Perfect Aire 1PAMSHQCW12-15 User manual

12,000 BTU / 15 SEER QUICK CONNECT
With 11,500 BTU Heat Pump
Before using your air conditioner,
please read this manual carefully
and keep it for future reference,
along with your receipt.
Your Source for Home Comfort
FOR MODELS:
1PAMSHQCW12-15
Indoor Wall Unit
1PAMSHQCW12-15
Outdoor Condenser
DUCTLESS MINI-SPLIT
USER MANUAL

Contents
This manual provides the information needed for proper use and maintenance of this air conditioner.
Basic preventative care can help extend the life of this unit. The “Troubleshooting Tips” section in this
manual contains a chart with solutions to the most common problems. Referring to this section may
save time and prevent the need for a service call in the event of a problem.
Safety Precautions
Warning .......................................................................................................................................2
Caution ........................................................................................................................................3
Identification of Parts
Indoor unit....................................................................................................................................4
Outdoor unit.................................................................................................................................4
Display.........................................................................................................................................4
Operating Instructions
Special functions .........................................................................................................................5
Operating temperature ................................................................................................................5
Manual operation.........................................................................................................................5
Airow direction control ...............................................................................................................6
Air conditioner operating modes..................................................................................................7
Care and Maintenance
Before maintenance ....................................................................................................................8
Cleaning the unit..........................................................................................................................8
Cleaning the air lter....................................................................................................................8
Long periods of non-use / Pre-season inspection .......................................................................8
Troubleshooting Tips
Normal function of the air conditioner..........................................................................................9
Troubleshooting guide ...............................................................................................................10
NOTE: All the illustrations in this manual are for explanation purposes only. Unit purchased may
be slightly different.
The design and specications of the air conditioner are subject to change without prior notice for
product improvement. Contact customer service for details.
-1-
• Contact an authorized service technician for repair or maintenance of this unit.
• Contact an installer for installation of this unit if necessary.
• The air conditioner is not intended for use by young children without supervision. Young children should be
supervised to ensure that they do not play with the air conditioner.
• Disabled persons may require assistance with set up.
• If the power cord is to be replaced, replacement work should be performed by authorized personnel only.
• Installation and repair work must be performed in accordance with the national wiring standards by authorized
personnel only.
CAUTION
!

Safety Precautions
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation due to ignoring instructions may cause harm or damage.
Failure to adhere to each of the following precautions can lead to results classied as follows:
WARNING
CAUTION
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to property.
Meanings of symbols used in this manual are as shown below.
!
!
Never do this.
Always do this.
WARNING
! !
• DO NOT attempt to extend the electrical
cable by slicing the wires, and never
use multiple plugs. A poor electrical
connection, poor insulation or voltage
which is higher than permitted can
cause re.
• Avoid prolonged and direct contact with
the cool air blowing from the unit.
• Never insert ngers, sticks or other objects
in the air inlet and outlet vents.
• Never attempt to repair, relocate, or
modify the air conditioner yourself. Always
contact a trained service technician if
required.
• Do not install your air conditioner in a wet
room such as a bathroom or laundry room.
• In the event of any abnormalities such as
a burning smell, immediately turn off the
device and turn off power at the electrical
supply disconnect or main electrical
breaker panel, then contact an authorized
service technician.
• Always contact an authorized service
technician for repair or maintenance of
this unit.
• Installation and repair work must be
performed in accordance with the
national wiring standards by authorized
personnel only.
• Contact an authorized installer for
installation of this unit if necessary.
• The air conditioner is not intended for use
by young children without supervision.
Young children should be supervised to
ensure that they do not play with the
air conditioner.
• Disabled persons may require assistance
with set up and usage.
! !
!
-2-

