Perception Kayak User manual

Owner’s Manual

Thank you
CONTENTS
3 Kayak Anatomy
4 Outfitting & Features
5 Transportation
6 Storage
7 Care & Maintenance
8 Safety
9 Accessories
10 Warranty
11 Service & Support
Thank you for choosing Perception. Now it’s time to embark on your
adventures in the most dependable kayak on the market. At Perception, our
heritage of quality and innovation is built into every boat.
Kayaking is a fun and exciting way to experience the outdoors, or to enjoy
an active means to hang out with friends and family. We hope you make the
most out of the opportunities available both close to home and afar.
With proper care, your Perception kayak will provide years of satisfaction.
Most importantly, our kayaks are designed to grow with you, and with
proper knowledge and training there’s no limit to where you’ll end up.
This owner’s manual and additional information is available at perceptionkayaks.com.

3
A
A
F
A
A
B
A
A
BOW
BOW
STERN
STERN
D
B
B
B
C KK
C
E
D
HJ G
I
F
EE
SIT ON TOP
A: Carry handles
B: Tankwell with bungee
C: Seating system
D: Footwells
E: Self-bailing scupper holes
F: Skid plate
SIT INSIDE
A: Carry handles
B: Cargo hatches
C: Seating system
D: Safety lines
E: Bungee
F: Foot braces
G: Thigh braces
H: Cockpit coaming
I: Rudder*
J: Rudder liftlines*
K: Bulkhead*
*Not available on all models
kayak anatomy

4
outfitting & features
SIT ON TOP SEATING (SOT)
Adjust the rear nylon straps first until the seatback is
in the upright position. The straps should be tight.
Next adjust the front nylon straps until seatback is in
a firm vertical position.
ZONE®DLX SEATING
The padded seatback adjusts forward and back with the
strap behind the seatback. Tighten the backrest by
pulling forward on the nylon strap behind the seat or
loosen it by pushing on the thumb tab. For good
rotation while paddling it shouldn’t be too tight.
The backrest may also be raised by pulling the toggle
strap at the front of the seat forward and the backrest
can be lowered by pushing the chrome button down.
The leg lifters located at the front part of the seat are
adjusted with the two straps to the sides of the seat. Pull
up to raise or push on the thumb tab to lower.
ZONE®EXP
To adjust the backband t, tighten or loosen the strap
with the larger webbing ladderlocks found on the
backside of the strap. Fine tune the height adjustment
with the three smaller webbing straps.
The adjustable thigh pads found on some touring and
sea kayak models are adjusted by removing the front
screw and loosening the back screw. Slide the thigh pad
forward or back and in and out to nd a comfortable
position. Replace the screws and tighten. A good
position for the thigh pad is a couple of inches in front
of your kneecap or where it’s most comfortable.
COMFORT SEATING SYSTEM (CSS)
The lightweight EVA foam seatback adjusts by
loosening the nylon straps and bringing the seatback
into the upright position. Place the two hooks of the
bungee cord threaded through the seat back into
the two deck fitting locations behind the seating well.
Seating systems vary by model. If you need additional
assistance on using the adjustment mechanisms,
please visit our website at perceptionkayaks.com.
KEEPERS™FOOT BRACES
The adjustment lever is located
on the backside of the footpedal.
To adjust, squeeze the lever and
slide the footpeg to the desired
location. Release the lever to lock
it in place.
USING THE RUDDER SYSTEM
After market rudder systems are available.
Please contact your local dealer for any questions
regarding setup or installation, or visit
perceptionkayaks.com for video instruction.
Once your rudder is installed, use the lift line
(located on the right side of the boat, toward the rear
of the cockpit) to drop the rudder into the water by
pulling it forward.
To operate the rudder, use the footbrace pedals. To
maintain a straight position, both pedals should be
even with each other. To steer the kayak right, push
the right pedal away from you. To steer the kayak
left, push the left pedal away from you. Allow the
pedal that is not in use to automatically move
towards you when the other pedal is pushed.
HATCH COVERS
To remove the covers, find the tab and peel off. To
replace the cover, hook it under the hatch rim and
press it on firmly the entire way around.
KAJAK SPORT
HATCH COVERS DUAL DENSITY
HATCH COVERS

