Performance Tool W50033 User manual

WARNING
It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance
instructions contained on the product label and instruction manual prior to operation of this product. The
owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning labels and
while in use, maintaining the unit in good working order. If the owner and/or operator are not fluent in English,
the product warnings and instructions shall be read and discussed with the operators’ native language by the
purchaser/owner or his designee. Make sure that the operator comprehends its contents. Safety information
shall be emphasized and understood prior to usage. The product shall be inspected per the operating
instructions.
Users of this product must fully understand these instructions. Each person operating this product must also
be of sound mind and body and must not be under the influence of any substance that might impair their
vision, dexterity or judgment.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
1/4 IN DRIVE REVERSIBLE
CORDLESS DRIVER
OWNERS MANUAL
Stock Number W50033
This product has been carefully engineered and manufactured to give you dependable operation. Please read this manual thoroughly
before operating your new product, as it contains the information you need to become familiar with its features and obtain the
performance that will bring you continued enjoyment for many years. Please keep this manual on file for future reference.
Please read these instructions carefully and retain them for future use.
California
Title 20
Certified
BC

Work Area
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical Safety
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the
risk of electric shock.
Personal Safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tool may result in serious
personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal
injuries.
c) Avoid accidental starting. Ensure the switch is in the off-position before
plugging in. Carrying power tools with your finger on the switch or
plugging in power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry
or long hair can be caught in moving parts. Air vents often cover
moving parts and should also be avoided.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of these devices can reduce dust-related hazards.
d) Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
SPECIFICATIONS
Driver
Battery Voltage ..................3.6 Volts(DC)
Battery Type ..............1.3AH Lithium-lon
Torque ........................35.4in/lbs. (4N.M)
Speed (no load) ........................ 180RPM
Specifications are subject fo
change without notice
IMPORTANT SAFETY INFORMATION
AC Power Adaptor / Charger
Input..................................... 110-1120V
Output ..................... 5Volts (DC) /300mA
Charging Time .....................3 to 5 hours
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry
or long hair can be caught in moving parts. Air vents often cover
moving parts and should also be avoided.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of these devices can reduce dust-related hazards.
ToolUse and Care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.Any
power tool that cannot be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool's operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits etc., in accordance with
these instructions and in the manner intended for the particular type
of power tool, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Battery Use and Care
a) Ensure the switch is in the off position before inserting battery pack.
Inserting the battery pack into power tools that have the switch on
invites accidents.
b) Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a
risk of fire when used with another battery pack.
c) Use power tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
d) Under abusive conditions, liquid may be ejected from the battery, avoid
contact. If contact accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from
the battery may cause irritation or burns.
WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious
injury. The term "power tool" in all of the warnings listed below refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool. Save these instructions.

8. Use only the supplied charger when charging your tool. The use of any
other charger could damage the tool or create a hazardous condition.
It will also void any warranty for the tool, battery or charger.
9. Do not attempt to open the charger. There are no customer
serviceable parts inside. Return it to the manufacturer of the product
for repair.
10. DO NOT incinerate the tool or batteries even if they are severely
damaged, worn out or destroyed . The batteries can explode in a re.
Toxic fumes and materials are created when lithium-Ion battery
packs are burned.
11. Do not charge or use the battery in explosive atmospheres, such as
in the presence of ammable liquids, gases or dust. Inserting or
removing the battery from the charger may ignite the dust or fumes.
12. If battery contents come into contact with the skin, immediately
wash the area with mild soap and water. If battery liquid gets into the
eyes, rinse water over the open eye for three minutes or until irritation
ceases. If medical attention is needed, the battery electrolyte is
composed of a mixture of liquid organic carbonates and lithium salts.
WARNING: Burn hazard. Battery liquid may be ammable if
exposed to spark or ame.
1. Be sure to place the tool on a clean dry surface within 2 feet of a
115V/AC 60HZ wall receptacle.
2. Insert AC adaptor into the Charging Port Located on the back of
the unit.
3. Plug the AC adaptor into the closest wall outlet.
4. Allow 3 to 5 hours for the battery to become fully charged.
5.
Disconnect the unit after charging as the unit should be ready for use.
• Do not disassemble or open, drop (mechanical abuse), crush, bend or
deform, puncture, or shred.
• Do not modify or remanufacture, attempt to insert foreign objects into
the battery, immerse or expose to water or other liquids, or expose to
re, excessive heat including soldering irons, or put in microwave oven.
• Only use the battery / tool with a charging system specied by the
manufacturer/supplier.
• Do not short-circuit a battery or allow metallic or conductive objects to
contact both battery terminals simultaneously.
• Dispose of used batteries promptly according to the manufacturer/
supplier's instructions.
• Improper battery use may result in a re, explosion, or other hazard.
• Battery / tool usage by children should be supervised.
1. This manual contains important safety and operating instructions.
2. Before using the battery charger, read all instructions and cautionary
warnings on the battery charger and the product using battery.
CAUTION: To reduce the risk of injury, use this charger only with this
product. Batteries in other products may burst causing personal
injury or damage.
3. Do not expose the charger to rain or snow.
4. Use of an attachment not recommended or sold by the manufacturer of
this product may result in a risk of re, electric shock, or injury to persons.
5. To reduce the risk of damage to the electric plug and cord, pull by the
plug rather than the cord when disconnecting the charger.
6. Make sure the cord is located so that it will not be stepped on, tripped
over, or otherwise subjected to damage or stress.
7. An extension cord should not be used unless absolutely
necessary. Use of an improper extension cord could result in a risk
of re, electric shock or electrocution.
SPECIFIC SAFETY INSTRUCTIONS
WARNING: Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities contains chemicals known to
cause cancer, birth defects or other reproductive harm. Some examples
of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products,
• Arsenic and chromium from chemically-treated lumber (CCA). Your risk
from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well venti-
lated area, and work with approved safety equipment, such as those dust
masks that are specially designed to lter out microscopic particles.
•
Avoid prolonged contact with dust from power sanding, sawing,
grinding, drilling, and other construction activities. Wear protective
clothing and wash exposed areas with soap and water. Allowing
CHARGING BATTERY
MAINTENANCE
• Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord. Contact
with a "live" wire will make exposed metal parts of the tool "live" and shock the operator.
• Use clamps or another practical way to secure and support the work piece to a stable platform. Holding the work by hand or against your body
leaves it unstable and may lead to loss of control.
dust to get into your mouth, eyes, or lay on the skin may promote
absorption of harmful chemicals
WARNING: Use of this tool can generate and/or disperse dust, which
may cause serious and permanent respiratory or other injury. Always use
NIOSH/OSHA approved respiratory protection appropriate for the dust
exposure. Direct particles away from face and body.
WARNING: ALWAYS use safety glasses. Everyday eye glasses are
NOT safety Glasses.Also use a face or dust mask if cutting operation is
dusty. ALWAYS WEAR CERTIFIED SAFETY EQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3)
• ANSI S12.6 (S3.19) hearing protection
• NIOSH/OSHA/MSHA respiratory protection
BATTERY SAFETY INSTRUCTIONS
CHARGING SAFETY INSTRUCTIONS
Use only mild soap and a damp cloth to clean the tool.
Do not allow any liquids to get inside the tool. Do not immerse any part of the tool in liquids.