!
CAUTION
!
Safety Precautions (continued)
• Never ip any switches with a wet hand. It
may cause an electric shock.
• Never use the device for any purpose
other than the intended use.
• Never place food, precision instruments,
plants,animals, paint, etc. on the unit. Do
not expose plants or animals directly to
the air ow from the air conditioner.
• Never clean the air conditioner with water.
• Never use combustible cleaning agents as
these could cause a re or deformation.
• Never place any burning objects close to
the device if they could be directly affected
by the emitted air.
• Never step onto the outdoor device and
never place anything on it.
• Never use an unsteady or rusty base.
• Never install the air conditioner in places
where combustible gas can be emitted.
Emitted gas may collect and cause an
explosion.
• Never allow the air conditioner to run for
too long with the doors or windows open.
• The air conditioned space should be
ventilated periodically.
• Always turn off power at the electrical
supply disconnect or main electrical
breaker panel if the unit is not going to
be used for any lengthy period of time.
Collections of dust can cause re.
• Always turn the air conditioner off during a
storm. Otherwise, electrical parts may get
damaged.
• Check that the condensate drain line
is securely connected. If not, water will
escape.
• Assure that the condensate drain line
slopes away from the indoor unit to
prevent condensate water from damaging
the unit or nearby objects.
• The air conditioner must be grounded in
accordance with the local codes.
• For electrical safety purposes we
recommend that you install an earth-
leakage circuit-breaker.
-3-

Identification Of Parts
Indoor Unit
Front panel
Air inlet
Air lter
Air outlet
 Horizontal air ow grille
 Vertical air ow louver (inside)
Display panel
Outdoor Unit
Connecting pipe
Connecting cable
Stop valve
NOTE: All the pictures in the manual are for explanation purposes only. The actual shape of the unit you purchased may
be slightly different, but the operations and functions are the same.
Air inlet (side) Air inlet (rear)
Air outlet
Display
"run" indicator light
This light illuminates when the air conditioner is powered on.
"timer" indicator light
This light illuminates during timer operation.
"defrost" indicator light
This light illuminates when the air conditioner starts defrosting automatically or when the warm air control feature is
activated in heating operation.
LED Display
Displays the temperature setting when the air conditioner is operating. Should an error occur, the error code will
appear on this display.
Signal Receiver
LED Display
Part Names
-4-

NOTE: The unit must be turned off before operating the
manual control button. If the unit is operational, continue
pressing the manual control button until the unit is off.
1.Open and lift the front panel up to an angle until it remains
xed with a clicking sound.
2.One press of the manual control switch will lead to the
forced AUTO operation. If you press the switch twice
within ve seconds, the unit will operate under forced
COOL operation.
3.Close the panel rmly to its original position.
CAUTION:
• This switch is used for testing purposes only and should
only be used if absolutely necessary.
• To restore the remote control operation, use the remote
control directly.
Special Functions
Refrigerant Leakage Detection
The indoor unit will sound an alarm and display the code "EC" on the LED display panel when the outdoor unit detects a
condition indicating refrigerant leakage.
Louver Angle Memory
The unit will memorize the open angle of the horizontal louver (within the louver's range of safe use).If the louver is placed
outside an angle of safe operation, you can return it to a standard angle by: (1) pressing the manual control button and
(2)turn off power at the electrical supply disconnect or main electrical breaker panel. It is strongly suggested that the
open angle of the horizontal louver is not set too small so air can properly ow from the unit . This will also help avoid
condensation from forming and dropping from the louver.
Operating Instructions
Operating Temperature
Manual Operation
Units are equipped with a switch to run emergency operation mode. It can be accessed by opening the front panel. This
switch is used for manual operation in case the remote control fails to work or maintenance is necessary.
Mode
Temperature Cooling Operation Heating Operation Drying Operation
Room Temperature 62ºF–90ºF (17ºC–32ºC) 32ºF–86ºF (0ºC–30ºC) 50ºF–90ºF (10ºC–32ºC)
Outdoor Temperature 32ºF–122ºF (0ºC–50ºC) 5ºF–86ºF (-15ºC–30ºC) 32ºF–122ºF (0ºC–50ºC)
Note:
1. Optimum performance will be achieved within these operating temperatures. If air conditioner is used outside of the
above conditions, certain safety protection features may come into operation and cause the unit to function abnormally.
2. If the air conditioner runs for a long time in cooling mode and the humidity is high (over 80%), condensed water may
drip out of the unit. In this situation, set the vertical air ow louver to its maximum angle (vertically to the oor) and set
HIGH fan mode.
Suggestion: It is strongly recommended that you maintain electrical supply when the outside ambient temperature is
below 32ºF (0ºC). In this situation, even though the unit is powered off, the unit will use a small amount of power to
keep it from getting too cold and guarantee it will run smoothly when resuming full operation.
AUTO/COOL
AUTO/COOL
Manual Switch
-5-