5
transportation
ROOF RACK
A crossbar roof rack (“sports rack”), or “J cradle” for
your vehicle is the best method of transporting a
kayak. It should be lashed down at each crossbar, as
well as at the bow and stern to each end of the
vehicle. Kayak cradles are recommended for boats
being transported “at” to lessen chances of
deformation from being lashed too tightly to the bars.
Rotomolded kayaks can be transported on their edge or
upside down (hull up) safely using kayak stackers. For
Airalite kayaks we recommend that they be transported on
their bottom using cradles to prevent deformation.
USING FOAM BLOCK RACKS
Foam block racks can be used for transporting
kayaks if extreme caution is practiced in rigging the
load. They should be wide enough for adequate
support. The boats must be securely attached to
the top of the vehicle through the doors or windows
and attached securely to both the front and back of
the vehicle. If these tie down points at the front and
back aren’t available on your vehicle, foam block
racks should NOT be used.
INCLEMENT WEATHER
If traveling when inclement weather is threatening,
position the kayak upside down if possible. A kayak
heavy with water can become dangerous. Use a
portage cover to seal the cockpit if an upside down
position is not possible. Periodically check your
straps to ensure they have not stretched while wet.
ROTOMOLDED
ROTOMOLDED
AIRALITE
IMPORTANT:
Always check your tie down rigging often as
ropes and straps may loosen in transport.

6
storage
SHORT TERM STORAGE
Be sure to empty the kayak of all water. The kayak
may be stored on its side or in a vertical position
temporarily. Storage in these positions for an
extended period of time could cause flattening or
deformation in the side of the hull.
LONG TERM STORAGE
In addition to emptying all water out, you should
clean the kayak by rinsing with freshwater especially
if the kayak has been used in salt water or becomes
muddy. Store out of direct sunlight and indoors, if
possible. UV exposure can shorten the lifespan of
any kayak and can degrade its finish. Kayaks can be
stored slung on their sides via web straps,
positioned 1/3 of the way along the hull (as shown).
Be sure to not leave straps or ropes tightly wound
around the hull for extended periods of time as it
may cause deformation.
Your kayak can also be stored hull up (as shown) on
parallel bars with weight supported evenly
throughout its length. For large cockpit
(recreational) boats, position the bars so that the
cockpit coaming rests on the bars. For smaller
cockpit kayaks, position bars so that they contact
the deck between the cockpit and any hatches.
CAUTION:
Do not suspend your kayak by using the grab loops
at either end of the boat. This can cause the hull to
distort over time.

7
care & maintenance
ROTOMOLDED KAYAK CARE
Our “roto” kayaks are made of high-density linear
polyethylene, which is virtually maintenance free. A
minimal amount of care in storage and transporting
will help the kayak maintain a like-new condition for
many years.
Polyethylene will become more flexible when in warm
conditions such as a hot, sunny day. It is possible for
a kayak strapped tightly to a roof rack to temporarily
deform at the weight bearing points. Use a padded
rigid bar sport rack in addition to a kayak J cradle or
saddles to disperse the weight.
CLEANING
Usually, a quick rinse of fresh water is all that is necessary
to keep your hull clean and functioning in good order.
This is very important after paddling in salt water,
especially if your boat is outtted with a rudder system.
Be sure to thoroughly rinse the rudder, rudder cables,
and footbraces with fresh water to remove salt residue.
Supercial scratches may occur, but can be removed or
reduced by use of a marine boat polish designed for
polyethylene hulls. Sanding or use of an abrasive
rubbing compound is not recommended.
To keep your kayak shining and minimize the long-term
degradation caused by UV exposure, use an ultraviolet
protectant such as 303 Protectant. 303 can also be used
lightly on the top of the hatches and on the seat
outtting and plastic buckles and straps, in addition to
the kayak itself. 303 is available at your local Perception
dealer or online at harmonygear.com.
WARNING:
Avoid dragging kayak across the ground to
prolong its life and maintain its look and
performance. Two people, utilizing the carrying
handles, is the best way to transport the boat.
Alternately, you can transport using a kayak cart,
available at your dealer or at harmonygear.com.