1 YEAR LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These warranties give specific legal rights. Except
where prohibited by local law, the law of the State of Washington governs all warranties and all exclusions and limitations of warranties and remedies.
There may be other rights which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal use and service. A defective product
may be returned for a free replacement within 90 days from the date of purchase, provided that product is returned to place of purchase immediately
after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which
our examination shall disclose to be defective and under warranty.
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be replaced under normal use and
service. These warranties shall not apply to any product or part which is used for a purpose for which it is not designed, or which has been repaired or
altered in any way so as to affect adversely its performance or reliability, nor shall these warranties apply to any product or part which has been subject
to misuse, neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in connection with its
products. Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no express or implied
warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes no implied warranty of merchantability and no implied
warranty of fitness for any particular purpose, except that for goods purchased primarily for personal, family or household use and not for commercial or
business use, PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied warranty of fitness for a
particular purpose), but only for the particular qualities or characteristics, and for the duration, expressly warranted above. The laws on limitation of
implied warranties may differ from state to state, so the above limitations may not apply in all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any manner related to any product, or
to the design, use, or any inability to use the product. The sole and exclusive remedy for a defective product or part shall be the repair, or replacement
thereof as provided above. The laws on limitation of remedies or on consequential, incidental or special damages may vary from state to state, so the
above limitations may not apply in all cases.
OPERATION
1
23
4
5
8
7
10
9
6
This tool is equipped with a ¼” magnetic, quick release chuck. The chuck will accept standard hex shank bits and power groove hex
shank bits. Standard hex bits inserted into the chuck will be help into place by a powerful magnet. Power groove hex shank bits will lock
into place inside the chuck. Please see the directions below.
For Standard Hex Shank Bits
1. Push up on the chuck with two ngers and insert the bit
2. After inserting the bit release the chuck and allow it to move back into
place. The magnet inside the chuck will hold the bit in place.
3. Grasp the tool rmly with both hands, align the bit with the screw and
press it rmly into the screw.
4. To select forward cordless screwdriver rotation, press the trigger lock
from right to left at against the cordless screwdriver body.
5. To select reverse, press the trigger lock lever in the opposite direction.
6. The center position locks the tool.
7. To remove the bit, push up on the chuck and pull out the bit.
For Power Groove Hex Shank Bits
1. Push up on the chuck with two ngers and insert the bit
2. After inserting the bit release the chuck and allow it to move
back in place. The chuck will lock the bit in place.
3. Grasp the tool rmly with both hands, align the bit with the
screw and press it rmly into the screw.
4. To select forward cordless screwdriver rotation, press the trigger
lock from right to left at against the cordless screwdriver body.
5. To select reverse, press the trigger lock lever in the opposite direction.
6. The center position locks the tool.
7. To remove the bit, push up on the chuck and pull out the bit.
CONTROLS & COMPONENTS
Pistol Driver:
1. 1/4 in. Quick Release Chuck
2. LED Work Light
3. Forward/Reverse Switch
4. Trigger Switch
5. Charging port
Accessories:
6. AC adaptor/charger
7. 18 pcs: 1 in. Hex shank screwdriver bits
8. 1pc: 2-1/4in. Hex shank magnetic bit holder
9. 2 pcs: 2 in. Hex shank Bits;
(PH2 Phillips, No. 5 Slotted)
10.3 pcs: Power groove twist drill bits
Check out the collection of power tools we offer.