Operating Instructions (continued)
Airow Direction Control
Adjust the air ow direction properly to avoid discomfort or uneven
room temperatures. Adjust louvers while the unit is in operation
To set the horizontal air ow (left–right):
• Manually adjust the vertical louvers using the deector rod.
To set the vertical air ow (up–down):
• Use the remote control to adjust the horizontal louver.
• The horizontal louver can be moved at a range of 6º for each
press, or swing up and down automatically. Please refer to the
"Remote Control Operation Manual" for details.
IMPORTANT: Do not put your ngers too far into the louvers while
the unit is operating as the high-speed fan inside can cause injury.
CAUTION
• Do not operate the air conditioner for long periods with the
air ow direction set downward in cooling or dehumidifying
mode. Otherwise, condensation may occur on the surface of
the horizontal louver causing moisture to drop onto the oor or
furnishings.
• When the air conditioner is started immediately after it was
stopped, the horizontal louver might not move for approximately
10 seconds.
• The open angle of the horizontal louver should not be set too
small as this may restrict air ow; COOLING or HEATING
performance may be impaired as a result.
• Do not move the horizontal louver manually; doing so will cause
the horizontal louver to be out of sync. If the horizontal louver is
accidentally adjusted manually, please turn off the unit, wait 10
seconds, then turn the air conditioner back on.
!
Range
Deector Rod
Range
-6-

Operating Instructions (continued)
Air Conditioner Operating Modes
AUTO Mode
• When you set the air conditioner in AUTO mode, it will automatically select cool, heat, or fan only operation depending
on set temperature and the room temperature.
• The air conditioner will control room temperature automatically to the temperature point you set.
SLEEP Mode
• When you push SLEEP button on remote control during cool, heat, or AUTO operation, the air conditioner will
automatically increase (cooling) or decrease (heating) 2ºF (1–2ºC) per hour for the rst 2 hours, hold steady for the next
5 hours, and then switch off.
• This mode saves energy while maintaining comfort while sleeping.
ADDITIONAL MODES and FUNCTIONS
Refer to the remote control manual for information on operating modes and features
such as the Timer, Turbo feature, and Lock option.
Sleep Mode - Cooling Sleep Mode - Heating
DRY Mode
• Dry mode results in light dehumidication of the room.
• The fan speed will be automatically controlled in dry mode.
• During the dry operation, if the room temperature is lower than 50ºF (10ºC), the compressor stops operation and
restarts once the room temperature is above 54ºF (12ºC).
OPTIMAL OPERATION
To achieve optimal performance, please note the following:
• Adjust the air ow direction correctly so that it is not directly blowing on persons nearby.
• Adjust the temperature to achieve the highest comfort level. Do not adjust the unit to excessive temperature levels.
• Close doors and windows on COOL or HEAT modes or performance may be reduced.
• Do not put any object near air inlet or air outlet, as the efciency of the air conditioner may be reduced and the air
conditioner may stop running.
• Clean the air lter periodically to prevent reduction in heating/cooling efciency.
• Do not operate unit with horizontal louver in closed position.
Set
Temp.
OFF
OFF
2ºF
1 hour 1 hour 1 hour 5 hours 5 hours 1 hour
2ºF
2ºF 2ºF
Set
Temp.
-7-

