self-timer
OptioW80_QSG.fm Page 17 Wednesday, July 1, 2009 3:49 PM

18
• The functions available in Capture mode may be different.
• You can select Z(2 sec. Self-timer) by pressing the four-way
controller (3) and then (5) after selecting g(10 sec. Self-timer).
zSelecting the Focus Mode
Each time you press the four-way controller (5), the focus mode
switches between the following modes.
Memo
Standard
Macro
1cm Macro
Pan Focus
Infinity
Manual Focus
OptioW80_QSG.fm Page 18 Wednesday, July 1, 2009 3:49 PM
