Performance Tool W5171 User manual

53 BIN DUAL ANGLE TILT BIN
STORAGE SYSTEM
Stock Number W5171
OWNER’S MANUAL
WARNING: This product and its packaging contain a chemical known to the State of California to
cause cancer, birth defects or other reproductive harm.
Always wear eye protection when using tools.
Please read these instructions carefully and retain them for future use.
© Copyright 2016 WILMAR CORPORATION,
P.O. Box 88259 Tukwila, WA 98138
WARNING
It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance
instructions contained on the product label and instruction manual prior to operation of this product.
The owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning
labels and while in use, maintaining the unit in good working order. If the owner and/or operator are
not fluent in English, the product warnings and instructions shall be read and discussed with the
operators’ native language by the purchaser/owner or his designee. Make sure that the operator
comprehends its contents. Safety information shall be emphasized and understood prior to usage.
The product shall be inspected per the operating instructions.
Users of this product must fully understand these instructions. Each person operating this product
must also be of sound mind and body and must not be under the influence of any substance that
might impair their vision, dexterity or judgment.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
If you encounter any problems or difficulties, please contact our customer service department at:
1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.
LIMITED LIFETIME WARRANTY
PERFORMANCE TOOL extends only the following warranties, and only to
original retail purchasers. These warranties give specific legal rights. Except
where prohibited by local law, the law of the State of Washington governs all
warranties and all exclusions and limitations of warranties and remedies. There
may be other rights which vary from state to state.
PERFORMANCE TOOL warrants the product to be free from defects in materials
and workmanship under normal use and service. A defective product may be
returned for a free replacement within 90 days from the date of purchase,
provided that product is returned to place of purchase immediately after discovery
of defect. These warranties shall be valid only when a sales receipt showing the
date of purchase accompanies the defective product being returned. These
warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other
consumables which must be replaced under normal use and service. These
warranties shall not apply to any product or part which is used for a purpose for
which it is not designed, or which has been repaired or altered in any way so as
to affect adversely its performance or reliability, nor shall these warranties apply
to any product or part which has been subject to misuse, neglect, accident or
wear and tear incident to normal use and service.
PERFORMANCE TOOL does not authorize any other person to make any
warranty or to assume any liability in connection with its products. Except for
warranties of title and the limited express warranties set forth above,
PERFORMANCE TOOL makes no express or implied warranties of any kind with
respect to its products. In particular, PERFORMANCE TOOL makes no implied
warranty of merchantability and no implied warranty of fitness for any particular
purpose, except that for goods purchased primarily for personal, family or
household use and not for commercial or business use,
PERFORMANCE TOOL makes an implied warranty of merchantability (and, if
otherwise applicable, an implied warranty of fitness for a particular purpose), but
only for the particular qualities or characteristics, and for the duration, expressly
warranted above. The laws on limitation of implied warranties may differ from
state to state, so the above limitations may not apply in all cases.
PERFORMANCE TOOL shall not be liable for consequential, incidental or special
damages resulting from or in any manner related to any product, or to the design,
use, or any inability to use the product. The sole and exclusive remedy for a
defective product or part shall be the repair, or replacement thereof as provided
above. The laws on limitation of remedies or on consequential, incidental or
special damages may vary from state to state, so the above limitations may not
apply in all cases.
© Copyright 2016 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138

PARTS LIST
TOOLS REQUIRED
ASSEMBLY INSTRUCTIONS
• #2 Phillips head screwdriver
• 10 mm wrench
1. Place the top tray upside down on a at surface.
2. Position one of the I-Beam frame legs on the inside of the top tray. NOTE: The
tear drop shaped holes on the I-Beam should be facing in, with the larger circle
portion of the openings facing down.
3. Use a large screw and nut to fasten the I-Beam frame legs to the top tray on
both sides.
4. Place the base on the opposite end of the I-Beams, aligning the holes on the
I-Beam with the holes on the base, and fasten with large machine screws.
5. Place the bottom bin support rail on the bottom set of holes in the I-Beams .
6. Align the holes in the base support brackets with the threaded holes on the
base, and holes in the I-Beams. Fasten the top and bottom holes with two large
machine screws.
7. Insert remaining bin support rails on to the I-Beams. Make sure the 3 holes in
the support rails are closer to the top.
8. Align the vertical support brackets on back of the bin support rails, and secure
with small machine screws.
No. Description Qty.
1 Base 1
2 Base Support Brackets 2
3 “I-Beam”Frame Legs 2
4 Bin Support Rail 7
5 Vertical Support Bracket 3
SPECIFICATIONS
NOTE: Specications are subject to change without notice.
Small Plastic Bins: ........................................ 36 (4-1/16 x 3-1/16 X 7-1/2 in.)
Medium Plastic Bins: .................................... 12 (5-7/8 x 4-7/8 X 9-1/8 in.)
Large Plastic Bins:......................................... 5 (7-1/4 x 6-7/8 X 11 in.)
Rack Height: ................................................. 49 in. Tall
Rack Width: .................................................. 41-5/8 in. Wide
Rack Depth: .................................................. 12 in. Deep
Construction: ................................................ Powder Coated Steel
LEVEL APPLICATIONTILT BIN APPLICATION
9
6
1
3
2
5
4
7
8
7
7
7
8
No. Description Qty.
6 Top Tray 1
7 Large Machine Screws 20
8 Hex Nuts 8
9 Small Machine Screws 21
LEVEL
TAB
TILT
TAB
BIN SUPPORT
RAIL
BIN SUPPORT
RAIL