Care and Maintenance
Before Performing Maintenance
Turn the system off before cleaning. Power supply must be disconnected before cleaning the indoor unit.
Cleaning the Indoor Air Handler
• Power supply must be disconnected to prevent shock or re hazard. The cabinet of the indoor unit may be dusted with
an oil-free cloth or with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent. Rinse
thoroughly and wipe dry.
• Never use harsh cleaners, wax or polish on the cabinet front. (See CAUTION below.)
• Be sure to wring excess water from the cloth before wiping down the unit.
• Turn on power to the air conditioner only after the unit has dried completely.
Long Periods of Non-Use
If you plan to idle the unit for an extended period of time, perform the following:
1.Clean the indoor unit and lters.
2.Operate the fan for about half of a day to dry the inside of the unit.
3.Stop the air conditioner and disconnect power to it.
4.Remove the batteries from the remote control.
The outdoor unit requires periodic maintenance and cleaning. Do not attempt
to do this yourself. Contact a trained service technician for assistance in
cleaning the outdoor unit.
After a long period of non-use, check that the wiring is in good condition and is
properly connected, clean the indoor unit and lters, check that the air lter is
installed, and check that the air inlet and outlet are not blocked.
Step 1
Removing the Air Filter for Cleaning:
Step 2a
Filter Handle
Step 2b
CAUTION
• A cloth dampened with cold water may be used on the indoor unit if it is very dirty. Then wipe it with a dry cloth.
• Do not use a chemically treated cloth or duster to clean the unit.
• Do not use benzine, thinner, polishing powder, or similar solvents for cleaning. These may cause the plastic surface
to crack or deform.
• Never use water hotter than 104ºF/40ºC to clean the front panel, it could cause deformation of discoloration. Do not
expose lter directly to the sun as that may cause lter to shrink.
• Do not touch the metal parts of the unit when removing the lter. Injuries can occur when handling sharp metal
edges.
• Do not use water to clean inside the air conditioner. Exposure to water can destroy the insulation, leading to possible
electric shock.
• When cleaning the unit, rst make sure that the power and circuit breaker are turned off.
!
Cleaning the Air Filter
A clogged air lter reduces the cooling efciency of this unit. Please clean the
lter once every 2 weeks using the following instructions:
1.Lift the indoor unit panel up to an angle until it stops with a clicking sound.
For some models, please use suspension bars to prop up the panel.
2.Take hold of the handle of the air lter and lift it up slightly to take it out
from the lter holder, then carefully pull it downwards to remove it from the
indoor unit.
3.Rinse lter thoroughly using liquid dishwashing detergent and warm water.
Never use hot water over 104ºF (40ºC) to clean air lter. Gently shake
excess water from the lter. Be sure lter is thoroughly dry before returning
it to the air conditioner. As an alternative to washing the lter, vacuum the
lter clean.
-8-

Troubleshooting Tips
Normal functions of the air conditioner
The following occurrences may take place during normal operation:
1. Protection of the Air Conditioner
• Compressor protection - The compressor will not restart for 3-4 minutes after it stops.
• Anti-cold air - When the indoor heat exchanger is in one of the following three situations and the set temperature
has not been reached, the unit is designed not to blow cold air on HEAT mode: (1) Heating has just started, (2) unit is
defrosting, or (3) low temperature heating is occurring.
• Defrosting - Frost may be generated on the outdoor unit during heat cycle when outdoor temperature is low and
humidity is high resulting in lower heating efciency of the air conditioner. When this occurs, the air conditioner will
stop the heating operation and start defrosting automatically. The time to defrost may vary from 4 to 10 minutes
according to the outdoor temperature and the amount of frost built up on the outdoor unit. The indoor or outdoor fan
stops running when defrosting.
2. White mist coming out from the indoor unit
• White mist may appear as a result of a large temperature difference between air inlet and air outlet when the unit is
set on COOL mode in an indoor environment that has a high relative humidity.
• When the air conditioner restarts in HEAT mode operation after defrosting, white mist may occur due to moisture
generated from defrosting process.
3. Low hissing sound
• You may hear a low hissing sound when the compressor is running or has just stopped running. It is the sound of the
refrigerant owing or coming to a stop.
• You can also hear a low squeaking sound when the compressor is running or has just stopped running. This is
caused by heat expansion and cold contraction of the plastic parts in the unit when the temperature is changing.
• A noise may be heard due to louver restoring to its original position when power is turned on.
4. Dust is blown out from the indoor unit.
• This is normal during rst use of the unit or if the air conditioner has not been used for a long period of time.
5. A peculiar smell comes out of the indoor unit.
• Building material, furniture, or smoke can cause odor to come from the air conditioner.
6. The air conditioner turns to FAN only mode when set in COOL or HEAT mode.
• When the indoor temperature reaches the temperature setting on air conditioner, the compressor will stop
automatically and the air conditioner turns to FAN only mode.
• The compressor will start again when the indoor temperature rises above the set point on COOL mode or falls below
the set point on HEAT mode.
7. The air conditioner runs Anti-mildew function after turning off the unit.
• When turning off the unit in COOL (AUTO COOL, FORCED COOL) and DRY modes, the air conditioner will run the
Anti-mildew function for 7-10 minutes.
• When turning off a unit that has been running on HEAT mode, the unit will continue operating for about 30 seconds at
LOW fan speed, then stop the operation and shut off automatically.
8. Dripping water may generate on the surface of the indoor unit when cooling in a high relatively humidity (higher
than 80%). Adjust the horizontal louver to the maximum air outlet position and select HIGH fan speed.
9. Heating mode
• The air conditioner draws in heat from the outdoor unit and releases it via the indoor unit during heating operation.
• When the outdoor temperature falls, heat drawn in by the air conditioner decreases accordingly.
• At the same time, the heating demand on the air conditioner increases due to larger difference between indoor and
outdoor temperature. If a comfortable temperature cannot be achieved by the air conditioner, we suggest you use a
supplementary heating device.
10. Auto-restart function
• Power failure during operation will stop the unit completely.
• When the power is restored, the unit will restart automatically with all of the previous settings preserved by the
memory function.
-9-

