Performance Tool M641 User manual

WARNING!
READ, UNDERSTANDAND FOLLOW ALL INSTRUCTIONSAND WARNINGS BEFORE
OPERATING THIS TOOL. FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY
AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY.
6" Dual Action Air Sander
OWNER’S MANUAL
Stock Number M641
3
SPECIFICATIONS
Specifications are subject to change without notice
IMPORTANT SAFETY INFORMATION
WARNING!
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO
SO MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY
DAMAGE AND WILL VOID WARRANTY.
1.
2.
3.
4.
Use only paper sanding disks with the proper adhesive. Read, under-
stand and follow all adhesive manufacturers’ directions. DO NOT USE
CLOTH BACKED SANDING DISKS WITH THIS TOOL.
Make sure sanding pad RPM rating matches Free Speed rating
of this tool.
Wear a dust mask while operating this tool. Read, follow and un-
derstand manufacturers instructions on paint, primer, paint preps,
glazing, body ller, etc. for additional respirator and ventilating
requirements.
Always use approved eye and ear protection when using air powered
tools. If raising dust/debris, wear a suitable mask. Do not wear loose
clothing or jewelry.
5. Always operate tool a safe distance from yourself and others in the
work area. Keep footing and balance at all times.
6. Make sure work piece is secure to allow safe operation of the tool with
both hands. Do not hold the work piece in your hand, lap or against
any part of your body.
7. Make sure trigger is in the “off” position before connecting or discon-
necting the tool from air source. Disconnect tool from air source
before changing accessories, performing service and when not in use.
Pad size...............................................................................................6 in.
Sanding surface.....................................................................28-1/4 sq. in.
Spindle/thread size..........................................................5/16 in. / 24 UNF
Orbital stroke .................................................................................5/16 in.
Air pressure .................................................................................. 90 P.S.I.
Average air consumption.............................................................. 5 C.F.M.
Free speed ..........................................................................10,000 R.P.M.
Air inlet....................................................................................1/4 in. N.P.T.
Recommended hose size.......................................................... 3/8 in. I.D.
Length...............................................................................................9.1 in.
Weight ............................................................................................3.8 lbs.

45
IMPORTANT SAFETY INFORMATION
OPERATION
1. Regulate pad speed with air regulator knob.
2. Start the sander off the sanding surface. Set the sander on the
surface gently and evenly and start the work. Let the sander do
the work. The weight of the sander will provide efcient sand-
ing. Applying pressure to the sander will only slow the speed of
the pad and reduce sanding efciency. This will also overload
the motor and cause premature wear of the tool and void the
warranty.
3. Work the sander back and forth in a wide, overlapping motion.
Lift the sander off the surface before releasing the trigger.
4. Start with a paper grit coarse enough to remove high spots and
rough areas. Continue using progressively ner grit to attain
desired nish.
Sanding pad
Air regulator knob
Air Inlet
Trigger
8. Follow air source manufacturer’s directions for connection of regula-
tors, lters and other accessories to air source. Do not install quick
couplers directly at tool air inlet. This causes inlet failure due to
excess weight and vibration. Use a whip hose between tool and quick
couplers.
9. DO NOT OVERLOAD! Do not force tool. Match tool capacity to work
load requirement. Use tool within its rated capacity and only for its
designated purpose. Overloading air tools will cause premature wear
and/or permanent damage of internal and external drive parts and will
void warranty.
10. Inspect hoses and ttings for wear and damage prior to using tool.
Do not carry or drag tool by the air hose. Keep air hose free from
obstruction, twisting and binding.
Oil tool before each use. 4 to 5 drops of a good grade Air Tool Oil
placed in the air inlet is sufficient. Use proper air pressure and
CFM rating listed for this tool.
Drain water from hoses and compressor tank. Water in the
air supply line will cause gumming and loss of power. Clean the
air lter on the supply line and ush the tool with gum solvent or
a 50/50 mix of air tool oil and kerosene. It may be necessary to
disassemble the tool to properly clean and re-lubricate.
LUBRICATION & MAINTENANCE
AIR SOURCE
Clean air of correct air pressure is recommended for the power
supply for this tool. A maximum of 90 PSI at the tool is recom-
mended for most air tools of this class. Check specications sec-
tion for recommended pressure. (Depending on length of air hose
and other circumstances, air pressure at compressor may need to
be increased to 100 PSI to ensure 90 PSI at the tool.)
Water in the air hose and compressor tank contributes to reduced
performance and damage of the air tool. Drain the air tank and l-
ters before each use and as necessary to keep the air supply dry.
Hose length over 25’ causes loss in line pressure. Increase hose
I.D. or increase compressor pressure to compensate for the pres-
sure loss. Use an in-line pressure regulator with gauge if air inlet
pressure is critical.

