Perfect Pergolas MOD 8 User manual

MOD 8 – ASSEMBLY INSTRUCTIONS
Parts List
A - 2 x Main Beams, scarfed both ends, pre-drilled –
2.5mtrs Length
B - 4 x Cross Ra er, scarfed both ends – 1.5mtrs Length
C - 4 x Posts, Notched and Pre-Drilled - 2.4mtrs Length
D - 8 x Struts Pre-Drilled
E - 16 x Angle Brackets
F - 4 x Coach Bolt Sets (bolt, washer and nut)
G - 96 x Wood Screws (for angle brackets) 25mm x No.8
H - 16 x Wood Screws (for struts) 50mm x No.8
I - 4 x Post Fixings (Spike, Concrete-In or Bolt-Down
incl. ankerbolts)
Fig 3. - Fi ng of Post Supports
Fig 2. - Marking Out Post Posi ons
Op on 1:
Original Spiked System
With a measure make sure lines
A and B are the same length.
Op on 2:
Bolt Down System
Op on 3:
Concrete-in System
x 4 Ankerbolts
included
1000mm
2000mm
Ar s c impression – not to scale
Fig 1. - Module 8
Perfect Pergolas Ltd, PO Box 283
Cirencester, Glos GL7 9EY
t: 0844 800 4703
e: [email protected]
w: www.perfectpergolas.co.uk
* N.B.: Please take measurement
dimensions to CENTRE of post fi xings.

Fig 7. - Finish
As some of the screws & bolts may have become loose during assembly, it is important to re-check that
they are ght and ensure they are securely fastened.
For further informaon, please go to www.perfectpergolas.co.uk
© Perfect Pergolas Limited 2014
Fig 4. - Fing Main Beam
F
F
C
A
A
C
I
Fig 6. - Fixing Struts
A
C
D
H
H
Fig 5. - Aaching Cross Raers to Main Beam
G
B
EA