8
safety
Any person using kayaks built and/or sold by
Perception is personally responsible for determining
that their abilities are equal or superior to the
conditions encountered and exercising proper
judgment in choice of where and when to paddle.
Any person using Perception kayaks assumes all risks
and takes complete responsibility for any and all
damages, or injuries, including death, which may result
from use of or participation in Perception kayaks.
Consult your physician prior to beginning your
paddlesport training.
DON’T:
• Never exceed your ability and assess how far and
how long you can paddle or swim.
• Never paddle alone.
• Never consume alcohol, drugs, or any other
substance that may affect your coordination,
judgment, or ability when paddling.
• Never paddle in flood conditions.
• Never allow minors to use the boat without adult
supervision.
• Avoid bracing yourself in the kayak in such a way
that you have to release any outtting to escape.
• Do not impair entry or exit access to the kayak
when installing additional outtting.
DO:
• Wear a Coast Guard approved personal flotation
device (PFD).
• Wear a helmet when paddling whitewater or in
the ocean.
• Get paddlesports instruction from a licensed or
certified instructor.
• Dress appropriately for weather conditions; cold
water and/or weather can result in hypothermia.
• Check your equipment prior to each use for signs
of wear or failure.
• Scout unfamiliar waters. If necessary, paddle to
shore and carry your boat past uncertain areas.
• Stay aware of appropriate river water levels, tidal
changes, dangerous currents, and weather
changes.
• Follow manufacturer’s recommendations for use
and outfitting of your kayak.
• Leave your paddling location and agenda with
someone at home before departing.
• Obtain certified first aid and rescue training and
carry first aid and rescue equipment.
WARNING:
Kayaking can be hazardous with potential risk of
serious injury and even death.

9
accessories
ANGLER ACCESSORIES:
Angler versions are customized for each model
and include all or some of the following
accessories.
• Flush Mount Rod Holders
• Scotty Bait Caster Rod Holder
• Molded-In Rod Holders
• Molded-In Ruler
• Stand-Up Assist Strap
• 3.5 lb Anchor Kit
• Anchor Trolley
• Anchor Cleat
OTHER ACCESSORIES:
There are a wide variety of accessories designed
for your kayak to enhance the performance and
overall experience. Not all accessories are
available for all models.
SPRAYSKIRT
For longer trips or rougher conditions, a sprayskirt is
worn by the paddler to create a watertight seal,
preventing the cockpit from filling up with water.
DRY BAG
Ultra-light and water-resistant storage for an extra
level of protection and accessibility for gear.
ESSENTIALS CHECKLIST:
PERSONAL FLOTATION DEVICE (PFD)
A USCG approved, comfortable and secure fitting
PFD should be worn at all times. Shorter PFDs are
available that are ideal for kayak paddling.
PADDLE
Choosing a paddle is almost as important as your
choice of boat. Blade shape, length, weight, and
material all offer different experiences. On longer
trips, it is strongly recommended that you have a
spare paddle that can be easily stowed on your deck.
SAFETY EQUIPMENT
USCG regulations require an audible signal device (a
horn or whistle) to be used in all watercraft. In addition,
it is recommended that all paddlers carry a bilge pump
(to drain water from the kayak), and a paddle oat.
Be sure to secure training in the operation of a paddleoat.
PERSONAL GEAR
There are many items that you may wish to take with you
on a paddling trip. Your location, length of journey, group
size, weather, etc. will all play a part in this “essentials list.”
• Drinking water
• Snacks
• Extra clothes in a drybag
• Map or chart
• First- Aid
• Matches
• Sun protection
To help you learn about the logistics of a paddling trip and
correct paddling technique we strongly recommend a
good beginner-level paddling course from a certied
instructor.
A COMPLETE LINE OF OUR ACCESSORIES CAN BE
FOUND ONLINE AT HARMONYGEAR.COM

