Pa ge 2 Pentek Model 4284 Operating Manual
Pentek Model 4284 Operating Manual − Revision History
References made in this manual to the Texas Instruments TMS320C4 User's Guide are made specifically to Revision C of that publication, dated August 1993
WARRANTY
Pentek warrants that all products manufactured by Pentek conform to published Pentek specifications and are free from defects in mate−
rials and workmanship for a period of one year from the date of delivery when used under normal operating conditions and within the
service conditions for which they were furnished
The obligation of Pentek arising from a warranty claim shall be limited to repairing or at its option, replacing without charge, any product
which in Pentek’s sole opinion proves to be defective within the scope of the warranty
Pentek must be notified in writing of the defect or nonconformity within the warranty period and the affected product returned to Pentek
within thirty days after discovery of such defect or nonconformity
Buyer shall prepay shipping charges, taxes, duties and insurance for products returned to Pentek for warranty service Pentek shall pay
for the return of products to buyer except for products returned from another country
Pentek shall have no responsibility for any defect or damage caused by improper installation, unauthorized modification, misuse, neglect, inade−
quate maintenance, accident or for any product which has been repaired or altered by anyone other than Pentek or its authorized representatives
The warranty described above is buyer’s sole and exclusive remedy and no other warranty, whether written or oral, is expressed or implied
Pentek specifically disclaims fitness for a particular purpose Under no circumstances shall Pentek be liable for any direct, indirect, special,
incidental or consequential damages, expenses, losses or delays (including loss of profits) based on contract, tort, or any other legal theory
Date Rev Applicable Serial #’s Comments
01/03/94 Pre 9401003 − 9441043 Initial Product Release − Manual generated by Engineering Dept
06/03/94 A 9401003 − 9441043 Complete rewrite, reformat and update Changed pinout of TCK connector Added Software
examples and Appendices
06/10/94 A 1 9401003 − 9441043 Added header file listings to sample 4284 setup code in Appendix A, Section A 1
07/08/94 B 9401003 − 9441043 Listed Pentek part # for ordering Comm Port cables Minor change to detail block diagram Add
section 4 8 on memory usage & table of transfer times
10/11/94 B 1 9401003 − 9441043 Changes to Tables 4−8 to properly represent transfer timing for 50 MHz 'C40 Delete Table 4−9 &
refer to 'C40 Manual for DMA timing info Changes to Sections 2 11 4 and 3 2 1, regarding which
signals are inputs and which are outputs
11/11/94 B 2 9401003 − 9441042 Correct pin numbering error in Table 2−12 System Clock jumper installed between pins 1−2, not 11−12
12/29/94 C 9441043 − Forward New features: Flash EEPROM and Turbo−MIX Properly identify jumper blocks SW1 and SW2 in
Figure 2−2 Expanded discussion of Reset Operation Add more transfer timing tables for 40 and
50 MHz parts, using block repeat, DMA and Turbo−MIX Descriptions of these tables updated
Turbo−MIX example added to Appendix A Flash EEPROM programming code added to Appen−
dix A Update Boot Code in Appendix B
01/27/95 C 1 9441043 − Forward Add info re:Option 010, in which A32 address is independent of A24 address, and Memory Window
jumpers affect A24 window only Correct Table 2−2 (A16 address 8700 is reserved) A24 inhibit bit also
prevents A32 access This change affects Section 2 4 3, Section 3 11 2 4, and Table 3−12
01/05/96 C 2 9441043 − Forward Mention FTL in Section 1 9 (Software Support) Add info on mating connector for front panel Serial
and GPIO connectors (Sec 2 11) Add Section 2 14, describing blinking of Front Panel LED on
power−up Correction to note in Section 4 2 1, reference to EPROM rev should be Revision E, not B
Indicate that use of the Linker Command File shown in Sections 4 3 1 and A 6 requires a change to
main Changes to Hex File Loader & Starter in Section A 7
09/10/96 D 9441043 − Forward Sec 3 8 5: 'C40 Int to VME Status bit in Transfer Mode Reg is accessible to the 'C40 (not VME) for read
only Add Tables & Figures to Table of Contents Update MIX Appendix to Rev F 1
07/02/97 D 1 9441043 − Forward IACK Vector Register must be re−written to clear VME interrupts generated by 4284 This infor−
mation added as a Note in Section 3 11 1, and to text in Section 4 6 1
09/22/97 D 2 9441043 − Forward Section 4 2 1 − The code that triggers a boot from Flash EEPROM is A55A 5AA5, not A55A A55A −
this changes the last paragraph on pg 52, the first paragraph on pg 53, Table 4−4, and the first
paragraph on page 57
05/04/98 E 9441043 − Forward Add Parallel C to Software Development Support section (1 9) Replaced board diagram with VSB ver−
sion of board Added section 3 12 on VSB Modified Table 3−7 to include VSB addresses
05/21/98 E 1 9441043 − Forward Revisions to VSB section (3−12) − renamed Table 3−14 (VSB Control Register) and renamed some bits
in the table Add Tables 3−15 − 3−17 illustrating bit field usages in VSB Control Register Add VSB
interface to Detailed Block Diagram (Fig 4−1) In SW Development Support section (1 9) Parallel C is
now called Diamond
7/23/98 E 2 9441043 − Forward Correct & cross reference to Table 3−16 in Table 3−14
10/12/98 E 3 9441043 − Forward Correct address range for VME Master Access in Table 3−7 (0xB000 0000 − 0xBFFF FFFF)
10/22/98 F 9441043 − Forward Regardless of DRAM Window size, DRAM must be mapped on an address bounmdary that is a multiple
of the actual DRAM size This changes text in Secs 2 4 2 and 2 4 3, and Tables 2−5 − 2−7, and deletes
Tables 2−8 & 2−9 (these tables all concerned base address vs window size) Add note to Sec 2 4 3 indi−
cating that for DRAM access, each ‘C40 address is equivalent to four VME addresses Reinforce same
concept in Sec 4 10 Give VME address of DRAM in Sec 3 10 & add a note to the ‘C40 memory Map stat−
ing that DRAM is shared w/ VME Sec 4 2 3 − Host Control Reset does NOT reset MIX or VSB Change
timer address in Sec A 4 (1st executable line under main()) to 0x100020 Remove MIX Appendix & refer−
ences to it (this info now included in 800 00001)
12/06/99 F 1 9441043 − Forward Sec 1 9 − Removed SPOX, FTL & Diamond from Software Support list Corrections to Tables 2−5 thru
2−7, which were correct up until last Rev Sec 2 1 2 1 − Comm Port Cable is Model 2104, not 2014 Table
4−3: Removed extra ‘0’ in last row of address column Added NOTEs to Sec’s 4 2 4 & 4 3 5 about initial−
izing the Local Control Register if you do not boot from the factory EPROM Remove Sec 4 4 2 (Down−
loading SPOX programs), and the sentence referencing SPOX in Sec 4 4
7/26/00 F 2 9441043 − Forward Sec 1−12: delete reference to Opt 060 Additional corrections to Tables 2−5 thru 2−7 Update Boot Code
listing in Appendix B