Troubleshooting Tips (continued)
Troubleshooting Guide
ISSUE POSSIBLE SOLUTIONS
OPERATION (RUN) indicator or other
indicator lights are continuously ashing. The unit may stop operation completely or run in a safety operation mode.
Wait 10 minutes; the issue may be automatically resolved. If the issue has
not resolved itself after approximately 10 minutes, disconnect the power
and then connect it again. If the problem still exists, disconnect the power
and contact Perfect Aire Consumer Services at 877-365-6274.
One of the following error codes appear on
the LED Display:
• E0, E1, E2, E3, etc.
• P0, P1, P2, P3, etc.
• F1, F2, F3, etc.
Fuse blows frequently or circuit breaker
trips frequently. Stop the air conditioner immediately, disconnect the power, and contact
Perfect Aire Consumer Services.
Water or objects fall into the air conditioner.
The remote control will not work or works
abnormally.
Make sure the batteries in the remote control do not need to be replaced.
If they do not need to be replaced, stop the air conditioner immediately,
disconnect the power, and contact Perfect Aire Consumer Services.
ISSUE CAUSE POSSIBLE SOLUTIONS
Unit does not start
Power cut. Wait for power to be restored.
Loose or disconnected power supply. Check that the electrical connections are correctly
and securely connected.
Fuse may have blown. Replace the fuse.
Batteries in remote control may be exhausted. Replace the batteries.
The time you set for the timer is incorrect. Cancel timer setting completely or wait for the unit
to start according to the time set on the timer.
Unit not cooling or
heating room well
even though air is
owing out from the
air conditioner
Inappropriate temperature setting.
Set temperature correctly. For details on how
to set the temperature, refer to Remote Control
manual.
Air lter is blocked. Clean the air lter.
Doors or windows are open. Close the doors or windows.
Air inlet or outlet of indoor or outdoor unit has
been blocked. Clear obstructions away rst, then restart the unit.
Compressor protection has been activated. Wait for the protection feature to complete
(3-4 minutes).
If the issue has not been corrected utilizing the above troubleshooting tips, please contact Perfect Aire Consumer
Services at 877-365-6274 or a trained service provider. Do not attempt to repair the unit yourself.
-10-

Your Source for Home Comfort
Distributed by:
Perfect Aire, LLC
5151 Belt Line Rd.
Suite 878
Dallas, TX 75254
Specification and performance data is subject to change without notice.
Printed in China
877-365-6274
www.perfectaire.us