10
3-year limited warranty
Perception at its manufacturing facility, the Consumer
will be responsible for a $50.00 shipping and handling
fee.
If service is required in a country that is not the country
of purchase, Consumer will comply with all applicable
export laws and regulations and be responsible for all
customs duties, value add tax (VAT), and other
associated taxes and charges. For international service,
the Perception Distributor may repair or exchange
defective products and parts with comparable products
and parts that comply with local standards.
Conuence Outdoor retains the right to satisfy warranty
via repair or replacement of products or of components
deemed defective. In addition, Perception reserves the
right to replace original kayaks or equipment with
comparable current products.
LIMITATIONS AND EXCLUSIONS
This limited warranty does not apply to:
• Normal wear and tear and aging of product.
• Kayaks damaged by extreme weather or
environmental conditions.
• Kayaks damaged while in possession of a freight
carrier, a dealer, Consumer, or any party other than
Perception.
• Kayaks damaged by accident, neglect, improper use
or handling.
• Kayaks that have been towed by power or sail
boats.
• Kayaks designated as Prototypes.
• Kayaks sold as “demos” or in “as is” condition.
• Kayaks determined to have been used for any
activity other than an activity which is customary for
the product.
• Kayaks that have been structurally or dimensionally
altered or modied.
TERMS AND CONDITIONS
For the original retail purchaser (“Consumer”),
Perception kayaks by Conuence Outdoor are
warranted against material or manufacturing defects in
the hull and deck for three (3) years from date of original
purchase of the kayak.
Parts, accessories, and outtting are warranted for a
period of one (1) year against material or manufacturing
defects from the date of purchase.
Perception kayaks sold as “2nd Quality” as indicated on
the Manufacturer’s Statement of Origin (MSO),
Conuence Outdoor provides this limited warranty for
one (1) year for the hull and deck and one (1) year for
parts, accessories, and outtting.
This limited warranty is only valid with the purchase of a
Perception kayak from an authorized Perception dealer.
This warranty is non-transferable.
HOW TO REGISTER YOUR BOAT
The warranty registration form should be completed
online at perceptionkayaks.com within 30 days of
original purchase to be activated. It is suggested that
you keep your sales receipt should it be required in the
future for proof of purchase.
OBTAINING WARRANTY SERVICE
If you have a problem with your kayak and you suspect
that it may be due to defective materials or
workmanship, contact the nearest authorized Perception
kayak dealer and arrange to have the problem
inspected. Consumer is responsible for delivery to, and
pickup from, the closest authorized dealer.
If the authorized Perception dealer’s inspection indicates
a defect that is attributable to materials or workmanship,
Conuence Outdoor will repair or replace your
Perception kayak free of charge at the company’s option.
Proof of purchase such as a sales receipt may be
required. If repairs or evaluation are required by
• Kayaks used for commercial or rental purposes.
This limited warranty excludes all other warranties,
expressed or implied, including implied warranties of
merchantability and tness for a particular purpose, with
regard to Perception Kayaks. Some state, country, or
provincial laws do not allow the exclusion of certain
implied warranties, so the above exclusion may not
apply to you.
This limited warranty excludes any incidental or
consequential damages or expenses resulting from any
defects. Conuence Outdoor’s aggregate liability shall
be limited to an amount equal to Consumer’s original
purchase price paid for the defective product. Some
state, country, or provincial laws do not allow the
exclusion or limitation of incidental or consequential
damages, so the above exclusion may not apply to you.
To the extent any limitation or exclusion contained herein
is contrary to any country, state, or provincial law, such
limitation or exclusion shall be severable and all other
terms herein shall remain in full force and effect and are
valid and enforceable.
This warranty gives you specic legal rights and you may
also have other rights. For Consumers who are covered
by state, country or provincial consumer protection laws
or regulations, the benets from this warranty are in
addition to all rights conveyed by such consumer
protection laws and regulations.

11
IMPORTANT INFORMATION
Boat Model:
Serial Number:
Date of Purchase:
Dealer Name:
FINDING YOUR SERIAL NUMBER
The serial number is located near the stern (rear) of
the boat, just below the line where the deck and side
meet. On most boats it is engraved in an indention on
the right side of the boat.
NOTICE: STATE REGULATIONS
Some states require that all kayaks be registered. To
register your kayak you will need your Manufacturer’s
Statement of Origin (MSO). This serves as the title to
your kayak and should have been provided when you
took delivery. If not, check with your retailer. If it has
been lost, have your dealer contact Perception and
we will provide a replacement.
Note: Make sure the serial number on your MSO
matches that on your hull.
QUESTIONS?
Visit our Frequently Asked Questions section at
perceptionkayaks.com to answer these and many
other commonly asked questions about our kayaks
and accessories:
How do I adjust the seat?
How do I move the footbraces for solo paddling?
How do I install the rudder?
How can I get replacement parts?
What other accessories are available for my kayak?
SERVICE AND SUPPORT
If you have a problem with your kayak that you
believe is covered under warranty, contact the nearest
authorized Perception dealer. You can nd a listing of
all dealers on our website.
If you have additional questions about your kayak or
accessories, please visit our online support webpage
at perceptionkayaks.com for resources or to find
information on contacting a customer service
representative.
CONTACT US
(p) 888-52-KAYAK (888-525-2925)
(f) 888-373-1220
Service and support hours are Monday through Friday
from 9 a.m. to 5:30 p.m. EST.
All warranties and part orders need to be handled
through an authorized dealer, we do not sell direct.
service & support

©2014 Confluence Outdoor
Confluence Outdoor
575 Mauldin Road, Suite 200
Greenville, SC 29607
perceptionkayaks.com