No. DESCRIPTION QTY No. DESCRIPTION QTY
1. Housing 1
2. Rubber 1
3. Spring 1
4. O-Ring 1
5. Valve Stem 1
6. O-Ring 1
7. O-Ring 1
8. O-Ring 1
9. Valve Body 1
10. Bracket 1
11. Trigger Screw 1
12. Screw 1
13. Trigger 1
14. Washer 1
15. Cap 1
16. Air Regulator 1
17. Retainer Ring 1
18. O-Ring 1
19. Air Inlet 1
20. Retainer Ring 1
21. Bearing 2
22. End Plate 2
23. Cylinder 1
24. Pin 1
25. O-Ring 1
26. Rotor 1
27. Rotor Blade 5
28. Work Spindle 1
29. Key 1
30. Rear Gasket 1
31. Rear Cover 1
32. Screw 2
33. Screw 2
34. Washer 5
35. Cap 1
36. Washer 1
37. Balancer 1
38. Screw 1
39. Bushing 1
40. Spindle Lock 1
41. Washer 1
42. Washer 1
43. Screw 1
44. Screw 1
45. Washer 1
46. Bearing 1
47. Washer 1
48. Retainer Ring 1
49. Drive Spindle 1
50. Rubber 1
51. O-Ring 4
52. Pad 1
6
PARTS LIST
INSUFFICIENT POWER:
Probable Cause Solution
Dirty or clogged air passages......... Flush and lubricate tool, drain air tank and supply line
Insufficient air supply...................... Increase line pressure, Make sure compressor
matches tool's air pressure and consumption needs
Air leakage...................................... Use PTFE tape at all fittings and joints. Check tool for
worn or damaged O-rings & seals.
Worn/damaged wear & tear parts... Replace as necessary.
Tool matching ................................. Be sure you are using a tool suited for the torque
requirements of the job at hand.
TROUBLESHOOTING
LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These war-
ranties give specic legal rights. Except where prohibited by local law, the law of the State of Washington governs
all warranties and all exclusions and limitations of warranties and remedies. There may be other rights which vary
from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under
normal use and service. A defective product may be returned for a free replacement within 90 days from the date
of pur-chase, provided that product is returned to
place of purchase immediately after discovery of defect. After 90 days and up to one year from date of purchase,
PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective
and under warranty.
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be
replaced under normal use and service. These warranties shall not apply to any product or part which is used for a
purpose for which it is not designed, or which has been repaired or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to
misuse, neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in
connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes
no express or implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL®
makes no implied warranty of merchantability and no implied warranty of tness for any particular purpose, except
that for goods purchased primarily for personal, family or household use and not for commercial or business use,
PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied
warranty of tness for a particular purpose), but only for the particular qualities or characteristics, and for the dura-
tion, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations may not apply in
all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in
any manner related to any product, or to the design, use, or any inability to use the product. The sole and exclusive
remedy for a defective product or part shall be the repair, or replacement thereof as provided above. The laws on
limitation of remedies or on consequential, incidental or special damages may vary from state to state, so the
above limitations may not apply in all cases.
7
